Crestron TS-770-GV User manual

The Crestron® TS-770-GV and TS-1070-GV are tabletop touch screens
that feature web browsing, Smart Graphics® software and HTML5
UItechnology, custom-programmable virtual buttons, H.265/H.264
streaming video, and PoE+(Power over Ethernet Plus)network power.
The touch screens also provide built-in applications for room scheduling,
conferencing, and home control.
The TS-770-GV and TS-1070-GV are modified versions of the TS-770 and
TS-1070 series touch screens, which eliminate the microphone, the
Bluetooth® communications beacon, and Wi-Fi® network connectivity to
comply with government applications demanding extra privacy and
security.
NOTE:The TS-770-GV and TS-1070-GV are functionally similar. For
simplicity within this guide, the term "touch screen"is used except
where otherwise noted.
In the Box
1TS-770-GVor TS-1070-GV*, Tabletop Touch Screens
Additional Items
1 Grommet, Cable, Closed (2055455)
1 Grommet, Cable, Open (2055456)
1 Cover, Cable Compartment (2055457)
*Refer to the TS-770-GV-B-S and TS-1070-GV-B-S product pages at www.crestron.com
for a complete list of color variations.
Place the TouchScreen
The touch screen may be placed on any flat, level surface such as a desk,
conference table, lectern, or podium. The rubber strips on the bottom of
the touch screen prevent it from moving easily.
NOTE:To clean or disinfect a touch screen display, use a soft, clean,
damp (not wet) cloth with any commercially available non-ammonia
glass cleaner or disinfectant cleaner. Bezels do not provide a complete
watertight seal, so apply cleaning solution to the cloth rather than the
surface of the touch screen. Wipe the touch screen clean and avoid
ingress of moisture beneath the bezels.
1
TS-770-GV and TS-1070-GV QuickStart
7 in. and 10.1 in. Tabletop Touch Screens, Government Version

Connect the Touch Screen
Route all necessary cables to the touch screen, and then make
connections to the bottom of the touch screen.
Observe the following when connecting the touch screen:
lPower and data connection is provided to the touch screen by a single
Ethernet cable. A Crestron PoE (Power over Ethernet) power supply,
such as the PWE-4803RU, or a PoE-capable network switch is
recommended (both not included).
lThe USB port is used to connect compatible Crestron LED accessories
to the touch screen.
NOTE: The TS-770-GV may use either PoE or PoE+ to supply power
to compatible LED accessories over USB; the TS-1070-GV must use
only PoE+ to supply power to LED accessories over USB.
lApply power after all connections have been made.
Install the Cable Grommet
The touch screen ships with two cable grommets that can used depending
on the planned cable route to the touch screen:
lUse the open grommet if cables will be routed out from the rear of the
touch screen. A cable compartment cover is also provided for this
installation.
lUse the closed grommet if cables will be routed from underneath the
touch screen.
To install the cable grommet:
1. If using the open grommet, push the cables into the openings in the
grommet.
2. Push the grommet into its slot on the bottom of the touch screen so
that the two tabs on either side of the grommet engage the slots in
the touch screen.
3. If using the open grommet, slide the cable compartment cover into its
slot on the bottom of the touch screen so that the front tab engages
the latch.
2
TS-770-GV and TS-1070-GV QuickStart
7 in. and 10.1 in. Tabletop Touch Screens, Government Version

Configure the Touch Screen
When power is applied for the first time, the following screen is displayed.
The touch screen may take up to two minutes to boot.
Touch the screen to display the main Setup screen (TS-1070 shown).
Device settings for the touch screen may be configured using the built-in
setup screens or the web configuration interface. For more information
on configuring the touch screen, refer to the TS-770 and TS-1070 Product
Manual (Doc.8555).
Access the Device Setup Screens
To access the built-in setup screens, place five fingers on the display and
hold for 15 seconds.
Use the setup screens to configure various settings for the touch screen,
including Ethernet setup, IP table setup, audio setup, display setup,
standby timeout, application selection, diagnostics, and the virtual
toolbar.
3
TS-770-GV and TS-1070-GV QuickStart
7 in. and 10.1 in. Tabletop Touch Screens, Government Version

Access the WebConfiguration Interface
The touch screen provides a web configuration interface that is used to
view and configure various touch screen settings and to select an
application. The interface can be accessed using the touch screen IP
address or the XiO Cloud® service.
Touch Screen IPAddress
To access the web configuration interface using the touch screen IP
address:
1. Ensure that the touch screen is connected to the network.
2. Use the Device Discovery tool in Crestron Toolbox™ software to
discover the touch screen and its IP address on the network.
3. Enter the control system IPaddress into a web browser.
XiOCloud Service
The XiO Cloud service allows supported Crestron devices across an
enterprise to be managed and configured from one central and secure
location in the cloud. Supported devices are configured to connect to the
service. Use of the service requires a registered XiOCloud account.
NOTE:The device may be disconnected from the service by navigating to
the Cloud Services tab in Crestron Toolbox software (Functions >
Device Info >Cloud Services). For details, refer to the Crestron Toolbox
help file.
To access the web configuration interface using the XiOCloud service:
1. Record the MAC address and serial number that are labeled on the
shipping box or rear panel of the device. The MAC address and serial
number are required to add the device to the service.
2. Do either of the following:
lFor existing accounts, access the XiO Cloud service at
https://portal.crestron.io.
lFor new accounts, register for a XiO Cloud account at
www.crestron.com/xio-cloud-registration.
3. Claim the device to the service as described in the XiO Cloud User
Guide (Doc. 8214).
4. Select the device from the cloud interface to view its settings.
Set the Time Zone
The time zone must be set on the touch screen if it will not be paired with
a control system IPtable.
To set the time zone:
1. Access the web configuration interface using either the touch screen
IP address or the XiO Cloud service.
2. Select the Settings tab.
3. Navigate to System Setup >Time/Date.
4. Select the time zone where the touch screen will be used from the Time
Zone drop-down menu.
5. Click Save Changes on the top right of the screen.
4
TS-770-GV and TS-1070-GV QuickStart
7 in. and 10.1 in. Tabletop Touch Screens, Government Version

Create an AdminAccount
The first time the web configuration interface is accessed, a dialog box is
displayed asking the user to create an admin account. A similar message
is displayed when connecting to the device in Crestron Toolbox software if
an admin account has not already been created.
To create an admin account:
1. Enter a username and password for the admin account in the
appropriate text fields.
CAUTION:Do not lose the username and password for the admin
account, as the device must be reset to factory settings to regain
access.
2. Click OK. A dialog box is displayed stating that enabling authentication
will restart the web session.
3. Click Yes to confirm and restart. The username and password created
in step 1 must be entered to regain access to the web configuration
interface.
NOTE:The username and password must also be entered when
connecting to CrestronToolbox or XPanel.
Select an Application
The touch screen ships with various built-in applications. An application
may be selected from the default project that ships with the touch screen.
NOTE:Applications can be selected and configured from the device
setup screens or from the web configuration interface at any time. For
more information, refer to the TS-770 and TS-1070 Product Manual
(Doc.8555).
To select a touch screen application:
1. Tap Touch Here to Enable a Specific Application on the device splash
screen. Refer to the first image in Configure the Touch Screen.
2. Select the desired touch screen application from the Choose
Application Below menu that is displayed.
3. Click Confirm. The touch screen reboots to display the user interface
for the selected application.
5
TS-770-GV and TS-1070-GV QuickStart
7 in. and 10.1 in. Tabletop Touch Screens, Government Version

If a custom user project will be used, tap User Project. Custom user
projects can be uploaded using the web configuration interface or
Crestron Toolbox software.
Visit the Product Pages
Scan the QR code to visit the product page.
TS-770-GV
www.crestron.com/model/6510832
TS-1070-GV
www.crestron.com/model/6510833
Additional Information
Original Instructions
The U.S. English version of this document is the original instructions.
All other languages are a translation of the original instructions.
