Desa RM60 User manual

PORTABLE
FORCED
AIR HEATER
OWNER’S MANUAL
IMPORTANT: Read and understand this manual before assembling, start-
ing, or servicing heater. Improper use of heater can cause serious injury.
Keep this manual for future reference.
ARL LOGO G 004
®
Model RM60
60,000 Btu/Hr
H.S.I. Series

2
104672
PORTABLE FORCED AIR HEATER
60,000 Btu/Hr H.S.I. Series
UNPACKING
1. Remove all packing items applied to
heater for shipment.
2. Remove all items from carton.
3. Check items for shipping damage. If
heater is damaged, promptly inform
dealer where you bought heater.
SAFETY
INFORMATION
Carbon Monoxide Poisoning: Early
signs of carbon monoxide poisoning re-
semble the flu, with headaches, dizziness,
and/or nausea. If you have these signs, the
heater may not be working properly. Get
fresh air at once! Have heater serviced.
Some people are more affected by carbon
monoxide than others. These include preg-
nant women, persons with heart or lung
diseaseoranemia,thoseundertheinfluence
of alcohol, and those at high altitudes.
Make certain you read and understand all
Warnings. Keep this manual for reference.
It is your guide to safe and proper operation
of this heater.
• Use only kerosene or No. 1 fuel oil to
avoid risk of fire or explosion. Never
usegasoline,naphtha,paintthinners,al-
cohol, or other highly flammable fuels.
• Fueling
a)Personnelinvolved with fueling shall
be qualified and thoroughly familiar
with the manufacturer’s instructions
and applicable federal, state, and lo-
cal regulations regarding the safe
fueling of heating units.
b)Only the type of fuel specified on the
heater’s data plate shall be used.
c) All flame, including the pilot light, if
any, shall be extinguished and the
heaterallowed tocool, priortofueling.
d) During fueling, all fuel lines and fuel-
lineconnectionsshallbeinspectedfor
leaks. Any leaks shall be repaired
priortoreturningthe heater to service.
e)At no time shall more than one day’s
supply of heater fuel be stored inside
abuilding in the vicinity of the heater.
Bulk fuel storage shall be outside the
structure.
f) All fuel storage shall be located a
minimum of 25 feet from heaters,
torches, welding equipment, and
similar sources of ignition (excep-
tion: the fuel reservoir integral with
the heater unit).
g)Whenever possible, fuel storage shall
beconfined to areas where floor pen-
etrations do not permit fuel to drip
onto or be ignited by a fire at lower
elevation.
h)Fuel storage shall be in accordance
with the federal, state, or local au-
thority having jurisdiction.
• Never use heater where gasoline, paint
thinner, or other highly flammable va-
pors are present.
• Follow all local ordinances and codes
when using heater.
• Heaters used in the vicinity of tarpau-
lins, canvas, or similar enclosure ma-
terials shall be located a safe distance
fromsuch materials.Therecommended
minimum safe distance is 10 feet. It is
further recommended that these enclo-
sure materials be of a fire retardant na-
ture.These enclosure materials shallbe
securely fastened to prevent them from
igniting or from upsetting the heater
due to wind action.
• Use only in well-vented areas. Before
using heater, provide at least a three-
square-foot opening of fresh, outside
air for each 100,000 Btu/Hr of rating.
Thisheaterproducescarbonmonoxide,
which is listed by the State of Califor-
niaas a reproductive toxin under Propo-
sition 65.
• Use only in places free of flammable
vapors or high dust content.
WARNINGS
IMPORTANT: Read this Owner’s
Manual carefully and completely
before trying to assemble, oper-
ate,orservicethisheater.Improper
use of this heater can cause seri-
ous injury or death from burns,
fire, explosion, electrical shock,
and carbon monoxide poisoning.
DANGER: Carbon monoxide
poisoning may lead to death!
• Use only the electrical voltage and fre-
quency specified on model plate.
• Use only a three-prong, grounded ex-
tension cord.
• Minimum heater clearances from com-
bustibles:
Outlet: 8 Ft. Sides: 4 Ft.
Top: 4 Ft. Rear: 4 Ft.
• Locate heater on a stable and level sur-
face if heater is hot or running or a fire
may occur.
• When moving or storing heater, keep
heater in a level position or fuel spill-
age may occur.
• Keep children and animals away from
heater.
• Unplug heater when not in use.
• Whenusedwiththermostat,heatermay
start anytime.
• Never use heater in living or sleeping
areas.
• Never block air inlet (rear) or air outlet
(front) of heater.
• Never move, handle, refuel, or service
a hot, operating, or plugged-in heater.
• Never attach duct work to front or rear
of heater.
•WarningtoNewYorkCity Residents
For Use Only At Construction Sites
inaccordancewithapplicableNYCcodes
under NYCFD certificate of approval
#4803, #4899, #4908, #4909, or #4934.

3
104672
OWNER’S MANUAL
Figure 2 - Cross Section Operational View
Clean
Heated
Air Out
Figure 1
Handle
Fuel Cap
Lower Shell
Power Cord
Fuel Tank
Hot Air Outlet
Air Filter
End Cover
Fan Guard
Upper Shell
Side Cover
Ignition Control Assembly
(assembly on inside of side cover)
PRODUCT IDENTIFICATION
The Fuel System: The air pump forces
air through the air line. The air is then
pushed through the nozzle. This air causes
fuel to lift from the tank. A fine mist of fuel
is sprayed into the combustion chamber.
TheAirSystem: Themotorturnsthefan.
The fan pushes air into and around the
combustion chamber. This air is heated and
provides a stream of clean, hot air.
The Ignition System: The ignition con-
trolassemblyprovidespowertotheignitor.
This ignites the fuel/air mixture in the com-
bustion chamber.
The Flame-Out Control System: This
system causes the heater to shut down if the
flame goes out.
Fuel
Filter Air Line
To Burner
Air
Output
Filter
Air Pump
Air Intake
Filter
Cool
Air In
Fan
Combustion ChamberIgnitor Motor
Ignition Control
Assembly
Air For Fuel System Air For Combustion
And Heating Fuel
Nozzle
Fuel
Tank
THEORY OF OPERATION
Donotuse heavyfuels suchasNo.2fueloil
or No. 2 Diesel. Using heavy fuels will
result in a clogged fuel filter and/or nozzle.
IMPORTANT: Use a KEROSENE ONLY
storagecontainer.Besurestoragecontaineris
clean. Foreign matter such as rust, dirt, or
waterwillcausetheignitioncontrolassembly
to shut down the heater. Foreign matter may
also require you to clean fuel system often.
Provideatleastathree-square-footopening
offresh,outsideairforeach100,000Btu/Hr
rating. Provide extra fresh air if more heat-
ers are being used.
Example: A60,000Btu/Hrheaterrequires
one of the following:
• atwo-car garage door (16 feet wide open-
ing) raised 1 1/2"inches
• a single-car garage door (9 feet wide
opening) raised 2 1/2" inches
• two windows (30 inches wide opening)
raised 4 1/2" inches
FUELS
WARNING:Useonlykerosene
orNo.1fueloiltoavoidriskoffire
orexplosion.Neverusegasoline,
naphtha, paint thinners, alcohol,
or other highly flammable fuels.
VENTILATION
WARNING: Follow the mini-
mum fresh, outside air ventila-
tionrequirements.Ifproperfresh,
outside air ventilation is not pro-
vided, carbon monoxide poison-
ing can occur. Provide proper
fresh, outside air ventilation be-
fore running heater.

4
104672
PORTABLE FORCED AIR HEATER
60,000 Btu/Hr H.S.I. Series
TO START HEATER
1. Follow all ventilation and safety
information.
2. Fill fuel tank with kerosene or No. 1
fuel oil.
3. Attach fuel cap.
4. Plug power cord of heater into three-
prong,groundedextensioncord. Exten-
sion cord must be at least six feet long.
STORING,
TRANSPORTING,
OR SHIPPING
Note: If shipping, transport companies re-
quire fuel tanks to be empty.
1. Drain fuel tank. Drain fuel through fuel
capopening. Be sureallfuel is removed.
2. If any debris is noted in old fuel, add 1
or 2 quarts of clean kerosene to tank,
stir, and drain again. This will prevent
excess debris from clogging filters dur-
ing future use.
3. Replace fuelcap. Properlydisposeofold
and dirty fuel. Check with local auto-
motive service stations that recycle oil.
4. If storing, store heater in dry place.
Make sure storage place is free of dust
and corrosive fumes.
IMPORTANT: Do not store kerosene over
summer months for use during next heating
season.Usingoldfuelcoulddamageheater.
Extension CordWire Size
Requirements
• 6 to 10 feet long, use 18 AWG rated
cord
• 11 to 100 feet long, use 16 AWG
rated cord
• 101 to 200 feet long, use 14 AWG
rated cord
5. Plug extension cord into standard 120
volt/60hertz,three-hole, grounded out-
let. Note: Ignitor will preheat for five
seconds then heater will start.
TO STOP HEATER
Unplug extension cord from outlet.
TO RESET HEATER
1. Unplug extension cord from outlet and
wait 10 seconds (two minutes if heater
has been running).
2. Plug extension cord into standard 120
volt/60hertz,three-hole, grounded out-
let. Note: Ignitor will preheat for five
seconds then heater will start.
PREVENTATIVE MAINTENANCE SCHEDULE
WARNING: Never service heater while it is plugged in, operating, or
hot. Severe burns and electrical shock can occur.
Item
Fuel tank
Air output and lint filters
Air intake filter
Fuel filter
Ignitor
Fan blades
Motor
How Often
Flush every 150-200 hours of operation or
as needed
Replace every 500 hours of operation or
once a year
Wash and dry with soap an water every 500
hours of operation or replace as needed
Clean twice a heating season or replace as
needed
No maintenance required
Clean each season or as needed
Not required/permanently lubricated
How To
See Storing, Transporting, or Shipping,
above
SeeAir Output, Air Intake, and Lint Filters,
page 6
SeeAirOutput, Air Intake, and Lint Filters,
page 6
See Fuel Filter, page 7
See Fan, page 6
OPERATION
WARNING: Review and un-
derstand the warnings in the
Safety Information section, page
2. They are needed to safely op-
erate this heater. Follow all local
codes when using this heater.

5
104672
OWNER’S MANUAL
REMEDY
1. Check circuit breaker in electrical panel
2. Check all electrical connections. See
Wiring Diagrams, page 10
3. See Ignitor, page 7
4. If fan does not turn freely, see Pump Ro-
tor, page 8
5. Replace ignition control assembly
6. Replace motor
1. Fill tank with kerosene
2. See Pump Pressure Adjustment, page 6
3. See Fuel Filter, page 7
4. See Nozzle Assembly, page 8
5. Drain and flush fuel tank with clean
kerosene. See Storing, Transporting, or
Shipping, page 4
6. Check electrical connections. See Wir-
ing Diagrams, page 10
7. Replace ignitor, see page 7
8. Replace ignition control assembly
1. See Pump Pressure Adjustment, page 6
2. See Air Output, Air Intake, and Lint Fil-
ters, page 6
3. See Fuel Filter, page 7
4. See Nozzle Assembly, page 8
5. Make sure photocell boot is properly
seated in bracket
6. Clean photocell lens
7. Check electrical connections. See Wir-
ing Diagrams, page 10
8. Replace photocell
9. Replace ignition control assembly
FAULT CONDITION
Motordoesnotstartfivesecondsafterheater
is plugged in
Motor starts and runs but heater does not
ignite
Heaterignitesbutignitioncontrolassembly
shuts heater off after a short period of time
POSSIBLE CAUSE
1. No power to heater
2. Bad electrical connection between mo-
tor and ignition control assembly or ig-
nition control assembly and power cord
3. Blown fuse on ignition control assembly
4. Binding pump rotor
5. Defective ignition control assembly
6. Defective motor
1. No fuel in tank
2. Pump pressure incorrect
3. Dirty fuel filter
4. Obstruction in nozzle
5. Water in fuel tank
6. Bad electrical connection between igni-
tor and ignition control assembly
7. Defective ignitor
8. Defective ignition control assembly
1. Pump pressure incorrect
2. Dirty air intake, air output, and/or lint
filter
3. Dirty fuel filter
4. Obstruction in nozzle
5. Photocell assembly not properly in-
stalled (not seeing the flame)
6. Dirty photocell lens
7. Bad electrical connection between pho-
tocell and ignition control assembly
8. Defective photocell
9. Defective ignition control assembly
TROUBLESHOOTING WARNING: Never service heater while it is plugged in, operating, or
hot. Severe burns and electrical shock can occur.
WARNING: High voltage!
WARNING: High voltage!
WARNING: High voltage!
Note: For additional help, visit DESA
International’s Technical Service web
site at www.desatech.com.
www.desatech.com

6
104672
PORTABLE FORCED AIR HEATER
60,000 Btu/Hr H.S.I. Series
Figure 6 - Pressure Gauge Plug Removal
Relief
Valve
Pressure
Gauge
Plug
Figure 7 - Adjusting Pump Pressure
Pressure
Gauge
Fan
Motor
Figure 3 - Upper Shell Removal
Figure 5 - Air Output, Air Intake, and Lint
Filters
Flush
Setscrew
Motor
Shaft
Figure 4 - Fan Cross Section
Air Intake Filter
Filter End Cover
Fan Guard
Air Output Filter
Lint Filter
Upper
Shell
Fan
Guard
SERVICE
PROCEDURES
UPPER SHELL REMOVAL
1. Remove screws along each side of
heater using 5/16" nut-driver. These
screws attach upper and lower shells
together.
2. Lift upper shell off.
3. Remove fan guard.
FAN
IMPORTANT: Remove fan from motor
shaft before removing motor from heater.
The weight of the motor resting on the fan
could damage the fan pitch.
1. Remove upper shell (see above).
2. Use 1/8" Allen wrench to loosen set-
screw which holds fan to motor shaft.
3. Slip fan off motor shaft.
4. Clean fan using soft cloth moistened
with kerosene or solvent.
5. Dry fan thoroughly.
6. Replace fan on motor shaft. Place fan
hub flush with end of motor shaft (see
Figure 4).
7. Place setscrew on flat of shaft. Tighten
setscrew firmly (40-50 inch-pounds).
8. Replace fan guard and upper shell.
AIR OUTPUT, AIR INTAKE,
AND LINT FILTERS
1. Remove upper shell (see Upper Shell
Removal).
2. Remove filter end cover screws using
5/16" nut-driver.
3. Remove filter end cover.
4. Replace air output and lint filters.
5. Wash or replace air intake filter (see
Preventative Maintenance Schedule,
page 4).
6. Replace filter end cover.
7. Replace fan guard and upper shell.
IMPORTANT: Do not oil filters.
PUMP PRESSURE
ADJUSTMENT
1. Remove pressure gauge plug from filter
end cover.
2. Install accessory pressure gauge (part
number HA1180).
3. Start heater (see Operation, page 4).
Allow motor to reach full speed.
4. Using a flat blade screwdriver, adjust
pressure. Turn relief valve to right to
increase the pressure. Turn relief valve
to left to decrease the pressure. Set
pump pressure to 3.4 psi.
5. Stop heater (see Operation, page 4).
6. Remove pressure gauge. Replace pres-
sure gauge plug in filter end cover.
WARNING: Never service
heater while it is plugged in, op-
erating,or hot.Severeburns and
electrical shock can occur.

7
104672
OWNER’S MANUAL
Fuel Filter
Side Cover Upper Fuel Line
Figure 8 - Fuel Filter Removal
SERVICE
PROCEDURES
Continued
FUEL FILTER
1. Remove 4 side cover screws using
5/16" nut-driver.
2. Remove side cover.
3. Pull upper fuel line off fuel filter neck.
4. Carefully pry bushing and fuel filter out
of fuel tank.
5. Wash fuel filter with clean fuel and re-
place in tank.
6. Attach upper fuel line to fuelfilterneck.
7. Replace side cover.
IGNITOR
1. Remove upper shell and fan guard (see
Fan, page 6).
2. Remove fan (see Upper Shell Removal,
page 6).
3. Remove 4 side cover screws with a
5/16" nut driver. Remove side cover
(see Figure 8).
4. Disconnect ignitor wires (gray) from
ignition control assembly (see Figure
9). Pull the ignitor wires up through the
hole in the lower shell.
5. Disconnect fuel line hose and air line
hose.Removephotocellfromphotocell
bracket (see Figure 9).
6. Remove combustion chamber. Stand
combustion chamber on end with
nozzle adapter bracket on top (see Fig-
ure 10).
7. Remove ignitor screw with a 1/4" nut
driver. Carefully remove ignitor from
nozzle adapter bracket.
CAUTION:Donotbendorstrike
ignitor element. Handle with care.
Combustion
Chamber
Photocell
Bracket
Photocell
Assembly
Air
Line
Hose
Fuel
Line
Hose
Combustion
Chamber
Photocell
Bracket
Ignitor
Wires
Ignitor
Nozzle
Adapter
Bracket
Ignition
Control
Assembly
Side Cover
Figure 9 - Disconnecting Ignitor Wires
from Ignition Control Assembly (see
Wiring Diagrams, Figure 18 or 19
appropriately, page 10)
Ignitor
Ignitor
Screw/
Washer
Assembly
Nozzle
Adapter
Bracket
Nozzle Adapter
Bracket Opening
Ignitor
Element
Figure 10 - Ignitor Replacement
8. Carefully remove replacement ignitor
from styrofoam packing.
9. Carefully guide ignitor into opening in
nozzle adapter bracket. Do not strike
ignitorelement.Attach ignitor to nozzle
adapter bracket with screw using a 1/4"
nut driver (see Figure 10). Torque 8 to
15 in. lbs. Do not over torque.
10. Replace combustion chamber.
11. Route the ignitor wires back down
through the hole in the lower shell.
Connect wires to the ignition control
assembly.
12. Replace side cover (see Figure 8).
13. Connect and route fuel line hose and
air line hose to nozzle adapter (see Fig-
ure 9).
14. Replace photocell in photocell bracket.
Route wires as shown in Figure 11,
page 8.
15. Replace fan (see page 6).
16. Replace fan guard and upper shell (see
page 6).
Continued
WARNING: Never service
heater while it is plugged in, op-
erating,or hot.Severeburns and
electrical shock can occur.

8
104672
PORTABLE FORCED AIR HEATER
60,000 Btu/Hr H.S.I. Series
Sandpaper
.003"/.004"
Gap
Measured
With
Feeler
Gauge
Blade
Rotor
Gap Adjusting Screw
Gap Adjusting Screw
InsertRotor Air Output
Filter
Blade
Pump Plate
Air Intake Filter
Filter End
Cover
Fan Guard
SERVICE
PROCEDURES
Continued
Figure 11 - Removing Air and Fuel Line
Hoses
PUMP ROTOR
(Procedure if Rotor is Binding)
1. Remove upper shell (see page 6).
2. Remove filter end cover screws using
5/16" nut-driver.
3. Remove filter end cover and air filters.
4. Remove pump plate screws using 5/16"
nut-driver.
5. Remove pump plate.
6. Remove rotor, insert, and blades.
7. Check for debris in pump. If debris is
found, blow out with compressed air.
8. Install insert and rotor.
9. Check gaponrotor.Adjust to.003"/.004"
if needed (see Figure 15).
Note: Rotate rotor one full turn to in-
sure the gap is .003"/.004" at tightest
position. Adjust if needed.
10. Install blades, pump plate, air filters,
and filter end cover.
11. Replace fan guard and upper shell.
12. Adjust pump pressure (see Pump Pres-
sure Adjustment, page 6).
Note: If rotor is still binding, proceed
as follows.
13. Perform steps 1 through 6 above.
14. Placefine grade sandpaper (600 grit) on
flatsurface. Sand rotor lightly in “figure
8” motion four times (see Figure 16).
15. Reinstall insert and rotor.
16. Perform steps 10 through 12 above.
Figure 14 - Rotor Location
Figure 15 - Gap Adjusting Screw
Locations
Figure 16 - Sanding Rotor
Figure 12 - Removing Nozzle/Adapter
Assembly
Figure 13 - Nozzle and Nozzle Adapter
NOZZLE ASSEMBLY
1. Remove upper shell (see page 6).
2. Remove fan (see page 6).
3. Remove fuel and air line hoses from
nozzle assembly (see Figure 11).
4. Turn nozzle assembly 1/4 turn to left
and pull toward motor to remove (see
Figure 12).
5. Place plastic hex-body into vise and
lightly tighten.
6. Carefully remove nozzle from the
nozzle adapter using 5/8" socket
wrench (see Figure 13).
7. Blow compressed air through face of
nozzle. This will free any dirt in
nozzle area.
8. Inspect nozzle seal for damage.
9. Replace nozzle into nozzle adapter un-
til nozzle seats. Tighten 1/3 turn more
using 5/8" socket wrench (40-45 inch-
pounds).
10. Attach nozzle assembly to burner strap.
11. Attach and route fuel and airline hoses
to nozzle assembly as shown (see Fig-
ure 11). Route photo cell wires as
shown in Figure 11.
12. Replace fan (see page 6).
13. Replace fan guard and upper shell.
Fuel Line Hose
Nozzle/
Adapter
Assembly
Combustion
Chamber
Air Line Hose
Burner
Strap
Nozzle Face
Nozzle
Nozzle Seal
Nozzle Adapter
Air Line Fitting
Fuel Line Fitting
Nozzle/Adapter
Assembly
Combustion
Chamber
Photocell
Wires

9
104672
OWNER’S MANUAL
SPECIFICATIONS
Output Rating (Btu/Hr) 60,000
Fuel Use Only Kerosene or No. 1 Fuel Oil
Fuel Tank Capacity (U.S. Gal.) 5.0
Fuel Consumption (Gal. Per Hr.) .44
Pump Pressure Setting 3.4 psi
Electric Requirements 120 V/60 Hz
Amperage (Normal Run) 2.0
Hot Air Output (CFM) 180
Motor RPM 1725
Motor HP 1/15
Shipping Weight
(Approximate Pounds) 35
Heater Weight without Fuel
(Approximate Pounds) 30
TECHNICAL
SERVICE
You may have further questions about op-
eration or troubleshooting. If so, contact
DESA International’s Technical Service
Dept. at 1-800-323-5190.
You can also visit DESA International’s
Technical Service web site at
www.desatech.com.
Note: Use only original replacement parts.
Thiswillprotectyourwarrantycoveragefor
parts replaced under warranty.
PARTS UNDER WARRANTY
Contact authorized dealers of this product.
If they can’t supply original replacement
part(s), call DESA International’s Techni-
calService Department at1-800-323-5190.
When calling DESA International, have
ready:
• your name
• your address
• model and serial numbers on your heater
• how heater was malfunctioning
• purchase date
Usually,wewillaskyoutoreturnthedefec-
tive part to the factory.
PARTS NOT UNDER
WARRANTY
Contact authorized dealers of this product.
If they can’t supply original replacement
part(s), call DESA International’s Parts
Department at 1-800-972-7879 for referral
information. Parts Centrals are listed in the
AuthorizedServiceCenterbookletsupplied
with heater.
When calling DESA International, have
ready:
• model number of your heater
• the replacement part number
REPLACEMENT
PARTS

10
104672
PORTABLE FORCED AIR HEATER
60,000 Btu/Hr H.S.I. Series
Blue
Photocell
Power Plug
120V/60Hz
IGNITOR
Ignitor
Blue
White
Red
Gray Gray
Green
Motor
White
Black
AC NEUTRAL (L2)
PHOTOCELL
PHOTOCELL
MOTOR RETURN
MOTOR MAIN
120V (L1)
IGNITOR
Ignition Control
Assembly
Green
104040
Figure 17 - Wiring Diagram for Heaters Using 104040-02 Ignition Control Assembly
WIRING DIAGRAMS
Blue
Photocell
Power Plug
120V/60Hz
IGNITOR
Ignitor
Blue
White
Red
Gray
Gray
Green
Motor
White
Black
L2 AC NEUTRAL
PHOTOCELL
PHOTOCELL
MOTOR RETURN
MOTOR MAIN
L1 (120V)
IGNITOR
Ignition Control
Assembly
Green
PART# 102350
Figure 18 - Wiring Diagram for Heaters Using 102350-01 Ignition Control Assembly

11
104672
OWNER’S MANUAL
ACCESSORIES
Purchase accessories and parts from your
nearest dealer or service center. If they can
not supply these accessories or parts, either
contact your nearest Parts Central or DESA
International’s Parts Department at 1-800-
972-7879forreferralinformation.PartsCen-
trals are listed in the Authorized Service
Center booklet supplied with heater.
AIR GAUGE KIT - HA1180
Special tool to check pump pressure.
THERMOSTAT KIT -
HA1210
Keeps your building at the tempera-
ture you select day and night. Helps
economize on fuel.
STANDARD WHEELS AND
HANDLE KIT - HA1206
Makes heater even more portable and con-
venient. Easy to assemble.
HEAVY DUTY WHEELS AND
HANDLE KIT - HA1202
For heavy duty applications. Makes your
heater even more portable and convenient.
A 008
IGNITION CONTROL
ASSEMBLY/PHOTOCELL
TESTER - HA1170
Special tool used to test the ignition control
assembly and photocell.

12
104672
PORTABLE FORCED AIR HEATER
60,000 Btu/Hr H.S.I. Series
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
9-2
9-1
9-3
9-4
9-5
17
18
19
20
21
22
23
24
25
26
27
28
29
30
34
35
36
32 33 31
ILLUSTRATED
PARTS
BREAKDOWN
Motor and Pump Assembly
12-11
12-18
12-17
12-16
12-15
12-14
12-1312-12
12-10
12-1
12-3 12-412-5 12-6
12-7
12-8
12-9
12-2
RM60

13
104672
OWNER’S MANUAL
PARTS LIST This list contains replaceable parts used in your heater. When ordering parts, be sure to provide the correct
model and serial numbers (from the model plate), then the part number and description of the desired part.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 M51104-01 Handle 1
2 098511-67 Upper Shell 1
3 M11084-29 Screw, #10-16 x 3/4" 2
4 100647-01 Screw, #10-16 x 1/2" 6
5 098512-50 Combustion Chamber 1
6 M10908-2 Screw, #6-32 x 3/8" 2
7 103154-01 Photocell Bracket 1
8 M16656-23 Photocell Assembly 1
9 ∆Burner Head Assembly 1
9-1 100735-17 Nozzle Assembly
9-2 102548-01 Ignitor Kit 1
9-3 104056-01 Nozzle Adapter 1
9-4 102336-01 Nozzle Adapter Bracket 1
9-5 104023-01 Screw/Washer Assembly 1
10 M11084-26 Screw, #10-16 x 3/8" 2
11 103684-01 Fan 1
12 ∆Motor and Pump Assembly 1
12-1 102001-01 Motor 1
12-2 079975-03 Pump Body 1
12-3 M22009*** Insert 1
12-4 M22456-2*** Rotor 1
12-5 M29608 Pump End Cover 1
12-6 M29632 ⊕ Lint Filter 1
12-7 M29633 ⊕Intake Filter 1
12-8 M29609 Filter End Cover 1
12-9 M12461-31 Screw, #10-32 x 1" 3
12-10 M27694 ∞Adjusting Screw 1
12-11 M10993-1 ∞Pressure Relief Spring 1
12-12 M22997 ∞Plug 1
12-13 M8940 ∞Steel Ball, 1/4" Diameter 1
12-14 M29612-01 ⊕Output Filter 1
12-15 M12461-32 Screw #10-32 x 1 1/8"6
KEY PART
NO. NUMBER DESCRIPTION QTY.
∆Not available as an assembly
*** Included in Rotor Kit (Part No. HA3005) ⊕Included in Filter Kit (Part No. HA3014)
∞Included in Pump Adjustment Kit (Part No. HA3020)
RM60
12-16 103676-01 Nylon Elbow, 90°1
12-17 M8643-2*** Blade 4
12-18 FHPF3-6C Screw 2
13 M51105-01 Fan Guard 1
14 098219-31 Power Cord 1
15 M11143-1 Strain Relief Bushing 1
16 NTC-4C Hex Lock Nut, 1/4-20 2
17 M11084-26 Screw, #10-16 x 3/8" 4
18 M50631 Rubber Bumper 2
19 097461-03AA Side Cover 1
20 101205-01 Motor Bracket 1
21 M30865-02 Bushing 2
22 M11271-8 Clip Nut 6
23 M50104-02 Bushing 1
24 M11084-26 Screw, #10-16 x 3/8" 6
25 M10908-14 Screw, #8-32 x 3/8" 1
26 098511-81 Lower Shell 1
27 M50814-06 Rubber Airline 1
28 079973-01 Fuel Line 1
29 M50876-05 Fuel Filter with bushing 1
30 M10990-3 Rubber Bushing 1
31 101695-01 Button Plug 1
32 102349-01 PCB Support 5
33 104068-03 Ignition Control Assembly 1
34 097702-01 Fuel Cap (Includes Gasket) 1
35 098513-24 Fuel Tank 1
36 M51108-01 Shell Heat-Shield 1
PARTS AVAILABLE - NOT SHOWN
098493-01 General Information Decal 1
103814-01 Wire Tie (Plastic) 1

WARRANTY AND REPAIR SERVICE
WARRANTY SERVICE
Should your heater require service, return it to your nearest authorized service center. Proof of purchase must be presented with the heater. The
heaterwill be inspected.A defect maybe caused byfaulty materials orworkmanship. If so,DESA International willrepair or replacethe heater
without charge.
REPAIR SERVICE
Return the heater to your nearest authorized service center. Each Service Center is independently owned and operated. Repairs not covered by
the warranty will be billed at standard prices. We reserve the right to amend these specifications at any time without notice.
Illustrated parts lists can be obtained free of charge. Send a self addressed stamped envelope to the address listed below. List the heater model
number and the date located in the lower right corner of this page. A service manual may be purchased from the address listed below. Send a
check for $5.00 payable to DESA International. When writing for information regarding your heater, be sure to include the model number and
serial number as shown on the model plate.
For information about this warranty write:
Corporate Headquarters
2701 Industrial Drive
P.O. Box 90004
Bowling Green, KY 42102-9004
www.desatech.com
LIMITED WARRANTY
DESA International warrants this product and any parts thereof, to be free from defects in materials and workmanship for one (1) year from
the date of first purchase when operated and maintained in accordance with instructions. This warranty is extended only to the original retail
purchaser, when proof of purchase is provided.
Thiswarranty coversonlythecostof partsandlaborrequiredto restoretheproducttoproper operatingcondition.Transportationandincidental
costs associated with warranty repairs are not reimbursable under this warranty.
Warranty service is available only through authorized dealers and service centers.
This warranty does not cover defects resulting from misuse, abuse, negligence, accidents, lack of proper maintenance, normal wear, alteration,
modification, tampering, contaminated fuels, repair using improper parts, or repair by anyone other than an authorized dealer or service center.
Routine maintenance is the responsibility of the owner.
THIS EXPRESS WARRANTY IS GIVEN IN LIEU OF ANY OTHER WARRANTY EITHER EXPRESSED OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
DESA International assumes no responsibility for indirect, incidental or consequential damages. Some states do not allow the exclusion or
limitation of incidental or consequential damages or limitations or exclusions may not apply to you. This Limited Warranty gives you specific
legal rights and you may also have other rights which vary from state to state.
Model No.
Serial No.
Date of Purchase
(To be filled in by purchaser)
KEEP THIS WARRANTY
104672-01
Rev. C
08/99
NOTA UPC
104672 01
