INVUETM
###
COOPER LIGHTING
AREA/ROADWAY
DIMENSIONS
• One-piece, die-cast
aluminum housing with
cast indicator mark on
backside of housing
references 5° integral
aiming marks on yoke
arm for precise vertical
aiming control
• Die-cast aluminum door
is secured with two (2)
tamper resistant recessed
stainless steel fasteners
• Lens is impact resistant
.20” tempered clear or
optional frosted
contoured glass, sealed to
the door with a one-piece
molded silicone gasket
• Heavy-duty die-cast
aluminum yoke arms
utilize a positive-lock
adjustment mechanism
for both solid attachment
and infinite aiming
• Choice of seven (7) high
efficiency optical systems.
• Die-cast aluminum base
assembly grounds yoke
arms and allows for 357˚
of horizontal rotation
• Approximate net weight:
3 lbs. (1.4 kgs.)
DESCRIPTION
PHOCUS defines the ultimate
floodlighting solution; powerful
performance, easily concealable
size and a stunningly beautiful
shape. Available in wattages up
to 150 watt T-4 Quartz Halogen.
PHOCUS is versatile in
application. Ground, wall,
ceiling, burial and remote
mounting configurations offer a
wide variety of application
alternatives to accomplish
specific design requirements.
Offering seven (7) uniquely
shaped optical distributions, plus
an array of Quartz Halogen PAR
lamps, PHOCUS is unrivaled in
it's optical versatility. An
available family of light control
accessories provides custom
cutoff solutions to meet specific
distribution requirements.
PHQ
PHOCUS FLOOD
HALOGEN
50-150W
Quartz Halogen
ARCHITECTURAL
FLOOD LUMINAIRE
NOTES: 1 T4 lamps feature a mini-can base, PAR30 lamps feature a medium screw base. 260W PAR30 halogen lamp not available in FL40 distribution. 3Custom and RAL
color matching available upon request. Consult your INVUE Lighting Systems Representative for further information. 4Add as suffix in the order shown. 5Order
separately, replace XX with color suffix. 6Specifications and dimensions subject to change without notice. 1111
FLOODLIGHTING
6 1/4"
[158mm]
7 7/8"
[201mm]
1 5/8"
[42mm]
7 3/8" [188mm] 7 3/8" [188mm]
IP66 Rated U.L. 1598 3G Vibration Tested
CSA Listed 25°C Ambient ISO 9001
Certifications
Options 4
FR=Frosted Flat Glass Lens
L=Lamp Included (Standard)
Accessories 5
VA3003-XX=Color Filter Adapter with Red Gel
VA3004-XX=Color Filter Adapter with Bright Blue Gel
VA3005-XX=Color Filter Adapter with Deep Green Gel
VA3006-XX=Color Filter Adapter with Warm Orange Gel
VA3001-XX=Top Visor
VA3002-XX=Four Sided Shield
VA3007-XX=Wire Guard
ORDERING INFORMATION
SAMPLE NUMBER: PHQ-150-HL-120-VWF-WD-DP-L
Product
Family
PHQ=PHOCUS
Quartz
Halogen
Lamp
Wattage 1
T4 Halogen
Lamps
100=100W
150=150W
PAR30 Halogen
Lamps
50=50W
60=60W
75=75W
Lamp Type
HL=Quartz
Halogen
Voltage
120=120V
Optical Systems
T4 Halogen
Lamps
NS=Narrow Spot
Axial
HNF=Horizontal
Narrow
Flood
HMF=Horizontal
Medium
Flood
HWF=Horizontal
Wide Flood
VNF=Vertical Narrow Flood
VMF=Vertical Medium Flood
VWF=Vertical Wide Flood
PAR30 Halogen Lamps
SP10=10° Spot
FL25=25° Flood
FL35=35° Flood
FL40=40° Flood 2
Mounting Options
Ground Mount
GD=Direct Ground Mount
GS=Spike Mount
Wall/Ceiling Mount
WD=Direct Wall Mount
Options &
Accessories
(See Below)
Colors (add as
suffix/must specify) 3
BK=Black
AP=Grey
BZ=Bronze
WH=White
DP=Dark Platinum
GM=Graphite
Metallic
VR=Verde Green
PHQ
Quartz Halogen-T4 100, 150W
Quartz Halogen-PAR30 50, 60, 75W
WATTAGE TABLE

INVUETM
1112 COOPER LIGHTING
DIMENSIONS
FLOODLIGHTING
• One-piece, die-cast
aluminum housing with
cast indicator mark on
backside of housing
references 5° integral
aiming marks on yoke
arm for precise vertical
aiming control
• Die-cast aluminum door
is secured with two (2)
tamper resistant recessed
stainless steel fasteners
• Lens is impact resistant
.20” tempered clear or
optional frosted
contoured glass, sealed to
the door with a one-piece
molded silicone gasket
• Heavy-duty die-cast
aluminum yoke arms
utilize a positive-lock
adjustment mechanism
for both solid attachment
and infinite aiming
• Choice of seven (7) high
efficiency optical systems
• Die-cast aluminum ballast
enclosure. Wiring
compartment features a
removable access cover
and is completely sealed
from electrical
components to prevent
water or vapor entry into
the fixture
• Approximate net weight:
10 lbs. (4.5 kgs.)
DESCRIPTION
PHOCUS defines the ultimate
floodlighting solution; powerful
performance, easily concealable
size and a stunningly beautiful
shape. Available in wattages up to
150 watt T-6 Metal Halide and 250
watt T-4 Quartz Halogen.
PHOCUS is versatile in
application. Ground, wall, ceiling,
burial and remote mounting
configurations offer a wide variety
of application alternatives to
accomplish specific design
requirements. Offering seven (7)
uniquely shaped optical
distributions, plus an array of
HID and Quartz Halogen PAR
lamps, PHOCUS is unrivaled in
it's optical versatility. An available
family of light control accessories
provides custom cutoff solutions
to meet specific distribution
requirements.
PHH
PHOCUS FLOOD
HID
39-150W
Metal Halide
ARCHITECTURAL
FLOOD LUMINAIRE
9 1/2" [241 mm] 10 1/4" [260 mm]
6 1/4"
[159mm]
10 1/2"
[267mm]
4 1/4"
[107mm]
NOTES
:1T6 lamps use G12 base. 2Available in Dual-Tap, 120 and 277V only. 370W magnetic ballast limited to Dual-tap 120/277V or 120/347V. 439W PAR20 lamps use
medium screw base. 5Products also available in non-US voltages and 50Hz for international markets. Consult factory for availability and ordering information.
6Magnetic ballasts only. 7Dual-tap is 120/277V wired 277V. 8Multi-tap is 120/208/240/277V wired 277V. 9Triple-tap is 120/277/347V wired 347V. 10 120 through
277V only. Not available with 150 MH lamp, or GBB, GRB, GSR ground mount options. 11 PAR 20 MH lamps available in 39W only. 12 GBB, GRB, GSR mounting
options include a magnetic potted burial ballast enclosure. Not available in 150W MH. Maximum 50' remoting distance from fixture head. 13 For use when ground
mounting in non-earth or interior surface environments. 14 Custom and RAL color matching available upon request. Consult your INVUE Lighting Systems
Representative for further information. 15 Add as suffix in the order shown. 16 Fusing available on GIB and WIB mounting options only.17 Order separately,
replace XX with color suffix. 18 Specifications and dimensions subject to change without notice.
ORDERING INFORMATION
SAMPLE NUMBER: PHH-39-MH-120-EB-FL30-GIB-DP
Options 16
F=Single Fuse
(120, 277 or 347V) Specify Voltage 6
FF=Double Fuse
(208, 240 or 480V) Specify Voltage 16
FR=Frosted Flat Glass Lens
L=Lamp Included
Accessories 17
VA3003-XX=Color Filter Adapter with Red Gel
VA3004-XX=Color Filter Adapter with Bright Blue Gel
VA3005-XX=Color Filter Adapter with Deep Green Gel
VA3006-XX=Color Filter Adapter with Warm Orange Gel
VA3001-XX=Top Visor
VA3002-XX=Four Sided Shield
VA3007-XX=Wire Guard
Product Family
PHH=PHOCUS
HID
Lamp
Wattage 1
HID T6 Lamps
39=39W 2
70=70W 3
100=100W
150=150W
HID PAR Lamps 4
39=39W 2
Lamp Type
MH=Metal Halide
Optical Systems
HID T6 Lamps
NS=Narrow Spot
Axial
HNF=Horizontal Narrow
Flood
HMF=Horizontal
Medium Flood
HWF=Horizontal Wide
Flood
VNF=Vertical Narrow
Flood
VMF=Vertical Medium
Flood
VWF=Vertical Wide
Flood
HID PAR Lamps 11
SP10=10° Spot
FL30=30° Flood
Mounting Options
Ground Mount
GBB=Direct Burial Mount
(supplied with
burial ballast) 12
GIB=Integral Ballast Box
GRB=Remote Mount
(supplied with
remote burial ballast) 12
GRNB=Remote Mount (requires
remote potted ballast by
others) 13
GSR=Spike Mount (supplied with
remote burial ballast) 12
Wall/Ceiling Mount
WIB=Integral Ballast Box
WRNB=Remote Mount (requires
remote potted ballast by others)
Options &
Accessories
(See Below)
Voltage 5
120=120V
208=208V
240=240V
277=277V
347=347V
DT= Dual-Tap
Wired 277V 6, 7
MT=Multi-Tap
Wired 277V 6, 8
TT=Triple-Tap
Wired 347V 6, 9
UNV=120-277V
Universal
Electronic
Ballast
Ballast
MB=Magnetic
EB=Electronic 10
Colors (add as
suffix/must specify) 14
BK=Black
AP=Grey
BZ=Bronze
WH=White
DP=Dark Platinum
GM=Graphite Metallic
VR=Verde Green
IP65 Rated U.L. 1598 2G Vibration Tested
CSA Listed 25°C Ambient ISO 9001
Certifications
PHH
Metal Halide T6 39, 70, 100, 150W
Metal Halide PAR20 39W
WATTAGE TABLE
