Cooper CEAG Webmodule ZB-S User manual

Operating Instructions
Webmodule ZB-S
Target group: Skilled electricians
400 71 860 051 (A)

CEAG Notlichtsysteme GmbH 2
Operating Instructions
Webmodule ZB-S
Index
1 Safety Instructions ........................................................................................ 3
2 Conformity with standards........................................................................... 3
3 Technical data................................................................................................ 3
3.1 Description / Scope of application ......................................................................... 3
4 Installation...................................................................................................... 3
4.1 Mounting ................................................................................................................. 3
4.2 Electrical connection............................................................................................... 3
4.3 Commissioning the Webmodule on the ZB-S ........................................................ 4
4.4 Deactivate the webmodule on the control unit ZB-S.............................................. 4
4.5 Monitoring via an internet browser ......................................................................... 5
5 Homepage / Login......................................................................................... 6
6 Submenus ...................................................................................................... 8
6.1 Overview ZB-S........................................................................................................ 8
6.2 Overview SKU......................................................................................................... 9
6.3 DLS/TLS/3PhW..................................................................................................... 11
6.4 Settings ................................................................................................................. 12
6.5 Email-Messages.................................................................................................... 14
6.6 Other webmodules................................................................................................ 15
7 Example of locating a luminaire failure ..................................................... 16
8 Data gets synchronized .............................................................................. 19

CEAG Notlichtsysteme GmbH 3
Operating Instructions
Webmodule ZB-S
Service
Störung
Failure
24V
+-PE
1 Safety
Instructions
 The Webmodule ZB-S shall
only be used for its intended
purpose and in undamaged
and perfect condition!
 When working on the elec-
tronic device make sure that
it is disconnected from the
voltage! Pay attention to the
different power supplies in
mains or battery operation.
Observe the national safety
rules and regulations for
prevention of accidents as
well as the safety instruc-
tions included in these ope-
rating instructions marked
with !
2 Conformity with
standards
Conform to: EN 60950-1.
Developed, manufactu-
red and tested acc. to ISO
9001.
3 Technical data
Supply
voltage: 24 V DC
Power
consumption: < 1.5 W
Connection: RJ45
Insulation class: III
Degree of protection acc. to
EN 60529: IP 20
Ambient temperature:
-10 °C .. +55 °C
Connection
terminal: 1,5 mm²
Weight: 0,1kg
Dimensions:
90 x 35 x 58mm
3.1 Description /
Scope of application
The webmodule ZB-S for
visualisation and monitoring
of a central battery system
ZB-S via local ethernet (LAN)
with a customary WEB-brow-
ser (e. g. Internet ExplorerTM).
Integrated mail-client for a
comfortable and event based
failure notification for up to 5
email addressees. Password
protected access accounts
capable of parametrisation.
Note:
For operation of the web-
module with a ZB-S system
the following software-state
must be installed in the con-
trole module:
P/F/H (Mega 128/RS485/
FTT 10A)
4 Installation
For the mounting
and operation of
electrical apparatus, the
respective national safety
regulations as well as the
general rules of engineering
will have to be observed!
4.1 Mounting
Pay attention to tempera-
tures outside the permitted
range during operation. The
permissible ambient tem-
perature may not exceed
55°C.
The module was designed for
DIN rail mounting (2TE) to be
only mounted in the cabinet.
An external mounting out-
side the ZB-S cabinet is not
Status/
Failure LED
Network
connection
RJ45
Service
Pin
Connection of
the 6-pole
data cable to
the control
unit ST-S
+ - PE
24 V DC from
DC/DC inverter
The webmodule ZB-S is
supplied with 24V DC of the
DC-DC inverter of the ZB-S.
The PE connector must be
connected to the protection
earth (PE) in the ZB-S.
Note: The DC-DC inverter
can supply max. 20 pcs.
further DLS/3Ph-busmodu-
les/TLS-modules!
The 6-pole data cable con-
nects the webmodule with
the ST-S control unit:
permitted.
4.2 Electrical connection

CEAG Notlichtsysteme GmbH 4
Operating Instructions
Webmodule ZB-S
Connection of the data
cable to the control unit
ST-S
Note:
Keep the distance of the
data cable between the
webmodule and the con-
trol unit ST-S as short as
possible. Please avoid a
wiring around the char-
ging unit.
4.3 Commissioning the
Webmodule on the
ZB-S
After connection of the
power supply (24V DC), the
webmodule needs approx.
1.5 minutes for booting.
After the booting, the red
LED of the webmodule
flashes slowly. To log on
the webmodule on the ST-S
control unit, the service pin
of the webmodule must
be pressed for approx. 1
second.
The menu „webserver
setup“ appears in the
display of the control unit
of the ZB-S. During the log
on procedure the display
shows a lot of question
marks.
After approx. 3-5 seconds
the display shows the
standard settings of the
webmodule:
The webmodule gets
automatically activated to
the control unit, which is
displayed by the red LED
(some seconds) of the con-
trol unit and the webmo-
dule. After 1-2 minutes the
procedure is finished and
the webmodule is ready to
operate.
LED-display of the web-
module:
LED flashes slowly:
webmodule is not activated
on the control unit.
Status-LED flashes fastly
3x :
when pushing the service
pin for approx. 10 seconds
the webmodule will be set
back into delivery status.
Service pin of the webmo-
dule:
Pressing the service pin for:
1 sec.: login/logout of the
webmodule on the control
unit ST-S
The webmodule can be
deactivated on the control
unit. For this, the service
pin of the webmodule has
to be pressed for approx. 1
sec. The screen showed in
the picture above appears.
With the push button „arrow
left“ or „arrow right“ the
webmodule can be set as
„not installed“. Press o.k.
and back with menu button.
Now the webmodule is off-
line and the red LED flashes
slowly.
> 10 sec.: resets the modu-
le to the delivery status
Attention!
All programmed data get
lost!
4.4 Deactivate the
webmodule on the
control unit ZB-S

CEAG Notlichtsysteme GmbH 5
Operating Instructions
Webmodule ZB-S
During activities on the con-
trol unit of the ZB-S, e.g.
programming of luminaires,
it is possible that the con-
nection between the control
unit and the webmodule is
interrupted for a short time.
This gets displayed by a red
LED on the control unit or
rather on the webmodule.
The webmodule allows a
visualisation of a ZB-S/
US-S central battery system
via ethernet.
If the device shall be in-
stalled in a factory intranet
it is necessary to get all
required information, like
network settings or mail
settings from the IT-depart-
ment in charge (see chapter
6.4, Settings)
Direct access via IP-address:
e. g.: 192.168.100.5
with HTTP via TCP
Furthermore the webbrow-
ser shows „data is synchro-
nized“. The connection will
automatically be restored
after a short time.
4.5 Monitoring via an
internet browser
Functional schematic:

CEAG Notlichtsysteme GmbH 6
Operating Instructions
Webmodule ZB-S
5 Homepage / Login
By entering the TCP/IP-
address (s. 5.a: ex works:
192.168.1.200) in the
internet-browser the home-
page will open.
5.a
Ex works 2 logins are given
which can be modified
individual at anytime:

CEAG Notlichtsysteme GmbH 7
Operating Instructions
Webmodule ZB-S
5.1: User: Admin
Password: ceag
Permits unlimited use of the
web server.
5.3: A change of the
password for the acutal ac-
count is possible in the lo-
wer part of the entry mask.
Herefore it is necessary to
enter the old password, too.
5.1+5.2
5.3
5.2: User: Guest
Password:(no
password required)
Permits only access to
status information.
Note:
Change the factory set
password to avoid an
unauthorized access!

CEAG Notlichtsysteme GmbH 8
Operating Instructions
Webmodule ZB-S
6 Submenus
6.1 Overview ZB-S
6.1.1 After successful
login the mask „Overview
ZB-S“ appears by showing
all relevant statuses of
the system (control unit),
battery and charging unit as
well as display of the next
automatic test (FT/BT) and
software information on the
control unit ZB-S.
The statuses are shown
6.1.3
6.1.2
6.1.1
coloured:
green: function o.k.
yellow: FT/BT runs
red: function failure
6.1.2 When logged in
as „admin“ it is possible
to push the buttons for the
following commands:
- block device
- release device
- start function test
- reset deep discharge
protection
6.1.3 Choosing the me-
nus on the left side you get
in the marked submenus.

CEAG Notlichtsysteme GmbH 9
Operating Instructions
Webmodule ZB-S
6.2 Overview SKU
6.2.1 In the mask „over-
view SKU“ the informati-
on about the equipment
of the subracks with the
corresponding SKU´s is
displayed with the following
statuses:
green: circuit o.k.
red: circuit failure
6.2.1
6.2.2
6.2.2 With a click on the
individual circuit the appen-
dant mask starts.

CEAG Notlichtsysteme GmbH 10
Operating Instructions
Webmodule ZB-S
6.2.3 Circuit mask
6.2.3.1 The circuit mask
shows the status of circuit
as well as
6.2.3.2 the installed
luminaires with marking
of destination and switch
allocation.
6.2.3.2
6.2.3.1
The status of the luminaire
is shown as follows:
grey: offline
yellow: online
red: failure
