Cornwell Tools CSEFJ350BK-BL User manual

Capacity ................................3.5 Ton
Low Height ................................3.5"
Raised Height............................20.25"
Length .................................29.75"
Chassis Width ............................14.2"
Saddle Diameter............................4.7"
Shipping Weight .......................105.6 Lbs.
• Operating Manual • Warning Information • Parts List
SPECIFICATIONS
CSEFJ350BK, -BL, -NG, -RD, -RG 12/08/15
CSEFJ350BK -BL, -NG, -RD, -RG
3-1/2 Ton Floor Jack
Copyright © Professional Tool Products, 2015,
All rights reserved

CSEFJ350BK, -BL, -NG, -RD, -RG 2 12/08/15
This is the safety alert symbol. It is used to alert you
to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
IMPORTANT: READ THESE INSTRUCTIONS BEFORE OPERATING
BEFORE USING THIS DEVICE, READ THIS MANUAL COMPLETELY AND THOROUGHLY, UNDERSTAND ITS OPERATING
PROCEDURES, SAFETY WARNINGS AND MAINTENANCE REQUIREMENTS.
It is the responsibility of the owner to make sure all personnel read this manual prior to using the device. It is also the responsibility of
the device owner to keep this manual intact and in a convenient location for all to see and read. If the manual or product labels are lost
or not legible, contact Cornwell for replacements. If the operator is not fluent in English, the product and safety instructions shall be
read to and discussed with the operator in the operator's native language by the purchaser/owner or his designee, making sure that
the operator comprehends its contents.
THE NATURE OF HAZARDOUS SITUATIONS
The use of portable automotive lifting devices is subject to certain hazards that cannot be prevented by mechanical means, but only
by the exercise of intelligence, care, and common sense. It is therefore essential to have owners and personnel involved in the use
and operation of the equipment who are careful, competent, trained, and qualified in the safe operation of the equipment and its
proper use. Examples of hazards are dropping, tipping or slipping of loads caused primarily by improperly securing loads, overloading,
off-centered loads, use on other than hard level surfaces, and using equipment for a purpose for which it was not designed.
METHODS TO AVOID HAZARDOUS SITUATIONS
• Read,study,understandandfollowallinstructionsbeforeoperatingthisdevice.
• Inspectthejackbeforeeachuse.Donotusejackifdamaged,altered,modied,inpoorcondition,leakinghydraulicuid,or
unstable due to loose or missing components. Make corrections before using.
• Liftonlyonareasofthevehicleasspeciedbythevehiclemanufacturer.
• WeareyeprotectionthatmeetsANSIZ87.1andOSHAstandards,usersandbystanders.
• Donotusejackbeyonditsratedcapacity.Donotshockload.
• This is a lifting device only. Immediately after lifting, support the vehicle with jack stands capable of sustaining the load before
working on the vehicle.
• Useonlyonahardlevelsurfacefreefromobstructionssothejackisfreetorepositionitselfduringliftingandloweringoperations.
• Centerloadonsaddle.Besuresetupisstablebeforeworkingonvehicle.
•Donotmoveordollythevehiclewhileonthejack.
• Donotuseanymaterialsthatmayserveasrisers,spacersorextendersbetweenthestockliftingsaddleandtheload.
• Donotuseanyadaptorsthatreplacethestockliftingsaddleunlessapprovedorsuppliedbythejackmanufacturer.
•Donotuse(ormodify)thisproductforanyotherpurposethanthatforwhichitwasdesignedwithoutconsultingthemanufacturer's
authorized representative.
• Alwayslowerthejackslowlyandcarefully.
• ThisproductmaycontainoneormorechemicalsknowntotheStateofCaliforniatocausecancerandbirthdefectsorother
reproductive harm. Wash hands thoroughly after handling.
• Failuretoheedthesewarningsmayresultinseriousorfatalpersonalinjuryand/orpropertydamage.
CONSEQUENCES OF NOT AVOIDING HAZARDOUS SITUATIONS
Failure to read this manual completely and thoroughly, understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS,
MAINTENANCEINSTRUCTIONSandnotcomplywiththem,andneglectingtheMETHODSTOAVOIDHAZARDOUSSITUATIONS
could cause accidents resulting in serious or fatal personal injury and/or property damage.
WARNING: Indicates a hazardous situation
which, if not avoided, could result in death
or serious injury.
WARNING
WARNING
WARNING
WARNING
WARNING INFORMATION

CSEFJ350BK, -BL, -NG, -RD, -RG 3 12/08/15
OWNER/USER RESPONSIBILITY
The owner and/or user must have an understanding of the manufacturer’s operating instructions and warnings before using this jack. Personnel
involved in the use and operation of equipment shall be careful, competent, trained, and qualified in the safe operation of the equipment and its
proper use when servicing motor vehicles and their components. Warning information should be emphasized and understood. If the operator is not
fluent in English, the manufacturer’s instructions and warning shall be read to and discussed with the operator in the operator’s native language by
the purchaser/owner, making sure that the operator comprehends its contents. Owner and/or user must study and maintain for future reference the
manufacturers’ instructions. Owner and/or user is responsible for keeping all warning labels and instruction manuals legible and intact. Replacement
labels and literature are available from the manufacturer.
INSPECTION
Visual inspection should be made before each use of the jack, checking for leaking hydraulic fluid and damaged, loose or missing parts. Each jack must be
inspected by a manufacturer’s repair facility immediately, if subjected to an abnormal load or shock. Any jack which appears to be damaged in any way, is
found to be badly worn, or operates abnormally MUST BE REMOVED FROM SERVICE until necessary repairs are made by a manufacturer’s authorized repair
facility. It is recommended that an annual inspection of the jack be made by a manufacturer’s authorized repair facility and that any defective parts, decals or
warning labels be replaced with manufacturer’s specified parts. A list of authorized repair facilities is available from the manufacturer.
SETUP
Please refer to the exploded view drawing on page 5 in this manual in order to identify parts:
1. Removethe2-piecehandlefrombox.Insertnarrowportionoftopsection(7)intobottomsection(8)andsecurewithhandlebutton(21).
2. Greasetheinsideofthehandleyoke(11)andremovethehandlesetscrew(10)fromtheyoke(11).Insertthehandleallthewayinthehandle
 yoke(11)untilitengagestheuniversaljointassembly(13).Securethehandletothehandleyoke(11)withthehandlesetscrew(10).
3. Airmaybecometrappedinthehydraulicsystemduringshippingandhandling.Trappedairwillaffectthepumpingperformanceofthejack.Ifthis
occurs, follow the air purging procedure below:
 a) Rotatethehandle.inaclockwisedirectionuntiltight.Rotatethehandleinacounterclockwisedirectiontwocompleterevolutions.
 b) Pumpthehandleapproximately10-15completepumpstrokes.
 c) Rotatethehandleinaclockwisedirectionuntiltight.Proceedtopumpthejacktomaximumliftheight.
 d) Repeatstepsa)andc)untilallairhasbeenpurgedfromthesystem.
OPERATION
This is the safety alert symbol used for the OPERATING INSTRUCTIONS section of this manual to alert you to potential personal injury
hazards. Obey all instructions to avoid possible injury or death. IMPORTANT: Before attempting to raise any vehicle, check vehicle service
manual for recommended lifting surfaces.
1. To raise load: Turn the handle in a clockwise direction until tight. Position the jack under the load. Proceed to pump the handle in order to raise
the lift arm to the load. As the saddle at the end of the lift arm gets closer to the load, reposition the jack so the saddle will contact the load firmly
and the load is centered on the saddle. Make sure the saddle is correctly positioned. Raise the load to the desired work height. Place jack stands
of appropriate capacity at the vehicle manufacturers's recommended support areas that provide stable support for the raised vehicle. DO NOT
CRAWL UNDER VEHICLE WHILE LIFTING VEHICLE OR PLACING OR REMOVING THE JACK STANDS! Once jack stands are positioned, turn
the handle VERY SLOWLY. Lower the load to rest on the jack stands. Inspect the relationship between the jack stands and load to make sure the
setup is stable and safe. If the setup is not stable or safe, follow the preceding steps until corrected.
2. To lower load: Follow the procedures mentioned in "To raise load" section of the OPERATING INSTRUCTIONS in order to raise the load off the
jack stands. Once the load has cleared the jack stands, remove the stands from under the load and away from the work area. Turn handle very
slowly in a counterclockwise direction until the load is completely lowered to the ground. Once the jack's lifting saddle has cleared the load,
remove the jack from under the load. CAUTION: Keep hands and feet away from the hinge mechanism of the jack. DO NOT
CRAWL UNDER VEHICLE WHILE LIFTING VEHICLE OR PLACING OR REMOVING THE JACK STANDS!
PREVENTATIVE MAINTENANCE
This is the safety alert symbol used for the PREVENTATIVE MAINTENANCE section of this manual to alert you to potential personal injury hazards.
Obey all instructions to avoid possible injury or death.
1. Alwaysstorethejackinawellprotectedareawhereitwillnotbeexposedtoinclementweather,corrosivevapors,abrasivedust,oranyotherharmful
elements. The jack must be cleaned of water, snow, sand, grit, oil, grease or other foreign matter before using.
2. The jack must be lubricated periodically in order to prevent premature wearing of parts. A general purpose grease must be applied to all zerk grease
fittings, caster wheels, front axle, elevator arm, handle base pivot bolts, release mechanism and all other bearing surfaces. Worn parts resulting from
inadequate or no lubrication are not eligible for warranty consideration. See page 6 for lubrication instructions.
3. Itshouldnotbenecessarytorefillortopoffthereservoirwithhydraulicfluidunlessthereisanexternalleak.Anexternalleakrequiresimmediaterepair
which must be performed in a dirt-free environment by an authorized service center.
IMPORTANT: In order to prevent seal damage and jack failure, never use alcohol, hydraulic brake fluid or transmission oil in the jack. Use Chevron Hydraulic
OilAWISO32,itsequivalentUnocalUnaxAW150orhydraulicjackoil.
4. Every jack owner is responsible for keeping the jack labels clean and readable. Use a mild soap solution to wash external surfaces of the jack but not
any moving hydraulic components.
5. Inspect the jack before each use. Do not use the jack if any component is cracked, broken, bent, shows sign of damage or leaks hydraulic fluid. Do not
use the jack if it has loose or missing hardware or components, or is modified in any way. Take corrective action before using the jack again.
6. Any hydraulic repairs within the warranty period must be performed by an authorized service center.
CSEFJ350BK, -BL, -NG, -RD, - RG 3-1/2 TON FLOOR JACK

CSEFJ350BK, -BL, -NG, -RD, -RG 4 12/08/15
WARRANTY COVERAGE
CornwellQualityToolsCompany(“Cornwell”)warrantsagainstdefectsinthehydraulicpumponthisproductforaperiodofTWO(2)
YEARSfromthedateoforiginalretailpurchase.CornwellQualityToolsCompany(“Cornwell”)warrantsagainstdefectsinthebalance
ofcomponentsonthisproductforaperiodof90daysfromthedateoforiginalretailpurchase.Subjecttotheconditionsandlimitations
setforthbelow,Cornwellwill,atitsoption,eitherrepairorreplaceanypartoftheproduct(s)thatprovesdefectivebyreasonofimproper
workmanship or materials.
This warranty does not cover any damage to this product that results from accident, abuse, misuse, natural or personal disaster, or any
unauthorized disassembly, repair, or modification. Repairs, disassembly and modification are only authorized to be made by Cornwell
or a warranty service center approved by Cornwell.
WARRANTY SERVICE
To obtain warranty service, contact your Cornwell dealer.
EXCLUSIONS AND LIMITATIONS
THIS WARRANTY AND THE REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, REMEDIES
AND CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. CORNWELL SPECIFICALLY DISCLAIMS ANY AND ALL
IMPLIED WARRANTIES, INCLUDING, TO THE EXTENT PERMITTED BY APPLICABLE LAW, ANY WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. IF CORNWELL CANNOT LAWFULLY DISCLAIM IMPLIED WARRANTIES UNDER THIS
LIMITED WARRANTY, ALL SUCH IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. IN
NO EVENT SHALL CORNWELL BE LIABLE TO THE PURCHASER OR TO THE USER OF A CORNWELL PRODUCT FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES BASED UPON BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLIGENCE, TORT,
OR ANY OTHER LEGAL THEORY. SUCH DAMAGES INCLUDE, WITHOUT LIMITATION, EXPENSES, LOST REVENUES, LOST SAVINGS,
LOST PROFITS, OR ANY OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE PURCHASE, USE OR INABILITY
TO USE THE CORNWELL PRODUCT.
Some states do not allow the exclusion or limitation of incidental or consequential damages or exclusions or limitation on the duration
of implied warranties or conditions, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal
rights, and you may also have other rights that vary by state.
Repair kits and replacement parts are available for many Cornwell products, regardless of whether or not the product is still covered
by awarranty plan.
PROPER STORAGE
It is recommended that the jack be stored in a dry location with all wheels touching the ground on a relatively level surface.
TROUBLESHOOTING
Important: Service jacks are self-contained devices used for lifting, but not sustaining, a partial vehicular load. In accordance with ASME-PALD Load
SustainingTest:“Aloadnotlessthantheratedcapacity…shallnotlowermorethan1/8"(3.18mm)inthefirstminute,noratotalof.1875"(4.76mm)in10
minutes.”LoweringwithinthisrangeisconsiderednormaloperationandisNOTawarrantabledefect.
PROBLEM ACTION
1.Unitwillnotliftratedload. Purge air from hydraulic system by following procedure under
SETUP.
2. Unit will not sustain rated load or
feels“spongy”underratedload.
Purge air from hydraulic system as above.
3.Unitwillnotlifttofullheight. Purge air from hydraulic system as above.
4. Handle tends to raise up while the unit is under rated load. Pump the handle rapidly several times to push oil past ball valves in
power unit.
5. Unit still does not operate. Contact Cornwell authorized hydraulic service center.

PARTS
CSEFJ350BK, -BL, -NG, -RD, - RG 3-1/2 TON FLOOR JACK
1 RS35T01 Star Clip 2
2 RS35T02 Washer (M20) 2
3 RS35B03 Front Wheel 2
4 RS35B10 Rear Caster Assy. 2
5 RS35T08 Hex Nut & Lock Washer (M16) 2
6 RS35B11 Yoke Retaining Bolt & Washer 2
7 RS35024 Handle Lever "B" 1
8 RS35025 Handle Lever "A" 1
9 RS35010C Handle Bumper 1
10 RS35T13 Set Screw - Handle 1
11 RS35011BK Handle Yoke Black 1
RS35011BL Handle Yoke Blue 1
RS35011NG Handle Yoke Neon Green 1
RS35011RD Handle Yoke Red 1
RS35011RG Handle Yoke Orange 1
12 RS35012 Power Unit Assy. Complete 1
13 RS35T18 Universal Joint Assy. 1
14 RS35B24 Block Linkage
(incl. Split Pin, Ret. Rings) 1
15 RS35T12 Grease Fitting 1
16 RS35T04 Retaining Ring 2
Item Part
No. No. Description Qty.
Item Part
No. No. Description Qty.
17 RS35017 Saddle 1
18 RS35018 Saddle Screw 1
19 RS35020C Rubber Saddle Pad 1
20 RS35T19 Return Spring 2
21 RS35THB Handle Button (not shown) 1
22 RS35023 Yoke Stop Rod 1
A RS35022BK Power Unit Cover - Black 1
RS35022BL Power Unit Cover - Blue 1
RS35022NG Power Unit Cover - Neon Green 1
RS35022RD Power Unit Cover - Red 1
RS35022RG Power Unit Cover - Orange 1
B Main Frame 1
C Lift Arm 1
Not Shown RSCSEFJ350BKPLK Product Label Kit - Black 1
Not Shown RSCSEFJ350BLPLK Product Label Kit - Blue 1
Not Shown RSCSEFJ350NGPLK Product Label Kit - Neon Green 1
Not Shown RSCSEFJ350RDPLK Product Label Kit - Red 1
Not Shown RSCSEFJ350RGPLK Product Label Kit - Orange 1
Only items identified by part number are available for purchase.
A
C
B
1
2
3
55
6
7
8
9
10
11
12
13
20
21
14
15
16
17
18
19
6
4
22
4
4
[phone]
CSEFJ350BK, -BL, -NG, -RD, -RG 5 12/08/15

CSEFJ350BK, -BL, -NG, -RD, -RG 6 12/08/15
HYDRAULIC JACK MAINTENANCE GUIDE
IMPORTANT: Service jacks are designed for lifting purposes only; always support raised load with jack stands.
REGULAR MAINTENANCE
•MONTHLYorasnecessary(dependingonusage)
 1. Usingagreasegun,add grease to grease fitting in the lift arm pivot shaft.
  (Useamulti-purposeNLGItypegreaseonly.)
2. Lubricate all linkages and pivot points.
  (Usewhitelithiumspraygreaseonly.)
 3. Removehandle;lubricatehandlereceptacleandhandleend.
  (Usewhitelithiumspraygreaseonly.)
4. Lubricate both rear casters, bearing and both front wheels.
  (Usewhitelithiumspraygreaseonly.)
5. Tighten all accessible hardware.
*
*
*
Numbers shown in this
illustration match the
step numbers above
(Regular Maintenance)
*
View when lift arm is raised
View from rear
NOTE: Premature wearing of parts or components caused by loose or missing hardware that have not been replaced or tightened in a correct and timely
manner are not eligible for warranty consideration.
CSEFJ350BK, -BL, -NG, -RD, - RG 3-1/2 TON FLOOR JACK
4
4
1
3
