Costway BE10019 User manual

Baby Swing & Highchair & Booster
Balançoire, Chaise Haute et Rehausseur de Chaise pour Bébé
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
If you're having difficulty, our friendly
customer team is always here to help.
USA office: Fontana AUS office: Truganina GBR office: Ipswich FRA office: Saint Vigor d'Ymonville
USA:[email protected]
AUS:[e-mail]
GBR:[e-mail]
FRA:[e-mail]
BE10019

Attention: To prevent possible injury by entanglement, remove this toy
when the child starts trying to get up on its hands and knees in a
crawling position.
Danger! Keep all small parts and packaging materials for this product
away from babies and children, otherwise they may pose a choking
hazard.
The product must be installed and used under the supervision of an
adult.
Read through each step carefully and follow the proper order.
Remove all packaging, separate and count all parts and hardware
before installation.
Please ensure that all parts are correctly installed, incorrect installation
can lead to a danger.
We recommend that, where possible, all items are assembled near the
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Ensure a secure surface during installation, and place the product
always on a flat, steady and stable surface.
Before You Start
Please read all instructions carefully and keep it for future reference.
EN
General Warnings
BABY SWING & HIGHCHAIR & BOOSTER
The product is intended for children able to sit independently
up to 3 years or with a maximum weight of 33 lbs
INSTRUCTIONS FOR ASSEMBLY AND USE
IMPORTANT! READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE.
For the safety of your child please read these instructions before using
the product.
02 03

baby swing, highchair, booster 3 in 1
Standard configuration pares
Three style Installation Instructions
1.Frame 2.Seat 3.Hanging tube(L+R)
L R
8.Toy bar 9.Remote control
4.Footrest 5.Front tray
7.Belt(Booster use)6.AC-DC Power adapter
baby swing highchair booster
4 5
8
79
6
1 2 3
*The picture is for reference only,
please refer to the real object.
*2 toys are included. The pictures
are for reference only, please refer
to the real object.
1.Installation of Rocking Chair: As shown in the figure, hold the button on the
horizontal tube of the rear leg and pull the support tube back until you hear the
"click" sound, which means you pull it in place; then adjust the upper boxes on
both sides to the highest gear, the 8th gear (as shown in Fig. c).
2.To install the spreader rod, align the left and right spreader rod with the
corresponding markings on the left and right upper boxes and press them
inward until you hear a "click" indicating that the rod is in place. Note: Incorrect
alignment will prevent the rod from being installed.
OK
OK
1
OK
b
a2
Click
Click
R R
L L
04 05
8

*The picture is for
reference only, please
refer to the real object.
3.Installation of the foot pedal: Align the left and right ends of the foot pedal
with the corresponding holes under the front end of the seat, and press until
you hear a "click" sound, which indicates that the installation is in place.
5.Installation of the toy shelf: As shown in the figure, align the plastic tubes on
both sides of the toy shelf with the corresponding holes on both sides of the
seat and install them. You will hear a "click" sound, which indicates that the
installation is in place.
6.Installation of battery: as shown in the figure, use a slotted screwdriver to
pull the battery compartment cover under the front bracket outward and install
LR14(C)1.5Vx4 batteries (note the "+" and "-" poles), and then cover the
battery compartment cover.
4.Installation of seat installation: Adjust the seat back to a horizontal angle (as
shown in Figure a), and then clip the seat into the slot on the frame suspender
until you hear a "click" sound, which indicates that the installation is in place.
OK
b
a3
Click
Click
Click
NO
OK
b
a
4
b
a5
+LR14(C) 1.5V - + LR14(C) 1.5V - + LR14(C) 1.5V - + LR14(C) 1.5V -
5V DC
b
a
6
06 07
Batteries: not included

3-Level Adjustment of the
Pedal Angle
5-Level Adjustment of the
Backrest
Back and Forth
Adjustment of the
Toy Rack Anti-Sway Function of the Swing
2-level Adjustment of the
Pedal Length
Function Description of Baby Swing
(when using the swing function, please use the product at level 7 or 8)
7.Five Gear Adjustments of the Backrest: Hold the adjusting handle firmly and
pull it up and down to adjust the gear. The toy rack can be adjusted back and
forth, and you can pull the toy shelf forward or backward to freely adjust the
gears.
8.The angle of the pedal is adjusted in three gears. The upward adjustment
can directly pull the pedal up. For downward adjustment, press and hold the
round buttons on both sides of the pedal and then press down. The length of
the pedal is adjusted in two gears. Press and hold the square buttons on both
sides of the pedal, and press and pull outward to adjust the length.
9.Anti-sway Function: If children fall asleep or you do not want it to swing, turn
the boom to make the anti-sway button. Align the " " arrow position on the
inside of the left and right upper boxes, and then push the anti-sway button
inward to stop the rocking of the rocking chair. In reverse, the rocking function
of the rocking chair can be restored by pushing the anti-rocking button
outward.
10.Folding Function: As shown in the figure, first adjust the foot to the lowest
angle and the backrest angle to the first gear. Hold the front bracket and press
the unlocking button(as shown in Fig. a). Then hold the folding button on the
horizontal tube of the rear bracket and pull it upwards to complete the folding.
Note: The actions are carried out at the same time, and incorrect
operation may result in failure to fold or damage to the folding structure.
7
8
9
1
2
43
10
a
3 4
Fold the Chair Complete
08 09
