PROGRAMMING GUIDE
1D/2D/OCR/DOTCODE READER - D760,D860,S760 AND S860
This document pertains to the following D760, D860, S760, S860:
Model
D760 Construction Orange
D760 Safety Green
D760 Utility Gray
Model
S760 Blue
S760 Green
S760 Red
S760 White
S760 Yellow
Model
S860 Black
Model
D860 Black

TABLE OF CONTENTS
COMPANION APP 3
RESETS 3
BLUETOOTH CONNECTION MODE 4
PREFIX/SUFFIX 5
VIBRATE/BEEP MODES 6
ACTIVE MODES 7
PRESENTATION MODES 8
HID KEYBOARD LANGUAGE SETTINGS 9-10
AUTOMATIC RECONNECTION 11
BLUETOOTH CONNECTION ROLES 12
DATA MODE - FOR SPP MODE ONLY 13
PROGRAMMING 14
OCR 15-24
1D SYMBOLOGIES
UPC/EAN 25-35
CODE 128 36
GS1-128 36
CODE 39 37-38
CONVERT CODE 39 TO CODE 32 (ITALIAN PHARMA CODE) 39
CODE 32 PREFIX 39
CODE 93 40
INTERLEAVED 2 OF 5 41
CODABAR 42-43
MSI 44-45
GS1 DATABAR 46-47
2D SYMBOLOGIES
PDF417 48
MICROPDF417 48
DATAMATRIX 48
MAXICODE 48
QR CODE 49
MICROQR 49
AZTEC 49
HAN XIN 49
DOTCODE 49
POSTAL CODES 50-51
SAMPLE BARCODES 52-53

3
COMPANION APP
Make sure the scanner is not connected to a host computer or device before scanning a command
barcode.
Factory Reset
Congures the scanner to factory defaults. The scanner powers o after scanning this barcode.
Scan QR code with mobile device to
download app.
Scan QR code with mobile device to
download app.
Set up your scanner with Socket Mobile Companion App.
• Easy to follow instructions for pairing scanners
• Check scanner status
• Check warranty and register scanners
Learn more about Application Mode.
RESETS
Pairing Reset
If the scanner is paired with a device, unpair it before trying to connect to a dierent device.
Step 1: Scan barcode (for serial number that begins 1931 and above only).
Or follow steps to manually reset scanner:
A. Power on the scanner.
B. Press and hold down the scan button.
C. Press and hold down the power button.
D. After you hear 3 beeps, release both buttons.
The scanner will unpair and automatically power o.
Step 2: Remove or forget the scanner from the Bluetooth list on the
host device.
The scanner is now discoverable.
Both steps above must be done to complete the unpairing.

4
BLUETOOTH CONNECTION MODE
Make sure the scanner is not connected to a host computer or device before scanning a command
barcode.
Scan command barcode(s) to congure the scanner.
Basic Mode (HID) (default)
(All host devices)
Congures the scanner to Human Interface Device (HID) mode. The scanner will be discoverable as a
keyboard to other Bluetooth devices.
Application Mode (MFi-SPP) for Apple Devices
*Required for Apple iOS applications developed with Socket Mobile SDK.
Application Mode (Auto Connect-SPP) for Windows or Android 8.0 and later
*Congures the scanner to Serial Port Prole.
Application Mode (SPP) for Windows or Android version 7.0 and lower
*Congures the scanner to Serial Port Prole (SPP).
*For compatible applications developed with Socket Mobile SDK: socketmobile.com/partners/app

5
You can congure the scanner to automatically add a prex and/or sux to each scan of data. Scanner is
allowed 1 prex and 2 suxes.
For custom prex and sux, contact [email protected].
Note: Scanning multiple commands in a single instance will overwrite (not append) the previous
command.
Sux – Carriage Return (default)
Congures the scanner to add a carriage return after decoded data.
Sux – Tab
Congures the scanner to add a tab after decoded data.
Sux – Carriage Return and Line Feed
Congures the scanner to add a carriage return and line feed after decoded data.
Data As Is
Congures the scanner to return only the decoded data (i.e., no prex or sux).
PREFIX/SUFFIX

Make sure the scanner is not connected to a host computer or device before scanning a command
barcode.
Vibrate “On” (default)
Enable the scanner to vibrate to indicate a successful scan.
Vibrate “O”
Disable the scanner from vibrating to indicate a successful scan.
Beep “On” (default)
Enable the scanner to vibrate to indicate a successful scan.
Beep “O”
Disable the scanner from beeping to indicate a successful scan.
VIBRATE/BEEP MODES
6

Scan one of the barcodes to recongure the scanner to remain powered on for a longer time.
These settings drain the battery faster. Please ensure the scanner is charged daily.
2 hours (default)
Scanner powers o in 2 hours when idle/inactive while connected and 5 minutes when disconnected.
Continuous Power for 4 hours
Congures the scanner to remain on for 4 hours.
Continuous Power for 8 hours
Congures the scanner to remain on for 8 hours.
Scanner Always On
Congures the scanner to never power o.
ACTIVE MODES
7

PRESENTATION MODES
Scan one of the barcodes to congure the scanner to automatically scan barcodes.
These settings drain the battery faster. Please ensure the scanner is charged daily.
Mobile Mode (default)
Reverts back to manual scan mode.
#FNB 41FBA50000#
Auto Mode (recommended)
Congures the scanner to switch to presentation mode when power is detected on the charging pins. The
scanner will remain on presentaion mode until the scan button is pressed to exit the mode.
#FNB 41FBA50003#
Detect Mode
Congures the scanner to switch to presentation mode when power is detected on the charging pins. The
automatic scan will continue until power is removed.
#FNB 41FBA50002#
Stand Mode
Scanner is permanently in presentation mode.
#FNB 41FBA50001#
Command barcode is for model D760 and S760 only.
8

9
Scan only when the scanner is in Basic Mode (HID prole).
These barcodes are to congure the scanner for dierent languages using Microsoft Windows keyboard
layout.
English (Default)
English UK
French
German
Italian
HID KEYBOARD LANGUAGE SETTINGS

HID KEYBOARD LANGUAGE SETTINGS
Japanese
Polish
Spanish
Swedish
ANSI Emulation
ANSI Emulation can be slower on Windows systems.
10

AUTOMATIC RECONNECTION
All Bluetooth Connection Modes are OK.
Important! After scanning this command barcode, power o and power on the scanner to make sure it is
congured properly.
Enable Automatic Reconnection from scanner (default)
Congure the scanner to automatically initiate a connection to the last paired computer/device after the
scanner is powered on.
Disable Automatic Reconnection from scanner
Congure the scanner to wait for a computer/device to initiate a Bluetooth connection after the scanner
is powered on.
11

BLUETOOTH CONNECTION ROLES
Advanced users only.
Basic Mode (HID) Keyboard
Changes a scanner in HID-Peripheral mode to HID-Keyboard mode.
For Mac OS, Apple iOS, and other smart devices.
Basic Mode (HID) Peripheral
Changes a scanner in HID-Keyboard mode to HID-Peripheral mode.
For some MS Windows or Android mobile devices.
Scan only with scanner in Application Mode (SPP).
Acceptor (default)
Congures the scanner to accept a Bluetooth connection puts the scanner in discoverable mode.
Initiator
Congures the scanner to initiate a connection to a computer/device with the Bluetooth Device Address
specied in the barcode.
The barcode must be formatted in Code 128 and contain the data #FNIaabbccddee# such that
aabbccddee is the Bluetooth Device Address of the computer/device you want to connect to the scanner.
You must create a custom barcode for each computer/device that you want to connect to the scanner.
You can use barcode generating software or website (e.g., http://barcode.tec-it.com)
12

DATA MODE-FOR SPP MODE ONLY
Advanced users only.
Packet Mode (default)
Congures the scanner to transmit decoded data in packet format.
Raw Mode - Android and Windows only
Congures the scanner to transmit decoded data in raw (unpacketed) format.
13

This chapter describes how to set up the scanner for OCR, 1D and 2D barcodes.
What is OCR?
OCR - Optical Character Recognition. OCR is a technology used to convert images
containing written text (i.e travel documents) into machine readable text data.
>>123456>>
>>>ABCDEF>>>
What is a 1D barcode?
Linear, 1 dimensional barcodes are a row of parallel lines of varying thickness. The information is stored in
the widths of the bars and spaces. 1D barcodes are used in retail products.
What is a 2D barcodes?
2D barcodes are a pattern of black and white blocks arranged in a square or rectangles.
Two dimensional barcodes can hold signicant amount of information and are more typically used than 1D
barcodes. 2D barcodes are used for manufacturing, warehousing, etc.
For command barcodes not available in the guide, contact [email protected].
After scanning a command barcode, power o and on the scanner to make sure it’s congured.
To enhance the speed of reading, disable all symbologies and enable the desired symbology only.
Disable All Symbologies
*No beep when scanning this command barcode
Note: Most computer monitors allow scanning the barcodes directly on the screen. When scanning
from the screen, be sure to set the document magnication to a level where you can see the barcode
clearly, and bars and/or spaces are not merging.
PROGRAMMING
14

Make sure the scanner is not connected to a host computer or device before scanning a command
barcode.
To enable or disable OCR-A, scan one of the following barcodes.
Enable OCR-A
Disable OCR-A (default)
OCR-A Variant
Font variant sets a processing algorithm and default character subset for the given font. To choose a
variant, scan one of the following barcodes. Selecting the most appropriate font variant optimizes
performance and accuracy.
Note: Enable OCR-A before setting this parameter. If disabling OCR-A, set the variant to its default
(OCR-A Full ASCII).
OCR-A Full ASCII (default)
supports the following characters:
!”#$()*+,-./0123456789<>ABCDEFGHIJKLMNOPQRSTUVWXYZ\^
OCR
15

OCR-A Reserved 1
supports the following characters:
$*+-./0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZ
OCR-A Reserved 2
supports the following characters:
$*+-./0123456789<>ABCDEFGHIJKLMNOPQRSTUVWXYZ
OCR-A Banking
supports the following characters:
-0123456789<>
OCR
16

To enable or disable OCR-B, scan one of the following barcodes.
Enable OCR-B
Disable OCR-B
OCR
17

OCR-B Variant
OCR-B has the following variants. Selecting the most appropriate font variant aects performance and
accuracy. For the best performance in travel document reading, x the target document and the decoder
in place of 7-9 inches (18-23 centimeters).
Note: Enable OCR-B before setting this parameter. If disabling OCR-B, set the variant to its default
(OCR-B Full ASCII).
OCR-B Full ASCII
supports the following characters:
!#$%()*+,-./0123456789<>ABCDEFGHIJKLMNOPQRSTUVWXYZ^|Ñ
OCR-B Banking
supports the following characters:
!#$%()*+,-./0123456789<>ABCDEFGHIJKLMNOPQRSTUVWXYZ^|Ñ
OCR-B Limited
supports the following characters:
+,-./0123456789<>ACENPSTVX
OCR-B ISBN 10-Digit Book Numbers
supports the following characters:
-0123456789>BCEINPSXz
18
OCR

OCR-B ISBN 10 or 13-Digit Book Numbers
supports the following characters:
-0123456789>BCEINPSXz
OCR-B Travel Document Version 1 (TD1)
3 Line ID Cards
supports the following characters:
-0123456789<ABCDEFGHIJKLMNOPQRSTUVWXYZ
OCR-B Travel Document Version 2 (TD2)
2 Line ID Cards
supports the following characters:
-0123456789<ABCDEFGHIJKLMNOPQRSTUVWXYZ
Travel Document 2 or 3 Line ID Cards Auto-Detect
supports the following characters:
!#$%()*+,-./0123456789<>ABCDEFGHIJKLMNOPQRSTUVWXYZ^|Ñ
19
OCR

OCR-B Passport
supports the following characters:
-0123456789<ABCDEFGHIJKLMNOPQRSTUVWXYZÑ
OCR-B Visa Type A
supports the following characters:
-0123456789<ABCDEFGHIJKLMNOPQRSTUVWXYZ
OCR-B Visa Type B
supports the following characters:
-0123456789<ABCDEFGHIJKLMNOPQRSTUVWXYZÑ
OCR-B ICAO Travel Documents (default)
This allows reading either TD1, TD2, Passport, Visa Type A, or Visa Type B without switching
between these options. It automatically recognizes the travel document read.
OCR
20
