Courtyard Creations KTS816C-WM User manual

KTS816C-WM
PAGE 1 OF 2
STOP DON’T RETURN TO STORE!
COURTYARD CREATIONS INC.
Step 2:
At the rear of the seat/back assembly (#1), fasten the seat and
the back by using bolts (#4) and washers (#7). Keep the
bolts loose. See Figure 2.
Note:
The bolts on the seat/back assembly (#1) should be
loose before assembling the chair. See Figure 1.
Step 1:
Open the seat/back assembly (#1) and place it onto a
non-abrasive surface, such as a carpet. See Figure 1.
Attention:
Make sure that each bolt needed for all steps matches the
corresponding figure to ensure proper assembly.
#4 BOLT M6*16
16
7
4
8
1
FIGURE 2FIGURE 1
HEX.KEY WRENCH 4MM
HEX.KEY WRENCH 6MM
BOLT CAP M6
BOLT CAP M6
BOLT CAP
WASHER d6.5*D13*1.0
BOLT M6*14
BOLT M6*16
BOLT M6*35
RIGHT LEG
LEFT LEG
SEAT/BACK ASSEMBLY
17KAA0201----Y4
17KAA0101----Y4
18000337002
18000337006
18000337004
17C33A0712001Y4
17FA05040301-Y4
17C02A0755131Y4
17C33A0706001Y4
KTS816C-CS02
KTS816C-CS03
KTS816C-CS01
1
1
2
2
8
6
11
12
10
9
7
8
2
2
4
1
1
1
6
5
4
3
2
1
Q’TY
MATERIAL CODE PART
PART
NO.
MATERIAL CODE PART Q’TY
PARTS LIST
PART
NO.
ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by children. Children
should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
Quote the following FQC NO. when contacting the service center.
SERVICE CENTER TOLL FREE NO.
TEL: [phone]
FAX: [phone]
!
!
!
!
!

8
8
10
FIGURE 6
STOP DON’T RETURN TO STORE!
PAGE 2 OF 2
Step 6:
Tighten the bolts on the seat assembly (#1). Make sure that
all of the bolts have been tightened completely and cover
them with bolt caps (#8, #9 and #10). See Figure 6.
#6 BOLT M6*35
35
3
2
8
6
7
1
FIGURE 5
Step 5:
At the back of the chair, fasten the seat/back assembly (#1)
to the legs (#2 and #3) by using bolts (#6) and washers (#7).
See Figure 5.
Step 4:
At the front of the chair, fasten the legs (#2 and #3) to the
cross brace on the seat/back assembly (#1) by using bolts
(#5). See Figure 4.
Step 3:
At the front of the chair, fasten the legs (#2 and #3) to the cross
brace on the seat/back assembly (#1) by using bolts (#4) and
washers (#7). See Figure 3.
#5 BOLT M6*14
14
5
9
3
2
1
FIGURE 4
#4 BOLT M6*16
16
8
4
7
3
2
1
FIGURE 3
Note:
The labels marked “L” and “R” on the legs (#2 and #3) should
coincide with Figure 3 to ensure proper assembly.
R
L
Cleaning and Maintenance
• Wash frame parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach, acid, or other solvents
on the frame parts.
• Cushions may be washed on the surface only by using mild soap and water or commercial foaming upholstery cleaner if
necessary. If washed, rinse well and hang to dry. Do not machine wash or dry.
• We recommend the use of furniture covers when not in use.
• Inspect and tighten all bolts and fasteners on a regular basis to ensure the proper performance and safety of your chair.
• In order to prolong the life and beauty of your chair, we recommend that it be stored in a dry and protected area during off
season periods.
The store where you made your purchase
does not stock parts for this item.
If you need parts,
whether they are missing or damaged,
STOP!
Missing A Part?
No Need To Go Back To
The Store
Call us between 9:00 AM and 4:30 PM
Eastern Time Monday through Friday
Call Toll Free:
TEL: [phone]
FAX: [phone]
READ THESE INSTRUCTIONS COMPLETELY BEFORE STARTING ASSEMBLY
SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU
HAVE ALL OF THEPARTSLISTED.
IF YOU DO NOTLOCATE ALL OF THE PARTS LISTED, INSPECT THE
PACKING MATERIAL FOR SMALL PARTSTHAT MAYHAVEBECOME
SEPARATED DURING SHIPMENT.
IF YOU EXPERIENCEANY DIFFICULTY DURING ASSEMBLYOR IF ANY
PARTS ARE MISSING OR DAMAGED,CALL THE HELP LINE AT
1-877-539-7436 BEFORERETURNING THIS ITEM TO THE STORE.
PROVIDE THEFOLLOWING INFORMATION WHEN CALLING:
1-MODEL NUMBER OF THEPRODUCT.
2-PARTNUMBER AND MATERIAL CODE OF THE PARTFROM THE PARTS
LIST.
MOST PROBLEMS CAN BERESOLVED WITHOUT RETURNING THIS
PRODUCT TO THERETAILER.
