ClimaRad Vita H1C-S Operating and maintenance instructions

and
for 6 seconds
1
2022.001
Maintenance instructions ClimaRad Vita H1C-S
3. Loosen the screws and remove the upper
housing from the unit (1). Tilt the lower
housing forwards (n.b.: this is held in place
with magnets.) Position it in the brackets
provided for this purpose (2).
1
2
Replacing air supply filters
Important: Only reset the filter hour counter if you have replaced the filters.
1
1
2
2
3
When should you replace the filters?
• With normal use, every 2 years or earlier if the message 'Filter vervuild' appears
on the display (for example in homes and offices).
• In the case of intensive use, after 1 year or earlier if the message 'Filter
vervuild' appears on the display (e.g. for care homes and schools).
Go to to view the instruction video.www.climaRad.nl/filtervervanging
Maintenance frequency for filters
Ordering filters
Order new filters at
www.climarad.nl/filters
2. Unscrew the locking screws
from the housing. The lower
housing now moves forward.
1.First switch the device off by
pulling the plug out of the socket.
left right
left
right
3 old filters will
slide out
Slide 3 new filters in
4. Open both valves by pulling
them towards you.
6. Slide three new filter elements
into the device on the left side.
The old filter elements are
automatically ejected from the
right side.
5. Remove the black caps.
7. Put the two black filter caps
(left and right) back in position
and close both valves again.
8. Reinstall the air distributor (1),
tilt the lower housing back in
position (2), and tighten the
screws again (3).
9. Put the plug back into the
socket and reset the filter hour
counter (Press + and –
simultaneously for 6 seconds). The
'filter vervuild' message will now
disappear.
left right
Press

ONDERHOUD: luchtafvoerfilters
2
3
Cleaning the air output filters and coarse filter
Replacing air output filters
Cleaning the air ducts
1
The air output filters are located at the bottom of
the device. Vacuum the visible dirt off the filters.
This guarantees the air flow. You do not need to
remove the air output filters to do this.
3x
4
1
1
8. Reinstall the air distributor (1),
tilt the lower housing back in
position (2), and tighten the
screws again (3).
9. Put the plug back into the
socket when finished.
1
1
22
2
1
3
2.The output filters (3 pieces) are
located at the bottom of the
device, in the middle. These can
be removed by placing a finger
behind the notch.
3. Push 3 new filters into the
holders and then push the plug
back into the socket.
1. First switch the device off by
pulling the plug out of the socket.
First follow steps 1 to 4 of
'replacing the air supply filters'.
5. Turn both blue caps anti-
clockwise and then remove them.
6. Remove dirt from both ducts
with a vacuum cleaner or a soft
cloth (do not use water).
left right
left right
7. Push both blue filter caps back
in completely in order to ensure
correct operation and screw them
back into position.
ClimaRad B.V. - Lübeckstraat 25 - 7575 EE - Oldenzaal - NL - [e-mail] - www.climarad.co.uk - tel. [phone]
