Maintenance Instructions Clima ad 2.0R
Maintenance frequency for filters
When should you replace the filters?
• veruildWith normal use, every 2 years or earlier if the message 'Filter ' appears on
the display (for example in homes and offices).
• vervuildIn the case of intensive use, after 1 year or earlier if the message 'Filter '
appears on the display (e.g. for care homes and schools).
Ordering filters
Order new filters at
www.climarad.nl/filters
1. Switch off the device first by
removing the plug from the
socket.
Replacing air supply filters
2. There is a locking screw at the
bottom of each of the two (or
four) radiator consoles. Remove
these locking screws.
3. Tilt the radiator and, if
required, lock it with an Allen key
or screwdriver.
4. Push the left-hand and right-
hand slide on top of the ClimaRad
inwards and open both covers by
pulling them towards you.
5. Remove the black filter caps on
the left and right.
6. Slide the three new filters in the
unit from the left-hand side. The
old filters will automatically slide
out on the right-hand side.
7. Replace the black filter caps on
the left and right.
8. Close the covers on the left-
hand and right-hand side of the
unit, and slide both latching slides
outwards.
9. Unlock the radiator and tilt it
back. Push the plug back into the
socket and reset the filter hour
counter (by simultaneously pressing
on the + and - on the display for 6
seconds ). The message 'Filter
vervuild' will disappear. Tighten the
locking screws again.
Important: Reset the filter hour counter only if you have replaced
the filters.
Go to to view the instruction video.www.climaRad.nl/filtervervanging
Slide 3 new filters in
3 old filters will
slide out
left
right
left
left left
right
right
right
Press
Future comfort today

ONDERHOUD: luchtafvoerfilters
12
3
Cleaning the air outlet filters
Replacing the air outlet filters
Cleaning the air ducts
1
1
2
The air outlet filter is located at the bottom of the unit.
When visibly dirty, remove the dirt from the air outlet filter with a
vacuum cleaner. This guarantees the flow of air. You do not need to
remove the air outlet filter.
1. Pull the plug from the socket
and pull the filter tray at the
bottom of the ClimaRad forwards.
9. Unlock the radiator and tilt it
back. Push the plug back into the
socket and tighten the retaining
screws.
2. Remove the 3 filters from the
tray.
3. Insert 3 new filters in the 3
sections of the tray and press
down firmly.
4. Slide the filter tray closed until
you hear a clicking sound. Push
the plug back into the socket.
Follow the steps 1 to 4 under
'Replacing the air supply filters'.
5. Turn both blue caps once
against the direction of the clock
and remove them.
6. Remove any dirt from both
channels with a vacuum cleaner or
a soft cloth (do not use water).
7. Push both blue filter caps fully
back in for a correct operation
and tighten.
8. Close the covers on the left-
hand and right-hand side of the
unit, and slide both latching slides
outwards.
ClimaRad B.V. - Lübeckstraat 25 - 7575 EE - Oldenzaal - NL - [email protected] - www.climarad.co.uk - tel. [phone]
