Kid's Balance Bike
TS10038
USER’S MANUAL
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
US:[e-mail]
UK:[e-mail]
AU:[email protected]
US office: Fontana UK office: Ipswich AU office: Truganina

Before You Start
General Warnings:
Danger! Keep all small parts and packaging materials for this product away from
babies and children, otherwise they may pose a choking hazard.
The product must be installed and used under the supervision of an adult.
Read through each step carefully and follow the proper order.
Remove all Packaging, separate and count all parts and hardware before
installation.
Please ensure that all parts are correctly installed, incorrect installation can lead to
a danger.
We recommend that, where possible, all items are assembled near the area in
which they will be placed in use, to avoid moving the product unnecessarily once
assembled.
Ensure a secure surface during installation, and place the product always on a flat,
steady and stable surface.
Please read all instructions carefully and keep it for future reference.
WARNING
Please read this manual carefully before using the product. In order to
avoid the safety problem, please use this balance bike in the correct way
according to this manual. Failure to comply with the manual may affect
children's safety.
Assembly by an adult. Toy may contain
potentially hazardous small part, sharp part,
sharp point, sharp edge in the unassembled
state.
Model No.: TS10038
Applicable Age: 2-6 YEARS OLD
Max. Load: 50KG/110LBS
02 03
A B C
Front Frame Rear Frame Handlebar D
E F
Front Fork
Saddle Pedal G H
Training Wheel Wrench
Part name
D-1

1. TO AVOID SERIOUS INJURY, continuous adult supervision is
required.
2. Shoes must be worn at all times.
3. Only one rider at a time.
4. Not to be used by children over the age of 2-6 years old,
insufficient strength.
5. Please check if every part and component is connected well before
using it. Otherwise, it will be dangerous and easy to break.
6. Keep away from the fire.
7. Warning: Plastic bags are dangerous. In order to avoid the danger
of suffocation, please put the bag away from the baby and children's
place.
8. Please do not load heavy things on balance bike. Otherwise, it will
be unstable and dangerous.
9. Please make sure all the connected parts are well locked before
using balance bike.
10. Ride-on toys should not be used near motor vehicles, streets,
swimming pools, on or near steps, hills, roadways, or inclines.
11. Do not use it in the downtown area or roadway as a vehicle.
12. To avoid injury, balance bike must be played on flat ground,
don’t play on slope ground. Please make sure there is no obstacle.
13. The maximum loading weight is 50KG/110LBS, only for one child.
Every riding time is no more than 1 hour.
14. The balance bike shall be used with caution, since skills are
required to avoid falls or collisions causing injury to the user or third
parties.
15. Adult assembly is required.
16. Prior to assembly, this package contains small parts: hardware,
which is a choking hazard and may contain sharp edges and sharp
points.
17. Keep away from children until assembled.
18. Protective equipment should be worn (e.g: protective helmet,
protective knee pads and protective elbow pads). Not to be used in
traffic.
First, unscrew the handlebar (C)
screw and nut with the wrench
(H), then insert the handlebar (C)
into the front fork (D) in the
direction of the arrow. Note that
the handlebar is aligned with the
front fork hole, then pass the
screw through the nut and lock it
with the wrench (H).
First loosen the connection of the
seat pipe, insert the saddle (E)
according to the dotted line, and
lock it with the wrench (H). As
shown in the figure, align the
training wheel (G) with the rear
wheel hole, and then tighten the
knob.
WARNING
Align the front frame (A) and the
rear frame (B) with each other as
shown in the figure. Tighten the
hexagon socket screws (B-1) with
the wrench (H).
As shown in the figure, insert the
pedal (F) into the hole of the front
fork (D) in the direction of the
arrow, and note that the foot
shrapnel pops up. Then insert the
fender (D-1) into the front fork
(D) according to the dotted line.
Insert the assembled frame into
the front fork (D) together.
Installation instruction
04 05
3
4
1
2

1. In order to avoid accidental injuries of your child, please check and
maintain this balance bike periodically. Wipe the balance bike directly
with dry cloth to clean it.
2. Apply lubricant periodically to the rotating parts like the front and
rear axles and handlebar shaft to extend the product's service life.
3. Periodically check if the screws are loose, and replace the damaged
components if there's any problem.
4. Aways check if the connecting bolt between the balance bike and
saddle is tightened and be sure that it is tightened with a torque no
less than 15N•m.
Maintenance and Repair
