Conlan C1000 User manual

Codetastatur
C1000
Mykey - Art. Nr: 480000 (sort), 480001 (hvid)
Classic - Art. Nr: 482000 (sort), 482001 (hvid)
User manual
C1000_usermanual_ENGjan20

2
Table of contents
1. Introduction
2. Installation
3. Programming users
3.1 User positions
3.2 Programming user codes
3.3 Programming codes for
special functions
3.4 Smart reading
4. CongurationofC1000
4.1 Service code
 4.2 Congurationoverview 
4.3 Change the Master code
4.4 Change the Service code
4.5 LED Indications
4.6 Outputs
4.7 Special settings
5. Blocking
6. Manual reset
7. Technicalspecications
8. Connection examples
page 3
page 3
page 4
page 4
page 4
page 5
page 6
page 7
page 7
page 7
page 7
page 8
page 8
page 9
page 10
page 11
page 11
page 11
page 12

3
1. Introduction
C1000isaexiblekeypadandMifarereaderinoneunitformanydierent
applications.
InstandbytheyellowLEDislit(● ○ ○)
BycorrectcodetheyellowandthegreenLEDlights(●● ○)
By incorrect code the red LED is lit (○ ○ ●)
C1000hasabuzzerforindicatingwhilekeying,correctcode,incorrectetc.and2tran-
sistor outputs, independant from each other, so the C1000 can give access by code.
The C1000 is a stand alone unit, the can be programmed directly by Master code and
Service code.
2. Installation
Mountthereaderonaevensurface.(usethefollowingdrilltemplateforpreciset-
ting).
Connectthewirestopowersupply,doorstrike,assemblyboardetc.
Colour scheme
Red: 9 - 25V DC /30mA
Black: 0V GND
Yellow: Output2(opencollector,max.500mA)0Vactive
White: Output 1 (open collector, max. 500mA) 0V active
Orange: External controlling red LED, 0V active
Green: External controlling green LED, 0V active
Blue: REX, 0V active
Brown: Highsecurity/externalbuzzer
Note: Right after applying the voltage all the LED’s lights and the buzzer sounds
do nottouchthereaderuntilltheyellowLEDlightsandthebuzzerissilent.
See connection examples on the last page.

3. Programming users
Programming the C1000 is simple and easy to understand.
3.1 User positions
C1000has200positionsforcodes.Thepositionsaredividedasfollowing:
User position Function
1 - 100 Activates output 2 (the code in position 1 is 1234 - default)
101 - 150 Activates output 1
151 - 190 Activates output 1 and 2
191 - 200 Reserved for special functions
3.2 Programming user codes
The Master code is used to program/change/delete the users. By default the Master
code is 4711.
LED indication: No light: ○Light: ●Flash: * Clearbuer:
New users
(4711 - standard) ○ ● ○ ●● ○ ●● ○  ○ ● ○
To program more users, continue from “key in the user position” or press to
exit. ● ○ ○
Changeing user codes
It’sthesameprocedureasprogrammingnewusers,justoverwritetheuserpositions.
#
Key in the
Master code #
Key in the
user position #
Key in the
user code
#

4

5
Delete specic users
(4711 - standard) ○ ● ○ ●● ○ ○ ● ○ ● ○ ○
Delete all users
(4711 - standard) ○ ● ○ ○ ○ ●
○ ●
● ○ ○
3.4 Programming codes/Mifare tags for special functions
Programming the codes is described in 3.2. This entry activates the output(s) for 5 sec-
onds (factory setting). Only 1 user can enter at the time.
Programming the same user twice
Byprogrammingthesamecodeonthesamepositiontwicetogglestheoutput.
(Ie. the code is entered to unlock the door and entered to lock it again).
Programming the same user 3 times
By programming the same code on the same position 3 times, the output is
designatedasswitchononly.
(Ie. the door is permanently unlocked when the code is entered).
Programming the same user 4 times
By programming the same code on the same position 4 times, the output is
designatedasswitchoonly.
(Ie. the door is only locked when the code is entered).
#
Key in the
Master code #
Key in the
user position ##
#
Key in the
Master code #
Key in
2500 #

6
3.5 Smart reading
Thispositionmakesitpossibletoprogramcodesquickerwithoutenteringnewposi-
tions. Key in a position and it counts automatically to the next position. Codes can be
programmedalternativelyasyouseet.
○ ● ○ *● ○ * ○ ○ For more
codes/tags
repeat from
here
Note:Thisprogrammingmodeoverwritesexistingpositions.
#
Key in the
Master code #
Key in
05 #
Key in the start-
ing position #
Key in the code
orshowtag

7
4.CongurationofC1000
4.1 The Service code
The Service code is used for C1000’s advanced settings such as changing the Master
code,Servicecode,LEDindicationsandmuchmore.Theoverviewofthesettingsand
the factory settings can be seen in 4.2 Conguration overview.
The Service code is 12347890 (factory setting).
Note: Before the Service code can be used the voltage must be turned OFF and
ON (the Service code can now be entered within 10 seconds).
After entering the Service code the reader is in programming mode (the green LED
lights). Each time a setting is made the C1000 goes back to the previous point and the
next setting can be made.
Thenavigationisbyenteringtheposition/valuefollowedby#.
4.2Congurationoverview
Position Setting Factory default
00 Master code (1 til 8 cifre) 4711
01 Service code (1 til 8 cifre) 12347890
02  LEDindications   Normal=Yellow,active=Yellowandgreen
03 Outputs Output time for 1 and 2 is 5 seconds
04 Special functions
05 Smart reading
06 Background light
08 Backup/cloning the settings
2500 Alle codes on the user positions are deleted
0250 Reset to factory default
4.3 Change the Master code
By default the Master code is 4711 and can only be used to program, change or delete
users on the C1000.
TochangetheMastercode,enterthefollowing:
○ ● ○ ●● ○ ○ ● ○
#
Key in the
Service code #
Key in
00 #
Keyinanew
codeorshowtag

4.4 Change the Service code
TheServicecodeisusedtoconguratetheC1000’ssettings.
TochangetheServicecode,enterthefollowingwithin10secondsafterpoweron:
○ ● ○ ●● ○ ** ○ ○ ● ○
4.5 LED indications
TheC1000’s3LED’scanbeadjustedatwill.
ToadjusttheLEDindicationsenterthefollowing:
adjust the LED’s for standby indication (normal).
adjust the LED’s for correct code/tag indication (active).
   adjustthekeyingindication(howtheLEDwillreactwhilekeying).
ToadjusttheLED’spressonthefollowing:
  =yellowLED(togglebypress)
= green LED (toggle by press)
= red LED (toggle by press)
  =buzzer(worksonlyonactiveandkeyingindication(togglebypress))
= save and go one step back
To save the settings press or press / to go back to the previous
point (not saving).
#
Key in the
Service code #
Key in
01 #
Keyinanew
codeorshowtag #
Repeatnew
code/tag
#
02
#
1
#
2
#
3
1
2
3
0
#
8
***
***
***
***
#*

4.6 Outputs
TheC1000has2transistoroutputs,whichbothareactivatedfor5seconds(factory
default)whenacorrectcodeisentered.Theoutputactivationtimecanbechanged
and inverted.
To cahnge these settings key in:
   acitvationtimeforoutput1(whitecore)
   activationtimeforoutput2(yellowcore)
The time is set as:
● ○ ○ ○ ● ○ ○ ○ ●
If no value is entered in hours, minutes or secondsisthevalueautomatically0(which
corresonds to set the output as toggle).
bonding the positions and output 1
bonding the positions and output 2
Bothoutputsarebondedtospecicpositions.Byfactorydefaultpositions1to100are
bounded to output 2 and positions 101 to 150 to output 1.
The value can not be crossed.
inverted outputs
output 1 (● ○ ○ = inverted / ○ ○ ○ = not inverted)
output 2 (○ ● ○ = inverted / ○ ○ ○ = not inverted)
To save the settings press or press / to go back to the previous
point (not saving).
9
#
02
#
1
#
2
○ ●●
#
Key in hours
0 to 60 #
Key in minutes
0 to 60 #
Key in seconds
0 to 60
#
3
#
4
#
5
1
2
#*

4.7 Special settings
These settings is used to change the C1000’s special functions such as turning the
buzzeron/o,enableHighSecurityetc..
To change these settings, key in:
 =Servicecodewithouttimeout(●= inactive / ●= active)
= Master code be changed by Master code (●= inactive / ●= active)
= Mute reader (●=o/●= on)
 =Brownwirefunction(●= external buzzer / ●=HighSecurity)
 =HighSecurity(●= inactive / ●= active)
= Bell/star key (●=deletenon-nishedcodes/●= activates output 1*)
*When the bell/star key is set to activate output 1 can codes and Mifare tags only activate output 2.
High Security
HighSecurityincreasestheC1000’ssecuritybyensuring2positionshavetobeactivat-
ed before the output is activated (the positions must be next to each other).
Special positions
On positions 191 to 194 special functions can be activated by code. The programming
islikeprogramminganewuser.
191 = No buzzer
192=Input1(brownwire)function(HighSecurityorexternalbuzzer)
193=HighSecurity
194 = Bell/star key function (activates output 2 by press)
To save the settings press or press / to go back to the previous
point (not saving).
Note:ApowercucleputsthefunctionsbacktothesettingsmadebytheServicecode.
10
#
04
●○ ○
1
2
3
4
5
6
#*

5. Blocking
The C1000 is blocked for 1 minute after 4 incorrect codes.
LED indication: ○ ○ *
6. Manual reset
The C1000 can be reset to factoty default manually.
•Turnthevoltageo.
•Connecttheyellowandbrownwire.
•Turnthevoltageon(9-25VDC)thereadersLED’slightsandthebuzzersounds.
•Turnthevoltageoanddisconnecttheyellowandbrownwire.
TheC1000isnowresettofactorydefaultandtheusercodes/tagsaredeleted.
7.Technicalspecications
Voltage: By 12V DC, 30mA
Voltage range: 9 - 25V DC
Mifare reading: Max. 50 mm
Output: 2x open collector, max. 500mA
Input:  Externalbuzzer/HighSecurity(brown)andREX,0Vactive(blue)
Rang: IP67
Color:  Blackorwhite
Cabel:  2,5meterwhite,8cores
Size(HxBxD): 130x50x8mm
11

9. Connection examples
Direct connection
Relay connection
Thank you for choosing Conlan’s products.
For technical support, call: [phone]
+12V DC
0V DC
REX, 0V active
High Security/external buzzer, 0V active
External controlling green LED, 0V active
External controlling red LED, 0V active
CT 2000 Prox
ALARM SYSTEM A/S
Prox
1 3
5
7 9
2
4 6
8
0
0V GND
Doorstrike
+ 12V DC
+ 12V DC
0V GND
Doorstrike
+ 12V DC
+ 12V DC
+12V DC
0V DC
REX, 0V active
Hight Security/external buzzer, 0V active
Relay
External controlling green LED, 0V active
External controlling red LED, 0V active
CT 2000 Prox
ALARM SYSTEM A/S
Prox
1 3
5
7 9
2
4 6
8
0
NO
NC
C
Relay
0V GND
Doorstrike
+ 12V DC
+ 12V DC
0V
+ 12V DC
