FOREWORD
ThankyouforchoosingClubCar,thenamemostwidelyrecognizedastheindustryleaderinvehicleefciency
andlong-lastingvalue.Youhavechosenthenestvehicleonthemarket.Pleaseprotectyourinvestmentand
ensurethatyourClubCarvehicle(s)providesyearsofreliable,superiorperformancebyreadingandfollowingthe
maintenanceinstructionsinthismanual.
Yourcomfortandsafetyareimportanttous,soweurgeyoutoreadandfollowthestep-by-stepoperatinginstructions
andsafetyprecautionsinthismanual.Theseinstructionsmustbefollowedinordertoavoidtheriskofseverepersonal
injury.Ifyourentorloanyourvehicletoothers,werecommendthatyouaskthemtoreadthismanualbeforethey
operatethevehicle.
ClubCarproductsarebackedbyacustomersupportsystemdesignedtoofferyoufast,courteousservice.Intheevent
yourvehicleneedsrepairsorservice,pleasecontactyourlocalauthorizedClubCardealerordistributor;whowillbe
abletoprovidetechnicaladvice,performwarrantywork,andsellpartsandservicemanuals.
ForthenameandaddressoftheauthorizedClubCardealerordistributornearestyou,logontoourwebsiteat
www.clubcar.comorcall1-800-ClubCar(258-2227).Ifyouwouldprefertowritetous,directyourletterto:ClubCar,
Attention:MarketingServices,P .O.Box204658,Augusta,Georgia30917-4658USA.
Wehopeyouwillconsiderthisowner’smanualapermanentpartofyourvehicle.Ifyousellthevehicle,pleaseinclude
themanualsothatthenextownerwillhavetheimportantoperating,safety,andmaintenanceinformationitcontains.
REGULARMAINTENANCEITEMSPERIODICMAINTENANCEITEMS
EngineOilFilter
CCP/N103887901
SparkPlugO.H.V.
EitherCCP/NAM1232301or101881101
EngineAirFilter
CCP/N102558201
SpringTune-UpKit
CCP/NAM1262501
EngineFuelFilter
CCP/N102003201
Fuse,10Amp,StartingCircuit(gasolinevehicle)
FuseunderSeatnearSolenoid
CCP/N1012295
BatteryTerminalProtectorSpray
CCP/N1014305
Fuse,15Amp,Tow/RunSwitch(electricvehicle)
FuseunderSeatbeneathElectronicsModuleCover
CCP/N102538601
DryMolyLube
CCP/N1012151
Fuse,10Amp,HeadlightCircuit(ifequipped)
FuseunderSeatbeneathElectronicsModuleCover
CCP/N1012295
Fuse,0.5Amp,BrakeLightCircuit(ifequipped)
FuseunderFloormatbeneathFloorCoverPlate
CCP/NAM1214301
Page2PrecedentGoldStandardRemanufacturedVehicleOwner’sManual

TABLEOFCONTENTS
SafetyDecalandFeatureIdentication..................................................................................................................4
PracticeSafety....................................................................................................................................................11
Proposition65–StateofCalifornia.......................................................................................................................11
SafetyDetails.....................................................................................................................................................12
GeneralWarnings...............................................................................................................................................12
GeneralInformation............................................................................................................................................16
ModelIdentication.............................................................................................................................................16
SafetyCommittee...............................................................................................................................................17
Precedent2Plus2and2in1Vehicles................................................................................................................17
ControlsandIndicators–ElectricVehicles...........................................................................................................18
ControlsandIndicators–GasolineVehicles.........................................................................................................23
Pre-OperationandDailySafetyChecklist.............................................................................................................28
DrivingInstructions.............................................................................................................................................30
Towing...............................................................................................................................................................32
TransportingonaTrailer.....................................................................................................................................32
Storage–ElectricVehicle....................................................................................................................................33
Storage–GasolineVehicle.................................................................................................................................35
Maintenance......................................................................................................................................................38
PeriodicServiceSchedules.................................................................................................................................39
PeriodicLubricationSchedules............................................................................................................................43
Batteries–ElectricVehicles................................................................................................................................45
BatteryCharger–ElectricVehicles......................................................................................................................48
Battery–GasolineVehicles.................................................................................................................................52
EngineOil–GasolineVehicles............................................................................................................................53
FuelingInstructions–GasolineVehicles..............................................................................................................56
CleaningtheVehicle...........................................................................................................................................57
Accessories........................................................................................................................................................57
SubsequentOwnerRegistration..........................................................................................................................58
VehicleSpecications–ElectricVehicles.............................................................................................................59
VehicleSpecications–GasolineVehicles...........................................................................................................61
Warranties..........................................................................................................................................................63
PrecedentGoldStandardRemanufacturedVehicleOwner’sManualPage3

SafetyDecalandFeatureIdentication
SAFETYDECALANDFEATUREIDENTIFICATION
Thefollowingpagescontainsafetydecalandfeatureidenticationinformation.Fordetailedinformationonspecic
features,readtheappropriatesectioninthismanual.
ELECTRICVEHICLE
2011
9
7
8
6
4
1
3
25
1101825101Decal,On/OffKeySwitch(abovekeyswitch)6BatteryWarningLight
2102518001Decal,OperatingInstructions(onsteeringwheel)7AcceleratorPedal
3102519301Decal,RolloverWarning(oninstrumentpanel)8BrakePedal
4102555901Decal,PrivateSpeedNotice(belowinstrument
panel)(withprivatespeedoption)9ParkBrakePedal
5103783001Decal,OperatingInstructions(onsteeringwheel)
Page4PrecedentGoldStandardRemanufacturedVehicleOwner’sManual

SafetyDecalandFeatureIdentication
ELECTRICVEHICLE
1377
3
2
4
1
5
6
1103384601Decal,WaterExposureCaution5Forward/ReverseControl
2103384701Decal,BatteryTerminalWarning(oncomponent
mountingplate)6BatteryChargerReceptacle
3103384801Decal,T ow/RunWarning7
4Tow/RunSwitch8
PrecedentGoldStandardRemanufacturedVehicleOwner’sManualPage5

SafetyDecalandFeatureIdentication
GASOLINEVEHICLE
2757
25
1
3
6
97
8
4
1101825101Decal,On/OffKeySwitch(abovekeyswitch)6LowOilWarningLight
2102519201Decal,OperatingInstructions(onsteeringwheel)7AcceleratorPedal
3102519301Decal,RolloverWarning(oninstrumentpanel)8BrakePedal
4102555901Decal,PrivateSpeedNotice(belowinstrument
panel)(withprivatespeedoption)9ParkBrakePedal
5103783002Decal,OperatingInstructions(onsteeringwheel)
Page6PrecedentGoldStandardRemanufacturedVehicleOwner’sManual

SafetyDecalandFeatureIdentication
GASOLINEVEHICLE
295
1
1101960501Decal,RotatingParts/HotManifoldWarning(on
engine,starter/generator,andtransaxle)4Choke
2102517801Decal,Gas/GovernorWarning(onfueltank
hold-downbracket)5Forward/ReverseControl
3102517901Decal,FrameGroundWarning(onvehicleframe,
underseat)
PrecedentGoldStandardRemanufacturedVehicleOwner’sManualPage7

SafetyDecalandFeatureIdentication
PRECEDENT2PLUS2(FACTORY-INSTALLEDSEATKITSHOWN)
415
2
1
3
4
2
1101705701
Decal,FallingOffWarning(onrear-facingseat
handrailand/oronbacksideofforward-facing
seatbacks)
5
2Handhold6
3Handrail7
4Footrest8
Page8PrecedentGoldStandardRemanufacturedVehicleOwner’sManual

SafetyDecalandFeatureIdentication
PRECEDENT2IN1
1388
2
1
3
4
1101609401Decal,CrushAreaWarning(onrear-facingseat
handholds)5
2101972001Decal,Flip-SeatBedLoadWarning6
3Handhold7
4Footrest8
PrecedentGoldStandardRemanufacturedVehicleOwner’sManualPage9

SafetyDecalandFeatureIdentication
BOXBED
1300-17100-10443
1
1101553901Decal,BedLoadingWarning5
26
37
48
Page10PrecedentGoldStandardRemanufacturedVehicleOwner’sManual

PracticeSafety
PRACTICESAFETY
399
Figure1PracticeSafety
Safetysignslikeyouseeabovemayatrstseemshocking,buttheirimpactismildcomparedwiththereality
ofseverepersonalinjury.
Yoursafetyandsatisfactionareoftheutmostimportancetous.Thatiswhybeforeoperatingthevehicle,weurge
youtoreviewtheinformationinthismanual.UnderstandandbecomefamiliarwiththeDANGER,WARNING,and
CAUTIONstatementsandproceduresitcontains,alongwiththesafetydecalsthatareafxedtoyourvehicle.
Taketimetounderstandthelanguageofsafety.Itisalanguagethatcansaveyourlife.
PROPOSITION65–STATEOFCALIFORNIA
WARNING
•Thisproductcontainsoremitschemicalsorsubstancesthathavebeendeterminedbythestateof
Californiatocausecancerandbirthdefectsorotherreproductiveharm.
PrecedentGoldStandardRemanufacturedVehicleOwner’sManualPage11

SafetyDetails
SAFETYDETAILS
WARNING
•Thisowner’smanualshouldbereadcompletelybeforeattemptingtodriveorservicethevehicle.
Failuretofollowtheinstructionsinthismanualcouldresultinpropertydamage,severepersonal
injury,ordeath.
Itisimportanttonotethatsomevitalstatementsthroughoutthismanualandonthedecalsafxedtothevehicleare
precededbythewordsDANGER,WARNING,orCAUTION.Foryourprotection,werecommendthatyoutakespecial
noticeofthesesafetyprecautions.Safetyprecautionsareessentialandmustbefollowed.
Throughoutthismanualandontheoperationandsafetydecalsafxedtothevehicle,thewords“golfcar”and
“vehicle”areusedinterchangeably.“Golfcar”isdenedintheNoticeofthismanualandnootherrepresentationis
statedorimplied.
Ifanyoftheoperationorsafetydecalsonthevehiclebecomedamaged,havebeenremovedorcannotbeeasily
read,theyshouldbereplacedimmediatelytoavoidpossiblepropertydamage,personalinjury,ordeath.Contactyour
distributor/dealer.
DANGER
•ADANGERindicatesanimmediatehazardthatwillresultinseverepersonalinjuryordeath.
WARNING
•AWARNINGindicatesanimmediatehazardthatcouldresultinseverepersonalinjuryordeath.
CAUTION
•ACAUTIONwiththesafetyalertsymbolindicatesahazardorunsafepracticethatcouldresultin
minorpersonalinjury.
CAUTION
•ACAUTIONwithoutthesafetyalertsymbolindicatesapotentiallyhazardoussituationthatcould
resultinpropertydamage.
GENERALWARNINGS
Thefollowingsafetystatementsmustbeheededwheneverthevehicleisbeingoperated,repaired,orserviced.
SeeSafetyDecalandFeatureIdenticationonpage4.Otherspecicsafetystatementsappearthroughout
thismanualandonthevehicle.
DANGER
•Battery–Explosivegases!Donotsmoke.Keepsparksandamesawayfromthevehicleandservice
area.Ventilatewhenchargingoroperatingvehicleinanenclosedarea.Wearafullfaceshieldand
rubbergloveswhenworkingonornearbatteries.
•Gasoline–Flammable!Explosive!Donotsmoke.Keepsparksandamesawayfromthevehicleand
servicearea.Serviceonlyinawell-ventilatedarea.
DANGERCONTINUEDONNEXTPAGE
Page12PrecedentGoldStandardRemanufacturedVehicleOwner’sManual

GeneralWarnings
DANGER
•Donotoperateengineinanenclosedareawithoutproperventilation.Theengineproducescarbon
monoxide,whichisanodorless,deadlypoison.
•Thevehiclewillnotprovideprotectionfromlightning,yingobjects,orotherstorm-relatedhazards.If
caughtinastormwhiledrivingaClubCarvehicle,exitthevehicleandseekshelterinaccordancewith
applicablesafetyguidelinesforyourlocation.
WARNING
•Followtheproceduresexactlyasstatedinthismanual,andheedallDANGER,WARNING,and
CAUTIONstatementsinthismanualaswellasthoseonthevehicleandbatterycharger.
•Donotleavechildrenunattendedonvehicle.
•Priortoleavingthevehicleunattendedorservicingthevehicle,settheparkbrake,placethe
Forward/ReversehandleorswitchintheNEUTRALposition,turnthekeyswitchtotheOFFposition,
andremovethekey.Chockthewheelswhenservicingthevehicle.
•Improperuseofthevehicleorfailuretoproperlymaintainitcouldresultindecreasedvehicle
performance,severepersonalinjury,ordeath.
•Anymodicationorchangetothevehiclethataffectstheelectricalsystem,stabilityorhandling
ofthevehicle,orincreasesmaximumvehiclespeedbeyondfactoryspecications,couldresultin
severepersonalinjuryordeath.
•Checkthevehicleforproperlocationofallvehiclesafetyandoperationdecalsandmakesuretheyare
inplaceandareeasytoread.SeeSafetyDecalandFeatureIdenticationonpage4.
•Onlytrainedtechniciansshouldserviceorrepairthevehicleorbatterycharger.Anyonedoingeven
simplerepairsorserviceshouldhaveknowledgeandexperienceinelectricalandmechanicalrepair.
Theappropriateinstructionsmustbeusedwhenperformingmaintenance,service,oraccessory
installation.
•Wearsafetyglassesorapprovedeyeprotectionwhenservicingthevehicleorbatterycharger.Weara
fullfaceshieldandrubbergloveswhenworkingonornearbatteries.
•Donotwearlooseclothingorjewelrysuchasrings,watches,chains,etc.,whenservicingthe
vehicleorbatterycharger.
•Useinsulatedtoolswhenworkingnearbatteriesorelectricalconnections.Useextremecautionto
avoidshortingofcomponentsorwiring.
Electricvehiclesonly:
•PlaceTow/RunswitchintheTOWpositionbeforedisconnectingorconnectingthebatteries.Failureto
heedthiswarningcouldresultinabatteryexplosionorseverepersonalinjury.
•Toavoidunintentionallystartinganelectricvehicle,disconnectthebatteriesanddischargethe
controller.SeeDisconnectingtheBatteries–ElectricVehiclesonpage15.
Gasolinevehiclesonly:
•Toavoidunintentionallystartingagasolinevehicle,disconnectthebatteryandsparkplugwire.See
DisconnectingtheBattery–GasolineVehiclesonpage14.
•Frameground–Donotallowtoolsorothermetalobjectstocontactframewhendisconnectingbattery
cablesorotherelectricalwiring.Donotallowapositivewiretotouchthevehicleframe,engine,or
anyothermetalcomponent.
PrecedentGoldStandardRemanufacturedVehicleOwner’sManualPage13

GeneralWarnings
DISABLINGTHEVEHICLE
1.Settheparkbrake.
2.TurnthekeyswitchOFFandremovethekey.
3.PlacetheForward/ReversecontrolintheNEUTRALposition.
4.Inaddition,chockthewheelsifservicingorrepairingthevehicle.
DISCONNECTINGTHEBATTERY–GASOLINEVEHICLES
1.Disablethevehicle.SeeDisablingtheVehicleonpage14.
2.Disconnectthebatterycables,negative(–)cablerst,asshown(Figure3).
3.Disconnectthesparkplugwire(s)fromthesparkplug(s).
CONNECTINGTHEBATTERY–GASOLINEVEHICLES
1.Connectthebatterycables,positive(+)cablerst.
2.Tightenbatteryterminalsto80in-lb(9N·m).
3.CoatterminalswithBatteryT erminalProtectorSpray(CCP/N1014305)tominimizecorrosion.
4.Connectthesparkplugwire(s)tothesparkplug(s).
TOW
RUN
2
3
4
5
6
+
1
1
(–)
(+)
3
2
(Viewedfromdriversideofvehicle)
1.PlaceTOW/RUNSwitchinTOWbeforedisconnectingorconnecting
batterycables.
2.Removenegativebatterycable.
3.Removepositivebatterycable.
Connectbatterycablesinreverseorder.
2
(+)
1
(–)
(Viewedfromdriversideofvehicle)
1.Removenegativebatterycable.
2.Removepositivebatterycable.
Connectbatterycablesinreverseorder.
49A
Figure2BatteryCableRemoval–6x8-VoltBattery
Conguration
50
Figure3BatteryCableRemoval–Gasoline
Page14PrecedentGoldStandardRemanufacturedVehicleOwner’sManual

GeneralWarnings
DISCONNECTINGTHEBATTERIES–ELECTRICVEHICLES
1.Disablethevehicle.SeeDisablingtheVehicleonpage14.
2.PlaceTow/RunswitchintheTOWpositionbeforedisconnectingorconnectingthebatteries.Failuretoheed
thiswarningcouldresultinabatteryexplosionorseverepersonalinjury.
3.Disconnectthebatteries,negative(–)cablerst,asshown(Figure2).
4.Afterdisconnectingthebatteries,wait90secondsforthecontrollercapacitorstodischarge.
CONNECTINGTHEBATTERIES–ELECTRICVEHICLES
1.EnsuretheT ow/RunswitchisintheTOWposition.
2.Connectthebatterycables,positive(+)cablerst.
3.Tightenbatteryterminalsto110in-lb(12.4N·m).
4.CoatterminalswithBatteryT erminalProtectorSpray(CCP/N1014305)tominimizecorrosion.
RECYCLINGLEAD-ACIDBATTERIES
WARNING
•Lead-acidbatteriescontainlead(Pb),othermetals,acidsandothercompounds.Ifimproperlyhandled,
theycancontaminatebothwaterandsoil,causingenvironmentaldamageandpersonalinjury.
Lead-acidbatteriesareidentiedbythesymbolshownbelowandshouldbeproperlyrecycled(Figure4).Theycannot
bedisposedasmunicipalwasteandmustbecollectedseparately.Responsibilityforenvironmentalprotectionmustbe
shared,notonlybythemanufacturersofthebatteries,butbypeoplewhousethebatteriesaswell.Pleasecontact
yournearestClubCardealerordistributorforinformationonhowtoproperlyrecycleyourbatteries.
1403
Figure4DisposeofLead-acidBatteriesProperly
PrecedentGoldStandardRemanufacturedVehicleOwner’sManualPage15

GeneralInformation
INTERNATIONALSAFETYSYMBOLSONBATTERIES
Anyoneusing,repairing,orservicingthevehiclemustunderstandandheedthesafetysymbolsonthevehiclebattery
orbatteries.
123456
1.Shieldeyes.3.Nosmoking,noopenames,nosparks.5.Batteryacidhazard.
2.Readandfollowoperatinginstructions.4.Keepawayfromchildren.6.Explosivegashazard.
RefertoGeneralWarningsformoreinformation.
1642
Figure5InternationalSafetySymbolsonBatteries
GENERALINFORMATION
PrecedentGoldStandardRemanufacturedvehiclesareavailablewitheitherelectricorgasolinepower.Throughout
thismanual,importantfeaturesuniquetoeachmodelarehighlighted.Weurgetheowner/operatortoreadand
understandthismanualandtopayspecialattentiontothefeaturesspecictohis/hervehicle(s).
MODELIDENTIFICATION
Theserialnumberofeachvehicleisprintedonabarcodedecalmountedeitherbelowthepassengersidecupholder
orabovetheacceleratororbrakepedal(Example:PR0601-123456)(Figure6,Page17).
Thetwolettersatthebeginningoftheserialnumberindicatethevehiclemodel.Thefollowingfourdigitsindicatethe
modelyearandproductionweekduringwhichthevehiclewasbuilt.Thesixdigitsfollowingthehyphenrepresentthe
uniquesequentialnumberassignedtoeachvehiclebuiltwithinagivenmodelyear.SeefollowingNOTE.
NOTE:Havethevehicleserialnumberavailablewhenorderingpartsormakinginquiries.
BuildCode:Thebuildcode(4)isave-digitnumberthatappearsonthevehicleserialnumberdecal.Thebuildcode
existstoenabletheusertoidentifythecorrectowner’smanualforavehicle.Thisowner’smanualisvalidforthebuild
coderangeindicatedonthebackcoverofthisowner’smanual.
Page16PrecedentGoldStandardRemanufacturedVehicleOwner’sManual

SafetyCommittee
PH0901-123456
BC54679
S ER IAL NUMBE R
AS SEMBLED IN USA
4
123
1400
Figure6SerialNumberDecal
SAFETYCOMMITTEE
Ifthegolfcaristoberentedorispartofaeet,westronglyrecommendthatasafetycommitteebeappointed.Oneof
themainconcernsofthiscommitteeshouldbethesafeoperationofthegolfcars.Thisshouldincludeataminimum:
•Wheregolfcarsshouldbedriven.
•Ensuringthatproperwarningsofdrivinghazardsaredisplayedandvisible.
•Whoshouldandwhoshouldnotdrivegolfcars.
•Instructingrsttimedrivers.
•Maintaininggolfcarsinasafedrivingcondition.
•Howvariousrulesaretobeenforced.
Thesafetycommitteeshouldincludealltheseitemsandsuchothersasthecommitteefeelsnecessaryorappropriate.
PRECEDENT2PLUS2AND2IN1VEHICLES
Thesemodelsaredesignedtoprovideasmoothandcomfortablerideforfourpassengers.Thisowner’smanual
shouldbereadthoroughlypriortooperatingthevehicle.
The2Plus2and2in1vehiclesshouldbedrivenandmaintainedasstatedinthisowner’smanualwiththefollowing
additions:
WARNING
•Vehicleshouldbedrivenatslowerspeedswhenfourpersonsareinthevehicle.
•Passengersshouldholdontohandholdsorhandrailsatalltimes.SeePrecedent2Plus2
(Factory-InstalledSeatKitshown)onpage8.Drivershouldkeepbothhandsonthesteeringwheel
whilevehicleismoving.
•Donotleavechildrenunattendedontherearseatwhilevehicleismoving.
•Nomorethanfourpersonsshouldbeonthevehicleatonetime.
PrecedentGoldStandardRemanufacturedVehicleOwner’sManualPage17

ControlsandIndicators–ElectricVehicles
MAINTENANCE
Refertopages39through43forPeriodicServiceandLubricationSchedules.SeefollowingNOTE.
NOTE:Ifthevehicleisconstantlyhaulingheavyloads,thepreventivemaintenanceproceduresshouldbeperformed
moreoftenthanrecommendedintheserviceandlubricationschedules.
CONTROLSANDINDICATORS–ELECTRICVEHICLES
SeeGeneralWarningsonpage12.
WARNING
•Ifrentingorloaningthevehicle,makesurethedriverisfamiliarwithallcontrolsandoperating
proceduresbeforeallowingthevehicletobedriven.
•DonotshifttheForward/Reverseswitchwhilethevehicleismoving.Toavoidinjurytoan
unsuspectingpassengerordamagetothevehicle,alwaysbringthevehicletoafullstopbefore
shiftingtheForward/Reverseswitch.
•Releasetheacceleratorpedalandthenpressthebrakepedalrmlyuntilthevehiclestops.Toavoid
unintentionallystartingorrollingthevehicle,settheparkbrake,placetheForward/Reverseswitchin
theNEUTRALposition,turnthekeyswitchtotheOFFposition,andremovethekeywhenleaving
thevehicle.
KEYSWITCH
Thekeyswitchismountedonthedashtotherightofthesteeringcolumn(Figure7).Ithastwopositions,OFFand
ON,whichareclearlylabeled.SeefollowingNOTE.
NOTE:WhenthekeyisturnedtotheOFFposition,themainvehiclesystemsaredisabled.Thekeyswitchmaybe
usedasanemergencystop.
ThekeycanberemovedonlywhenthekeyswitchisintheOFFposition.
52
Figure7KeySwitch
6
Figure8Forward/ReverseRockerSwitch
Page18PrecedentGoldStandardRemanufacturedVehicleOwner’sManual
