Cornwell Tools CSEVS6TBL User manual

-Save these instructions-
CSEVS3TBL/TNG/TRG, CSEVS6TBL/TNG/TRG 1 03/10/20
Manufactured to comply with the
ASME PASE-2019 Safety Standard
Copyright © Professional Tool Products, 2020
All rights reserved
OPERATING MANUAL •WARNING INFORMATION •PARTS LIST
CSEVS3TBL/CSEVS3TNG/CSEVS3TRG
CSEVS6TBL/CSEVS6TNG/CSEVS6TRG:
3 TON AND 6 TON JACK STANDS
(PAIR - BLUE, NEON GREEN, ORANGE)
SPECIFICATIONS
Maximum Capacity .................. 3 Ton (pair)............................ 6 Ton (pair)
Maximum Height..........................17-5/8".............................................24"
Minimum Height ..............................12"......................................... 15-3/4"
Base Size .................................. 7-1/4" x 8" ....................10-3/8" x 11-1/2"
Net Weight ................................. 14.3 Lbs. ....................................32 Lbs.
Shipping Weight......................... 15.4 Lbs. .................................34.2 Lbs.
CSEVS3TBL/NG/RG CSEVS6TBL/NG/RG
CSEVS3TBL (BLUE)
CSEVS3TNG (NEON GREEN)
CSEVS3TRG (ORANGE)
3 Ton Jack Stands (pair)
CSEVS6TBL (BLUE)
CSEVS6TNG (NEON GREEN)
CSEVS6TRG (ORANGE)
6 Ton Jack Stands (pair)
6 TON
3 TON

-Save these instructions-
CSEVS3TBL/CSEVS3TNG/CSEVS3TRG
CSEVS6TBL/CSEVS6TNG/CSEVS6TRG:
3 TON AND 6 TON JACK STANDS
(PAIR - BLUE, NEON GREEN, ORANGE)
CSEVS3TBL/TNG/TRG, CSEVS6TBL/TNG/TRG 2 03/10/20
This is the safety alert symbol. It is used to alert you
to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
IMPORTANT: READ THESE INSTRUCTIONS BEFORE OPERATING
THE NATURE OF HAZARDOUS SITUATIONS
METHODS TO AVOID HAZARDOUS SITUATIONS
BEFORE USING THIS DEVICE, READ THIS MANUAL COMPLETELY AND THOROUGHLY, UNDERSTAND ITS OPERATING
PROCEDURES, SAFETY WARNINGS AND MAINTENANCE REQUIREMENTS.
It is the responsibility of the owner to make sure all personnel read this manual prior to using the device. It is also the responsi-
bility of the device owner to keep this manual intact and in a convenient location for all to see and read. If the manual or product
labels are lost or not legible, contact Cornwell for replacements. If the operator is not fluent in English, the product and safety
instructions shall be read to and discussed with the operator in the operator's native language by the purchaser/owner or his
designee, making sure that the operator comprehends its contents.
The use of portable automotive supporting devices are subject to certain hazards that cannot be prevented by mechanical
means, but only by the exercise of intelligence, care, and common sense. It is therefore essential to have owners and personnel
involved in the use and operation of the equipment who are careful, competent, trained, and qualified in the safe operation of
the equipment and its proper use. Examples of hazards are dropping, tipping or slipping of loads caused primarily by improp-
erly securing loads, overloading, off-centered loads, use on other than hard level surfaces, and using equipment for a purpose
for which it was not designed.
• Read, study, understand and follow all instructions before operating this device.
• Inspect the jack stands before each use. Do not use if damaged, altered, modified, in poor condition or unstable due to loose
or missing hardware or parts. Make corrections before using the stands
• User and bystanders must wear eye protection that meets ANSI Z87.1 and OSHA standards
• Use as a matched pair only
• Do not use jack stands beyond its rated capacity. Do not shock load
• Maximum load capacity per matched pair shall not exceed the rated capacity of the individual stand
• Use only on a hard level surface capable of supporting the load
• Stands are to be used in matched pairs to support one end of the vehicle only. Do not simultaneously support both ends or
one side of the vehicle
• Apply the emergency brake and put the gear shift lever in park or in gear if a manual shift transmission, and chock the tires
that will not be lifted off the ground
• Center load on saddle. Do not use saddle lugs to support the load
• Check the stands for solid contact with the ground and vehicle
• Ensure both stands are set at same height and locking pawls are fully engaging the support column's teeth
• Do not crawl under vehicle when placing/removing stands
• Consult the vehicle manufacturer for the proper frame support locations
• No alterations shall be made to these stands
• Failure to heed these warnings may result in serious or fatal personal injury and/or property damage
WARNING: Indicates a hazardous situation
which, if not avoided, could result in death
or serious injury.
WARNING
WARNING
WARNING
WARNING: This product can expose you to chemicals including nickel, which is known to the State of California to cause can-
cer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

-Save these instructions-
CSEVS3TBL/CSEVS3TNG/CSEVS3TRG
CSEVS6TBL/CSEVS6TNG/CSEVS6TRG:
3 TON AND 6 TON JACK STANDS
(PAIR - BLUE, NEON GREEN, ORANGE)
CSEVS3TBL/TNG/TRG, CSEVS6TBL/TNG/TRG 3 03/10/20
SETUP
OPERATION
PREVENTATIVE MAINTENANCE
1. Install the support column in the stand where the support column teeth are facing toward the stand's locking pawl.
2. Raise the stand's locking handle to allow the column to go to its lowest position.
3. In order to prevent removal of the support column from the stand, use a hammer and flat end punch to hammer the jack's tab
in toward the column but not touching the column. Some stands are equipped with a bolt instead of a tab. In this case
the bolt can be threaded in toward the column until the bolt bottoms out. See figure 1 on page 4.
This is the safety alert symbol used for the PREVENTATIVE MAINTENANCE section of this manual to alert you to
potential personal injury hazards. Obey all instructions to avoid possible injury or death.
1. Always store the jacks stands in a well protected area where they will not be exposed to inclement weather, corrosive vapors,
abrasive dust, or any other harmful elements. The stands must be cleaned of water, snow, sand, grit, oil, grease or other foreign
matter before using.
2. Every jack stand owner is responsible for keeping the stand labels clean and readable. Use a mild soap solution to wash
external surfaces of the stand. Contact Cornwell Tools for a replacement label if your stand's label is not readable.
3. Inspect the stands before each use. Do not use the stands if any component is cracked, broken or bent. Do not use the stand
if it has loose ormissing hardware or components, or is modified in any way. Take corrective action before using the stand
again. Premature wearing or damage to components caused by loose or missing hardware is not eligible for warranty
consideration.
This is the safety alert symbol used for the OPERATING INSTRUCTIONS section of this manual to alert you to potential
personal injury hazards. Obey all instructions to avoid possible injury or death. IMPORTANT: Before attempting to raise
any vehicle, check vehicle service manual for recommended lifting surfaces.
1. Make sure the work floor is clean and free of debris and obstacles.
2. Chock the vehicle's tires that will not be lifted. Make sure the emergency brake is on and the vehicle's transmission is either in
the park mode or gear if a manual transmission.
3. Raise the vehicle to a safe working height and make sure the jack and vehicle setup are stable before positioning the jack
stands. DO NOT CRAWL UNDER THE VEHICLE TO POSITION OR REMOVE STANDS.
4. Position the jack stands right below the areas of the vehicle support points as specified by the vehicle manufacturer.
5. Lift the support columns as close to the vehicle as possible without the saddles on the columns coming in contact with the
vehicle. Make sure the support columns' teeth are engaged with the locking pawls.
6. Slowly and carefully lower the vehicle on the jack stands. Shock loads or loads dropped abruptly on stands can cause
premature metal fatigue or even stand failure depending on the weight of the vehicle and the speed of descent that impacts
the stands' support columns. The load should be supported in the center of the support column saddles, not the locating lugs
of the saddles.
7. Check the load for stability. If the load is not stable, lift the load off the stands and correctly reposition the stands.
8. When work is completed, raise the vehicle high enough off the stands where the stands can be easily removed.
CONSEQUENCES OF NOT AVOIDING HAZARDOUS SITUATIONS
Failure to read this manual completely and thoroughly, understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS,
MAINTENANCE INSTRUCTIONS and not comply with them, and neglecting the METHODS TO AVOID HAZARDOUS SITUATIONS
could cause accidents resulting in serious or fatal personal injury and/or property damage.
WARNING

-Save these instructions-
CSEVS3TBL/CSEVS3TNG/CSEVS3TRG
CSEVS6TBL/CSEVS6TNG/CSEVS6TRG:
3 TON AND 6 TON JACK STANDS
(PAIR - BLUE, NEON GREEN, ORANGE)
CSEVS3TBL/TNG/TRG, CSEVS6TBL/TNG/TRG 4 03/10/20
WARRANTY COVERAGE
Cornwell Quality Tools Company (“Cornwell”) warrants against defects on this product for a period of TWO (2) YEARS from the
date of original retail purchase. Subject to the conditions and limitations set forth below, Cornwell will, at its option, either repair or
replace any
part of the product(s) that proves defective by reason of improper workmanship or materials.
This warranty does not cover any damage to this product that results from accident, abuse, misuse, natural or personal disaster,
or any unauthorized disassembly, repair, or modification. Repairs, disassembly and modification are only authorized to be made by
Cornwell or
a warranty service center approved by Cornwell.
WARRANTY SERVICE
To obtain warranty service, contact your Cornwell dealer.
EXCLUSIONS AND LIMITATIONS
THIS WARRANTY AND THE REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES,
REMEDIES AND CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. CORNWELL SPECIFICALLY DISCLAIMS
ANY AND ALL IMPLIED WARRANTIES, INCLUDING, TO THE EXTENT PERMITTED BY APPLICABLE LAW, ANY WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IF CORNWELL CANNOT LAWFULLY DISCLAIM IMPLIED
WARRANTIES UNDER THIS LIMITED WARRANTY, ALL SUCH IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THE
DURATION OF THIS WARRANTY. IN NO EVENT SHALL CORNWELL BE LIABLE TO THE PURCHASER OR TO THE USER OF
A CORNWELL PRODUCT FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES BASED UPON BREACH OF
WARRANTY, BREACH OF CONTRACT, NEGLIGENCE, TORT, OR ANY OTHER LEGAL THEORY. SUCH DAMAGES INCLUDE,
WITHOUT LIMITATION, EXPENSES, LOST REVENUES, LOST SAVINGS, LOST PROFITS, OR ANY OTHER INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING FROM THE PURCHASE, USE OR INABILITY TO USE THE CORNWELL PRODUCT.
Some states do not allow the exclusion or limitation of incidental or consequential damages or exclusions or limitation on the
duration of implied warranties or conditions, so the above limitations or exclusions may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights that vary by state.
Repair kits and replacement parts are available for many Cornwell products, regardless of whether or not the product is still
covered by a warranty plan.

-Save these instructions-
PARTS LIST
CSEVS3TBL/CSEVS3TNG/CSEVS3TRG
CSEVS6TBL/CSEVS6TNG/CSEVS6TRG:
3 TON AND 6 TON JACK STANDS
(PAIR - BLUE, NEON GREEN, ORANGE)
CSEVS3TBL/TNG/TRG, CSEVS6TBL/TNG/TRG 5 03/10/20
Replacement parts not available due to safety precautions except for product label kits (1 pair):
RSCSEVS3TBLPLK - Product Label Kit for Blue Jack Stands
RSCSEVS3TNGPLK - Product Label Kit for Neon Green Jack Stands
RSCSEVS3TRGPLK - Product Label Kit for Orange Jack Stands
RSCSEVS6TBLPLK - Product Label Kit for Blue Jack Stands
RSCSEVS6TNGPLK - Product Label Kit for Neon Green Jack Stands
RSCSEVS6TRGPLK - Product Label Kit for Orange Jack Stands
Support
Column
Base
Tab
Fig. 1
