Cooper Lighting GPF15SPW764 User manual

142 STREETWORKS Outdoor Lighting Solutions Cooper Lighting
NOTE: 1 Refer to technical section for lamp/ballast/voltage compatibility. 2250/400W, 400/250W MH, HPS, and 400W MH only. 31000W only. 4Available in MH only. 1000W requires reduced envelope lamp. 5Available in HPS
only. 6Not available in 1000W. 7MOV option is not available for any system requiring a three position terminal block (Example—120/240V incoming line). In order for MOV option to function center terminal of three position
terminal block must be connected to “Earth” ground. 8400W or below, except for 400W Mag. Reg.
LATCHES
Formed aluminum flush
draw-action latches offer easy
access to lamp compartment
without tools.
HOUSING
Aerodynamically designed,
architecturally styled die-cast
aluminum housing. Standard dark
bronze polyester powder finish.
Other finish colors available.
Consult your Streetworks
Representative. ANSI
wattage/source label. Optional
NEMA twistlock photocontrol
receptacle.
DOOR
Spring-loaded die-cast aluminum
door with integral cast hinges for
removal without tools. Door gasket
is closed-cell silicone, providing
maximum protection of interior
components from the elements.
LENS
Heat- and impact-resistant
tempered glass lens.
REFLECTOR
Computer designed precision
formed reflector system delivers
superior beam control and
efficiency.
BALLAST
Ballast components are hard
mounted to fixture housing for
maximum heat dissipation and
extended component and lamp life.
Plastic terminal block. Prewired
with 3' 14/3 STWA cord.
MOUNTING
Heavy-duty steel yoke provides flex-
ibility in mounting to a variety of
surfaces. Slipfitter for 2 3/8" to 3"
O.D. tenon and trunnion mount also
available.
ORDERING INFORMATION
SAMPLE NUMBER: GPF15SPW764
SLIPFITTER, YOKE, OR TRUNNION-MOUNTED FLOODLIGHT
OPTIONS (add as suffix)
1=Single Fuse, Internally Mounted (120 or 277V)
2=Double Fuse, Internally Mounted (208, 240, or 480V)
4=Photocontrol Receptacle
BK=Black
AP=Grey
A=Captive Door Screws
C=Slipfitter 2 3/8" to 3" O.D.—cord thru housing
H=Plug-in Starter Receptacle 6
M=MOV Lightning Surge Protectors 7
R=Removable Power Tray 8
S=Slipfitter 2 3/8" to 3" O.D. with leads thru fitter
T=Trunnion Mount
U=UL/CSA Listed
W=Wall Mount
ACCESSORIES (order separately)
OA1179=Top/Bottom Visor
OA1180=Side Visor
OA1181=Wire Guard
OA1182=Vandal Shield
OA1208=TufGuard Vandal Shield
VS/NK=Vandal Shield (For Wattages Below 1000W)
VS/NK/1000=Vandal Shield (For 1000W Units)
GPF GENERAL PURPOSE FLOOD 150-1000W MH/HPS/MERCURY
FLOODLIGHTING
EPA:
Effective Projective Area: 2.7
SHIPPING DATA
Approximate Net Weight:
59 lbs. (27 kgs.)
OPTIONS + ACCESSORIES [Must be listed in the order shown and separated by a dash]
STREETWORKS™
OPTIONS +
ACCESSORIES
(See Below)
PRODUCT
FAMILY
GPF=General
Purpose
Flood
LAMP WATTAGE
15=150W
20=200W
25=250W
40=400W
75=750W
91=1000W
24=250/400
wired 250W
42=400/250
wired 400W
LAMP TYPE 1
S=High Pressure
Sodium
V=Mercury
M=Metal Halide
R=Super Metal Halide
BALLAST TYPE 1
H=Reac./HPF
N=Hi. Reac./NPF
P=Hi. Reac./HPF
R=Reac./NPF
W=CWA
C=CWI
M=Mag. Reg.
K=10KV CWA
VOLTAGE 1
2=120V
0=208V
4=240V
7=277V
8=480V
9=347V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
5T=5-Tap wired 277V2
DISTRIBUTION
76=7x6
77=7x73
12=1x24
23=2x34
24=2x45
43=4x34
44=4x45
55=5x55
62=6x24
65=6x54
OPTIONAL COLORS [Standard color is bronze, other finish colors available. Consult your Cooper Lighting representative]
BK
Black AP
Grey
B
D
E
C
AAA
B
D
E
C
B
D
C
Fixture A B C D E
Yoke (in.) 20 1/2 18 1/2 22 1/2 4
S (mm) 521 470 572 102
Trunnion (in.) 20 1/2 18 1/2 24 3/8 2 9/16 3 5/16
(mm) 521 470 619 65 84
Slipfitter (in.) 20 1/2 18 1/2 28 1/32 5 3/16 4 11/32
(mm) 521 470 712 132 110
YOKE MOUNT TRUNNION MOUNT SLIPFITTER MOUNT
NOTE: Depth Dimension: 150-400W HPS and MH, 1000W HPS 9 1/2" [241]. 1000W MH 10 1/2" [267].

STREETWORKS Outdoor Lighting Solutions 143Cooper Lighting
GPF GENERAL PURPOSE FLOOD FLOODLIGHTING
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
GPF40S76.IES
400-Watt HPS
50,000 Lumen Lamp
Tilt-45°
6
5
4
3
2
1
0
1
5 4 3 2 1 0 1 2 3 4 5
AB C ED
FOOTCANDLE TABLE
Select mounting height and read across for footcandle values of
each isofootcandle line. Distance in units of mounting height.
Mounting Footcandle Values for
Height Isofootcandle Lines
ABCDE
GPF40S76.IES / GPF40M76.IES
20' 10.00 5.00 2.00 1.00 0.50
25' 6.40 3.20 1.28 0.64 0.32
30' 4.44 2.22 0.89 0.44 0.22
35' 3.27 1.63 0.65 0.33 0.18
40' 2.50 1.25 0.50 0.25 0.13
GPF91S77.IES / GPF91M77.IES
30' 20.00 10.00 5.00 2.00 1.00
35' 14.69 7.35 3.67 1.47 0.73
40' 11.25 5.63 2.81 1.13 0.56
45' 8.89 4.44 2.22 0.89 0.44
50' 7.20 3.60 1.80 0.72 0.36
6
5
4
3
2
1
0
1
5 4 3 2 1 0 1 2 3 4 5
AB C ED
GPF40M76.IES
400-Watt MH
36,000 Lumen Lamp
Tilt-45°
GPF91S77.IES
1000-Watt HPS
140,000 Lumen Lamp
Tilt-45°
3
2
1
0
1
3 2 1 0 1 2 3
AB C ED
3
2
1
0
1
3 2 1 0 1 2 3
AB C ED
GPF91M77.IES
1000-Watt MH
110,000 Lumen Lamp
Tilt-45°
BEAM AVAILABILITY AND LAMP ORIENTATION
Distribution
Type (HxV) HPS MH Orientation
7x6 •• Vertical
6x5 Cutoff •Horizontal
6x2 •• Horizontal
5x5 Cutoff •Horizontal
4x4 •Vertical
4x3 •Vertical
2x4 •Vertical
2x3 •Vertical
1x2 •Vertical
DRILLING PATTERN FOR YOKE- AND TRUNNION-MOUNT
YOKE MOUNT TRUNNION MOUNT
3 3/4" [95mm]
1 7/8"
[48mm]
7/8" [22mm]
dia. hole
1"
[25mm]
9/16" [14mm]
dia. hole (2)
2" [51mm]
1 1/2" [38mm]
5 3/8"
[137mm]
3 1/2"
[89mm]
