CONVECTAIR Piccolo 7831 Installation instructions

!"#
!""#$#
!%&'())('*+%,-,
#./0('*%1,!%&'023'*+%&
!!"#!$%#&'&()*+,-./0&/)&1-&2-3/&14&-.56+-7
421AA2357 Ind.A

INTRODUCTION :
Dear owner,
- Congratulations on the purchase of this premium electric heater. CONVECTAIR develops and
produces the highest quality heating product in the electrical industry.
- To obtain the best results and the ultimate in performance and comfort, please take a moment to
read the installation , operation and maintenance instructions detailed in this manual
QUICK START GUIDE .................................................................................................. Page 3
1- SPECIFICATIONS......................................................................................................... Page 4
2- RECOMMENDED SET-UP..................................................................................... Page 4
3- INSTALLATION AND MOUNTING.............................................................. Page 5
4- ELECTRICAL CONNECTION.............................................................................. Page 7
5- OPERATING INSTRUCTIONS........................................................................... Page 9
6- OVERHEAT CONTROL........................................................................................... Page 10
7- MAINTENANCE.. ........................................................................................................ Page 10
8- TROUBLESHOOTING ............................................................................................. Page 11
9- IDENTIFICATION OF YOUR HEATER ......................................................... Page 11
10- WARRANTY INFORMATION ........................................................................ Page 11
TABLE OF CONTENTS
WARNING :
Your heater is already equiped with a precise electronic thermostat. It must not be
connected to a wall thermostat.
!

- QUICK START GUIDE -
Electrical requirements : 240 V
Installating and connecting the heater
To turn the heater ON or OFF
To set the temperature
Fast heat
Trouble shooting page 10
To contact Convectair : see page 10
See pages 6 and 7.
See pages 5, 6 and 7.
Press the switch briefly
Set the temperature dial at the comfort zone. Wait for the temperature to stabilize.
Adjust up or down for the required comfort level (see page 8).
With the heater ON, press the button.
On/Off indicator
On/Off switch
ermostat adjustment
Accelerated heat ventilation
button (30 minutes)
Accelerated heat ventilation indicator
Comfort zone
Heating indicator
Fig. 1
"!

SPECIFICATIONS
- Your new PICCOLO is a fan heater partially enclosed.
- is heater is equipped with 2 fan forced heat levels : 750W regulated with the electronic
thermostat and 1500W accelerated heat on demand for 30 minutes.
- Minimum obstruction and designed to heat your room quietly, consistant heat, it is a per-
fect heater for your bathroom or other intermittant rooms.
- Your PICCOLO can be used with the optional CONVECTAIR Programmer Module (pilot
wire) allowing scheduled temperature set-backs in periods of prolonged absence providing
the same comfort and more savings.
READ CAREFULLY : :
These instructions are essential to install and use your new PICCOOLO safely.
!RECOMMANDED SET-UP
- Your heater must be installed in accordance with national and local codes and CONVECTAIR
recommends an installation by a qualified electrician.
- Your heater must be installed so that the control panel is out of reach from anyone in the
bath-tub or in the shower. Do not install over a bath-tub or spa.
- Do not install the heater behind a door, furniture or others obstacles, or in front of an airex-
haustvent. Keep combustible materials such as curtains, away from the heater.
- Your heater is equipped with a heating element that may reach high temperatures. Do not
install or operate in the presence of gasoline, paint solvents or other flammable products.
- Maintain the minimum required clearances ( height from floor, distances from side walls or
furniture, drapes, etc).
#!

"INSTALLATION AND MOUNTING
- Identify where you want to install the heater, providing sufficient clearance around the unit
(Fig.2).
- e PICCOLO heater is partially enclosed and clearance restrictions must be respected (Fig.
2).
e heater should be installed no lower than 30 cm (12 in.) from the floor. Leave a minimum
clearance of 10 cm (4 in.) on each side of the heater, 20 cm (8 in.) and 60 cm (24 in.) in front for
a proper air circulation.
- Clear a rectangular opening of 37.2 cm (143/5 in.) high, 31.5 cm (123/8 in.) wide and 8,5 cm (33/8
in.).Deep between the dreams of the wall (Fig. 3).
- Make sure that the electrical wires (and the pilot wire if needed) come out of the top left corner
of the wall opening (Fig.3).
- The heater can be dismantled in 3 pieces (Fig.3) :
the front facade (1), the ventilation block and panel
controls (2) and the built-in (3).
To dismantle the heater :
- Take off the facade by removing the 2 screws located
on the panel control and the 2 screws located at the
bottom of the facade (Fig. 4).
- Take off the ventilation block by removing the 2
screws (Fig. 5, A) and slide the ventilation block to
click the hooks (Fig. 5, B).
$!
Electrical wire exit

%!
- Before placing the inner junction box inside the wall opening, remove the knock out and
pass the electrical wires (Fig.6), and the pilot wire if needed, using an appropriate bushing
( not include).
- Insert the inner box and secure it to the wall having taken into account the reassembly of the
facade. Indeed, leave approximately 3 mm (1/8“) between the wall and the upper fold of the
inner box to facilitate the assembly of the facade (see Fig. 7a et 7b).
.
.
Power cable
wall
Facade
Inner
Box Screw
Screw

- Insert and hook the ventilation block and the protocol panel inside the inner box. Secure the
ventilation box with 2 screws (Fig.5).
- Connect the electrical wires ( see chapter 4 - connexion, page 7).
- When remounting the front facade, please make sure that the low small strip of the facade
(Rep.A) amounts down of the deflector of ventilation block (Rep.B), and this to guarantee
optimal performances.
- Place and hook the facade using the inner box
crease. Secure the control panel using 2 screws
and then secure the facade with 2 screws (Fig.4).
WARNING : Do not pinch wires when closing
the facade.
- Afix the control panel sticker provided in the
bag (Fig.8) and put the control wheel in place.
&!
BAD GOOD

#ELECTRICAL CONNEXION
- CONVECTAIR recommends that your heater be installed by a qualified
electrician and in accordance with national and local codes.
- To prevent short circuits and electrical shocks turn the power off at the main
panel before attempting the installation or making any repairs.
- If the power cable is damaged it must be replaced by the manufacturer, an
approved service depot or a technician with similar qualifications to avoid any danger.
- e connection of the heater must be done inside the inner box on the left side
of the control panel. Connect the wires using the wire connectors provided in the
bag (Fig.9).
CAUTION :
is heater must be connected to a 240 Volt (60 cycles) circuit.
- Disconnect the power supply before making wiring connections to prevent
electrical shock and equipement damage. If you are using a programmer system,
make sur to cut the power off ALL electrical heating circuits in the home (for more
information, see the CONVECTAIR model 7392 installation notice).
!
RESPECT WIRE COLOR WIRING
- You must connect the ground wire of the heater ( Green /
Yellow) with the copper wire.
- e purple wire with the seal at the extremity should not
be used for the electrical connexion.
- e purple wire is used only if the heater is connected with
the CONVECTAIR central programming system.
'!

$OPERATING INSTRUCTIONS
On/Off indicator
On/Off switch
ermostat adjustment
Accelerated heat ventilation
button (30 minutes)
Accelerated heat ventilation indicator
Comfort zone
Heating indicator
e electronic controls have been designed to achieve maximum savings.
- Once the heater is on, set the temperature dial at the comfort zone.
- Close the doors and windows the room where the heater is located. Let the temperature
stabilize for an hour.
- If the temperature is not quite right, adjust the thermostat dial up or down by half a mark.
- Let the temperature stabilize for another hour before checking again and repeat if necessary
(with a quarter adjustement this time).
- Once the thermostat is set at the desired comfort setting, do not touch the thermostat dial.
To turn the heater off, use the On/Off switch. To briefly raise the temperature, use the accele-
rated heat ventilation button.
Accelerated heat
When activating the accelerated heat, the Piccolo provides temporarily 1500W, allowing to warm
more quickly the room.
- When the heater on, press the accelerated heat ventilation button to obtain 1500W for a 30
minutes duration. The accelerated heat ventilation indicator turns on.
- To revert to standard operating mode, press the accelerated heat ventilation button.
- When the accelerated heat ventilation cycle is finished, the heater resumes normal heating mode
(750W).
(!

%OVERHEAT CONTROL
- is heater is equipped with overheat controls. In case of a malfunction of the unit (blocked
air output or intake, for example) the heater will stop heating automatically. After correcting
the malfunction the heater can be reset.
To restart the heater:
- Turn the heater off and turn its power supply off. Check that the front outlets are free of
obstruction. Wait 5 minutes and turn the heater back on.
If no heat is generated, call your electrician or the nearest CONVECTAIR repair center.
MAINTENANCE
%
&
- To keep your CONVECTAIR unit clean, regular maintenance is suggested. To remove dust,
use a soft cloth. To remove a stain, use a damp cloth. For a better performance and maximum
efficiency, it is suggested that dust and lint be regularly removed from the protective grill
situated at the back of your PICCOLO.
NEVER USE ABRASIVE OR ACETONE-BASED PRODUCTS TO CLEAN YOUR HEATER AS THIS
MAY DETERIORATE THE EPOXY FINISH.
!"#$%&'()$'*)+$&'%"'$',")%&!-
Your CONVECTAIR heater will become hot when in use. Caution is advised when young children are present.
Do not insert small objects in the heater : this could cause an electrical short circuit, fire or damage to the
inner components.
Any use or modifications not approved by CONVECTAIR may cause electrical short circuits, fire or injuries to
the users.
In certain cases, it is possible for yellowing of the surface to occur over time. is is not due to a manufacturing
defect.is is caused by surrounding air, which may contain smoke or dust, being heated and circulated
through the heater.
Prevention : it is suggested that surfaces be frequently cleaned especially with units installed in
locations where cigarette smoke is present or in the kitchen. Never use this heater during construction
work or other activities that generate a lot of dust.
ANY REPAIR ON YOUR CONVECTAIR HEATER SHOULD ONLY BE DONE BY A QUALIFIED TECHNICIAN,
AND ONLY AFTER HEATER HAS BEEN DISCONNECTED.
)*!

2 years against all defects / 5 years on heating element.
All CONVECTAIR heaters are subjects to a double warranty : 2 years on all parts and
manufacturing defects and 5 years on the heating element itself.
Warranty is applicable from date of purchase by the customer and under certain specific
conditions. All details furnished with each heater. Please keep your invoices (purchase and/or
installation).
REPAIR CENTER :
Contact CONVECTAIR to find closest repair center.
– Toll-free : 1-800-463-6478
– Website : www.convectair.ca
'TROUBLESHOOTING
Before calling your electrician, please go through these simple checks :
1- Make sure the breaker in the distribution panel is in the «ON» position.
2- Check that the On/Off switch is on.
3- Activate the accelerated heat ventilation.
4- If no heat is emitted, check the overheat protection (see section 6, p.9)
5- If the light is still off, and no heat is generated, call your electrician or the nearest
CONVECTAIR repair center.
(IDENTIFICATION OF YOUR HEATER
IMPORTANT : Product information appears on the heater’s identification label.
e identification label is located on the inside of the heater (visible throught the superior
opening of the facade).
It includes :
- e complete model number and its
production reference number (A) that
must be included in any warranty claim.
- Capacity (B).
- Standard certification (C).
) WARRANTY INFORMATION
