Cooke & Lewis CLGH3SS-C User manual

Barcode 5052931055739
FR
GB IE
CLGH3SS-C GB_FR v4d
CLGH3SS-C

[08] x 4
[06] x 1
[01] x 1
[07] x 4
[09] x 1
[10] x 4
[11] x 1
[05] x 2
[02] x 1
[03] x 2
[04] x 1
TEMPLATE
TEMPLATE

3
GB IE Built-in Gas Hob 05
FR Table de cuisson gaz encastrable 25
Installation
Installation 46
CLGH3SS-C

4
GB IE
Let's
get started...
Getting started... 05
Before you start 06
Safety 07
In more detail... 09
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Technical and legal information
Guarantee
CE Declaration of conformity
10
10
13
15
15
16
22
24
Appendix
46
Installation

5
Getting started...
GB IE
Before you start 06
Safety 07

6
Getting started...
GB IE
Before you start
Tools required
Before you start
To avoid the risks that are always present when you use
an electrical appliance it is important that this appliance is
installed correctly and that you read the safety instructions
carefully to avoid misuse and hazards. Please keep this
instruction booklet for future reference and pass it on to any
future owners. After unpacking the appliance please check
that it is not damaged. If in doubt, do not use the appliance
but contact Customer Services on 0844 800 1128 (UK),
1 800 535542 (Ireland) and 01 56 48 02 60 (France).
Check the package and make sure you have all of the parts
listed.
Decide on the appropriate location for your product.
If this product contains glass please take care when tting
or handling to prevent personal injury or damage to the
product.
The specications plate is available on this appliance. This
plate displays all the necessary identication information for
ordering replacement parts.
If you sell the appliance, give it away, or leave it behind
when you move house, make sure you also pass on this
manual so that the new owner can become familiar with the
appliance and its safety warnings.
SILICONE

7
Getting started...
GB IE
Safety
These instructions are for your safety. Please read through
them thoroughly prior to installation and retain them for
future reference.
This appliance complies with all current European safety legislation,
however, the Manufacturer must emphasise that this compliance does
not prevent the surfaces of the appliance from heating up during use and
remaining hot during its operation.
Accessible parts may become hot during use. Young children should be kept
away. Care should be taken to avoid touching the appliance (e.g hob, cooker).
The Manufacturer highly recommends that this appliance be kept out of the
reach of babies and small children.
Children should be supervised to ensure that they do not play with the
appliance.
This appliance is not intended for use by persons (including children) with
reduced physical sensory, or mental capabilities, or by those who lack
experience and knowledge, unless they have been given supervision and
instruction concerning the use of the appliance by a person responsible for
their safety.
Means for isolating the appliance must be incorporated in the xed wiring
in accordance with the current wiring regulations. An all-pole disconnection
switch having a contact separation of at least 3 mm in all poles should be
connected in xed wiring.
Damaged power cables should be replaced by a competent person or
qualied electrician.
Make sure that the power cord is not caught under or in the appliance and
avoid damage to the power cable.
Do not allow the electric cables to touch the hot parts of the appliance.
Do not install the appliance outdoors in a damp place or in an area which
may be prone to water leaks such as under or near a sink unit. In the event
of a water leak allow the machine to dry naturally.
Please dispose of the packing material carefully.
Do not use ammable sprays in close vicinity to the appliance.
• All installation work must be carried out by a
competent person or qualied electrician.
• This appliance must be installed correctly by a
suitably qualied person, strictly following the
manufacturer’s instructions.

8
Getting started...
GB IE
Safety
We also recommend that great care be taken during use and cleaning.
Read the cleaning and maintenance sections for this appliance carefully.
A steam cleaner is not to be used.
The appliance is not intended to be operated by means of external timer or
separated remote-control system.
The appliance is for domestic use only.
When a cooking zone has been on for a long time, the surface remains hot
for some time afterwards so do not touch the metal surface.
Do not store detergents or ammable materials beneath the hob.
Do not leave hot oils or fats unattended as they may catch light.
The Manufacturer declines all liability for personal or material damage as a
result of misuse or incorrect installation of this appliance.

9
In more detail...
In more
detail...
GB IE
Product functions 10
Operation 10
Care and maintenance 13
Troubleshooting 15
Recycling and disposal 16
Technical and legal information 16
Guarantee 22
CE Declaration of conformity 24

10
GB
IE
In more detail...
GB IE
Operation
1
2
4
A B C D
E F
EB
D
F
A C
Product functions
• 4 x Burners: Four zones of cooking.
• Flame safety device (FSD): Stops the gas supply to the gas hob
when the ame goes out.
• Auto - ignition
• LPG conversion kit supplied.
Control elements
Reference Description Qty Reference Description Qty
A Left Pan Support 1 D Semi-rapid burner 1
B Semi-rapid burner 1 E Rapid burner 1
C Right Pan support 1 F Auxiliary burner 1
Note: This diagram may be slightly different from the layout of the appliance.

11
In more detail...
GB IE
Operation
Caution
• If there is no electric current you can light the burners with
piezo electric spark gas ignitor.
• The burners can only be lit with safety thermocouples when
the knob is on MAXIMUM.
g. 4
g. 5
Operation
Use of the burners
On the control panel (g. 4) to the right every knob there is a diagram to
indicate the burner to which the knob in question refers. The burners can
be switched
on in several ways, according to the type of appliance and its
individual features.
> Manual “ON” switch (this is always possible
even if the electric current is off):
• Turn the knob (g. 5) corresponding to the
selected burner in a counter-clockwise
direction so that the knob is at MAXIMUM
(this corresponds to a large ame).
• Use a piezo electric spark gas ignitor.
> Automatic electric “ON” switch for burners with safety device
(thermocouples):
• Turn the knob (g. 5) corresponding to the selected burner in a
counter-clockwise direction so that the knob is at MAXIMUM.
• Once the burner is lit, keep the knob pressed in for about 10 seconds
in order to allow the ame to heat up the thermocouple. If the burner
goes out when the knob is let go, repeat the operation.

12
GB
IE
In more detail...
GB IE
Operation
NOTE:
> The use of a gas cooking appliance produces heat and humidity in the
place where it is installed.
> Therefore, you need to ensure the place is well ventilated, keeping the
natural ventilation openings clear and using a mechanical ventilation
device/ ue or electric fan.
> Intensive or prolonged use of the appliance may require additional
ventilation, such as opening a nearby window or increased ventilation
efciency obtained by increasing the power of the mechanical ventilators,
where applicable.
Advice for the best use of the burner:
> When boiling point is reached, turn the knob to MINIMUM.
> Always use pans with a lid.
Burner Recommended pan diameters (cm)
Auxiliary 12-14
Semi-rapid 14-26
Rapid 18-26

13
In more detail...
GB IE
Care and maintenance
Appliance cleanliness
> The appliance should be cleaned after use.
> Wipe the inner and outer surface of the appliance and its accessories
with wet cloth.
> Any liquid overowing from the pan must always be removed with
a cloth.
> The surface of the hob may be easily cleaned as follows:
Cleaning of enamel parts:
To maintain the features of the enamel parts, wash frequently with soapy
water.
Never use abrasive powders. Avoid leaving acid or alkaline substances on
the enamel parts (vinegar, lemon juice, salt, tomato juice, etc.) and washing
the enamel parts while they are still warm.
Cleaning of stainless steel parts:
Wash these parts with soapy water and then dry them with a soft cloth.
The shine is maintained by regularly cleaning them with special products
normally commercially available. Never use abrasive powders.
Cleaning of burner ame dividers:
Given that they are not xed, the ame dividers can be cleaned by
simply removing them and washing them with soapy water. After drying
them well and checking that the holes are not blocked, put them back
into their correct position.
Warning
Always switch off the electricity supply before
performing maintenance work. In the event of a fault,
contact customer services.
Caution
• Use soapy water and a cloth for cleaning. Never
use abrasive powders.
• Avoid banging pots and pans down on the hob.
• Do not leave any empty pan on the heating zone.
FUSE
OFF

14
GB
IE
In more detail...
GB IE
Replacement of parts
Warning
Always switch off the electricity supply before
performing maintenance work. In the event of a fault,
contact customer services.
Care and maintenance
FUSE
OFF

15
In more detail...
GB IE
Troubleshooting
The following circumstances may not be a problem. Do not contact the
customer services until the problem has been conrmed.
If your appliance is still not functioning properly after making the above
checks, please contact customer services.
1. Check that the mains supply has not been switched off.
2. Check that the fuse in the spur has not blown.
3. Ensure that the burner components are not excessively soiled as
this can lead to ignition problems.
Do not take the appliance apart yourself, as you may damage the hob.
Before calling After Sales Service, please do the following:
1. Check that the appliance is correctly connected.
2. Read the failure text above. If you are still unable to solve the
problem, switch off the appliance, do not try to take it apart
and call customer services.
Troubleshooting
Recycling and disposal
Environmental protection
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with
your Local Authority or retailer for recycling advice.
The symbol on the product or its packaging indicates
that this product cannot be treated as normal
household waste. This product must be handed over to
an electric and electronic equipment collection point for
recycling.
On ensuring that this product is disposed of correctly, you will help
to avoid possible negative consequences for the environment
and public health, which could occur if this product is not handled
correctly. To receive more detailed information about recycling this
product, contact your local government, domestic waste disposal
services or the outlet where the product was bought.

16
GB
IE
In more detail...
GB IE
Technical data
Power supply V / Hz 220-240 V~/ 50 Hz
Gas pressure Type / mbar / kW G20 / 20 / 7.16
G30 / 28 / 7.06
External dimensions (WxHxD) mm 580 x 50 x 500
Net weight kg 7.7
Technical and legal information
USER CHARACTERISTICS
GAS BURNERS TYPE PRESSURE INJECTORS CONSUMPTION THERMAL
CAPACITY
NOMINAL
mbar 1/100mm g/h l/h Kw Kcal/h
Auxiliary G20 20 72 - 95 1.0 860
G30 28 50 66 - 0.9 774
Semi Rapid G20 20 97 - 179 1.88 1617
G30 28 68 137 - 1.88 1617
Rapid G20 20 110 - 190 2.4 1720
G30 28 78 146 - 2.4 2064
Triple ring G20 20 115 - 271 2.85 2451
G30 28 91 248 - 3.4 2924

17
In more detail...
GB IE
All installation work must be carried out by a
competent person or qualied electrician.
Before connecting the mains supply ensure that
the mains voltage corresponds to the voltage on
the rating plate inside the cooker hood.
Warning: THIS APPLIANCE MUST
BE EARTHED.
Mains Supply could be connected to the Mains Voltage by Direct
Connection
Direct Connection
If the appliance is being connected directly to the mains an
omnipolar circuit-breaker must be installed with a minimum
opening of 3mm between contacts.
If the cable is damaged or to be replaced, the operation must be
carried out the by a qualied electrician with dedicated tools to
avoid any accidents.
The installer must ensure that the correct electrical connection has
been made and that it complies with wiring diagram.
The cable must not be bent or compressed.
The cable must be checked regularly and replaced by authorized
technicians only.
Technical and legal information
DOUBLE POLE SWITCHED
FUSED SPUR OUTLET
USE A 3AMP FUSE
FUSEON
EUR UK
USE A 13AMP FUSE

18
GB
IE
In more detail...
GB IE Technical and legal information
Electrical Requirements
Any permanent electrical installation must comply with the latest
I.E.E. Regulations and local electricity company regulations. For
your own safety a qualied electrician or contractor who is on the
roll of the National Inspection Council for Electrical Installation
Contracting (NICEIC) should undertake the electrical installation.
Electrical Connection
Before connecting the mains supply ensure that the mains
voltage corresponds to the voltage on the rating plate inside
the appliance.
WARNING: THIS APPLIANCE MUST BE EARTHED
The appliance is supplied with a 3-core mains cable and must be
connected to the electricity supply via a double pole switch having
a 3mm minimum contact gap on each connector.
For UK only
A Switched Fused Connection Unit to BS 1363 Part 4 is
recommended.
The fuse must be rated at 13 Amps.
The wires in the mains lead are coloured in accordance with the
following code:
Brown = L - Live
Blue = N - Neutral
Green/Yellow = - Earth
The connection point must be placed in a position adjacent to the
appliance so as to be readily accessible for an engineer in the
event of a breakdown.
Disconnect the appliance from the mains supply before
carrying out any kind of maintenance or cleaning.

19
In more detail...
GB IE
Installation Guidelines
Gas Supply Requirements (UK and ROI)
This installation must comply with the Gas Safety Regulations 1984.
The connection to the gas supply must comply with all current
regulations in force.
We are not legally able to offer advice on the installation of gas
appliances to non Gas Safe registered personnel.
Ventilation
All rooms require a window or equivalent (e.g. a door) which can be
opened. Some rooms require a permanent vent or extractor in addition
to a window (see below).
This unit must not be used in a room which is less than 5m3.
The following table details the requirements based on the kitchen
volume (L x W x H) in m3.
The above requirements also allow use of a gas oven and grill but if
there are any other fuel burning appliances in the same room, consult
the relevant British Standard (BS5440) or Gas Safe manual.
The above requirements also allow use of a gas oven and grill but if
there are any other fuel burning appliances in the same room, consult
the relevant British Standard (BS440) or Gas Safe document.
What you should do if you smell gas?
Switch off the gas supply
Open doors and windows
Call Transco 0800 111 999
Room Volume (m3)Air vent required (cm3)
5 100
6 to 10 50
6 to 11 No permanent vent required if a
door opens to the outside
11 or more None required
Technical and legal information

20
GB
IE
In more detail...
GB IE
Technical and legal information
Gas connection
Changing the nozzles
NOTE: The LPG nozzles are provided in a separate bag marked “LPG” and
if they are changed and the natural gas jets retained then the label should be
changed to “NATURAL”.
Lift up the burners and unscrew the nozzle using an dedicated tool and
replace the nozzles with those designed for LPG gas supply.
Caution
The hob installation and burner changes must be
carried out by a competent person. ie a Gas Safe
registered tter.
02
[08] x4
x1 [08]
01
[09] x1
x1
[09]
