Creative Zen Neeon Series User manual

1
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Türkçe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Language TOC.fm Page 1 Thursday, October 27, 2005 11:05 AM

2
Language TOC.fm Page 2 Thursday, October 27, 2005 11:05 AM

English
3
Congratulations_____________________
Zen Neeon is the new digital player from Creative. Read on to learn how to get started with your
new player!
To get the most out of your player, also read the comprehensive User’s Guide on your Installation
and Applications CD.
3
1 2
1. Power On / Off, Play /
Pause and Record button
Enables various functions,
depending on the mode you are in.
Starts and pauses recordings.
Press and hold to turn the player on
and off.
Press once to start playing tracks, and
press again to pause playback.
2. Scroller
For information on using
the Scroller, see “Using
the Scroller” on page 5.
3. Organic Light Emitting Diode
(OLED) Display
Shows playback status and current
battery level.
English.fm Page 3 Thursday, October 27, 2005 11:11 AM

4
4 5
10 9 8 7 6
4. Volume Increase /
Decrease buttons
Increases /
decreases the volume.
5. Button Lock switch
Locks or unlocks the
player.
6. Reset button
Resets your player
7. Microphone
Records voices.
8. Line-In jack
Connect audio sources to this jack to
make Line-In recordings.
9. Headphone jack
Connect earphones or headphones to
this jack.
10. USB / power adapter
connector
Connect your USB cable or
power adapter (available
separately) to this connector. For more
information on this and other Zen
Neeon accessories, visit
www.creative.com.
English.fm Page 4 Thursday, October 27, 2005 11:11 AM

5
Using the Scroller __________________
We use the term “Scroll-select” to mean the following actions:
Getting Started ____________________
Step 1: Set up software
1. Turn on your computer.
If you have Windows XP or Windows 2000, you must log in as an administrator in
Windows before you can set up the software. For more information, refer to your
operating system’s online Help.
2. Insert the Installation and Applications CD into your CD-ROM/DVD-ROM drive. Your CD
should start automatically. If it does not, follow the steps below:
i. Double-click the My Computer icon.
ii. Right-click the CD-ROM/DVD-ROM drive icon, and then click AutoPlay.
You can use the Scroller to move between tracks, or turn and hold the Scroller to move
within a track.
DO NOT connect your player to your computer before setting up the software.
Music
Play Mode
EQ
Delete
1. Turn the Scroller. 2. Highlight the menu
option you want.
3. Press the Scroller.
English.fm Page 5 Thursday, October 27, 2005 11:11 AM

6
3. Follow the instructions on the screen and when prompted, restart your computer.
4. When your computer restarts, follow the product registration instructions on the screen.
5. When prompted, connect your player to your computer’s USB port using the supplied USB
cable. Do not press the buttons on your player while connecting it to your computer.
You will require an Internet connection to register your product.
230
English.fm Page 6 Thursday, October 27, 2005 11:11 AM

7
Step 2: Turn on player
Your player comes preloaded with some music to get you started immediately.
1. Press and hold the Play/Pause button until your player turns on.
2. Connect your earphones and press the Volume
buttons to adjust the volume.
3. Press the Play/Pause button to play the
preloaded content.
4. When you turn on your player for the first time, the menu
will be in English. To change the language:
i. Press the Scroller.
ii. Scroll-select the Settings option.
iii. Scroll-select the Language option.
iv. Scroll-select a language.
5. After you have finished using your player, press and hold the Play/Pause button
until the OLED display turns off.
For more information on using the Scroller, see “Using the Scroller” on page 5.
English.fm Page 7 Thursday, October 27, 2005 11:11 AM

8
Step 3: Charge the battery
1. Make sure your player is connected to your computer’s USB port with the supplied USB
cable. Connect to a computer USB port only; avoid connecting to a USB hub.
When the battery is charging, the battery charging icon flashes on the OLED display.
2. Disconnect your player from your computer when the battery is fully charged and you see
on your OLED display. It takes approximately six hours to charge your player fully.
For Windows 98SE only: DO NOT charge your player's battery via the USB cable until
after you have installed the software.
When charging the battery, avoid transferring files between your player and computer as this
may lengthen the charging time.
For continuous charging, make sure your computer does not enter power conservation mode,
for example, Standby or Hibernation. For more information, refer to your operating system's
Help.
To charge your player without using the computer, use the Zen Neeon power adapter (available
separately).
English.fm Page 8 Thursday, October 27, 2005 11:11 AM

9
Step 4: Rip and copy music
Rip music from your CD collection to your player, or copy audio files (such as music you have
purchased online) from your computer.
To rip music from your CD collection
1. Make sure your player is connected to your computer as shown on page 6.
2. Double-click the My Computer icon on your desktop.
Alternatively, click Start →My Computer.
3. Double-click the Zen Neeon Media Explorer icon.
4. Click the Rip Audio CDs button.
5. Follow the instructions on the screen.
Album information is automatically retrieved if you are connected to the Internet, and have
registered with a music information provider like CDDB®.
To copy audio or data files from your computer
1. Make sure your player is connected to your computer as shown on page 6.
2. Double-click the My Computer icon on your desktop.
Alternatively, click Start →My Computer.
You will notice that your player is recognized as a Removable Disk.
3. Double-click the Zen Neeon Media Explorer icon.
4. Click the Browse Data button.
5. Locate your audio (MP3 or WMA files) or data files on your computer and copy them to
your player using the drag-and-drop method.
WMA files with Digital Rights Management (DRM) cannot be copied to your player using
Windows Explorer. You can only do so with applications that support this technology, such as
Zen Neeon Media Explorer and Creative MediaSource™.
English.fm Page 9 Thursday, October 27, 2005 11:11 AM

10
Step 5: Disconnect player
When disconnecting your player from your computer, always use the Windows Eject or
Safely Remove Hardware icon on the Taskbar to safely disconnect your player. If your
player is not disconnected safely, the content may become corrupted and the player will not
function correctly. Follow these steps below to safely disconnect your player:
To safely disconnect your player in Windows XP, Windows 2000 or Windows Me
Click the Safely Remove Hardware icon on the Taskbar, click Safely remove USB
Mass Storage Device, and disconnect your player when you are prompted to do so.
To safely disconnect your player in Windows 98SE
1. Wait at least 10 seconds after all file transfers are completed.
2. On your desktop, right-click the My Computer icon and select Explore.
3. Right-click the Removable Disk icon, click the Eject option.
4. Disconnect your player when you are prompted to do so.
English.fm Page 10 Thursday, October 27, 2005 11:11 AM

11
Playing a Track _____________________
1. Press the Play/Pause button until the OLED display lights up.
2. Press the Scroller, then scroll-select the Music option.
3. Press the Scroller, then scroll-select Browse.
4. Scroll-select a track.
Locking Your Player_________________
Locking disables all buttons on your player except the Scroller. Lock your player when you want
to prevent buttons from being accidently pressed.
To lock your player, move the switch toward the icon.
To unlock your player, move the switch away from the icon.
Using Playlists ______________________
You can instantly create a collection of audio tracks (a playlist) with Zen Neeon Media Explorer
and Creative MediaSource. For more information on creating playlists, see the online Help for
these applications.
1. In Music mode, press the Scroller.
2. Scroll-select Playlists.
3. Scroll-select a playlist.
4. Press the Play/Pause button to start playback.
To ensure proper playback of a playlist, add only tracks that are from the same Library folder
(for example, Root Library or Library A).
English.fm Page 11 Thursday, October 27, 2005 11:11 AM

12
Managing Music and Data ____________
Zen Neeon Media Explorer and Creative MediaSource are included with your player. Install and
try out both applications to decide which one is more suitable for your needs.
Zen Neeon Media Explorer
Use Zen Neeon Media Explorer if:
• you are new to digital music and want to transfer music from your CDs to your player
• you prefer to manage your player in the familiar “Windows Explorer” environment.
To start Zen Neeon Media Explorer, double-click the Zen Neeon Media Explorer icon under My
Computer or on the desktop.
For more information about using Zen Neeon Media Explorer, refer to its online Help.
Creative MediaSource
Use Creative MediaSource, a full-featured media organizer/player, if:
• you want to access additional features such as recording, automatic playlist generation and
audio format conversion
• you want to manage a music library on your computer.
To start Creative MediaSource, double-click the Creative MediaSource icon on your desktop.
For more information about using Creative MediaSource, refer to its online Help.
English.fm Page 12 Thursday, October 27, 2005 11:11 AM

13
More Information___________________
User’s Guide
Read the User’s Guide found on your Installation and Applications CD to learn about your
player’s many features. Go to d:\manual\<language>\manualfb.chm
(replace d:\ with the drive letter of your CD-ROM/DVD-ROM drive, and <language> with a language that
your User’s Guide is available in)
Creative Knowledge Base
Resolve and troubleshoot technical queries at Creative's 24-hour self-help Knowledge Base.
Go to www.creative.com, select your region and then select Support.
Product Registration
Registering your product ensures you receive the most appropriate service and product support
available. You can register your product during installation or at www.creative.com/register.
Please note that your warranty rights are not dependent on product registration.
Customer Support Services and Warranty
You can find Customer Support Services, Warranty and other information in the CD.
(replace d:\ with the drive letter of your CD-ROM/DVD-ROM drive, <region> with the region that you are in,
and <language> with the language that your document is in)
Customer Support Services d:\support\<region>\<language>\support.chm
Warranty d:\warranty\<region>\<language>\warranty.chm
Please keep your Proof of Purchase for the duration of the warranty period.
User’s Guide d:\manual\<language>\manualfb.chm
English.fm Page 13 Thursday, October 27, 2005 11:11 AM

14
Safety Advice _______________________
Refer to the following information to use your player safely, and to reduce the
chance of electric shock, short-circuiting, damage, fire, hearing impairment or
other hazards.
• Do not dismantle or attempt to repair your player, battery or power adapter.
Refer all servicing to Creative or authorized repair agents.
• Do not expose your player or battery to temperatures outside the range of 0°C to 45°C
(32°F to 113°F).
• Do not pierce, crush or set fire to your player or battery.
• Keep your player or battery away from strong magnetic objects.
• Do not subject your player to excessive force or impact.
• Do not expose your player or battery to water or moisture.
If your player is moisture-resistant (see product packaging for details), take care not to
immerse your player in water or expose it to rain.
• Do not listen to audio at high volume for prolonged periods of time.
• Do not attempt to remove the embedded battery. The player must be disposed of according
to local environmental regulations. To replace the battery, return your player to your regional
support office. For product service information, go to www.creative.com.
Improper handling may void the warranty for your player.
For more information, read the warranty available with your product.
English.fm Page 14 Thursday, October 27, 2005 11:11 AM

15
As with any digital media-based storage device, data should be backed up regularly. We strongly
recommend that you observe the usage precautions laid out in this booklet, and also back up
the data in your player regularly. In no event will Creative be liable for any indirect, incidental,
special or consequential damages to any persons caused by Creative's negligence, or for any lost
profits, lost savings, loss of use, lost revenues or lost data arising from or relating to this device,
even if Creative has been advised of the possibility of such damages. In no event will Creative’s
liability or damages to you or any other person ever exceed the amount paid by you for the
device, regardless of the form of the claim. Some countries/states do not allow the limitation or
exclusion of liability for incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
Copyright © 2005 Creative Technology Ltd. All rights reserved. The Creative logo, Zen Neeon and Creative MediaSource
aretrademarksor registeredtrademarksof CreativeTechnologyLtd. intheUnited Statesand/or othercountries. Microsoft,
Windows and the Windows logo are registered trademarks of Microsoft Corporation. CDDB is a registered trademark
of Gracenote, Inc.
English.fm Page 15 Thursday, October 27, 2005 11:11 AM

日本語
16
お買いあげいただきありがとうございます
Zen Neeon は、Creative の最新デジタルプレーヤーです。このプレーヤーの使用方法については、本
書をお読みください。
プレーヤーを最大限にご活用いただくためには、インストールおよびアプリケーション CD に収録さ
れている総合的な「ユーザーズガイド」もあわせてお読みください。
3
1 2
1. [電源の ON/OFF、再生／一時
停止、録音 ] ボタン
現在のモードによって様々な
機能が有効です。
録音の開始と一時停止を行います。
このボタンを押し続けると、プレーヤーの
オン／オフを切り替えることができます。
１度押すとトラックの再生を開始し、もう
１度押すと再生を一時停止します。
2. スクローラ
スクローラの使用方法につ
いては、「スクローラの使い
方」18 ページを参照してく
ださい。
3. OLED（Organic Light Emitting Diode）画面
再生ステータスと現在のバッテリー残量を
表示します。
English_JP.fm Page 16 Friday, October 28, 2005 1:52 PM

17
4 5
10 9 8 7 6
4. [ボリュームを上げる ]
ボタン／ [ ボリューム
を下げる ] ボタン
音量の上げ下げを行います。
5. ボタンロックスイッチ
プレーヤーのロックと
ロックの解除を行います。
6. [リセット ]ボタン
プレーヤーをリセットします。
7. マイク
音声を録音します。
8. ライン入力ジャック
音源をこのジャックに接続してライン入力
録音を行います。
9. ヘッドフォンジャック
イヤフォンまたはヘッドフォンをこの
ジャックに接続します。
10. USB ／電源アダプタコネクタ
USB ケーブルまたは電源アダ
プタ（別売り）をこのコネクタ
に接続します。その他の Zen
Neeon アクセサリを含めて、詳
細については、www.creative.com にアク
セスしてください。
English_JP.fm Page 17 Friday, October 28, 2005 1:52 PM

18
スクローラの使い方____________________
「スクロール選択」とは、次の操作を指します。
ご使用の準備__________________________
手順 1: ソフトウェアのセットアップ
1. コンピュータの電源をオンにします。
Windows XP または Windows 2000 の場合、ソフトウェアをセットアップする前に、Windows に
管理者としてログインしてください。詳細については、オペレーティングシステムのオンライン
ヘルプを参照してください。
2. インストールおよびアプリケーション CD をCD-ROM/DVD-ROM ドライブに挿入します。ディ
スクは Windows の自動再生モードに対応しているため自動的に起動します。自動的に起動しな
い場合は、CD-ROM ドライブの自動挿入機能を有効にする必要があります。次の手順に従って
ください。
i. [マイ コンピュータ ]アイコンをダブルクリックします。
ii. [CD-ROM/DVD-ROM ドライブ ] アイコンを右クリックし、[自動再生 ]をクリックします。
スクローラを使用してトラック間を移動でき、スクローラを押しながら上下すると、トラック内を移
動できます。
ソフトウェアをセットアップする前に、プレーヤーをコンピュータに接続しないでください。
1. スクローラを上下する。 2. 必要なメニューオプション
をハイライトする。
3. スクローラを押す。
English_JP.fm Page 18 Friday, October 28, 2005 1:52 PM

19
3. 画面に従い、指示されたらコンピュータを再起動します。
4. コンピュータを再起動したら、画面に表示される製品の登録に関する指示に従います。
5. 指示されたら、同梱されている USB ケーブルを使用して、プレーヤーをコンピュータの USB
ポートに接続します。プレーヤーをコンピュータに接続している時は、プレーヤーのボタンを押
さないでください。
製品登録を行うには、インターネットに接続する必要があります。
230
English_JP.fm Page 19 Friday, October 28, 2005 1:52 PM

20
手順 2: プレーヤーの電源投入
すぐに使い始められるように、プレーヤーにはあらかじめ何曲か用意されています。
1. プレイヤーの電源がオンになるまで [ 再生／一時停止 ] ボタンを押します。
2. ヘッドフォンを接続し、 [ボリューム ] ボ
タンを押して音量を調整します。
3. [ 再生 /一時停止 ] ボタンを押して用意されている曲
を再生します。
4. はじめてプレーヤーの電源をオンにした場合は、メニューが
英語で表示されます。言語を変更するには、次の操作を行い
ます。
i. スクローラを押す。
ii. [ 設定 ]オプションをスクロール選択します。
iii. [ 言語 ]オプションをスクロール選択します。
iv. 言語をスクロール選択します。
5. プレーヤーを使い終わったら、OLED 画面がオフになるまで [再生／一時停止 ] ボタン
を押します。
スクローラの使用方法については、「スクローラの使い方」18 ページを参照してください。
English_JP.fm Page 20 Friday, October 28, 2005 1:52 PM
