Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: [phone]
Fax: [phone]
Web Site: www.ClevelandRange.com
Email: [e-mail]
STEAMCRA T®GENERATOR STYLE
HIGH SPEED CONVECTION STEAMERS
MODEL: 24-CGA-10.2
Cleveland Standard Features
IICooking Capacity for up to ten 12˝ x 20˝ x 2 1/2˝ deep
Cafeteria Pans, five each compartment.
I
ITotally independent cooking compartments, each has its' own
generator, gas valve and water level controls - no shared
components
I
IExclusive High Efficiency Gas Power Burner (forced air)
Generator: Produces more steam for faster cooking while low-
ering operating costs (72M BTU's per compartment)
IIEasy Access Cleaning Port: Each generator has a deliming
port located on the outside, top of the unit
IIGenerator Cleaning Light for each compartment warns the
operator to delime generator
IIGenerator Steam Standby Mode: Holds generator at a
steaming temperature, allows unit to start cooking quickly
IIEach compartment has one, 60-Minute Electro-Mechanical
Timer with "SureCook" load compensating feature.
Manual Bypass Switch for constant steaming.
IIDurable 14 Gauge, 304 Stainless Steel construction for
compartment door, cooking cavity and steam generator
IIExclusive Two-Piece Compartment door: Slammable,
self-adjusting door provides and airtight seal, reversable door
gasket for extended life
IIExclusive Gemini Drain/Power Control System: Simple,
reliable 1/2" ball valve style drain automatically turns power
ON/O
II
Exclusive Brass Steam Jets distribute even-high velocity steam
throughout cooking compartment for faster cooking times
IIEasy, ront -Access Generator Controls comes with a
pullout drawer for simple servicing of unit
II6˝ Stainless Steel Adjustable Legs with langed eet
IIApprovals: CSA (AGA, CSA) and U.L/NS #4
IICompartment Steam Shut-Off Switch when compartment door
is opened
Options & Accessories
ËElectronic Timer with Compensating eature (ETC)
ËOn/Off Steam Switch Controls, no timer (MC)
Shall be Two Compartments, Cleveland Convection Steamer series
SteamCraft

Gemini
TM
10 , Model 24-CGA-10.2, Twin Gas Atmospheric
Steam Generator, 72M BTU's input per compartment.
Independent steam
enerator, as valve and water level control system.
Automatic
Generator Blowdown. Steam Generator with Automatic Water Fill on start up.
Exclusive remote probe-type water level controls. Exclusive Brass
“Steam Jet” distribution system. Two-piece free-floatin compart-
ment door.
Type 430 Stainless Steel exterior and cookin compartments.
Pullout service drawer for controls and Gemini Drain/Power Control
System.
Exclusive Cold Water Condenser desi n. Choice of Compartment
Controls. Manual
ËPropane Gas (PG)
ËDissolve ®Descale Solution, 6 one gallon container w/quart
markings (106174)
ËWater ilters
Short For Specifications
Stea Craft ®Ge ini TM 10
TWO COMPARTMENT FLOOR MODEL DESIGN
PRESSURELESS CONVECTION STEAMER
TWIN, INDEPENDENT GAS-FIRED GENERATORS
SECT. IV PAGE 13
1007

(NOT TO SCALE)
SECT. IV PAGE 14
1007
itho in U.S.A.
GAS E ECTRIC CO D WATER C EARANCE DRAINAGE
1
1
⁄ 4 ˝ IPS line size,
3
⁄ 4 ˝ connection 120V-1Phase, 60 Hz. 35 psi minimum RIGHT = 3˝ operating,
NATURAL PROPANE BTU 2 Blowers & Controls 60 psi maximum 12˝ if adjoining wall or
Piping
3
⁄ 4 ˝ N.P.T. Piping
3
⁄ 4 ˝ N.P.T. 72,000 each 150 watts each LE T = 3˝
Supply pressure Supply pressure Generator, One (E) 1/4" dia. REAR= 3˝
4.50˝ W.C. Min. 11.00˝ W.C. Min. 144,000 total
** Do not connect to G I NPT for Generator Allow 6˝ space min.
14.00˝ W.C. Max. 14.00˝ W.C. Max.
outlet. See note below. s
One (D) 1/4" dia when located near
Manufacturer must be notified if unit will NPT for Condenser combustible walls
be used above 2,000 feet
C
D
NOTES:
**DO NOT CONNECT TO G I OUTLET. CLEVELAND RANGE RECOMMENDS GAS IRED 120 VOLT STEAMERS BE HARD WIRED DIRECTLY TO ELECTRICAL SYSTEM.
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers. Included among those approval agencies are UL/NS #4 and CSA (AGA, CGA).
Each Compartment has
capacity for:
• ive, 12˝ x 20˝ x 21⁄2˝ deep
Cafeteria Pans.
WATER QUA ITY
REQUIREMENTS
The quality of water varies
greatly from region to region.
Steam equipment generators
must be drained daily and
chemically descaled periodically
to ensure proper operation. To
minimize service problems
caused by the accumulation of
minerals and chemicals in water
review the following quality
guidelines with a local water
treatment specialist. Inlet water
that is beyond these specified
guidelines should be treated to
achieve these acceptable limits.
Total Dissolved Solids less than
60 ppm, Alkalinity less than 20
ppm, Silica less than 13 ppm,
pH factor greater than 7.5,
Chlorine less than 30 ppm.
Right - 3”, Left - 3”,
Rear -3”
(12” on control side if adjoining
wall or equipment is over 30”
high for service access)
Contact factory
for variances to
clearances.
A B C
DE
1
1
⁄ 2 ˝ dia.
Do not connect other units to this
drain
Drain must not be located
beneath the steamer itself
Preferred floor drain location
should be a minimum distance
(from the unit) of at least 12” from
the left side, 12" from the right
side, 6” from the front and 6" from
the rear.
Do not use PVC pipe
