Copernicus Tech Tub Trolley FTT595 User manual

FTT595_606_1010_1010-usb - Version C - Released 13 July 2016 - Copernicus Educational Products Inc.
Assembly Guide
FTT595_606_1010_1010-USB_2016_C
Check out our other products online at
www.copernicused.com
?This product is meant to be assembled by an adult.
?In its unassembled state, small parts present a hazard.
?To be used under direct supervision of an adult.
WARNING
For assistance, please contact us:
1-800-267-8494
Email [email protected]
Have your packing slip ready for reference
FTT595
FTT606
FTT1010
FTT1010-USB
Please Recycle
PLEASE KEEP THIS GUIDE WITH THE PRODUCT
FTT595/FTT606
FTT1010/FTT1010-USB
®
2
Tech Tub Trolley Setup

FTT595_606_1010_1010-usb - Version C - Released 13 July 2016 - Copernicus Educational Products Inc.
To validate your warranty, submit the ON-LINE form at www.copernicused.com
Enter a draw to win a Copernicus Product for your classroom at the same time!
Validate Your Warranty
Component
Warranty
1
Year
Frame
Jim Phillips
Chief Cook and Bottle Washer
Dear Educator,
Thank you for purchasing one of our products. I hope the Trolley is useful in your classroom.
If you have any questions, concerns, or ideas please contact us by telephone at 1-800-267-8494 or
email at [email protected].
Enjoy using your new product and happy teaching.
®
2
Tech Tub
We do not inherit the
earth from our ancestors,
we borrow it from our
children.
NORTH AMERICAN
PROVERB
Change is the end result
of all true learning.
LEO BUSCAGLIA
What you leave behind is
not what is engraved in
stone monuments, but
what is woven into the
lives of others.
PERICLES
Education is the most
powerful weapon which
you can use to change the
world.
NELSON MANDELA
2
Life
Warranty
Frame
Time
Life
®
2
Tech Tub
Time
Warranty
Assembly Guide
FTT595_606_1010_1010-USB_2016_C
Check out our other products online at
www.copernicused.com
For assistance, please contact us:
1-800-267-8494
Email [email protected]
Have your packing slip ready for reference
FTT595
FTT606
FTT1010
FTT1010-USB
®
2
Tech Tub Trolley Setup

FTT595_606_1010_1010-usb - Version C - Released 13 July 2016 - Copernicus Educational Products Inc.
Warning! Hazard Risks!
3
This product is to be used under the supervision of an adult.
Indoor Use
Only
This product is intended for indoor use only. To reduce the risk of fire or electric shock, do not expose
this product to rain or moisture. The internal components are not sealed from the environment.
Read your power strip electrical specifications. Only plug in devices that are approved for use with this
power strip. Connect the supplied power strip directly to a wall outlet. Do not connect to another
power strip or use an extension cord. Unplug when not in use. Do not leave this product plugged in
for more than 72 consecutive hours. Turn off power strip before unplugging.
Power Strip
Specifications
Do not install or use the electrical components of this unit during a lightning storm.
Electrical Shock
In its unassembled state, this product contains parts that can be hazardous to small children. This
product should be assembled by an adult.
Small
Parts
Ensure that any cables extending across the floor to your product are properly bundled and marked to
avoid tripping or falling which may lead to personal injury.
Cable Trip
Hazard
Climb Hazard
Do not climb on, hang from or suspend objects from any components of your product unless otherwise
specified.
Read the electrical specifications of any electronic equipment you are using with your Copernicus
products. Failure to read these specifications and follow their instructions could result in damage to
your equipment or personal injury.
Electronic
Equipment
Adult
Supervision
Please read the warnings below for important safety information regarding your product. Failure to
read these warnings or to follow the instructions below could result in personal injury or damage to
your product that could void your warranty.

FTT595_606_1010_1010-usb - Version C - Released 13 July 2016 - Copernicus Educational Products Inc.
FT595
FTT606
®
2
Tech Tub
®
2
Tech Tub
(1)
Assembled in
assembly guide
Adjustable Handle (1)
Front Support (1)
Caster (2)
®
2
Tech Tub Trolley Frame (1)
4
Assembly begins on page 8.
®
2
Tech Tub Trolley- Base & 6 Device Setup

FTT595_606_1010_1010-usb - Version C - Released 13 July 2016 - Copernicus Educational Products Inc.
FTT1010
FTT1010-USB
®
2
Tech Tub
®
2
Assembled in Tech Tub
assembly guide
(1)
Adjustable Handle (1)
Front Support (1)
Caster (2)
®
2
Tech Tub
Trolley Frame (1)
Extension Bracket (2)
5
Assembly begins on page 10.
®
2
Tech Tub Trolley- 10 Device Setup

FTT595_606_1010_1010-usb - Version C - Released 13 July 2016 - Copernicus Educational Products Inc.
This symbol denotes a 2- or 3- Person Task. For safety, please ensure that there
are the suggested number of people working on steps displaying this symbol.
Watch for this symbol throughout the Assembly Guide. Wherever you see it, pay
close attention. The symbol denotes a step needing extra attention to ensure it is
done correctly.
The star symbol highlights an advisory note.
!
Watch for These Helpful Symbols
Before You Begin
As You Assemble the Unit
Lay out and identify all of the included parts.
The hardware has been packed according to step.
Read the assembly guide over once to familiarize yourself with them.
Please note that in its unassembled state, this product contains parts that can
be hazardous to small children. This product should be assembled by an adult.
!
Follow the steps in sequence.
Before beginning each step, find the part(s) that you need for that step.
Pay attention to the labels on the parts; they are there to help direct you at certain stages.
The title of each step states what you will be doing. Review the text and the pictures as you
build the unit.
?
?
?
Need Tech Support?
Have a Question?
Email our Tech Support Service
2-Person Task
Tips for Assembly
Customer Service - FAQ’s
For parts and other issues regarding the product:
- The handle doesn’t extend
missing
- I lost the key
Please call Copernicus Customer Service,
1-800-267-8494. Monday - Friday 8:30am - 4:30 pm EST.
OR
Email our Tech Support Service at [email protected]
where we will be happy to help.
6

FTT595_606_1010_1010-usb - Version C - Released 13 July 2016 - Copernicus Educational Products Inc.
Before beginning, you should have:
Additional tools required:
Adjustable wrench
1x
Contents - Box 1
Trolley Frame
1x
Extension bracket
2x
Used only with
FTT1010
FTT1010-USB
Hardware
Actual Size
In Box 1
Front Support
1x
M6 15mm
2x
M6 Acorn Nut
4x
M6 Washer
6x
M6 Lock Washer
4x
Allen Key
Not to Scale
(43281)
1x
A
B
C
D
M6 Lock Nut
2x
E
7
M5 Washer
4x
M5 Lock Nut
4x
F
G
FTT595
FTT606
FTT1010
FTT1010-USB
®
2
Tech Tub Trolley Setup

FTT595_606_1010_1010-usb - Version C - Released 13 July 2016 - Copernicus Educational Products Inc.
Slide Trolley Frame into ®
2
Tech Tub
Make sure screws on Trolley Frame align with holes on
®
2
Tech Tub
2
You will need: (Not to Scale)
Actual Size:
Use Hardware to Permanently Attach Base of Trolley Frame to ®
2
Tech Tub
Hardware is installed through bottom back section of ®
2
Tech Tub
Bottom View Inside View
2x
Adjustable wrench
1x
Allen Key
Not to Scale
(43281)
1x
A
A
A
E
C
®
2
Tech Tub Trolley- 6 Device Setup
1Trolley Frame
x1
You will need: (Not to Scale)
8
2x
E
2x
C
A
E
C
A
Ensure frame engages with feet
all the way
If you are installing the
10 Device Trolley
proceed to page 10.
FT595
FTT606

FTT595_606_1010_1010-usb - Version C - Released 13 July 2016 - Copernicus Educational Products Inc.
3
Actual Size:
You will need: (Not to Scale)
4
You will need: (Not to Scale)
Actual Size:
Attach Front Support to Bottom of ®
2
Tech Tub
Use Hardware to Permanently Attach Uprights of Trolley Frame to ®
2
Tech Tub
Hardware is installed through inside of ®
2
Tech Tub
Inside View
Front Support
x1
G
F
G
F
9
For - 6 device set up follow the assembly guide
found in the tub shipping box.
®
2
Tech Tub
B B
D D
C C
2x
B
2x
D C
2x
Adjustable wrench
1x
Adjustable wrench
1x
Tighten all hardware.
Be sure not to over tighten.
Note Orientation of Front
Support
2x
F
2x
G
The side cable organizer is NOT
included with the Base version.
!

FTT595_606_1010_1010-usb - Version C - Released 13 July 2016 - Copernicus Educational Products Inc.
1
Actual Size:
Attach Extension Brackets to Trolley Frame
You will need: (Not to Scale)
Pay attention to orientation of brackets when installing
Trolley Frame
x1
Extension Bracket
x2
Slide Trolley Frame into ®
2
Tech Tub
Make sure screws on Trolley Frame align with holes on ®
2
Tech Tub
2x
B
2x
C
2x
D
B
C
DB
C
D
Allen Key
Not to Scale
1x
FTT1010
FTT1010-USB
®
2
Tech Tub Trolley- 10 Device Setup
2Trolley Frame
x1
You will need: (Not to Scale)
10
Adjustable wrench
1x
Longer stud
goes through
chome tube
Ensure frame engages with feet
all the way

FTT595_606_1010_1010-usb - Version C - Released 13 July 2016 - Copernicus Educational Products Inc.
3
Actual Size:
You will need: (Not to Scale)
4
You will need: (Not to Scale)
Actual Size:
G
F
G
F
Use Hardware to Permanently Attach Uprights of Trolley Frame to ®
2
Tech Tub
Hardware is installed through inside of ®
2
Tech Tub
Allen Key
Not to Scale
1x
11
Use Hardware to Permanently Attach Base of Trolley Frame to ®
2
Tech Tub
Hardware is installed through bottom back section of ®
2
Tech Tub
Bottom View
A
A
Inside View
E
C
A
E
C
A
2x
A
2x
E
2x
C
Adjustable wrench
or 10mm wrench
1x
Adjustable wrench
1x
4x
F
4x
G

FTT595_606_1010_1010-usb - Version C - Released 13 July 2016 - Copernicus Educational Products Inc.
5
Actual Size:
You will need: (Not to Scale)
Attach Front Support to bottom of ®
2
Tech Tub
2x
B
2x
D
12
B B
D D
C C
C
2x
Adjustable wrench
or 10mm wrench
1x
For - 10 device set up follow the assembly guide
found in the tub shipping box.
®
2
Tech Tub
Tighten all hardware.
Be sure not to over tighten.
Note Orientation of Front
Support
Front Support
x1
