Cres Cor H-339-X-C Series Manual

5925 Heisley Road • Mentor, OH 44060-1833
Insulated
Holding Cabinet FL-2300
Rev. 4 (5/14) Page 1 of 4
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
ELECTRICAL SPECIFICATIONS:
MODEL Volts Watts Amps Hertz Phase NEMA
H-339-X-128C,
UA-8C, 188C,
12-188C, 1813C
120 900 7.5 60 1 5-15
H-339-X-128C-240,
188C-240, 12-188C-240,
1813C-240, UA-8C-240
240 900 3.8 60 1 6-15
HOW TO INSTALL UNIT:
1. Plug cord into 15-amp wall outlet.
2. Place cabinet in a well ventilated area.
3. Insert pan slides into the cabinet.
4. Push the switch on, turn the thermostat to No. 10
and run the unit for one hour.
NOTE: DO NOT PUT IN FOOD!
This step is to burn off manufacturing oils and
excessive adhesive.
5. Let the cabinet cool and wipe inside clean with
detergent and hot water before use.
HOW TO OPERATE UNIT: (Figure 1)
1. Push switch “ON”. Yellow light will come on.
2. Turn thermostat to the temperature you need.
NOTE: No. 7½ setting will give you about 180° F.
Proper food holding temperature is 140° F or
higher.
3. Preheat cabinet for 45 minutes
4. Put food into cabinet.
5. Turn the wing nut on the door vent to open the
vent when less humidity is needed.
To Turn Off Unit:
Push switch “OFF”. The yellow light will go off.
NOTE: Thermometer gives the inside cabinet
temperature.
Figure 1
Control Panel
OPERATING and MAINTENANCE INSTRUCTIONS
For INSULATED UNDERCOUNTER CABINETS
MODEL H-339-X-C Series

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
Insulated
Holding Cabinet FL-2300
Rev. 4 (5/14) Page 2 of 4
MAINTENANCE INSTRUCTIONS
BEFORE CLEANING CABINET:
1. Unplug power cord from wall.
2. Do NOT hose cabinet with water.
3. Do NOT get water on controls.
4. Do NOT use abrasives or harsh chemicals.
Hints:
1. Wipe up spills as soon as possible.
2. Clean cabinet regularly to avoid heavy dirt build-up.
3. Make a test spot with cleaner.
4. Follow manufacturer’s directions on cleaner.
5. Do not mix cleaners
6. Avoid drips and splashes.
CABINET
Inside and
Outside
(Aluminum)
SOIL CLEANER METHOD
DIRT
Mild detergent* and hot water, or
mild abrasive cleaner.
1. Use soft, damp cloth.
2. Rinse with hot water.
3. Wipe dry.
FINGERPRINTS,
GREASE OIL
Steam (no strong alkaline additive) 1. Rinse after steam cleaning.
2. Wipe dry.
Detergent* and hot water 1. Wipe with soft, damp cloth.
2. Rinse with hot water.
3. Wipe dry.
Chemical oven cleaner for
aluminum
Follow oven cleaner
manufacturer’s directions.
Mild abrasive cleaner.
Oily or waxy cleaner.
Apply with soft, clean cloth.
WATER SPOTS Mild abrasive cleaner. Wipe with damp cloth.
*Mild detergents include soaps and non-abrasive cleaners.
HOW TO ADJUST THE DOOR LATCH:
1. For vertical adjustment
(Up and down movement):
a. Loosen (2) screws located in magnetic
strike on cabinet.
b. Move strike up or down for alignment to
magnet on latch.
c. Tighten screws to secure
2. For horizontal adjustment
(Greater or lesser magnetic draw):
a. Loosen four (4) screws in latch on door.
b. Move latch forward or backward to adjust
magnetic draw.
c. Tighten screws to secure.
WARNING

5925 Heisley Road • Mentor, OH 44060-1833
Insulated
Holding Cabinet FL-2300
Rev. 4 (5/14) Page 3 of 4
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
MAINTENANCE INSTRUCTIONS
HOW TO REVERSE DOOR HARDWARE
FOR OPPOSITE HAND
Refer to Fig. 3 (hinge):
1. Pop off hinge covers with screwdriver.
2. Remove screws from hinges to cabinet; remove
door and unscrew latch strike from cabinet.
3. Remove hinges, latch and all remaining screws
from the right and left side of door. Keep all
screws.
4. Re-mount hinges and latch in the same hole
pattern on the opposite sides of the door. Plug all
extra holes with screws.
5. Remove all screws from the front sides of cabinet
(not the top and bottom).
6. Hold door up to cabinet and screw hinges to the
cabinet.
7. Open door and re-mount the latch strike to cabinet.
8. Plug all extra holes with screws and snap on the
hinge covers. Figure 3
TROUBLE-SHOOTING CHART
FAILURE POSSIBLE CAUSE/CHECK
1. Unit does not heat: a. Thermostat turned up.
b. Switch is “ON”.
c. Cord is plugged into outlet.
d. Circuit breaker/fuse for
wall outlet
2. Unit will not turn off: a. Thermostat turned down.
b. Switch is “OFF”
If cause is none of the above, refer to our list of
authorized service agencies, FL-1400.
Instructions for replacing parts are included in
replacement parts kits.
DESCRIPTION KIT NUMBERS FOR H-339 MODELS
-UA-8C -128C -188C 12-188C -1813C
Door Kit 5508-085-K 5508-083-K 5508-084-K 5508-084-K 5508-084-K
Rack Insert 0621-281-K 1170-129 1170-130 1170-122 1137-130-03
FIGURE 3
DOOR
TOP
SCREWS-T.H.M
#10-24 X 1/2"
COVER
HINGE
CABINET
BODY
#10-24 X 3/4"
C'SK SCREWS
REPLACEMENT PARTS
120V 240V
Switch ..................................0808-113-K...........0808-113-01-K
Cord Set ...............................0810-029...............0810-039
Heater Kit.............................0811-066-K...........0811-066-1K
Thermostat ...........................0848-008-ACK .....0848-008-ACK
Thermostat (before 2011) ....0848-008-ACK-1..0848-008-ACK-1
Thermometer........................5238-030-K...........5238-030-K
Door Latch Kit .....................1006-122-01-K .....1006-122-01-K
Strike Kit..............................1006-122-02-K .....1006-122-02-K
Hinge Kit..............................0519-074-K...........0519-074-K
Gasket Kit ............................0861-077...............0861-077
Casters..................................0569-313-K...........0569-313-K
Casters w/Brake ...................0569-313-BK........0569-313-BK

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
Insulated
Holding Cabinet FL-2300
Rev. 4 (5/14) Page 4 of 4
MAINTENANCE INSTRUCTIONS
16
12
12
16
* *
*
13
*
13
1
2
1>
2>
A
< <
S.W.
4
TB
8
33
H1 H2
11 10
12 14
9
7
H3
1
2
S
o
t
4 5 6 7 8 9 10
>
TCB
5 6
8465
17
> >
2 1 2 1
> >
W
Y
L6-15P
L5-15P
X
TB TERMINAL BLOCK SW SWITCH-POWER (LIGHTED) S SENSOR-AIR L6-15P FLANGED INLET,250V. 15A. L5-15P FLANGED INLET,120V. 15A. H2&3 HEATER-RIGHT & LEFT SIDE H1 HEATER-BOTTOM
DESCRIPTION
ITEM
LEGEND
* WIRE # 13 GROUND TO INNER BODY
SLEEVING (12-PLACES) TCB THERMOSTAT
OPTIONAL
** *
6-15P
G
5-15P
W
G
FOR H33912135C, H339X
**
*
51
OPTIONAL
& H339-CGM SERIES ONLY
*NOTE "A"
FOR 120 V.: ATTACH WIRE #5 TO TERMINAL #9 FOR 240 V.: ATTACH WIRE #5 TO TERMINAL #10 ADD WIRE NUT TO UNUSED LEAD
OPTIONAL
DIGITAL THERMOMETER
51
t°
TRANSFORMER
110V/220V
50 3
4 2 1
8 5
SENSOR
50
48
TRANSFORMER
110V/220V
2 3 15
SENSOR
t°
120V
240V
52
