Clevertronics FVP2LED-P Series Maintenance and service guide

1948707 V1.2 4 May 2021
THIS PAGE INTENTIONALLY BLANK
240V 2ft LED Weatherproof Vandal Resistant Batten
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Designed in Australia to comply with the requirements of
AS/NZS CISPR15: 2017
Models:
FVP2LED-P-yy 240V 50Hz
Options:
yy = MS-HL
Hi-Lo Sensor Control
yy = DD
DALI LED Driver
Spare Parts:
1330055
LED Driver - LC 50w 350-1050mA, 20-50V
8002699
PCA: LED Strip 5P8S, ALS-50-840-3-01-C
1330070
LED HL Driver - 55w, 500-1200mA,12-50V (-MS-HL Option)
1330056
LED Driver - LCA 50w 350-1050mA, one4all Ip PRE (-DD Option)
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.

1948707 V1.2 4 May 2021
Installation:
The Vandal Resistant Batten is a surface mount fitting.
The batten can be attached directly to any solid surface by drilling the base internal mounts as required.
Refer to the Dimensions Section for mounting points.
The batten can also be mounted to Unistrut utilizing the four (4) recessed screw holes on the back of the
case. Refer to Dimensions section.
1. Remove the diffuser and gear tray. Position
the batten base in the desired location.
5. Attach gear tray to lanyards.
2. Mark out the fixing points on the mounting
surface.
6. Wire mains power cable, 240V 50Hz, to
terminals marked A, N &.
3. Fasten the batten to the surface, using
appropriate fixing method.
7. Fit gear tray and diffuser.
4. Route power cable through the access hole.
Use the conduit entry point at the end or drill a
suitable entry hole in the rear of the batten
body (must be suitably sealed after cable
entry).
Sealing:
When drilling through the fitting base, a suitable silicone sealant must be applied to maintain the IP
rating. Always use a sealant that remains flexible. Apply enough sealant so that the material oozes out
completely around the washer when the bolt or screw is tightened.
Always use a gland or screwed conduit adapter. With conduit ensure that the other end of the conduit is
not left open. Even if it is inside the building, it allows water vapor and insects to enter the fitting. A
rubber washer and silicone sealant should also be used between the fitting body and the conduit nut
inside the fitting to guarantee a water-tight seal. Use PVC cement to seal all conduit joints. Glands are
intended for round cable and will not seal against TPS. Even when properly installed using round cable,
sealant may be necessary in extreme weather exposure.
Dimensions:
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
