Comelit HFX-700M KIT User manual

HANDS-FREEEXPANDABLE
VIDEOINTERCOMSYSTEM
,
OWNERSMANUAL
INSTALLATIONANDOPERATION
HFX-700MKIT

TABLEOFCONTENTS
Section1:UserArticle
1.Introduction
2.HFX-700MKIT
2.1.HFX-700MKITPartsIdentification
2.1.1.HFX-700MMainmonitor identification
2.1.2.HFX-700Mor EX-700D door camera identification
2.2.HFX-700MKITOperation
2.2.1.Visitor callsfrom door camera
2.2.2.Audio andvideomonitoring
2.2.3.
3.Expansionvideomonitor (EX-700H)
3.1.EX-700HIdentification
3.2.EX-700HOperation
3.2.1.Broadcast andintercomfunction
.Expansionaudio monitor (EX-700A)
4.1.EX-700A Identification
4.2.EX-700A Operation
4.2.1.Broadcast andintercomfunction
5.
Pushtotalkmode(similartowalky-talky)
4
Optional videoinput converter(EX-VIN)
5.1.EX-VINIdentification
5.2.EX-VINOperation
1
2
2
2
3
4
4
4
4
5
5
6
6
7
7
8
8
9
9
9

Section2:InstallationArticle
1.System layout
2.
3.HFX-700Minstallation
3.1.Examinepackagecontents
3.2.Install mainmonitor
3.3.Install door camera
3.4.HFX-700Mwiringandsetting
3.5.Jumperfunctiononmainmonitor
3.5.1.JP1,
3.5.2.JP2,
3.5.3.JP3,
3.6.Jumperfunctionondoor camera
3.6.1.JP1,
3.6.2.JP2,
. Expansionvideomonitor(EX-700H) installation
4.1.Examinepackagecontents
4.2.Install expansionvideomonitor
4.3.EX-700Hwiringandsetting
4.4.JumperfunctiononEX-700H
4.4.1.JP1,
4.4.2.JP2,
5.Expansionaudio monitor(EX-700A)installation
5.1.Examinepackagecontents
5.2.Install expansionaudio monitor
5.3.EX-700Awiringandsetting
5.4.JumperfunctiononEX-700A
5.4.1.JP2,
6.Expansiondoor camera (EX-700D)installation
6.1.Examinepackagecontents
6.2.Install expansiondoor camera
6.3.EX-700Dwiringandsetting
7.Metal door camerahousing(EX-700V)installation
7.1.Examinepackagecontents
7.2.Assembly procedure
8.
8.1.
8.2.
9.Technical specifications
10.Troubleshooting
Readbeforeinstallation
videodisplay optionduringdoor releaseoperation
door statusreportoptions
external doorbell triggeroptions
door control optionsand
CCDon/offduringtheoutput
light senor options
4
videodisplay optionduringdoor releaseoperation
door statusreportoptions
door statusreportoptions
Optional videoinput converter(EX-VIN)installation
Install videoinputconverters
EX-VINwiringandsetting
10
13
14
14
14
15
15
16
16
16
16
17
17
17
18
18
19
19
19
19
19
20
20
20
21
21
21
22
22
22
22
23
23
24
25
25
25
26
28
Section3:Appendix

1
1.Introduction
Thankyoufor purchasingtheHands-Free expandableVideoIntercom
SystemHFX-700M.
For moreinformationregardingthecompletelineofourproducts,
pleasevisit www.comelitusa.com
Thisintercom system uses2-wireinstallationandallowsyoutoidentify
andcommunicatewithcallersat thedoor, fromthesecurity and
convenienceofanyroom inyourhomeor office. Visitorsactivatethe
systemby pressinga call buttonontheoutdoor camera,whichsounds
a doorbellchimeaswell asturningontheinsidevideomonitor.
Atwo-way intercom thenletsyouspeakwithvisitorsafterfirst visually
identifyingthem.
It consistsofa monitor stationandanoutdoor doorbell/camera unit.
Thisunit iscapableofexpandinguptoa total of4indoor monitorsand
2door cameras. Expansionmonitorsavailablefor thissystem comein
twomodels,video(EX-700H) or Audio only (EX-700A).
Section1:UserArticle

2.HFX-700MKIT
2.1.HFX-700MKITPartsIdentification
2
8 9 10117
3
4
6
5
12
13
14
15
16
178mm
(7.0)
36mm
(1.42) 118mm
(4.65)
1.3.5" Color TFTScreen
2.Speaker
3.InuseLED
4.Monitor LED
5.Intercom LED
6.
7.Microphone
8.Cut-offbutton()
9.Intercom button()
10. Monitoringbutton()
11. Door releasebutton()
12. Powerswitch
13. Brightness tuner()
14. Sharpnesstuner()
15. Bell Volumetuner()
16. SpeakerVolumetuner()
17.
18.
19.
CommunicationLED
JP1, videodisplay optionduringdoor releaseoperation
Enablevideodisplay (JP1left)(default)
Disablevideodisplay (JP1right)
JP2, door statusreportoption
Bell toneindication(JP2left)(default)
LEDlightonDoor OpenButton(JP2right)
JP3, external doorbell triggeroption
N.O. dry contact(default)(allowbypasscurrent of24VDC/1A)
12VDC150mAcurrent output
2
[Mainmonitor]
2.1.1HFX-700MMainmonitoridentification
2
17
18
19

130mm
(5.12)"
36mm
(1.42)"
1.WhiteLED Illumination
2.1/3" Color CCD
3.Microphone
4.Speaker
5.Call button
6.Screwcover
7.
(-6degrees, 0degrees,8degrees, 16degrees)
8.Wiretodoor strike
9.WiretomainMonitor
10.
11.
CCDverticalviewangleadjustmentdial
JP2(automaticLEDlight supplement option)
JP1, lockcontrol outputoptionandCCDon/offduringtheoutput
98mm
(3.86)"
2
3
5
4
6
1
3
JP1
JP2
1 2 3 4
10
11
7
8 9
[DoorStation]
N.O. dry contact output; CCDon.(default)(24VDC/1A
bypass current)
12VDC/300mAcurrent output; CCDoffto. (tosavepower)
2.1.2.HFX-700MorEX-700DDoorCameraidentification

2.2.1.VisitorCallsfromDoorCamera
A.WhentheCall buttononthecamera ispressed, All monitorsonthe
systemwill ringwitha chimesoundandall monitorswillbeactivated.
B.Afterthecall, ifnothingonthemonitor ispressed,thesystem will time
out after30seconds. Ifthemonitor buttonispressed,thesystem
will stay activefor 90seconds.
C.Youareabletoterminatetheactivityonthemonitor atany timeby
pressingtheCut-offbutton.
D.Pressdoor releasebuttonfrommonitor canreleaseremotedoor
strikeat door camera.
Operatingthevideointercomsystem consistsofrespondingtovisitor
callsfromdoor camera, releasingadoor strikefrom indoor monitor;
audioandvideomonitoringfromany indoor monitor; voicebroadcast
from onemonitor toall others; engageintercom functionaftervoice
broadcast.
2.2.2.AudioandVideomonitoring
A.Pressingthemonitor buttonwill turnontheaudioandvideofrom
door camera.
B.Ifthereisa seconddoor cameraonthissystem, pressingtheMonitor
buttonagainwill scroll theimagetothesecondexpansiondoor
camera.
Atanytimeifyouwishtoterminatethemonitoring,presstheCut-off
buttontoterminatethesystem.
C.
4
2.2.HFX-700MKITOperation
2.2.3. (similartowalky-talky)Pushtotalkmode
A. onmeansvoiceisfree togooutfrom monitor to
door camera.
CommunicationLED
B.Duringtheconversation,presstheMonitor Buttonfor 2secondsto
switchtopush-to-talk mode.Inthismode, pressingtheMonitor Button
(CommunicationLEDwillturnon)willactivatetheone-way voice
communicationtothedoor camera; releasingtheMonitor Buttonand
(CommunicationLEDturnsoff )allowfor one-way voicecommunication
tocomeinfrom thedoor camera tothemonitor.
C.Thisfunctioncanbeuseful whentheenvironment at door cameraside
becomestoo noisy.

3.ExpansionVideoMonitor(EX-700H)
3.1.EX-700HIdentification
2
8 9 10 117
3
4
6
5
12
13
14
15
16
178mm
(7.0)
36mm
(1.42) 118mm
(4.65)
1.3.5" Color TFTScreen
2.Speaker
3.InuseLED
4.Monitor LED
5.Intercom LED
6.
7.Microphone
8.Cut-offbutton()
9.Intercom button()
10. Monitoringbutton()
11. Door releasebutton()
12. Powerswitch
13. Brightness tuner()
14. Sharpnesstuner()
15. Bell Volumetuner()
16. SpeakerVolumetuner()
17.
18.
CommunicationLED
JP1, videodisplay optionduringdoor releaseoperation
Enablevideodisplay (JP1left)(default)
Disablevideodisplay (JP1right)
JP2, door statusreportoption
Bell toneindication(JP2left)(default)
LEDlightonDoor OpenButton(JP2right)
5
[EX-700H]
1
17
18

Operatesthesameasthemainmonitor unit (Refertopage4).
6
3.2.EX-700HOperation
Mainmonitor
Doorcamera
Call button
Cut-off button
Intercombutton
Monitoringbutton
Doorreleasebutton
3.2.1.Broadcastandintercomfunction
A.Whensystem consistsofmainmonitor andexpansionmonitor andan
outdoor doorbell/camera unit,thesystemcanprovideintercom function.
B.Presstheintercombuttonfrom any monitor, allothermonitorswill
reactbymakingbellsound. Atthesametime,hostcanspeakand
broadcastvoicemessagetoall othermonitors.
C.Thebroadcast modecanlast for 20 seconds. Duringthe20seconds,
any othermonitor cananswerthecall by havingtheintercom button
pressedinordertoengagetheintercom communication. Oncethe
intercomcommunicationhasbeenestablished,talk timeisfor a
maximum of90seconds.Thisfunctionprovidesaudiointercom
communicationonly, monitorswill notshowany video.
D.Atanytimeifyouwishtoterminatethemonitoring,presstheCut-off
buttontoterminatethesystem.
Expansionmonitor
Cut-off button
Intercombutton
Monitoringbutton
Doorreleasebutton

4.ExpansionAudioMonitor(EX-700A)
4.1.EX-700AIdentification
1.Speaker
2.InuseLED
3.Monitor LED
4.Intercom LED
5.
6.Microphone
7.Cut-offbutton()
8.Intercom button()
9.Monitoringbutton()
10. Door releasebutton()
11. Powerswitch
12. Bell Volumetuner()
13. SpeakerVolumetuner()
14.
CommunicationLED
JP2, door statusreportoption
Bell toneindication(JP2left)(default)
LEDlightonDoor OpenButton(JP2right)
7
1
7 8 9 106
2
3
5
4
11 12
13
178mm
(7.0)
36mm
(1.42) 118mm
(4.65)
[EX-700A]
14

A.Operatesthesameasthemainmonitor unit (Refertopage13).
B.EX-700A only audiofunction, not videofunction.
4.2.EX-700AOperation
Mainmonitor
Doorcamera
Call button
Cut-off button
Intercombutton
Monitoringbutton
Doorreleasebutton
4.2.1.Broadcastandintercomfunction
A.Whensystem consistsofmainmonitor andexpansionaudio monitor
andanoutdoor doorbell/camera unit,thesystem canprovideintercom
function.
B.Presstheintercombuttonfrom anymonitor, all othermonitorswill
react by makingbell sound. At thesametime, host canspeakand
broadcastvoicemessagetoall othermonitors.
C.Thebroadcast modecanlast for 20seconds. Duringthe20 seconds,
any othermonitor cananswerthecall by havingtheintercom button
pressedinordertoengagetheintercom communication. Oncethe
intercomcommunicationhasbeenestablished,talk timeisfor a
maximum of90seconds.Thisfunctionprovidesaudiointercom
communicationonly.
D.Atanytimeifyouwishtoterminatethemonitoring,presstheCut-off
buttontoterminatethesystem.
Expansionnon-videomonitor
Cut-off button
Intercombutton
Monitoringbutton
Doorreleasebutton
8

5.
5.1.
Optionalvideoinputconverter(EX-VIN)
EX-VINIdentification
1.
2.
3.
PowerLED
The2-wireterminalsfor connectingot themainmonitor
BNCconnector for external camera videoinput
32
9
5.2.EX-VINOperation
1
AA.EX-VINconvertsvideosignal onthe2-wiretransmissionformat ofthe
system.
B.Pressthemonitor buttonfromany monitor tosee thecamera from
themaindoor camera, pressit againtoscroll totheexternal camera
deviceconnectedtotheEX-VIN.
C.Pressingthecut-offbuttontoexitthemonitoringmode.
*TheEX-VINdoesnotprovidepowertotheexternal CCTVCamera.

10
Section2:InstallationArticle
1.Systemlayout
System layout1:
HFX-700MKIT
EX-700D
EX-700H orEX-700A
NOTE:thesystem iscapableofexpandinguptoatotalof4monitors
(1mainvideomonitor +3expansionvideomonitorsor 3expansionaudio
monitors(any mixofvideooraudio)and2door cameras.
Maximumwiringdistance
(usingdrycontact lockcontrol at doorbell camera)
Signalwires
}Signalwires
Wireassignment
AWG#22
parallelwires
AWG#18
parallelwires
Wiretype
CAT-5
(AWG#24)
AMax BMax
100m
(328 feet) 100m (328 feet)
100m
(328 feet)
100m
(328 feet)
100m
(328 feet)
100m
(328 feet)
Signalwires
Maximumwiringdistance
(usingthe12VDC/300mAlockcontrol at doorbell camera)
Signalwires
Wireassignment
AWG#22
parallelwires
AWG#18
parallelwires
Wiretype AMax BMax
100m
(328 feet) 100m
(328 feet)
Signalwires
50m
(164 feet) 50m (164 feet)
NOTE :CAT-5isnotrecommendedfor thistypeofinstallation.
AMax
AMax BMax BMax BMax

Maximumwiringdistance
(usingthe12VDC/300mAlockcontrol at doorbell camera)
Signalwires
Wireassignment
AWG#22
parallelwires
AWG#18
parallelwires
Wiretype AMax BMax CMax
100m
(328 feet) 100m
(328 feet)
100m
(328 feet)
100m
(328 feet)
Signalwires
50m
(164 feet) 50m (164 feet)
NOTE :CAT-5isnotrecommendedfor thistypeofinstallation.
System layout2:
NOTE1:ThewiringHUBcanamplify anddistributethe2-wiresignal
amongthemainmonitor andsub-monitors.
NOTE2:thesystem iscapableofexpandinguptoa total of5monitors
with1EX-HUB or8total monitorswith2EX-HUBsconnectedinonesystem.
Maximumwiringdistance
(usingdrycontactlockcontrolat doorbell camera)
Signalwires
}Signalwires
Wireassignment
AWG#22
parallelwires
AWG#18
parallelwires
Wiretype
CAT-5
(AWG#24)
AMax BMax CMax
100m
(328 feet) 100m (328 feet) 100m (328 feet)
100m
(328 feet)
100m
(328 feet)
100m
(328 feet)
100m
(328 feet)
100m
(328 feet)
100m
(328 feet)
Signalwires
11

EX-700Hor EX-700A
HFX-700M EX-700D
POWERLED
POWER
IN
OUT1
OUT2
OUT3
OUT4
EX-HUB
EX-700Hor EX-700A
EX-700Hor EX-700A
NOTE1:OUT4 can also be
used toconnect to aexpansion
monitor.
NOTE2:wiringdistance<300ft.
CMax
POWERLED
POWER
IN
OUT1
OUT2
OUT3
OUT4
EX-HUB
CMax
AMax
AMax
BMax
CMax
12

ViewAngle:Properheight:
Theproperheight ofmonitor or door camerais160~170cm(63"~67")
fromtheground. Thismayvaryoneachinstallation. Viewrangeshould
beactively testedbeforecomplete.
Viewingwindowofdoor cameraisabout 70cm up-n-down, and100cm
left-n-right.
2.Readbeforeinstallation
13
NOTE1:Wiringdistance
NOTE2:theinstallationenvironment
170cm
(66.9)"
50cm(19.7)" 50cm(19.7)"
70cm
(27.6)" 100cm (39.3)"
Mainmonitor
165cm
(64.9)"
Frommainmonitor todoorcamera:
Maximum of328feetwithAWG18normal2-wireparallel wiresor CAT-5
cable.
Frommonitortomonitor(everysection):
Maximum of328feetwithAWG22normal 2-wireparallelwiresor CAT-5
cable.
Maximum of164feetwithAWG22normal 2-wireparallelwires.
Doorcamera
Pleaseavoidinstallationinanenclosed
environment asthismay causefeedback.
Pleaseavoidinstallationindirect sunlight
asthiscancauseablurry pictureor dark
shadowsonsubjectsfacingthecamera.
Pleaseavoidwireinstallationnearother
poweror signal linesandavoidplacing
unitsclosetohighpowerappliancesas
thismay causeaudio/videointerference.

A.Fastenthewall mount bracketusingtheprovidedhardware.
B.Fastenwiresonterminalsaccordingly (Referto3.4).
C.Select jumpersfor desiredfunction(Referto3.5).
D.Plug-inpinwiresandmount themonitor unit onbracket.
14
3.2.Installmainmonitor
Donotplug inthe
poweratthisstage.Wall mountbracketMonitor
3.HFX-700Minstallation
3.1.Examine package contents
Doorcamera X1X1 Mainmonitor
X1
Wall mountbracket
PT1
PT2
DG1
DG2
OUT+
OUT-
DR2
DR1
POWER
<+>
<->
X1
Manual
Adaptor
X1 X4
Whitewall
mountscrews
HANDS-FREEEXPANDABLE
VIDEOINTERCOMSYSTEM
,
OWNERSMANUAL
INSTALLATIONANDOPERATION
Screws wrench
X1
X4
Flatheadscrews
NOTE: Examinethefollowingcontentsofthepackage.

15
A.Openthehiddenlatch, andunscrewtoremovedoor camera unitfrom
bracket.
B.Fastenwall mountbracket tothesurfacewheretheunitwill beinstalled.
C.Fastenwiresonterminalsandselectjumpersfor desiredfunction
(Referto3.6).
D.Mount door camera unitbackonthebracketandsecuretheassembly
screw.
3.3.Installdoorcamera
Doorcamera Bracket
Pull outscrewcover
toaccess the screw
Screws wrench
PT1
PT2
DG1
DG2
OUT+
OUT-
DR2
DR1
POWER
<+>
<->
JP1
JP2
12 3 4
Mainmonitor
Wiring terminal
Red
Black
1
2
4
5
doorcamera
Wiringterminal
3
6
7
8
9
3.4.HFX-700Mwiringandsetting
A.Wirethesystem fromterminal toterminal accordingly.
1
2
3
4
5
6
7
8
9
Connecttoa N.C. magneticswitchsensor for
door statusdetection.
Triggera N.O. externalchimeor strobelight whichissynchronized
withdoor bell trigger.
Terminalsfor expansionmonitor(w/polarity)
Terminalsfor the2nddoorbell camera(EX-700D)or EX-VIN(nopolarity)
Terminalsfor the1stdoorbell camera (EX-700D)or EX-VIN(nopolarity)
Terminalsfor poweradapter
Terminalstomainmonitor (nopolarity)
Terminalsfor door strike
ElectricLock

16
3.5.2.JP2, doorstatusreport options
DG1
DG2
Externalchime
POWER
AC24Vor
DC24V1A
[Figure 1]
DG1
DG2
Externalchime
[Figure2]
3.5. Jumperfunction on mainmonitor
JP1
JP2
JP3
3.5.1.JP1, video display option during doorrelease operation
A.DG1/DG2triggera N.O. devicetosynchronizewithdoorbell trigger
andreact asJP3options. Wrongsettingmay causedamagetothe
equipment.
B.DG1(+)andDG2(-) havepolarity.
C.JP3onleft()for N.O. dry contact (default)(allowbypasscurrentof
24VDC/1A)(figure1).
D.JP3onright()for 12VDC150mAcurrent output(figure2).
A.Enablevideodisplay (JP1left )(default)ifdoor releaseisdry contact
output.
B.Disablevideodisplay (JP1right)ifdoor releaseis12VDC/300mA
direct currentoutput
A.PT1/PT2connecta N.C.switchsensor todetectdoor statusandreactas
JP2options
B.Bell toneindication(JP2left )(default)
C.LED lightonDoor OpenButton(JP2right)
3.5.3.JP3, externaldoorbell triggeroptions

EachDoor Cameraonthesystemisabletooperateandreleaseone
electriclock.Ona full system with2door cameras, theuserisableto
releaseuptotwoelectriclocks. Thesystem canonly releaseoneelectric
lockat atime,dependingonwhichdoor camerathecall originatedfrom.
Therearetwodoor releasewiringoptionsthat work withtheVideo
Intercom System.
Thesystem caneitherprovidea normallyopendry contact(figure1), or
canbeconfiguredtogivepower(12VDC300mA)straighttoanelectric
lockthat iswithinthepowerrequirements(figure2).Ifyouareusing
powerfrom thesystem (figure2), It isnecessary touseanelectriclock
that requireslessthan300mAofpowertoengagethestrike.
Figure 1:DoorReleaseOption1(Additional powersupply)
17
Figure 2:DoorReleaseOption2(Usingpower fromthesystem)
ElectricLock
PowerforLock
Door camera
12/24VDC
1AmpMax ElectricLock
JP1
JP2
12 3 4
Door camera
[Figure 1] [Figure 2]
JP1
3.6. Jumperfunctionondoorcamera
3.6.1.JP1,doorcontroloptionsandCCDon/off duringtheoutput
JP2
3.6.2.JP2,lightsenoroptions
A.Factory settingisleft()whichenablesautomaticLEDilluminationat
inlowlightingconditions.
B.Select andplugJP2toitsright()todisableLEDilluminationofthe
doorbell camera at all times.
NOTE1: Whenjumpersettingisontheleft()(factorysetting), the
DOORRELEASEterminalsprovideasN.O. dry contact, withnopolarity
allowingmaximum by-pass current ofAC24Vor DC24V1A.
NOTE2: Thisoptionwill keepthevideoonduringthereleaseofthestrike.
NOTE1: Whenjumpersettingisontheright(), theDOORRELEASE
terminalsprovidecurrentoutputofmaximum 12VDC/300mA.
NOTE2: Thisoptionwill cutCCDpowerduringtheoperationandthere
will bea momentarylossofvideouponreleaseofthestrike.
