Cobra 29 LTD Classic Contents Operating instructions

How to Use Your
Cobra 29 LTD Classic
Contents
Features..................................................................................................1
The CB Story.........................................................................................A1
FCC Regulations
FCC Warnings
Included Accessories
Controls & Indicators.......................................................................A2
Our Thanks to You.............................................................................A3
Customer Support
Installation
Location .............................................................................................2
Mounting and Connection .........................................................2
Antennas
CB Antenna.......................................................................................6
Marine Installation .........................................................................6
Ignition Noise Interface .................................................................7
Operating Your 29 LTD Classic
Turning On Your CB........................................................................8
Setting Channel Selector.............................................................9
Calibrate For SWR (Standing Wave Ratio)..............................10
To Receive..........................................................................................13
Selecting a Channel.......................................................................14
S-Meter ...............................................................................................14
NB-ANL/ANL/Off (Noise Blanker/Automatic.........................15
Noise Limiter Switch)
Bright/Dim Switch..........................................................................16
RF Gain Control................................................................................17
Setting Delta-Tune .........................................................................18
Setting Squelch ...............................................................................18
To Transmit........................................................................................20
Setting Dynamike...........................................................................20
Transmit..............................................................................................21
RF Meter.............................................................................................22
External Speaker .............................................................................23
PA (Public Address) ........................................................................24
Home And Office Set-Up .............................................................26
Temporary Mobile Set-Up ...........................................................27
How Your CB Can Serve You..........................................................28
A Few Rules You Should Know..................................................28
Channel 9 Emergency Messages..............................................28
CB 10 Codes......................................................................................30
Frequency Ranges.............................................................................32
29 LTD Classic Specifications .......................................................33
Warranty Information .....................................................................34
Notes........................................................................................................35
Optional Accessories .......................................................................38
Order Form ...........................................................................................40
If You Think You Need Service...................................Back Cover
Features of This Product
• 40 CB Radio Channels
• Heavy-Duty Dynamic
Microphone
• Full 4 Watts AM RF Power Output
• SWR Calibration Meter
• Instant Channel 9
• 4-Pin Microphone Connector
• Delta -Tune
• Switchable Automatic Noise
Limiter & Noise Blanker
• Adjustable Dynamike Boost
1
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN !
!
For Sales Information Please
Contact
RoadTrucker Inc
(www.RoadTrucker.com)
8312 Sidbury Rd.
Wilmington, NC 28411
[phone] / [phone]
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Installation
Location
2
Mounting and
Connection
Mounting and Connection
Hold the radio with the mounting bracket in
the exact desired location. If there is no inter-
ference, remove the bracket and use it as a
template to mark the location for the mount-
ing screws.
Location
Plan location of transceiver and microphone
bracket before starting the installation.
Select a location that is convenient for operation,
yet does not interfere with the driver or passenger.
The transceiver is usually mounted to the under-
side of the dash with the microphone bracket
beside it.
Note
The transceiver is held in the
universal mounting bracket by
two thumbscrews which allow
for adjustment at a convenient
angle.
The bracket includes two self-
tapping screws and star wash-
ers.The mounting must be
mechanically strong, conve-
niently located.
Drill the holes and secure the bracket.
2
1
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Installation
3
continued
Connect the antenna cable plug to the recep-
tacle marked “ANT” on the back of the unit.
3
Note
Before installing the CB radio,
visually check the vehicle’s
battery connection to deter-
mine which terminal, positive
or negative,is grounded (pos-
itive is the larger of the two)
to the engine block (or chas-
sis). A negatively grounded
vehicle has its negative lead
grounded to the chassis.
Note
In positive ground vehicles the
red wire goes to the chassis and
the black wire is connected to
the ignition switch.
ANT PA.SP. EXT.SP.
+POWER –
DATE OF 
MFG :JUNE 98 FCC ID:BBO3K229LTD
COBRA
MADE IN CHINA
SERIAL NO.:806135776
PRECISION ENGINEERED PRODUCT OF
COBRA ELECTRONICS CORP. CHICAGO, ILL.60707
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Installation
4
Note
Connecting to an accessory fuse
prevents the unit from being left
on accidentally,and also per-
mits operating the unit without
running the engine.
Note
In positive ground vehicles the
red wire goes to the chassis and
the black wire is connected to
the ignition switch.
In a negative grounded vehicle, connect the
red lead of the DC power cord to an accessory
12 volt fuse.
Connect the black lead to the negative side of
the vehicle.This is usually the chassis. Any con-
venient location with a good electrical contact
(remove paint) may be used.
4
5
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Installation
5
Plug power cable into back of unit marked
“Power”. Be sure to observe polarity markings.
Mount the microphone
bracket on either side of
the unit (driver’s left)
using two screws sup-
plied. Bracket should be
placed under the dash
so microphone is readily
accessible.
6
7
Attach the 4-pin microphone cable to
receptacle, on side of unit and install unit on
bracket securely.
8
ANT PA.SP. EXT.SP.
+POWER –
FCC ID:BBO3K229LTD
COBRA
MADE IN CHINA
PRECISION ENGINEERED PRODUCT OF
. CHICAGO, ILL.60707
SIG 1 3 5 7 9 +30dB
2 3 CAL
RF
SWR
RF
DYNAMIKE RFGAIN D
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
C
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

ANT PA.SP. EXT.SP.
+POWER –
DATE OF 
MFG :JUNE 98 FCC ID:BBO3K229LTD
COBRA
MADE IN CHINA
SERIAL NO.:806135776
PRECISION ENGINEERED PRODUCT OF
COBRA ELECTRONICS CORP. CHICAGO, ILL.60707
Antennas
CB Antenna
Since the maximum allowable power output of
the transmitter is limited by the FCC, the antenna
is critical in affecting transmission distance. Only
a properly matched antenna system will allow
maximum power output. Cobra loaded type
antenna models are highly recommended for
most installations. Consult your Cobra dealer for
further details, or call 773.889.3087 and speak to
a Cobra representative.
Marine Installation
The transceiver will not operate at maximum effi-
ciency in a boat without a ground plate, (unless it
has a steel hull). Before attempting installation ,
consult your dealer for information regarding an
adequate grounding system and prevention of
electrolysis between fittings in the hull and water.
CB Antenna
Note
For optimum performance in
passenger cars the ideal anten-
na location is on the center of
the roof. Second choice is on the
center of the trunk.
Note
Because many newer trucks
feature fiberglass door skins,the
outside mirror must be ground-
ed to the chassis..
Note
3-way Combination Antennas
are also available which allow
operation of all three bands
(AM-FM & CB), using a single
antenna.However,this type of
antenna usually results in less
than normal transmit and
receive range when compared
to a standard-type “Single
Band” CB antenna. Call 773-
889-3087 for further informa-
tion.
6
1A standard antenna connector is provided
on the transceiver for easy connection.
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Ignition Noise Interference
Use of a mobile receiver at low signal levels is
normally limited by the presence of electrical
noise.The primary source of noise in automobiles
is from the alternator and ignition system.
Typically, when signal level is adequate, the back-
ground noise does not present a serious problem.
Also, when extremely low level signals are being
received, the transceiver may be operated with
the vehicle’s engine turned off.The unit requires
very little current and therefore will not signifi-
cantly discharge the vehicle’s battery.
Even though the Cobra 29 LTD Classic has an
automatic noise limiter, in some installations igni-
tion interference may be high enough to make
good communications impossible. Many possibili-
ties exist and variations between vehicles require
different solutions. Consult your COBRA dealer or
a 2-way radio technician for help in locating the
source of a severe noise.
7
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

The CB/PA button should be in the
CB position.
Operation
Turning On
8
Turning On
Make sure the power cord, antenna and micro-
phone are connected to their proper connectors
before starting.
2
DYNAMIKE RFGAIN D
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
B
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CAL
SWR
RF
1
Rotate the On/Off Volume knob clockwise to
a normal listening level.
RF
DYNAMIKE RFGAIN DELTATUNE S
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
BRT
DIM
CH9
NOR
R
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CAL
SWR
RF
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Operation
9
Setting Channel
Selector
Setting Channel Selector
Select one of forty channels and adjust
volume.The selected channel is indicated by
the LED readout directly above the channel
selector knob
1
RFGAIN DELTATUNE SWR CAL
SNB/
ANL
ANL
OFF
CB
PA
BRT
DIM
CH9
NOR
RX/TX
MAX MIN MAX
S
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

ERFGAIN DELTATUNE SWR CAL
SNB/
ANL
ANL
OFF
CB
PA
BRT
DIM
CH9
NOR
RX/TX
MMAX MIN MAX
S
Operation
Calibrate For
SWR (Standing
Wave Ratio)
10
Note
Antenna Indicator LED will
illuminate when TX if SWR is
high.
Switch to the CAL position.
2
1
Calibrate for SWR (Standing Wave Ratio)
SWR calibration is done to properly adjust the
length of the antenna and to monitor the quality
of the coaxial cable and all RF connections.
This calibration is critical in order to achieve opti-
mum performance.
DYNAMIKE RFGAIN D
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
B
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CAL
SWR
RF
Select channel 20.
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Operation
11
Note
Calibration must be made in an
open area (never in a garage).
Vehicle doors must be closed.
No one should be standing near
the antenna.(See your antenna
directions for more complete
information).
continued
Push and hold mic button.
3
PUSH &
HOLD
While holding mic
button adjust the
SWR CAL knob so the
meter needle swings
to the CAL ▼mark on
the meter (located on the right).
4
RFGAIN DELTATUNE SWR CAL
SNB/
ANL
ANL
OFF
CB
PA
BRT
DIM
CH9
NOR
RX/TX
MAX MIN MAX
S
SIG 1 3 5 7 9 +30dB
2 3 CALSWR
RF
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Operation
12
Note
The reading will be slightly high-
er on Channels 1 and 40 com-
pared to Channel 20.
Note
When switched to SWR position
the meter needle should ideally
be as far to the left as possible.
Anything over 3 is not accept-
able. A slight antenna height
adjustment (higher or lower)
may be required.Repeat relcali-
bration steps.
Repeat the same steps two through five on
Channel 1 and 40.This will check SWR for all
channels.
6
While still holding down the mic button, set
the S/RF SWR CAL switch to the SWR position,
to read the SWR reading.
5
DYNAMIKE RFGAIN D
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
B
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CAL
SWR
RF
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Operation
13
Rotate the On/Off Volume knob clockwise
the green RT/TX LED will be illuminated.
To Receive
1
RF
DYNAMIKE RFGAIN DELTATUNE S
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
BRT
DIM
CH9
NOR
R
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CAL
SWR
RF
To Receive
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

The S/FR-SWR-CAL switch must be in the
S/RF position to read the meter.
Operation
14
1
S-Meter
S-Meter
Swings proportionately to strength of incoming
signal when receiving.
Switch to NOR to select desired channel.
1
Selecting A
Channel
Selecting A Channel
IN DELTATUNE SWR CAL
S
A
BRT
DIM
CH9
NOR
RX/TX
MMAX
S
DYNAMIKE R
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
C
SQUELCHVOLUME
SIG 1 3 5 7 9 +30dB
2 3 CALSWR
RF
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Operation
15
NB-ANL/ANL/
OFF (Noise
Blanker/
Automatic
Noise Limiter)
Switch
Note
The RF noise blanker is very
effective in reducing repetitive
noises such as ignition interfer-
ence.
When switched to ANL the Automatic Noise
Limiter is activated.This helps reduce noise
created by the vehicle’s electronics.
When switched to NB/ANL position the RF
Noise Blanker is also activated, providing
increased noise filtration.
When switched to OFF position all noise
filtration will be turned off.
DYNAMIKE RFGAIN D
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
B
D
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CAL
SWR
RF
NB-ANL/ANL/OFF (Noise
Blanker/Automatic Noise Limiter) Switch
1
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Operation
16
Bright/Dim
Switch
Bright/Dim Switch
Switch to BRT or DIM to control brightness
of the channel indicator and multi-function
meter for day or nighttime driving.
IN DELTATUNE SWR CAL
S
A
BRT
DIM
CH9
NOR
RX/TX
MMAX
S
1
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Operation
17
RF Gain Control
RF Gain Control
The RF Gain is used to optimize reception in
strong or weak signal areas.
Note
The RF Gain is used to optimize
reception in weak signal areas.
Turn counterclockwise to reduce
gain.
Rotate the RF Gain knob counterclockwise
to reduce gain in strong signal areas. In weak
signal areas turn clockwise to increase gain.
DYNAMIKE RFGAIN DELTATUNE S
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
BRT
DIM
CH9
NOR
R
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CAL
SWR
RF
1
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Full clockwise rotation closes the gate
allowing only very strong signals to enter.
Setting Delta-Tune
Delta-Tune functions as a“fine tune”control
enabling you to capture a more readable signal,
as well as eliminate adjacent channel interference.
Setting Squelch
Squelch is the “control gate”for incoming signals.
Setting Delta-
Tune
18
Operation
1
1
Rotate Delta-Tune knob to the center posi-
tion for optimum tuning.
DYNAMIKE RFGAIN DELTATUNE SWR CAL
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
BRT
DIM
CH9
NOR
RX/TX
MIN MAX MIN MAX
SQUELCH
F
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CAL
SWR
RF
NOISE
WEAK SIGNALS
MEDIUM SIGNALS
STRONG SIGNALS

GATE CLOSED
Gate closed
Setting Squelch
DYNAMIKE RFGAIN DELTATUNE SWR CAL
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
BRT
DIM
CH9
NOR
RX/TX
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CAL
SWR
RF
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Full counterclockwise rotation opens the
“gate”allowing all signals in.
To achieve the Desired Squelch Setting (DSS),
turn the Squelch control counterclockwise
until you hear noise. Now turn the control
clockwise just until the noise stops. This is the
DSS setting.
19
Operation
2
3
NOISE
WEAK SIGNALS
MEDIUM SIGNALS
STRONG SIGNALS
NOISE
WEAK SIGNALS
MEDIUM SIGNALS
STRONG SIGNALS

G AT E  OPEN
NOISE
WEAK SIGNALS
MEDIUM SIGNALS
STRONG SIGNALS

NOISE
WEAK SIGNALS
MEDIUM SIGNALS
STRONG SIGNALS
G AT E
Gate open
Gate set to Desired
Squelch Setting (DSS)
DYNAMIKE RFGAIN DELTATUNE SWR CAL
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
BRT
DIM
CH9
NOR
RX/TX
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CAL
SWR
RF
DYNAMIKE RFGAIN DELTATUNE SWR CAL
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
BRT
DIM
CH9
NOR
RX/TX
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CAL
SWR
RF
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Setting Dynamike
This controls the microphone sensitivity
(outgoing audio level).
To Transmit
To Transmit
20
Setting
Dynamike
Caution!
Be sure the antenna is properly
connected to the radio before
transmitting. Prolonged trans-
mitting without an antenna, or
a poorly matched antenna,
could cause damage to the
transmitter.
Be sure to read the F.C.C. Rules
and Regulations included with
this unit before transmitting.
Operation
1
Select desired channel.
1
DYNAMIKE RFGAIN DELTATUNE SWR CAL
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
BRT
DIM
CH9
NOR
RX/TX
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CALSWR
Initially, set fully clockwise so that maxi-
mum voice volume is available. Dynamike
may have to be reduced in some conditions.
DYNAMIKE RFGAIN DELTATUNE SWR CAL
S/RF
SWR
CAL
NB/
ANL
ANL
OFF
CB
PA
BRT
DIM
CH9
NOR
RX/TX
MIN MAX MIN MAX
SQUELCH
OFF
VOLUME
SIG 1 3 5 7 9 +30dB
2 3 CAL
SWR
RF
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]
