THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Folding Poker Table
TQ10082
USER’S MANUAL

Before You Start
General Warnings:
The product must be installed and used under the supervision of an adult.
Read through each step carefully and follow the proper order.
Remove all packaging, separate and count all parts and hardware.
Please ensure that all parts are correctly installed, incorrect installation can lead to
a danger.
We recommend that, where possible, all items are assembled near the area in
which they will be placed in use, to avoid moving the product unnecessarily once
assembled.
Ensure a secure surface during installation, and place the product always on a flat,
steady and stable surface.
Please use this product with caution. The use of this product requires superb skills
to avoid accidents to the user or others due to a fall or collision.
Please wear suitable protective equipment during use, e.g. protective helmet,
gloves, knee pads, elbow pads etc.
Warnings:
Attention! Use it with protective equipment.
Attention! Not use it in the traffic.
Attention! The product is not suitable for the children under 3 years.
Please read all instructions carefully and keep it for future reference.
02

Safety Alert:
Contains small parts, not suitable for
children under 36 months!
Maximum Load: 66 lbs/30 kg
Please read and understand this manual before use!
This manual contains important information, please keep it for future
reference. Before using for the first time, please charge the battery
for at least 4-6 hours, but not more than 10 hours.
Safety Alert: This stroller must be assembled by an adult.
ASpecifications
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or re-chargeable
batteries.
Only use the battery(ies) specified by the manufacturer.
Only use the charger(s) specified by the manufacturer.
The battery is replaceable.
03

Specifications
Battery
Charger In-put
Motor
Suitable age
Charging time
Maximum load
Car size
Package size
Speed
6V4.5Ah*1
6V500MA
RS380SP 6V (380#) 25W RPM12000*2
37-95 months
6-10 hours
66 lbs/30 kg For one person only
26*26*18.7”/66.5*66.5*47.6 cm
26*8.8*26”/66.5*66.5*47.6 cm
2-2.5miles/h, 3-6Km/h
Battery Safety Alert
● Non-rechargeable batteries cannot be charged;
● The rechargeable battery can only be charged under adult
supervision;
● Different types of batteries or old and new batteries cannot
be mixed;
● The battery should be inserted with the correct polarity;
● The power terminals must not be short-circuited;
● Exhausted batteries should be removed from the toy
04

B
Spare parts list
2
3
13
1
4
56
7
8
9
10 11 12
Number Name Image Quantity
Cushiong screw1 1
Head stock2 1
Backrest3 1
05

Seat4 1
Wheel5 2
Motor6 2
Body7 1
Universal wheel8 2
Rear axle9 1
Fixed piece10 2
Gasket11 2
M8 machine screw12 2
M4*14 screw13 20
06

CSafety Alert
To prevent accidents
● The vehicle must be under adult supervision. Always be within
the sight of an adult when in use.
● When driving a vehicle, you should wear a protective helmet,
must wear shoes, must sit in the seat.
● Ensure that your child is driving the vehicle in a safe driving
environment, home, garden or playground.
● The maximum load-bearing capacity of this car is 66 lbs/30 kg,
and it is limited to one person.
● It is forbidden to drive this vehicle in unsafe areas, such as
public transportation roads.
Warning
● Contains small parts, not suitable for children under 36 months
● The product must be assembled by an adult!
● The assembly contains potentially dangerous sharp edges or
sharp points!
WARNING :
To reduce the risk of injury, adult supervision is required. Never use
in roadways, near motor vehicles, on or near steep inclines or steps,
swimming pools or other bodies of water, always wear shoes, and
never allow more than one rider.
RISK OF FIRE. Do not bypass. Replace only with 5A protector.
CHOKING HAZARD—Small parts. Not for children under 3 yrs.
07

08
D
Wheels Assembly
As the picture shows:
1. Turn the body over and install the motor(Plug in the motor connection wire
pair according to the wire color and embed it in the body hole.)
2. Insert the wheels into the rear axle, follow the gasket, and tighten it with a
M8 machine screw. The other wheel is the same way.
As the picture shows:
Put the two universal wheels into the slots and, choose the M4*14 screws to
tight into the car body.

09
EFront Faucet and Backrest Assembly
1. Connect the wire from the head stock with the car body according to their
same color.
2. Insert the head stock into the car body according to the slot.
3. Tighten it with car body with the M4*14 screws.
4. Insert the backrest into the back position, and fix it with M4*14 screws.

10
Battery Connection and
Cushion Installation F
As shown in the figure, please connect the power wire according to their
same color, before tight the seat with the cushion screw!
Insert the seat into the slot as shown in the picture.
1 and 2: car front and rear switch, two forwards at the same time according
to move the car forward; two forwards at the same time according to move
the car backward; the separate handle controls left and right turns
separately.
3: for the player, can play songs alone and can also use the tool to
outsourcing
outsourcing
4: the car power supply
5: the light switch (optional)
12
4
5
3

11
GHow to use the remote control
(if equipped)
How to connect the remote control with the vehicle, check follows: First, open
the cover in back of the remote control,put two 1.5V aa battery (prepared by
yourself)
Note: Place the positive and negative poles. Place the power supply
short-circuited.
1. Turn off the power of the vehicle and press the code
button for 3-5 seconds (while pressing and holding the Left
and Right switch for the code matching key), turn on the
power of the vehicle after the indicator light flashes.
2. Forward and reverse switch: according to the forward direction, the vehicle
moves forward.
3. Stop button: Control the vehicle to stop in an emergency.
4. Speed selection: During driving, adjust the speed of the vehicle.
5. The remote control can be turned off automatically after two minutes of
no-touch.
In addition, the remote control can directly control the vehicle when the
battery is added, but without connecting with your own vehicle, other remote
control can also control it. After paired, this car is only controlled by your own
remote control!
Attention:
The remote control will die for about 10 seconds with no touch.
When replacing the remote control battery, you need to reconnect it.
1
2
345
6
7
1.Forward
2.Back
3.Brake
4.Left
5.Speed
6.Right
7.Speed display
Channel
1 2426
Frequency
(MHz)

12
H
Charging
Warning
This product has a charging protection function: when
charging, has no functions. Only adults can charge the
battery!
When charging, the power switch must be off.
Before the first use, the battery should be charged for 4-6 hours. The
charging time should not exceed 10 hours to prevent the battery from
overheating.
When the vehicle starts to slow down, charge the battery.
Use the only rechargeable battery and charger provided with the car. Never
replace the battery or charger with another brand.
Using other batteries or chargers may cause fire or explosion .
Do not use batteries or chargers with any other products.
1. Plug the charger port into the socket.
2. Insert the charger plug into the wall socket. The battery will start
charging.
The charging
hole

13
IFailure Recovery
Fault Type Checkpoint Troubleshooting
The vehicle
is not
running
Low battery Charging.
The running
time is
not long
Insufficient battery
charge
When charging, check whether the
battery connector is installed
properly.
Slow speed Low battery Charging, Please contact your
dealer
Battery aging Please contact your dealer to
replace the battery.
Over loading Reduce vehicle weight
The vehicle is used in
harsh conditions
Avoid using the vehicle in harsh
conditions. See safety notice
Battery aging Please contact your dealer to
replace the battery.
Thermal protector
tripped
Reset the protector. See protector.
Loose battery
connector or wire
Check the battery.
Battery is damaged Please replace the battery.
The electrical system
is damaged
Please contact customer services.
Motor damage Please contact customer services.

14
Need to
move
forward
Poor contact of wires
or connectors
Check whether the battery
connector is firmly inserted and
the wires around the motor.
Can not
charging
electricity
Loose battery/
Cahrging connector
Check whether the battery
connector is firmly inserted.
The charger is not
plugged in
Check whether the battery charger
is plugged into a working socket.
Charger not working Please contact customer services.
The motor or
gearbox
makes
a loud noise
Motor or gear dmaged.
The charger
has a
temperature
while
charging
This is normal working condition
Motor crashes A crash means that the power is
not transmitted to the terminal
and the vehicle needs to be
repaired.
Hard to
switch from
forward gear
to reverse
gear, vice
versa
Try to fully stop and change gears while the vehicle is
moving, please refer to the use of function keys.
Before calling, please read this manual and troubleshooting guide
completely. If you still need help to solve the problem,
please contact customer services.

J
Maintenance
● Parents are responsible for checking the main components of the vehicle
before use, and must regularly check for potential hazards.
For example,whether batteries, chargers, cables or wires, plugs, screws are
fastened to other parts of the shell, if such damage occurs, the toy must be
properly removed before the toy can be used.
● Make sure that the plastic parts of the vehicle are not cracked or broken.
● Occasionally use light oil to lubricate moving parts, such as wheels.
● Park the vehicle indoors or cover it with a tarpaulin to prevent wet weather.
● Keep the vehicle away from heat sources such as stoves and heaters.
Plastic parts may melt.
● Charge the battery after each use. Only adults should handle the battery.
When the vehicle is not in use, charge the battery at least once a month.
● Do not use hoses to clean the vehicle. Do not wash the vehicle with soap
and water. Do not drive the vehicle in rain or snow. Water can damage the
motor, electrical system and battery.
● Clean the vehicle with a soft dry cloth. To restore the gloss of plastic parts,
use wax-free furniture polish. Do not use car wax, do not use abrasive
cleaners.
● Do not drive the vehicle on loose soil, sand or fine gravel, otherwise the
vehicle will be damaged.
● When not in use, all power supplies should be turned off. Turn off the power
switch and disconnect the battery.
15

KProtector
The battery has a thermal fuse and rest protector, which will automatically
trip and cut off all functions if the vehicle electrical system or battery is
overloaded.The protector will reset, and the power will be restored 20
seconds after the device is turned off, and then turned on again. If the
thermal protector blows repeatedly during normal use, the vehicle may need
repair, please contact your dealer.
● Do not overload.
● Don't drive up steep slopes.
● Do not drive into a fixed object, otherwise it will cause the wheels to slip
and cause the motor to overheat.
● Do not drive in very hot weather, the parts may overheat.
● Do not allow water or other liquids to contact the battery or other electrical
components.
● Do not damage the electrical system, as this may cause a short circuit and
cause the protector to trip.
● The illustrations used in this manual are to illustrate the operation method
and product structure of the product. When there is a small difference
between the actual product and the illustration, please refer to the actual
product.
● In order to improve the quality of the product, we may change part of the
structure and appearance of the product without notice. Please understand.
To avoid power outages, please follow these guidelines:
● Sealed lead-acid batteries must be recycled or disposed of in an
environmentally friendly manner.
● Do not put lead-acid batteries in fire.
● Do not discard lead-acid batteries in your ordinary household trash. The
garbage law prohibits incineration, landfill or mixing of sealed lead-acid
batteries with domestic garbage.
Disposal of the battery
16

Please give us a chance to make it right and do better !
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP !
Contact Us!
Do NOT return this item.
US office: Fontana UK office: Ipswich AU office: Truganina
DE office: Hamburg
FR office: Saint Vigor d'Ymonville PL office: Gdańsk
US:[e-mail]
UK:[e-mail]
AU:[email protected]
