Cleveland 42-CKGM-200 User manual

Cleveland
™
Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: [phone]
Fax: [phone]
Web Site: www.ClevelandRange.com
Email: [e-mail]
CLASSIC CONVECTION STEAMERS
15 PSI BOILER BASE STYLE
MODELS: 42-CKGM-200
42-CKGM-300
Cle eland Standard Features
II
Cooking Capacity for up to six 12˝ x 20˝ x 2
1
⁄ 2 ˝ deep Cafeteria Pans.
I
IPressureless cooking with forced convection steam, permitting
doors to be opened while cooking continues.
IISolid State Controls operate water level and safety functions.
IIEach compartment is equipped with a 60 minute mechanical
timer, separate bypass switch for constant steaming and a cold
water condenser for superior cooking results.
IIInstant Steam Standby Mode: Holds generator at steaming
temperature. Allows unit to start cooking instantly.
IIDurable 14 Gauge Stainless Steel Construction:
For Compartment Door and Steam Cooking Cavity.
IISeparate Main Power Switch for “On/Off”
IIExclusive Steam Cooking Distribution System:
The exclusive
Convection Jets produce a high velocity convection steam without
fans. Coved Corner design in cooking compartment distributes heat
evenly and is easy to keep clean. Creased top & bottom enhance
drainage. Cold Water Condenser for each compartment maintains a
dry steam. Fully insulated cooking compartment for thermal efficiency.
Removable Stainless Steel Slide Racks for easy cleaning.
IIExclusive “Cool to the Touch” Compartment Door Design:
Free floating inner door with reversible door gasket provides an
air tight seal. Stainless Steel Slam/Latch Door Latch mechanism
provides greater reliability.
IILeft Hand Door Hinging: Compartment Doors hinged left,
controls on the right.
IIModular Cabinet Base with Hinged Door.
IIHigh Efficiency Gas Steam Generator with Electronic Spark
Ignition and Automatic Water Fill on start up.
II
Automatic Generator Drain at shutdown: Large
3
⁄ 4 ˝ drain valve
contains a “Water Jet” Spray Rinse Cleaning Cycle to keep drain clear.
IIAutomatic Water Level Control System with Low Water
Power Cut-Off.
II
Steam generator equipped with High Limit Pressure Safety Switch,
15 psi Safety Valve, and Steam enerator Pressure auge.
IINSF Certified 6˝ Stainless Steel Legs with adjustable
flanged feet for a one inch level adjustment.
IIas Pressure Regulator and Control Valve.
IIStandard Voltage for Control: 115 volts, 60 Hz, single phase.
IITable Top includes 2˝ deep Drain Trough with 3⁄4˝ Drain and
rate
II
6 gallon Tilting Kettle made of type 304 Stainless Steel,
2
⁄ 3 jacketed
Kettle includes:
IITrunnion mounted Steam Control Valve
II50 psi Kettle Steam Jacket Rating
IILift Off Cover
IIDouble Pantry Faucet with Swing Spout
Options & Accessories
ËRight Hand Door Hinging, Controls and Kettles on the Left (DHR)
Shall be Two Compartments, CLEVELAND Convection Steamer, plus one 6
gallon Direct Steam, tilting, kettle, Model 42 CKGM _____ , Gas fired Steam
Generator, NickelGuard, _____ M BTU. Solid State Controls operate timing,
water level and safety functions. Steam Generator with Automatic Water Fill
on start up, Automatic Blowdown with additional Manual Drain Valve and
Electronic Spark Ignition. For each cooking compartment: 60 minute
Mechanical Timer, Manual Operation Mode and Cold Water Condenser. Type
304 Stainless Steel cooking compartment.
ËElectronic Timer with Compensating Load Feature (ETC)
ËON/OFF Steam Switch only for compartment controls (MC)
ËCompartment Door Steam Shut Off Switch (SCS)
ËCafeteria pans in depths of 1˝, 21⁄2˝, 4˝ and 6˝
ËPower Take Off Kit ( PTO), Kettle Interconnecting Kit (IMK)
ËCorrectional Packages
ËStainless Steel Base Frame (FSS)
ËStainless Steel Insulated Flue Cover (SSF)
ËQuick Disconnect for gas line (QDC)
ËType 316 Stainless Steel Liner for high acid products (316-6 )
ËSecondary Low Water Cut-Off, factory installed (CAL )
(Required for AZ. AR. CA. CO. CT. DE. FL. A. HI. IL. IA. KS. MD. MA. MI. MN. MT.
NE. NV. NM. NC. OK. OR. PR. RI. TN. UT. VA. WA. WV., Buffalo, NY, Wash. DC)
ËBoiler Descaling Pump Kit (107142)
ËWater Filters
ËRear as Connection (R T)
ËCompartment Door Steam Shut Off Switch
Short Form Specifications
Shown with optional
Electronic Timer
Cle eland Classic Series
TWO COMPARTMENT, PRESSURELESS, PLUS ONE 6 GALLON KETTLE,
200, 00M BTU GAS FIRED STEAM GENERATOR
42” WIDE CABINET BASE DESIGN, with NICKELGUARD™
CONVECTION
STEAMERS
1
0
0
%
5
Y
e
a
r
B
o
i
l
e
r
W
a
r
r
a
n
t
y
N
i
c
k
e
l
G
u
a
r
d
™
SECT. III PA E 19
1007

(NOT TO SCALE)
SECT. III PA E 20
1007
Litho in U.S.A
Right - 6”, Left - 6”, Rear - 6” (12”
on control side if adjoining wall or
equipment is over 30” high for
service access)
For use in non-
combustible locations.
Contact factory for
variances to clearances
1 1/2” IPS common drain.
Do not connect other units
to this drain.
Do not use PVC pipe for
drain.
NOTES:
**DO NOT CONNECT TO FI OUTLET. CLEVELAND RAN E RECOMMENDS AS FIRED 120 VOLT STEAMERS BE HARD WIRED DIRECTLY TO ELECTRICAL SYSTEM.
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers. Included among those approval agencies are ASME/N. Bd, NSF and CSA (A A, C A).
ACTUAL CAPACITIES:
Kettle 6 gallons/23 liters or 192, 4 oz. servings.
• Other size servings may be calculated.
Each compartment has capacity for:
• Three, 12˝ x 20˝ x 21⁄2˝ or six, 12˝ x 20˝ x 1˝
deep Cafeteria Pans.
WATER UALITY RE UIREMENT
The recommended minimum water quality stan-
dards whether untreated or pre-treated, based
upon 10 hours of use per day, and a Daily
Blowdown, are as follows:
TOTAL DISSOLVED
SOLIDS less than 60 parts per million
TOTAL ALKALINITY less than 20 parts per million
SILICA less than 13 parts per million
pH FACTOR greater than 7.5
CHLORINE less than 30 parts per million
Consult a local water treatment specialist for an on
site water analysis for recommendations concerning
steam generator feed water treatment (if required),
in order to remove or reduce harmful concentrations
of minerals. The use of highly mineralized water will
mean that more frequent servicing of the steam
generator will be necessary. The fact that a water
supply is potable is not proof that it will be suitable
for the generator.
5.0 Amps
** Do not connect to FI
outlet. See note below.
