Connects2 PARK-401 User manual

- Ultrasonic Sensors: 4
- Ultrasonic Frequency: 40 kHz
- Operating Distance: >180cm
- Operating Voltage: 12V DC (Negative Ground)
- Current Consumption: 25mA @ 13.8V
- Operating Temperature: -30 Degrees C to +80 Degrees C
User Manual
Prior to Installation
Read the manual prior to installation. Technical knowledge is necessary for installation.
Please ensure you use the correct tools to avoid damage to the vehicle or product.
Connects2 can not be held responsible for the installation of this product.
Technical Support
Connects2 want to provide a fast and suitable resolution should you encounter any tech-
nical issues. With this in mind, when contacting Connects2, try to provide as much Infor-
mation as possible. This will speed up the process and help us to help you.
Please use our dedicated online technical support centre: support.connects2.com
Parking Sensor Kit
4 Sensors, Audio Only
PRODUCT FEATURES:
DISCLAIMER:
PARK-401
CONTENTS
- Control Unit
- Ultrasonic Sensors (x4) with 20cm connection cable including connector
- 2.3m sensor extension cable (x4)
- 1m DC power cable
- Buzzer with 1.75m cable
- 22.5mm hole saw
- Adhesive pads
- Instructions

www.connects2.com
2
Connects2Vision
INSTALLATION
NB: If the Sensors are painted before tment, please do not apply paint in many
coats, only sufcient paint to give good colour. Overloading paint onto sensors
may affect their function and performance
1. Connect the Black wire to a suitable ground and the Red wire to the reversing
light circuit or an interface which provides a reverse signal.
2. Attach a length of masking tape along the bumper where the sensors are to be
located and mark the position of the holes. It is advisable to choose a height of
between 50-80cm and a spacing of between 30-40cm.
3. Check for any metalwork, cables or fuel/oil storage before attempting to drill the
bumper. After checking the area, cut suitable holes using the cutting tool provided.
4. Rotate each sensor so the UP arrow is pointing upwards and insert the sensor into
the bumper.
5. Connect the extension cables between the sensors and control unit.
6. Mount the buzzer in a suitable location so it can be easily heard by the driver and
connect the cable to the control unit.
7. Engage reverse gear and ensure the system is working correctly and that the dis-
tance of the object detected corresponds with the warning beeps (see Awareness/
Distance/Sound information)
Subscribe to our YouTube Channel for installation
guides and tips... www.youtube.com/connects2
AWARENESS/DISTANCE/SOUND INFORMATION
Awareness: Safe Mode
Distance: 1.8-1.3m
Sound: BI...BI…BI…
Awareness: Safe Mode
Distance: 1.3-0.9m
Sound: BI..BI..BI..
Awareness: Alarm Mode
Distance: 0.9-0.6m
Sound: BI.BI.BI.
Awareness: Alarm Mode
Distance: 0.6-0.4m
Sound: BIBIBI
