144 STREETWORKS Outdoor Lighting Solutions Cooper Lighting
NOTE: 1150W units are S55 lamps. 2Refer to technical section for lamp/ballast/voltage compatibility. 3250/400W, 400/250 MH, HPS and 400W Metal Halide Only. 4175W and below. Cannot be used in combination with visor
accessory. 5Should only be used when fixture is tilted 45° or more above horizontal. 6Aluminum with thermostet acrylic enamel finish colors grey (AP), Bronze (BZ), Black (BK).
HOUSING + DOOR
Die-cast aluminum housing and
hinged & latched door assembly.
Standard finish color is grey.
Other finish colors available.
Consult your Streetworks
Representative.
ANSI wattage/source label.
Optional NEMA twistlock
photocontrol receptacle.
LENS
Thermal shock- and impact-
resistant clear tempered glass,
utilizing a foam in place gasketing.
REFLECTOR
Anodized aluminum reflector.
LAMP
Mogul-base porcelain lamp socket.
MOUNTING
Full steel yoke mounting
(prewired with 3' 16/3 STWA cord).
ORDERING INFORMATION
SAMPLE NUMBER: CFB10SR2774
SLIPFITTER-, YOKE-, OR TRUNNION-MOUNTED FLOODLIGHT
OPTIONS (add as suffix)
1=Single Fuse, Internally Mounted (120 or 277V)
2=Double Fuse, Internally Mounted (208, 240, or 480V)
4=Photocontrol Receptacle
WH=White
BK=Black
BZ=Bronze
A=Door Screws (no latches)
C=Slipfitter 2 3/8" to 3" O.D.—cord thru housing
B=Two Position Terminal Block (no cord supplied)
H=Plug-in Starter Receptacle
S=Slipfitter 2 3/8" to 3" O.D. with leads thru fitter
T=Trunnion
U=UL/CSA Listed
ACCESSORIES (order separately)
OA/RA1013=Photocontrol Shorting Cap
OA/RA1014=120V Photocontrol
OA/RA1016=105V-285V Photocontrol
OA/RA1027=480V Photocontrol
OA1197=Vandal Shield 5
OA1198=Wire Guard
OA1199=Visor 6
OA1223=TufGuard Vandal Shield
CFB UTILITY FLOOD 100-400W MH/HPS/MERCURY
FLOODLIGHTING
EPA:
Effective Projective Area: 1.3
SHIPPING DATA
Approximate Net Weight:
35 lbs. (16 kgs.)
OPTIONS + ACCESSORIES [Must be listed in the order shown and separated by a dash]
STREETWORKS™IP65 RATED
OPTIONS +
ACCESSORIES
(See Below)
PRODUCT
FAMILY
CFB=Utility
Flood
LAMP WATTAGE
10=100W
15=150W 1
17=175W
20=200W
25=250W
40=400W
24=250/400
wired 250W
42=400/250
wired 400W
LAMP TYPE 2
S=High Pressure
Sodium
V=Mercury
M=Metal Halide
R=Super MH
(horizontal only)
BALLAST TYPE 2
P=Hi. Reac./HPF
R=Reac./NPF
W=CWA
C=CWI
N=Hi. Reac./NPF
H=Reac./HPF
K=10KV CWA
VOLTAGE 2
2=120V
0=208V
4=240V
7=277V
8=480V
F=120/240 wired 120V
P=240 w/PCR wired 120V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
O=5-Tap wired 277V3
DISTRIBUTION
65=6x5
76=7x6
77=7x74
15 3/4" [400mm]
14 7/8"
[378mm]
7 1/4" [184mm]
OPTIONAL COLORS [Standard color is grey, other finish colors available. Consult your Cooper Lighting representative]
WH
White BK
Black BZ
Bronze

STREETWORKS Outdoor Lighting Solutions 145Cooper Lighting
CFB UTILITY FLOOD FLOODLIGHTING
DRILLING PATTERN FOR YOKE- AND TRUNNION-MOUNT
YOKE MOUNT TRUNNION MOUNT
3 3/4" [95mm]
1 7/8"
[48mm]
7/8" [22mm]
dia. hole
1"
[25mm]
9/16" [14mm]
dia. hole (2)
PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]
2" [51mm]
1 1/2" [38mm]
5 3/8"
[137mm]
3 1/2"
[89mm]
ACCESSORIES
OA1197 OA1198 OA1199
CFB40S76.IES
400-Watt HPS
50,000-Lumen Lamp
Tilt-45° Angle
A
B
C
D
E
01234
1
0
1
2
3
4
5
6
7
1234
CFB40M76.IES
400-Watt MH
36,000-Lumen Lamp
Tilt-45° Angle
01234
1
0
1
2
3
4
5
6
7
1234
A
B
C
D
E
FOOTCANDLE TABLE
Select mounting height and read across for footcandle values of each
isofootcandle line. Distance in units of mounting height.
Mounting Footcandle Values for
Height Isofootcandle Lines
ABC D E
CFB40S76.IES
25' 2.88 1.44 0.72 0.36 0.14
30' 2.00 1.00 0.50 0.25 0.10
35' 1.50 0.75 0.37 0.19 0.07
40' 1.12 0.56 0.28 0.14 0.06
CFB40M76.IES
25' 2.88 1.44 0.72 0.36 0.14
30' 2.00 1.00 0.50 0.25 0.10
35' 1.50 0.75 0.37 0.19 0.07
40' 1.12 0.56 0.28 0.14 0.06
