Cres Cor H137WSUA C Series Manual

OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137WSUA...C & H137WS18...C Series
Humidity Holding Hot Cabinet
5925 Heisley Road • Mentor, OH 44060-1833
Insulated
Hot Cabinets FL-2253
Rev. 15 (6/08)) Page 1 of 6
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
ELECTRICAL SPECIFICATIONS:
Model No. Volts Watts Amps Hertz Phase NEMA
H137WSUA12C
H137WSUA9C
H137WSUA5C
H137WSUA6C
H138WS185C
H138WS1834C
H138WS1816C
120 2000 16.7 60 1 5-20P
H137WSUA12C208
H137WSUA9C208
H137WSUA5C208
H137WSUA6C208
H138WS185C208
H138WS1834C208
H138WS1816C208
208 2000 9.6 60 1 6-15P
H137WSUA12C240
H137WUA9C240
H137WSUA5C240
H137WSUA6C240
H138WS185C240
H138WS1834C240
H138WS1816C240
240 2000 8.3 60 1 6-15P
NOTE: The above model numbers are basic models.
They may be followed by letters: M, L, D or ending with S and/or Z.
HOW TO INSTALL UNIT:
Place cabinet on level floor.1. Plug cord end into proper wall outlet.2. Fill water pan with 4 gallons (15 liters) of water.3. HOW TO PROOF:
Fill water pan with1. HOT water.
Turn power switch to “ON”.2. Turn “AIR” thermostat to “PROOF” (No. 1).3. Turn “HUMIDITY” thermostat to No. 3½.4. Preheat for ½ hour (30 minutes).5. Put fresh or6. fully thawed dough into cabinet.
NOTE: Do NOT put in frozen dough.
NOTE: The optional digital thermometer display
flashes when temperature in center of cabinet
is below 140°F/60°C or above 250°F/121°C.
Call the factory if you need different settings.
Use of treated or soft water may be required for
proper operation and to maintain warranty.
4. Place the cabinet in a well-ventilated area.
5. Push the switch to “On”, turn the “Air” thermostat
to No. 9 and run the unit for one hour.
NOTE: DO NOT PUT FOOD IN CABINET! This
step is to burn off manufacturing oils and
excess adhesive.
6. Let the cabinet cool and wipe inside clean with
detergent and hot water before first use.
Air is VERY HOT when door is opened.
WARNING

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137WSUA...C & H137WS18...C Series
Humidity Holding Hot Cabinet
Insulated
Hot Cabinets FL-2253
Rev. 15 (6/08 Page 2 of 6
HOW TO HOLD:
No water is needed in pan.
Push power switch to “ON.” Yellow light will1. come on.
Turn “AIR” thermostat to No. 9.2. Preheat cabinet for 30 minutes.3. Turn “AIR” thermostat to desired temperature.4. (See thermostat settings below.)
Put product into cabinet.5.
HOW TO HOLD WITH HUMIDITY:
Fill water pan with HOT water.1. Push power switch to “ON.”2. Turn the “AIR” Thermostat to No. 9.3. Turn the “HUMIDITY” thermostat to No. 9.4. Preheat for 30 minutes.5. Turn “AIR” thermostat to desired temperature.6. (See thermostat settings below.)
Put product into cabinet.7.
NOTES: 180°F/82°C is approximately No. 8. Proper food holding temperature is 140°F/60°C or higher.
SOME TYPICAL THERMOSTAT SETTINGS:
THERMOSTAT SETTINGS RESULT
Air Humidity Cab. Temp. Humidity
150° F Off 150° F N/A
Med Hold Off 175° F N/A
High Hold Off 205° F N/A
Maximum Off 220° F N/A
Proof 3½ 100° F 98%
Low Low 115° F 98%
Low Med 150° F 95%
Low High 150° F 95%
Low Hold Low 160° F 30%
Low Hold Med 160° F 50%
Low Hold High 160° F 95%
Med Hold Low 170° F 15%
Med Hold Med 170° F 35%
Med Hold High 170° F 85%
Med Hold Max 170° F 90%
High Hold Low 205° F 7%
High Hold Med 205° F 15%
High Hold High 205° F 40%
Maximum Maximum 220° F 30%
Note: These settings are based on laboratory conditions and may differ from conditions at point of use. Experiment
with the settings to determine what is best for your application.
Air is VERY HOT when door is opened.
WARNING

OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137WSUA...C & H137WS18...C Series
Humidity Holding Hot Cabinet
5925 Heisley Road • Mentor, OH 44060-1833
Insulated
Hot Cabinets FL-2253
Rev. 15 (6/08)) Page 3 of 6
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
HOW TO TURN UNIT OFF:
Push switch to “OFF” Position.
MAINTENANCE: WATER PAN
Drain, wipe and fill water pan daily. (Clear vinyl
drain hose is provided.)
Push hose onto drain nozzle under the base.1. Turn knob to open the drain.2.
MAINTENANCE: CABINET
Wipe the inside of cabinet after daily use.1. Leave doors slightly open to fully dry interior2. .
Delime or descale water pan parts as
required, to prevent damaging build-
up. WARRANTY COVERAGE MAY
BE AFFECTED WITHOUT PROPER
CLEANING.
Cleaning hints:
Wipe up spills as soon as possible.1.
Clean cabinet regularly to avoid heavy dirt build-up.2.
Make a test spot with cleaner.3. Follow manufacturer’s directions on cleaner.4. Do not mix cleaners.5. Avoid drips and splashes.6.
HOW TO CLEAN THE UNIT:
Soil Cleaner Method
CABINET
Inside
and
Outside
(Stainless Steel)
ROUTINE CLEANING Soap, Ammonia, or mild
*detergent and water.
1. Sponge on with cloth.
2. Rinse with water.
3. Wipe dry.
STUBBORN SPOTS AND
STAINS Mild abrasive made for stainless steel. 1. Apply with damp sponge or cloth. 2. Rub lightly.
BURNT-ON FOODS OR
GREASE Chemical oven cleaner for stainless steel. Follow oven cleaner manufacturer’s directions.
HARD WATER SPOTS
and SCALE Vinegar 1. Swab or wipe with cloth. 2. Rinse and dry.
*Mild detergents include soaps and non-abrasive cleaners.
Note: Gaskets are removable for cleaning.
BEFORE CLEANING CABINET:
Remove Power Cord from cabinet.1. Do NOT hose cabinet with water.2. Do NOT get water on controls.3. Do NOT use abrasives or harsh chemicals.4.
WARNING
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REPAIR SHOULD BE DONE BY AUTHORIZED SERVICE
PERSONNEL ONLY
RISK OF FIRE OR ELECTRIC SHOCK
DO NOT OPEN
WARNING

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137WSUA...C & H137WS18...C Series
Humidity Holding Hot Cabinet
Insulated
Hot Cabinets FL-2253
Rev. 15 (6/08 Page 4 of 6
REPLACEMENT PARTS:
120V 208V 240V
Power Unit 2000W 0675-003 0675-009 0675-009
2000W + dig thrm 0675-003-D 0675-009-D 0675-009D
Heater Kit, Air 2000W 0811-268 0811-269 0811-270
1000W 0811-074 0811-074-02 0811-074-1
Heater Kit, Water 1850W 0811-271 0811-271
High Limit 0848-060 0848-060 0848-060
Thermometer Analog 5238-030 5238-030 5238-030
Digital 5238-034 5238-034 5238-034
Transformer (used with digital thermometer) 0769-159 0769-159 0769-159
Thermostat, Air Solid State 0848-008-ACK 0848-008-ACK 0848-008-ACK
Thermostat, Water Solid State 0848-008-ACK 0848-008-ACK 0848-008-ACK
Relay 0857-130 0857-102 0857-102
Power Cord 2000W 0810-065-12 0810-039-07 0810-039-07
Power Switch 0808-116 0808-116 0808-116
Power Light 0766-094 0766-095 0766-095
Vent Fan 0769-165 0769-174 0769-174
Blower Kit 0769-180-K 0769-182-K 0769-182-K
Door, Complete
(Stainless Steel) UA12/UA6/1834/1816 1221-525
UA5/185 1221-545
UA9 1221-526
Door, Gasket
(Stainless Steel) UA12/UA6/1834/1816 0861-185
UA5/185 0861-250
UA9 0861-182
Door Hinge
(Stainless Steel) 0519-074-K
Door Latch All Models 1006-122-01-K

OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137WSUA...C & H137WS18...C Series
Humidity Holding Hot Cabinet
5925 Heisley Road • Mentor, OH 44060-1833
Insulated
Hot Cabinets FL-2253
Rev. 15 (6/08)) Page 5 of 6
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
WIRING DIAGRAM: 120V
t°
G
W
AIR
THERMOSTAT
768910
8
WATER
THERMOSTAT
10 9 4 5 6 7
t°
45
TERMINAL BLOCK
POWER
SWITCH
HEATER AIR
5-20P
120V; 20A
t°
B
N.O.
A
C.
HEATER WATER
RELAY
BLOWER
MOTOR
A
OPTIONAL
TRANSFORMER
110V/220V
24 3
5
1
8
SENSOR
1
245
9
7
5
11
6
9
1110
68
121413
1615
17 18
19
20
N.C.
N.O.
N.C.
C.
21
21
HIGH LIMIT
3
VENT
FAN
POWER LIGHT

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137WSUA...C & H137WS18...C Series
Humidity Holding Hot Cabinet
Insulated
Hot Cabinets FL-2253
Rev. 15 (6/08 Page 6 of 6
WIRING DIAGRAM: 208V/240V
t°
6-15P PLUG
240V, 15A B
G
W
TERMINAL BLOCK
OPTIONAL
POWER
SWITCH
TRANSFORMER
110V/220V
4 3 21
5 8
SENSOR
10
10
AIR
THERMOSTAT
9 8
1615
4 5
6
6 7
8
WATER
THERMOSTAT
20
t°
B
A
6 7
RELAY
9
11
18
1413
9 8 4 5
19
17
t°
12
6 7
1
2
A
208V, 15A
HEATER AIR
45
10
11
21
9
21
5
HEATER WATER
HIGH LIMIT
3
POWER LIGHT
BLOWER
MOTOR VENT
FAN
C.
C.
N.O.
N.C.
N.O.
N.C.
