Cooke & Lewis CLIND60ERF User manual

23 4 5
1
This file is the property of Kingfisher Group Plc. No copying, alteration or amendment ispermitted without
written authorisation from the Kingfisher Brand Team.
V1.1
PROCESS
BLACK
SEPARATIONS JOB INFO
VERSION #
24/02/20
Mohit
30/03/20
Deepak
01/09/18
Name
01/09/18
Name
01/09/18
Name
PLEASE NOTE THAT “SAFETY” AND “ASSEMBLY”
MANUALS SHALL BE PRINTED SEPARATELY
DO NOT PRINT THIS PAGE -
IT IS FOR INFORMATION ONLY
PID #: 00001
Agency Job #: GLOA11651
Induction Hob CLIND60RF_SM
Brand: Cooke & Lewis
Brand Contact: [email protected]
Barcode: 3663602553069
Vendor: Xxxxxxxxxxxxxxxxxxxxxx
No. of New Line Drawings: xx
Page Size: A5 / No. of Pages: 96
7
Artwork done by Impala Services Ltd
[email protected]
202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 1202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 1 30-03-2020 19:51:2130-03-2020 19:51:21

V10320
CLIND60ERF
5059340093833 5059340093840
202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 2202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 2 30-03-2020 19:51:2130-03-2020 19:51:21

3
These instructions are for your safety. Please read the following
instructions carefully before proceeding with the installation and
use of this appliance.
RWARNING: Refer to the section “Installation” of the instruction manual
for proper installation of the product to prevent any safety hazard.
RWARNING: All installation work must be carried out by a suitably
qualied person, strictly following local building regulations and
these instructions.
RWARNING: Read the instructions before using the appliance.
RTo avoid the risks that are always present when you use an electrical
appliance it is important that this electric hob is installed correctly and
that you read the safety instructions carefully to avoid misuse and
hazards. After unpacking the electric hob please check that it is not
damaged. If in doubt, do not use the appliance but contact Customer
Services on 0800 324 7818 (UK) and 1-800 932 230 (Eire).
RCheck the package and make sure you have all of the parts listed
and decide upon the appropriate location for your product.
RIf this product contains glass please take care with tting or handing
to prevent personal injury or damage to the product.
RThe specication plate shown on this appliance displays all the
necessary identication information for ordering replacement parts.
RIf you sell the appliance, give it away, or leave it behind when you
move house, please ensure that you pass on this manual so that
the new owner can become familiar with the appliance and its
safety warnings.
RWARNING: Before connecting the hob, check that the supplied
voltage and frequency match with that indicated on the appliance
rating plate.
Checking instructions
Safety
202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 3202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 3 30-03-2020 19:51:2130-03-2020 19:51:21

4
RFailure to install the appliance in accordance with these instructions
may result in a safety hazard.
RIf in doubt, ask for advice in store or from a qualied installer.
RWARNING: Consult local regulations regarding extraction outlets
and ensure these are complied with.
RWARNING: This appliance can be used by children aged from
8 years and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Keep the appliance and its supply cord out of the reach of children
less than 8 years old.
RDo not use inappropriate child safety shields or hob guards. These
can cause accidents.
RDo not use covers. These can cause accidents or overheating and
damage to the electric hob.
RWe recommend that great care be taken during use and cleaning.
Read the cleaning and maintenance sections of this appliance
carefully.
RRisk of electric shock! Do not use any high pressure cleaners or
steam cleaners, which can result in an electric shock.
RDanger of burns! The hotplates and surrounding area become very
hot. Never touch the hot surfaces. When a cooking zone has been
in use, the surface remains hot for some time afterwards. Be careful
not to touch the hot surface and not to place any objects on it.
RAfter use, switch o󰀨 the hob element its control and do not rely on
the pan detector.
RMetallic objects such as knives, forks, spoons and lids should not
be placed on the hob surface since they can get hot.
RNever use water to put out burning oil or fat. Switch o󰀨 the hotplate.
Extinguish ames carefully using a re blanket.
202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 4202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 4 30-03-2020 19:51:2130-03-2020 19:51:21

5
RRisk of re! The hotplates become very hot. Never place
combustible items on the hob.
RNever store objects on the hob.
RRisk of re! Do not use ammable sprays in close vicinity to the
appliance.
RRisk of re! Do not store detergents or ammable materials
beneath the hob.
RThis appliance is intended for domestic use only. The appliance
must only be used for the preparation of food and drink.
RThe appliance must be supervised during operation. Only use this
appliance indoors.
RThe manufacturer declines all liability for personal or material
damage as a result of misuse or incorrect installation of this
appliance. Please dispose of the packing material carefully.
RRisk of injury! Saucepans may suddenly move due to liquid
between the pan base and the hotplate. Always keep the hotplate
and saucepan bases dry.
RWARNING: There is a risk of electric shock and re if cleaning is
not carried out in accordance with these instructions.
RWARNING: Use only the same size of ttings and mounting screws
as recommended in this instruction manual. Failure to follow these
instructions may result in electrical hazards.
RWARNING: Switch o󰀨 the appliance at the mains supply before
carrying out any maintenance work.
RWARNING: Accessible parts may become hot when used with
cooking appliances. Children less than 8 years of age shall be kept
away unless continuously supervised. Care should be taken to
avoid touching the appliance.
RWARNING: Means for full disconnection must be incorporated in
the xed wiring in accordance with the local wiring installation rules
for your country. An all-pole disconnection switch having a contact
separation of at least 3 mm in all poles should be connected during
installation.
202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 5202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 5 30-03-2020 19:51:2130-03-2020 19:51:21

6
RWARNING: Only clean the hob when it has cooled down su󰀩ciently.
When the power to the cooktop is switched o󰀨, there will be no
residual heat indication but the cooking zone may still be hot. Take
extreme care!
RWARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in re. NEVER try to extinguish a re with
water, but switch o󰀨 the appliance and then cover ame e.g. with a
lid or a re blanket.
RCAUTION: The cooking process has to be supervised. A short term
cooking process has to be supervised continuously.
RWARNING: Danger of re: do not store items on the cooking
surfaces.
RWARNING: Use only hob guards designed by the manufacturer
of the cooking appliance or indicated by the manufacturer of the
appliance in the instructions for use as suitable or hob guards
incorporated in the appliance. The use of inappropriate guards can
cause accidents.
RWARNING: If the surface is cracked, switch o󰀨 the appliance to
avoid the possibility of electric shock.
RThe appliance is not intended to be operated by means of an
external timer or separate remote-control system.
RIf the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in
order to avoid a safety hazard.
IMPORTANT:
● Heavy-duty scourers, some nylon scourers and harsh/abrasive
cleaning agents may scratch the glass. Always read the label to
check if your cleaner or scourer is suitable.
●Never leave cleaning residue on the cooktop: the glass may
become stained.
●The appliance is for domestic use as a cooking device; do not use
as a source of heat.
202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 6202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 6 30-03-2020 19:51:2130-03-2020 19:51:21

7
IMPORTANT
This hob can be plugged directly into a mains power outlet using the 3 pin (UK) or
2 pin (EU) plug supplied.
Plugged Version (Factory Supplied - Maximum Input 2800W)
5059340093833 5059340093840
Permanently Wired Version (Professional Fit Only - Maximum Input 6400W)
Note: The electrical cable required for conversion to permanent wiring is not
supplied.
If you use the hardwired version, the appliance must be connected directly to the
mains using an omnipolar circuit breaker with a minimum opening of 3 mm between
the contacts.
The installer must ensure that the correct electrical connection has been made and
that it complies with the wiring diagram.
The cable must not be bent or compressed.
Regularly check the the mains connection and power cord for damage. If the supply
cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a safety hazard.
WARNING: This is a Class I appliance and MUST be earthed.
Brown = L or Live
Blue = N or Neutral
Green and Yellow = E or Earth
Electrical Installation
CAUTION: THE FOLLOWING SECTION IS FOR PROFESSIONAL
QUALIFIED ELECTRICAL INSTALLERS ONLY!
202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 7202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 7 30-03-2020 19:51:2130-03-2020 19:51:21

8
L2
L
L
(Brown/Black)
220-240V~50Hz
(Green/Yellow)
N
N
(Blue/Grey)
Brown
Black
Blue
Grey
N2 N1 L1
This appliance requires a 32 Amp Miniature Circuit Breaker when operating in
high power mode.
To avoid the risks that are always present when you use an electrical appliance it
is important that this appliance is installed correctly and that you read the safety
instructions carefully to avoid misuse and hazards. Please keep this instruction
booklet for future reference and pass it on to any future owners. After unpacking the
appliance please check that it is not damaged. If in doubt, do not use the appliance
but contact Customer Services.
The manufacturer declines all liability for damage caused to persons and objects
due to incorrect or improper installation of the appliance. Any permanent electrical
installation must comply with the latest wiring regulations applicable to your country
and for your own safety a qualied electrician or contractor should undertake the
electrical installation.
When connected to a mains outlet using the factory tted plug, the software will limit
the hob maximum power to 2800W. Once congured as a permanent installation,
the maximum power output is 6400W.
CONVERSION TO PERMANENT WIRING
CAUTION: THE FOLLOWING SECTION IS FOR PROFESSIONAL
QUALIFIED ELECTRICAL INSTALLERS ONLY!
202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 8202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 8 30-03-2020 19:51:2130-03-2020 19:51:21

9
REPLACING THE CABLE
1. Remove the screw and terminal cover.
2. Remove the factory tted cable and replace it with the correct grade for the
permanent installation as per the connection diagram above.
WARNING: DO NOT CONVERT THE HOB TO HIGH POWER WHILST STILL
CONNECTED WITH THE FACTORY FITTED CABLE AND PLUG.
ENSURE THE CABLE CONVERSION HAS BEEN COMPLETED BEFORE
PROCEEDING TO THE SOFTWARE CONFIGURATION.
FAILURE TO DO THIS THIS WILL DAMAGE THE HOB AND INVALIDATE YOUR
WARRANTY!
202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 9202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 9 30-03-2020 19:51:2230-03-2020 19:51:22

10
SOFTWARE CONFIGURATION
1. Turn on the hob using the ON / OFF
key. The hob will show “-” on each
cooking zone.
2. Touch the front left zone key and the
Timer key together for three seconds.
The hob will beep and show “5” in the
timer display.
3. Touch the Timer key once and the
display will change to “5E”.
4. Touch the front left zone key and the
Timer key again and the two front
zones will indicate “2” and “8”. This is
the factory setting of 2800W.
5. Touch the front left zone key to
switch the display to “6” and “4”. This
indicates high power at 6400W.
6. Touch the Timer key again to nish
conguration.
Note: If required, the hob can be converted back to a plugged version by following
the cable conversion and software steps above again.
202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 10202161_s1_s2_CLIND60ERF_SM_Cooke & Lewis_A5_IM_Multi_V02.indb 10 30-03-2020 19:51:2330-03-2020 19:51:23
