CONVECTAIR ALLEGRO II User manual

7315
7316
7317
7216680200R00
Share the warmth and leave a review.
convectair.com/sharethewarmth
Your input helps to create even better
products and experiences.
We value your feedback!
INSTALLATION AND USER’S GUIDE
To be read and kept by the user.
A BRAND OF GLEN DIMPLEX AMERICAS
ALLEGRO II
Convector

IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to reduce the risk of
fire, electrical shock, and injury to persons, including the following :
1. Read all instructions before installing or using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch
hot surfaces. Keep combustible materials, such as furniture, pillows,
bedding, papers, clothes, etc. and curtains at least 20” (50 cm) from
the front of heater, 6” (15 cm) from the sides and 4” (10 cm) from the top.
The installation must be at least 4” (10 cm) from the floor.
3. Extreme caution is necessary when any heater is used by or near children
or invalids and whenever the heater is left operating and unattended.
4. Do not operate any heater after it malfunctions. Disconnect power at
service panel and have heater inspected by a reputable electrician or a
Convectair service center before reusing.
5. Do not use outdoors.
6. To disconnect the heater, put controls to off or standby, and turn off power
to heater circuit at main panel.
7. Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electrical shock, or damage the heater.
8. To prevent a possible fire, do not block air intakes or exhaust in any manner.
9. The heater has hot and arcing or sparking parts inside. Do not use it in
areas where gasoline, paint, or flammable vapors or liquids are used or stored.
10. Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, or injury
to persons.
11. “SAVE THESE INSTRUCTIONS”.
Dear owner,
- Congratulations on the purchase of this new premium electric heater from CONVECTAIR,
manufacturer of the highest quality heating products in the electrical industry.
- To obtain the best results and the ultimate performance and comfort please carefully read the
installation and maintenance instructions shown in this manual.
shock, re or damage the heater.

Installation
2.
CAUTION: Convectair recommends that the Allegro be installed by a qualified
electrician, in accordance with national and local codes.
To reduce the risk of fire, do not store or use gasoline or other flammable vapors and
liquids in the vicinity of the heater.
Installation :
1- Free the mounting bracket by pressing and pulling
both locking tabs (Fig. B).
2- Relocate the mounting bracket to match the marks
with the holes for the bottom fasteners (Fig. C/D/E)
3- Make sure that the mounting bracket is level then
mark the 3 or 4 holes for fastening.
4- Place the mounting bracket and fasten it with
screws.
Locking
tab
470 mm
220 mm
150
Entraxe
258 mm
Longueur Appareil
A
Encombrement
de l’appareil
1500 => 2000W
(mm)
mm
Figure C
Width
Overall
dimension
Bracket
Height
2000W
170
100
4’’
6 11/16’’ 10,2’’
28
B
104
258
2
AA
500=>1250W
Bracket
750 => 1500W
4,1’’
1,1’’
10,2’’
7316 - ALLEGRO II - Figure C - Med
Power (W) 750 1000 1500 2000
Bracket 128mm 5’’ 208mm 8.1’’ 248mm 9,7’’ 405mm 16’’
Width 409mm 16,1’’ 489mm 19,3’’ 649mm 25,6’’ 849mm 33,5’’
A140mm 5,5’’ 140mm 5,5’’ 226mm 8,9’’ 221mm 8,7’’
Height 470mm 18,5’’ 470mm 18,5’’ 470mm 18,5’’ 470mm 18,5’’
Figure B

3.
7315 - ALLEGRO II - Figure D - Low
Power (W) 750 1000 1500 2000
Bracket 178mm 7’’ 248mm 9,8’’ 405mm 16’’ 535mm 21,1’’
Width 569mm 22,5’’ 649mm 25,6’’ 849mm 33,5’’ 1129mm 44,5’’
A226mm 8,9’’ 226mm 8,9’’ 223mm 8,8’’ 297mm 11,7’’
Height 360mm 14,2’’ 360mm 14,2’’ 360mm 14,2’’ 360mm 14,2’’
148mm
Entraxe
220mm
150mm
A
360mm
Longueur Appareil
Figure D
Width
Height
Overall
dimension
Bracket A
4’’
6 11/16’’ 5,8’’
170
100
170mm

Wiring Diagram
Thermal Cutout
L1
L2
Themperature
Sensor
Ground
DANGER:
High temperatures may be
generated under certain abnormal
conditions.
Do not partially or fully cover or
obstruct the front of this heater.
7317 - ALLEGRO II - Figure E - High
Power (W) 750 1000 1500 2000
Bracket 99mm 3,9’’ 128mm 5’’ 208mm 8,1’’ 320mm 12,5’’
Width 369mm 14,4’’ 409mm 15,9’’ 569mm 22,2’’ 769mm 30’’
A135mm 5,3’’ 140mm 5,5’’ 179mm 7’’ 226mm 8,9’’
Height 680mm 26,5’’ 680mm 26,5’’ 680mm 26,5’’ 680mm 26,5’’
220mm
150 mm
226mm
468mm
Entraxe
Longueur Appareil
680mm
Encombrement
de l'appareil
220mm
A
150mm
Entraxe
468mm
Encombrement de l'appareil
Version 500 & 1000 W
Autres Puissances
Figure E
A
2000W
Height
Width
Overall
dimension
Bracket
2000W
6 11/16’’ 18.4’’
170
100
28
B
104
258
2
AA
500=>1250W
Bracket
750 => 1500W
4,1’’
1,1’’
10,2’’
4.
4’’

Electrical Connection
R
PW
R
HEATER
B
B
G
POWER LINE
CANADA
C
PW
WITHOUT using a pilot wire
(PW)
.
CANADA U.S.A.
B- Black G - Green R - Red W - White C - Copper PW - Pilote Wire
R
PW
R
HEATER
B
B
G
POWER LINE
C
R
PW
W
B
B
G
POWER LINE
C
U.S.A.
R
PW
W
HEATER
B
B
G
POWER LINE
C
PW
WITH the use of a pilot wire
(PW)
.
5.
The unit must be hooked up with the rectangular junction box already installed
in the wall.
1- Connect the ground wire (C) to the green wire (G) inside the connection box.
2- Connect the black (B) and red (R) leads from the heater to the electrical supply
wires (see diagrams below).
3- Youwillnd,onthepowercord,afourthpurplewire(PW)withasealedend.
This wire must not be used for the electrical connection.This wire will be used
only if the unit is connected to a CONVECTAIR "Programmer" control system.
4- Carefully place all wires back into the box, close and screw the cover.
5- Hook the CONVECTAIR unit onto the mounting bracket tabs with the unit
slightly angled towards you. Push the CONVECTAIR towards the wall until it is
engaged on both locking tabs.
CAUTION : This unit must be connected to a 240 volts or 208 volts circuit,
60 cycles. Disconnect power supply before making wiring connections to
prevent electrical shock or equipment damage.
CONVECTAIR recommends that this heater be installed by a qualied
electrician and in accordance with national and local codes.
- A rectangular junction box must be installed in the wall, prior to electrical
hookup. The box must be of appropriate size to receive the necessary electrical
connections and the 2 3/4’’ x 4 1/2’’ (70mm x 115mm) cover that is supplied with
the unit cable.
- To prevent short circuits and electrical shocks turn the power off at the main
panel before attempting the installation or any repairs.
- If the power cable is damaged it must be replaced by the manufacturer, an
approvedservicecenteroratechnicianwithsimilarqualications.

Operating Instructions :
CONVECTAIR heaters operate in short cycles. The red indicator light
tells you when heat is on. The CONVECTAIR will always remain warm
and ambient temperature will remain constant. It is normal in very cold
temperatures for the unit to become hot. Caution is advised when young
children are present.
6.
Heat STANDBY
Temperature and operating
mode LCD display
Temperature
setting keys
Operating mode
selection key
Heating indicator symbol
Frost protection :
Program :
no heating.
the heater maintains the set temperature
the temperature is lowered to the desired setting
without changing the comfort setting (night
setback, unused rooms, temporary absence).
the temperature is set at 45°F(7°C) for long term
absences.
the heater can respond to signals from a
Programmer (CONVECTAIR 7392, sold
separately).
[no display]
°C/°F
ECo
HG
Economy
Setback:
STANDBY :
Comfort:

7.
Turning the heater ON.
Note : When the heater is rst connected, it will
be in STANDBY position, with a blank display. To
start, press briey on the Heating STANDBY key.
The display will show the default comfort set point :
19.0°C (66°F).
The setpoint display is set to °C by default.
In order to display in °F : press the STANDBY key to
put the heater in STANDBY. Then, press the Mode
and + keys at the same time and hold for about 3
seconds. The display will show °F.
Repeat this operation to go back to °C.
Toshutofftheheatingfunction,pressbrieyonthe
Heating STANDBY key. The display will go blank.
Note : the heater still retains all settings in memory.
It remains in standby mode.
Shutting off heater operation.
Setting the desired temperature.
Turn the heating on. The display shows 19.0°C (or
66.0°F if set in Fahrenheit). Using the + and – keys,
you can raise or lower the setting as you wish by 0.5°
each time the key is pressed.
This is how you can adjust the thermostat to your
desired temperature (see example).
To conrm this comfort level, you may follow the
following procedure, preferably in the evening (no
suninuence):closethedoorsoftheroomwhere
the heater is located ; wait about one hour to allow
for the temperature to stabilize, then adjust the
setting up or down (+ or – keys) until the temperature
feels right. Allow another hour to verify that the
temperature has stabilized at the correct level.
Selecting a °C or °F display.
Mode
Mode
Mode
Mode
Mode

8.
Comfort mode.
When the thermostat is in Comfort mode, the
heater will maintain the set temperature (19.0°C
66.0°F) without responding to any Programmer
instruction.
To change the set temperature, simply press the
+ or – keys to change the setting in steps of 0.5°.
Exception to the Comfort mode :
If the heater is connected to a Programming system, it will still respond to a Frost
Protection instruction.
To select the Comfort Mode :
Press the Mode key several times until the set temperature value appears on the
display (19.0°C. 66.0°F,...).
Eco mode.
When the heater is in Eco Mode, it will maintain
the temperature at a lower value. This setting is
useful to reduce energy consumption at night or
when a room is temporarily unused.
To select the Eco mode :
Press the Mode key briey until the word Eco
appears on the display.
To display the Eco temperature setting :
While in Eco mode, press the + or – key. The Eco
temperature setting will appear on the display (the
default setting is 3.5°C or 7°F below the Comfort
temperature).
Mode
Mode
Mode

9.
To change the Eco temperature :
When the display is in Eco mode, you have the option of choosing a set temperature.
The Eco temperature can be set at any value between the Frost Protection
temperature (7°C or 45°F) and the Comfort temperature minus 0.5°.
Select the Eco mode. Press and maintain the Mode key until the temperature
value starts to blink. Release the Mode key and adjust the temperature up or
downin0.5°stepsusingthe+or–keys.PressModetoconrmthesetting.
Note : the Eco temperature is relative to the Comfort temperature. If the Comfort
setting is changed, the Eco temperature will change automatically to maintain the
same difference between the two values.
Exceptions to the Eco Mode :
If the heater is connected to a Programming system, it will still respond to a Frost
Protection instruction.
Frost Protection setting : HG
In case of longer term absences (24hrs or more), the
HG mode will maintain the room temperature at 7°C
(45°F). You can reduce your energy consumption
while maintaining a safe minimum temperature.
To select the HG mode :
Press the Mode key until the display shows : HG.
Locking the heater controls.
The control pad can be locked from any Mode
selection to prevent tampering.
To lock the control : From any Mode setting, press
both the + and the – key at the same time and hold for
about 3 seconds. The display will blink to show that
the keyboard is locked.
Pressing any key when the keyboard is locked will
cause the screen to display «FF» and the heater will
not respond.
To unlock the keyboard, repeat the same procedure :
press and hold both + and – keys at the same time for
about 3 seconds.
Mode
Mode
Mode
Mode

10.
Mode
Program Mode :
This mode allows the heater to respond to
instructions from a central Programmer system
or from an individual Programmer module. The
thermostat display will show the instruction being
received (see summary table below).
To select the Program Mode :
PresstheModekeybrieyuntilthedisplayshowsthetemperaturesettingwith
the letter P on the top right of the screen (19.0 or 66.0, for instance).
The temperature is equal to the Comfort setting. To modify the set temperature,
simply press the + or – keys.
Suggestion :
For better comfort, we recommend that you keep this heater on the Programming
Mode.
This function allows your heater to react automatically to instructions sent by a
central Programmer System or by an individual Programmer module inserted in
the slot located next to the thermostat.
PROGRAMMER
INSTRUCTION
HEATER
DISPLAY
RESULTING MODE
Standby OFF Shuts off the heating function.
Setback on ECO Temperature is lowered by 3.5°C (7°F)
from the comfort setting (or as selected).
Frost Protection on HG Maintains the room temperature at 7°C
(45°F).
SUMMARY TABLE OF PROGRAMMING MODES SENT BY
A PROGRAMMER :
Note :
Frost Protection instructions from a Programming system will override all other
settings even if a heater is not set in the Program Mode.
In that case, the heater screen will display the appropriate symbol (see table
above) but the symbol « »willbeashing.

USING AN ELECTRIC HEATER WITH THE ‘‘AWC’’ :
When you use an electric heater wall mount controller instead of the built-in
thermostat display panel, the control panel of your heater becomes inactive.
When a key is pressed, the screen will display ‘‘AU’’ for ‘‘Automatic’’, then show
the temperature setting set by wall Remote.
Warning :
- Connecting your electric heater to an ‘‘AWC’’ will permanently reprogramm its
thermostat.
- If you wish to use it without an ‘‘AWC’’, the heater must be reinitialized by
Convectair (fees may be charged).
IDENTIFICATION OF YOUR HEATER
IMPORTANT : Product information appears
on the heater’s identication label.
Theidenticationlabelislocatedonthelower
right hand side of the heater (same side as the
thermostat). It includes :
– The complete model number and it
production reference number (rep. A) that must
be included in any warranty claim.
– Its capacity in watts (rep.B).
– Its approval standard (rep. C,D,E,F).
- MULLER
MADE IN FRANCE
AB
CF
DE
11.
Temperature Limiting Control :
This heater is equipped with a manual reset control. In case of a malfunction of
the unit (blocked air output or intake, for example) the heater will stop
heating automatically. After correcting the malfunction the heater can be reset.
To restart the heater, push the button on the upper back panel of the heater.

SERVICE CENTERS
Contact CONVECTAIR to find closest service center:
• Toll-free : 1 800 463-6478
• Website : www.convectair.com
WARRANTY INFORMATION
2 years against all defects / 5 years on the heating element.
All CONVECTAIR heaters are subjects to a double warranty: 2 years on all parts and
manufacturing defects and 5 years on the heating element itself.
Warranty is applicable from date of purchase by the customer and under certain spe-
cific conditions. All details are furnished with each heater. Please keep your invoices
(purchase and / or installation).
NEVER USE ABRASIVE OR ACETONE-BASED PRODUCTS TO CLEAN THE HEATER
AS THIS MAY CAUSE DETERIORATION OF THE EPOXY FINISH.
ANY REPAIR ON YOUR CONVECTAIR HEATER SHOULD ONLY BE DONE BY A
QUALIFIED TECHNICIAN AFTER DISCONNECTING THE HEATER.
MAINTENANCE INSTRUCTIONS:
To keep your unit clean, regular maintenance is suggested.
To remove dust, use a soft cloth. To remove stain, use a damp cloth.
Never use this heater during construction work or other activities that generate a lot
of dust.
For a better performance and a maximum efficiency, it is suggested that dust and
lint be regularly removed from the protective grill situated at the base of your heater.
CAUTION: Before any cleaning, make sure the power has been turned off at
the circuit breaker panel and that the heating element of the heater is cool.
NOTE: In certain cases, the grill may become yellow after a while. This phenomenon
is not due to a manufacturing defect. It is caused by the smoke or suspended particles
present in the surrounding air, heated and blown out through the grill. This coloration
can be reduced by cleaning the grill on a weekly basis.
The first time your CONVECTAIR heats, a light smoke could be released. This is normal
and should disappear after about 2 to 3 minutes.
1-800-463-6478 | [email protected] | www.convectair.ca
A BRAND OF GLEN DIMPLEX AMERICAS
