Costway MU70017 User manual

USER'S MANUAL / HANDBUCH /
MANUEL DE L'UTILISATEUR / MANUAL DEL USUARIO /
MANUALE UTENTE / INSTRUKCJA OBSŁUGI
Weighted Key Digital Piano / Elektrisches Klavier /
Piano Numérique / Piano Digital /
Piano Digitale / Pianino cyfrowe
MU70017
EN DE FR ES IT PL
UNITED STATES
CANADA UNITED KINGDOM
GERMANY
FRANCE
ITALY
SPAIN
JAPAN
RUSSIA
AUSTRALIA
With your inspiring rating, COSTWAY will be more consistent to offer you EASY
SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE!
Mit Ihrer inspirierenden Bewertung wird COSTWAY konsistenter sein, um Ihnen
EIN SCHÖNES EINKAUFSERLEBNIS, GUTE PRODUKTE und EFFIZIENTEN
SERVICE zu bieten!
Avec votre évaluation inspirante, COSTWAY continuera à fournir une
EXPÉRIENCE D’ACHAT PRATIQUE, des PRODUITS DE QUALITÉ et un
SERVICE EFFICACE !
Con su calificación inspiradora, COSTWAY será más consistente para ofrecerle
EXPERIENCIA DE COMPRA FÁCIL, BUENOS PRODUCTOS y SERVICIO
EFICIENTE.
Con la tua valutazione incoraggiante, COSTWAY sarà più coerente per offrirti
ESPERIENZA DI ACQUISTO FACILE, BUONI PRODOTTI e SERVIZIO
EFFICIENTE!
Dzięki twojej opinii COSTWAY będzie mógł oferować jeszcze WYGODNIEJSZE
ZAKUPY, LEPSZE PRODUKTY i SPRAWNIEJSZĄ OBSŁUGĘ KLIENTA.
US office: Fontana
UK office: Ipswich
DE office: FDS GmbH, Neuer Höltigbaum 36, 22143 Hamburg, Deutschland
FR office : 26 RUE DU VERTUQUET, 59960 NEUVILLE EN FERRAIN, FRANCE

FEATURES
Thank you for choosing our digital piano. The digital piano is elegant and
exquisite, and it is the perfect combination of the latest electronic technology.
◆Before using this instrument, you must read the instructions in detail.
USING DREAM SOUND SOURCE
At its core is a top grade French DREAM
SOUND sound source with high
resolution digital sampling to bring to you
a lifelike auditory experience for your
peformance.
MULTIMEDIA MP3 PLAY
With MP3 multimedia playback functions
providing full music entertainment.
SPECIAL REMINDER
Stay away from radio, TV, antenna receiver, router, refrigerator and all RF
electrical interference sources such as motorized appliances.
PRODUCT CARE
Careful maintenance and protection of this product plays an important role in
prolonging the service life of the product and reducing failure.
1. AVOID HEATING, DAMPNESS OR DIRECT SUNLIGHT
Do not over expose the product to direct sunlight, or place it near air
conditioning or extremely hot place.
2. DO NOT USE NEAR THE TV OR RADIO.
This product may cause video or audio interference to the reception of TV
and radio. If this happens, the product should be removed from the TV or
radio.
3. NO PAINT, DILUENT OR SIMILAR CHEMICALS SHALL
BE USED FOR CLEANING.
Clean the product with a soft cloth wetted with weak water solution and
neutral detergent. Soak the cloth in a solution and wring it dry until it
approaches drying.
Progressive
Hammer Action
Keyboard
4. DO NOT SHAKE, AVOID COLLISION
When moving, the product should be handled carefully and lightly. Violent
vibration and collision are strictly prohibited in order to avoid damage to the
shell or internal electronic components.
JACK SOCKET
04-pedal
Sustain Audio in Audio out USB/MIDI DC 15v
03-double headphones
02 03

1. POWER LINE CONNECTION
1. When used according to the access power line, one end is inserted into the
socket at the bottom of the piano operation plate. The other end is inserted
into the 220-240V household power socket.
2. If you do not use this product for a long time, unplug the power cord and
keep it properly.
2. AUDIO INPUT/OUTPUT PLUG
1. The audio output socket can be connected to large sound box equipment.
2. The audio input socket connects the external sound source to the electric
piano for playback.
3. MIDI INPUT AND OUTPUT SOCKET
The MIDI interface of this digital piano can be connected to music equipment
with MIDI.
4. USB TRANSPORT INTERFACE
Use the USB port of this digital piano to connect to a computer. Through
pre-installed music software on the computer, you can play the keyboard to
perform music performance, composition, editing, storage and other
functions. The edited music and the built-in accompaniment of the music
software can be connected to the digital piano through the software for
playback, or play according to the accompaniment music.
5. DOUBLE HEADSET SOCKET
Connecting the headset will automatically cut off the output of the built-in
loudspeaker, so it won't disturb others when playing *This product has two
headphone sockets, which can insert two headphones at the same time.
6. PEDAL SOCKET
Insert the end of the pedal line into the circular socket on the bottom of the
piano, and you can connect the 3 pedal sound effects .ln turn : weak tone,
posterior extension and portamento.
INSTALLATION
OPERATION GUIDE
TOUCHMETRONOMEDRUM
USB
USB port
digital display
CHORD SYNC FILL-IN
SPLIT DUAL RECORD
TEMPO TRANSPOSE PLAY
TONE
POWER VOLUME
RHYTHM
START/STOP
DEMO
Function Panel
04 05

Basic operation
Preparatory work
This section introduces you to the basic operating knowledge of digital piano
How to play
1. switch the "power supply" switch to the on state, the display screen is lit
up, and enter the normal playing state.
2. adjust the volume potentiometer and adjust the volume to the appropriate
position.
3. play music on the keyboard.
The choice of timbre
There are 800 timbres in this product (see TONE list).
Please follow the following steps to select the desired timbre
How to select tone color
1. Find the timbre you need in the TONE list and remember its timbre
number.
2. Press the tone key to enter timbre mode.
3. Select the desired timbre by selecting the "+"/"-" key, the timbre number is
(000-799).
The convenience of chord accompaniment
The following steps describe how to use the chord functionality of this
product. Before you begin, you should first select the rhythm you want to use
and set the speed value.
Automatic accompaniment
The choice of rhythm
This product has 600 built-in rhythms (see the RHYTHM list), please follow
the steps below to select the desired rhythm.
How to choose rhythm
1. Press the rhythm key to enter the rhythm mode.
2. Select the desired rhythm by selecting the "+"/"-" key, the rhythm number
is (000-599).
3. Press the "start / stop" key to start playing the rhythm.
4. To stop the rhythm to play, and then press the "start / stop" key.
Synthetic chord accompaniment
1. Press the start / stop button to start broadcasting the currently selected
rhythm.
2. press the "chord" button to enter the chord state. If the chord mode of
single multi-finger reuse conforms to the multi-finger chord playing method,
the piano responds to the multi-finger chord; where the single-finger chord
method is not in accordance with the multiple-finger chord method, the
response is recognized according to the single-finger chord.
3. To play a chord, press different fingerings to perform different
performances on the accompaniment keyboard (1-22 keys from the left).
4. Press the “chord” button again to turn off the chord state.
Synchronous start
You can set this product to start playing rhythmically while you play
accompaniment on the keyboard. The following steps describe how to use
synchronous startup.
Before you begin, you should first select the rhythm to use, set the speed value,
and select the chord accompaniment.
Using synchronous startup
1. In the chord state, press the synchronize button to enter the synchronous
start standby state.
2. When you play the chord, the accompaniment will automatically start
broadcasting.
3. To cancel synchronization, press the start / stop button.
Use of Music Library
The built-in music library of this product contains 80 pieces of music (see list
of demonstration songs), and the built-in music is used for playback and
appreciation.
Chord keyboard Keyboard melody
06 07

The playing of music in a library
1. find the music to be played in the library list and record its number.
2. press the key of "DEMO" to enter the mode of demonstration song.
3. select the song by selecting the "+" "-" key Number (000-079)
4. Press the DEMO key or start / stop the key to stop playing to exit this
mode.
The music will continue to play in order until you stop it.
The use of keyboard strength tactile function
When the keyboard of this product is opened for the strength tactile keyboard
"strength" function, the relative volume of the electronic output music will
vary according to the intensity that the keyboard is pressed, and can play
music with different volume and different feelings.
1. press the strength TOUCH button, and the strength touch function is
activated.
2. press TOUCH again and turn off the tactile function.
When booting, it is automatically in the state of starting the strength tactile
function.
The use of keyboard Drum instrument function
Press the Drum button, switch the keyboard of the digital piano to the drum
key board, press the DRUM button again, and turn off the function.
The use of Dual Voice function
When using the Dual Voice function to play the keyboard, you can emit two
different timbre at the same time, showing the resonance effect of the two
musical instruments.
How to use Dual Voice function
1. first enter the timbre mode, choose a musical instrument as the main
timbre.
2. press the "DUAL" button to enter the second timbre selection mode.
3. use the "+/-" button to select a musical instrument as the second timbre.
The use of keyboard split function
Using the keyboard split function, you can assign two different timbre (main
tone and split tone) to both ends of the keyboard, so that you can play one
timbre with your left hand and another with your right hand to play an
ensemble effect.
Use of metronome function
Press the "metronome" button, the metronome function is activated, you can
follow the beat sound to play. Press the metronome button again, and the
metronome function is turned off.
Please use the “Tempo” button to set the speed.
Recording
1. Press the recording key to enter recording mode.
2. The maximum number of recordings is 250, and when the recording is full,
there will be no room for new recording.
3. Each time you press this key, you erase the last memory, and re-enter
recording mode.
Play sound
1. Press the PLAY key to play the recorded notes and drums, and play them
in the timbre selected for the recording at that time
2. Press the PLAY key, and if there is no previous memory value, no action
occurs.
Left keyboard Right keyboard
08 09
