ClimaRad Sensa Horizontal 2015 Operating and maintenance instructions

Wanneer vervangt u de filters?
 Bij normaal gebruik: om de 2 jaar of eerder als de melding 'filter vervuild' op het
display verschijnt (bijvoorbeeld bij woningen en kantoren).
 Bij intensief gebruik: na 1 jaar of eerder als de melding 'filter vervuild' op het
display verschijnt (bijvoorbeeld bij zorgcomplexen en scholen).
Onderhoudsfrequentie filters
Maintenance ClimaRad Sensa Horizontal: replacing the air supply filters
and
press for 6 seconds
Filters bestellen
Bestel nieuwe filters via
www.climarad.nl/filters
2015.001
When should you replace the filters?
• With normal use, every 2 years or earlier if the message 'Filter vervuild' appears on
the display (for example in homes and offices).
• In the case of intensive use, after 1 year or earlier if the message 'Filter vervuild'
appears on the display (e.g. for care homes and schools).
Maintenance frequency for filters
Ordering filters
Order new filters at
www.climarad.nl/filters
Maintenance Instructions ClimaRad Sensa Horizontal 2015
2. Remove the cover of the Sensa
by lifting it upwards.
1. Switch off the device first by
removing the plug from the
socket.
3. Open the three clips on the top
and tilt the filter housing
forwards.
4. Slide the two contaminated
filters to the sides out of the fiter
housing.
6. Tilt the filter housing upwards
and secure with the three clips.
5. Slide the two new filters fully
into the filter housing so that they
do not project.
Caution: Make sure the filters do
not protrude from the filter
housing or that tools are trapped
between
the filter housing and the
radiator housing. This can
damage the filter housing and
cause air leaks along the edges.
Important: Reset the filter hour
counter only if you have
replaced the filters.
7. Put the cover back on the
ClimaRad Sensa V2X.
8. Push the plug back into the
socket and reset the filter hour
counter by simultaneously pressing
on the + and - on the display for 6
seconds. The message 'Filter
vervuild' will disappear.

ONDERHOUD: luchtafvoerfilters
Cleaning the filter tray
replacing the air outlet filters
1. Remove the cover of the Sensa
by lifting it upwards.
2. Use a vacuum cleaner to
remove as much dirt as possible
from the filter tray at the bottom.
3. Put the cover back on.
1. Switch off the device first by
removing the plug from the
socket.
2. Remove the cover of the Sensa
by lifting it upwards.
3. Loosen the two screws under
the filter cover.
4. Pull the two clips gently
towards you. Turn the filter grille
as far as forward as possible.
5. Push the three filters
backwards so that they can come
loose.
6. Push the three new filters in
the sections and press the grille at
the bottom with the two clips
firmly closed until you feel it
snap.
Screw the grille in position with
the two screws.
7. Put the cover back on. 8. Push the plug back into the socket.
Please note that the grid must be
properly closed for proper
operation.

Cleaning the airducts
ClimaRad B.V. - Lübeckstraat 25 - 7575 EE - Oldenzaal - NL - [e-mail] - www.climarad.co.uk - tel. [phone]
1. Switch off the device first by
removing the plug from the
socket.
2. Remove the cover of the Sensa
by lifting it upwards.
3. Remove the two caps by
turning them to the left and
removing them.
4. Grasp the round cups at the
three tabs and remove both.
5. Remove any dirt from both
channels with a vacuum cleaner
or a soft cloth (do not use water).
6. Insert the round cups.
7. Install both caps and tighten
them well for a correct operation.
9. Push the plug back into the
socket.
8. Put the cover back on.
