COMPANION Pro:nano X2 User manual

COOKING SYSTEM
Part No: COMP10289
IMPORTANT
• Important. Read these instructions for use carefully. Familiarise yourself with
the appliance before connecting it to its gas container. Keep these instructions
for future reference
• This appliance shall only be used with disposable 73% butane / 27% propane
only cartridges certified to EN417, DOT2P, UN2037
• IT MAY BE HAZARDOUS TO ATTEMPT TO FIT OTHER TYPES OF GAS
CONTAINERS
• USE OUTDOORS ONLY
• CAUTION: accessible parts may be very hot. Keep young children away.
SAFETY INSTRUCTIONS:
• Keep storage container away from stove when it is in use
• When being stored the appliance must be disconnected from the gas cylinder and
be stored separately
• DO NOT place stove inside storage container until it is cool to touch
• Is suitable for camping use ONLY
• Shall NOT be exposed to moisture or rain
• Do not modify this appliance
• Check that seals between the appliance and the gas container are in place and in
good condition before connecting the gas container.
• Do no use this appliance if it has damaged or worn seals
• Do not use this appliance if it is leaking, damaged or does not operate properly
• Only use the hose assembly as supplied with this appliance for connection to the
cylinder – DO NOT USE ADAPTORS
• This appliance must only be serviced by an authorized person
• DO NOT use multiple appliances to heat a single utensil
• Always operate the stove a minimum of 800mm away from flammable materials,
walls and ceiling on a flat level surface
• Only use pot supplied with appliance for direct connection or if using trivet ensure
that the a maximum pot size of 130mm in diameter is used
• Always use oven mitts or oven gloves when handling the stove after use
• DO NOT operate the stove below ground level or in areas where unburnt gas
could build up
• DO NOT move the stove when it is in use
• Clean the stove after use when it has cooled
• After use, turn the gas cylinder off, wait for the flame to go out
• Store the gas cartridges outdoors in a well -ventilated area or in a storage area
• compliant with AS1596
• NEVER assemble or operate the stove on unstable or uneven ground
• Always operate in well-ventilated areas
• To be used as a cooking appliance only, not to be used as a heater or modified for
any other reason
OWNERS MANUAL
CARBON MONOXIDE HAZARD
USE ONLY IN WELL VENTILATED AREAS.
CARBON MONOXIDE HAZARD USING THIS APPLIANCE IN AN ENCLOSED SPACE MAY
CAUSE DEATH. DO NOT USE IN CARAVANS, TENTS, MARINE CRAFT, CARS, MOBILE
HOMES OR SIMILAR LOCATIONS.
IF YOU SMELL GAS:
• If there is a leak from your appliance (smell of gas) and you cannot stop the gas
flow, remove the appliance to a well-ventilated location away from any ignition
source. Check for leaks using soapy water. Do not try to detect leaks using a flame
• Coat all connections with soapy water, if bubbles appear, remove cartridge and
re-attach before testing again
• If gas leak continues, contact your local supplier immediately
• Inspect the stove regularly for any signs or wear, leaks or incorrect operation
• If symptoms such as flaring burner, issues with lighting, leaks from seals or
problems with gas control are identified, do not attempt to repair, return to your
authorised stockist for service and maintenance
• This appliance must only be serviced by an authorized person
• When changing gas cartridges, ensure this is done outside in a well-ventilated
place, free from people, animals and ignition sources such as naked flames, pilot
lights and electrical equipment with heaters or elements
• This stove is not intended for use by young children or an infirm person unless
they have been adequately supervised by a responsible person to ensure that they
can use the stove safely. Young children should be supervised to ensure that they
do not play with the stove.
SAFETY INSTRUCTIONS
This appliance must only be used in an
above ground open air situation with
natural ventilation, without stagnant areas,
where gas leakage is rapidly dispersed by
wind and natural convection.
Any enclosure in which the appliance
is used should comply with one of the
following:
(A) An enclosure with walls on all sides,
but with no overhead cover.
(B) Within a partial enclosure that
includes an overhead cover and no
more than two walls.
(C) Within a partial enclosure that includes
an overhead cover and more than two
walls, the following must apply:
(1) At least 25% of the total wall area is
completely open.
(2) 30% or more in total of the remaining
wall side, back and front wall areas is
open and unrestricted.
(3) In the case of balconies, 20% or more
of the total wall area must remain
open and unrestricted.
1
1
1
2
2
A
B
C
PACKING AWAY:
IMPORTANT - Allow all parts of the appliance
to be completely cool before packing away
1. Remove cartridge support and fold in legs
2. Remove gas cartridge from cooker
2
3
4
CARE INSTRUCTIONS:
• Using warm soapy water with a mild detergent wipe down all surfaces, taking
care not to allow water to enter the burner outlet or aeration holes located on
the burner tube
• DO NOT submerge the stove in a sink or bowl
• DO NOT use abrasive cleaners or bleach
• Ensure the stove is clean and dry before storing
MAINTENANCE, SERVICE & STORAGE:
• If when in use, the burner flame is unstable, changing colour from yellow or
blue, or if it has a distinct smell, it is important that the stove be taken to your
local authorised gas appliance repairer for inspection
• Periodically check the gas control is tight and has no leaks, follow the testing
for leaks procedure
• For further information or assistance, please contact our Sales Department
For warranty and technical support please visit:
www.companionleisure.com.au
or call 1300 555 197
3. Invert pot and slide cooker inside
4. Insert pot trivot, with legs folded into pot,
attach lid, lock in place and store
Note: Gas cartridge can also be stored inside
pot depending on size. It is recommended to
use 100g or 220g gas cartridge with cooker
COM4985_COMP10289_Pro Nano Gravity Stove_MANUAL-GS.indd 1 13/10/2016 12:36 PM

1 3a 6b
2a 3b 6c
2b 4 6d
2c 5a 6e
5b 6f
Distributed by
Companion Brands
Bundoora VIC 3083
www.companionbrands.com.au
COM4985
ASSEMBLY
1. Remove cooker and components from pot
2. Attach base stand to gas cartridge
(a) Open stand as shown
(b) Attach to base of cartridge, locating
rim in the groves of stand
(c) Push legs in a clockwise direction until
the lock in place
3. Attach Cooker to Cartridge
(a) Unfold gas control from its stored position
and check that it is in the “Off” position
(b) Locate cooker on the cartridge and rotate
in a “clockwise” direction until it seals
(c) Check for any gas leaks before use using
a leak detecting agent or soapy water –
Never use a Flame
Note: It is suggested to use
Companion gas leak detector
spray on all connections prior
to operation
4. Attach Pot
(a) Locate pot on cooker, lining up the
securing tabs and turn in a “Clockwise”
direction until the pot is secured
5. Attach Pot Stand
(a) Unfold trivet legs but do not lock in place
(b) Locate the legs on the edge of the cooker
and lock in position
6. Operation
(a) Locate appliance on a stable and even
surface
(b) Turn the gas control in an “Counter-
Clockwise” direction for ½ turn
(c) Press the Piezo until the burner lights
Note: If Burner does not ignite, turn
the gas supply off and wait for excess
gas to disburse before repeating the
lighting process
(d) Adjust the flame by using the gas control
(f) Clockwise to decrease the flame and / or
extinguish the burner
Note: Once is burner is extinguished allow
the appliance to cool before moving
(e) Counter Clockwise to increase the flame
MODEL: COMP10289
INJECTOR: 0.19 mm
CONSUMPTION: 4.0 MJ/Hr - 82g/Hr
CERTIFICATE: 86396
