Introduction
Features and Functions
The TPS-4L compact wall mount touchpanel delivers amazing touchpanel
performance at an incredibly low cost. In the space of a common light switch, the
TPS-4L packs a bright, high-contrast 3.6" active matrix color touchscreen with
astonishing 16-bit Isys color graphics and 10 backlit pushbuttons.
Crestron®touchpanels offer an ideal user-interface for controlling everything from
audio distribution to complete home automation, providing a wide-open canvas for
the creation of custom control screens perfectly tailored to the needs of the end-user.
Touchpanels do away with piles of remote controls, cryptic front panels, and
cluttered wall switches, affording true "one-touch" control over a broad range of
complex devices and systems.
• 3.6" active matrix color touchscreen display
• 16-bit Isys graphics | 320 x 240 resolution
• Synapse image rendering algorithm
• 10 white backlit pushbuttons and engravable faceplate*
• WAV file audio feedback
• Ethernet and Cresnet®communications
• Stylish flush wall mount design | 10 designer colors
* Custom-engraved bezel can be designed and obtained by using the Crestron Engraver software. Version
2.6.1.0 and Crestron Database 17.6.0 or later are available from the Crestron website
(www.crestron.com).
Isys®
Isys power and beauty are infused throughout Crestron's entire touchpanel lineup.
Under the hood, the TPS-4L offers vibrant 16-bit color depth to produce
eye-catching graphics and high-res images. The Isys engine supports dynamic
graphics and text, full-motion animations, multimode objects, and PNG translucency
- all with astonishing speed.
Operations & Installation Guide – DOC. 6449A 3.6-Inch Wall Mount Touchpanel: TPS-4L •1

3.6-Inch Wall Mount Touchpanel Crestron Isys®TPS-4L
Synapse™
Crestron's exclusive synapse image rendering algorithm enables system
programmers to produce amazing graphics - faster and easier. Advanced antialiasing
delivers crisper, sharper objects and text. Enhanced 3D effects add new depth and
style. Since synapse is native to the touchpanel, memory requirements and upload
time are substantially reduced.
Tactile Pushbuttons
Ten programmable "hard" buttons are included for quick pushbutton access to
commonly used functions. Translucent white backlit buttons and a custom
engravable faceplate simplify operation while providing an alluring appearance.
Audio Feedback
Customized WAV files can be loaded on the touchpanel to add dimension to the
touchscreen graphics and pushbuttons with personalized sounds, button feedback,
and voice prompts.
High-Speed Connectivity
Both Cresnet and high-speed Ethernet are standard on the TPS-4L, providing for
easy network integration and seamless communications with Crestron control
systems.
Versatile Flush-Mount Design
The TPS-4L is designed for easy flush-mount installation in a wall, lectern or similar
flat surface. Mounting clips furnished with the TPS-4L facilitate a clean installation
in post-construction drywall and many furniture applications. Additional mounting
options are available.
10 Designer Colors
Optional faceplates are available in a choice of 10 designer colors to match any
décor. Faceplates may be ordered with or without custom engraving.
Specifications
Specifications for the TPS-4L are listed in the following table.
TPS-4L Specifications
SPECIFICATION DETAILS
Touchscreen Display
Display Type TFT Active matrix color LCD
Size 3.6 inch (9.1 cm) diagonal
Aspect Ratio 4:3 QVGA
Resolution 320 x 240 pixels
Brightness 300 nits (cd/m2)
Contrast 300:1
Color Depth 16-bit, 64k colors
Illumination Edgelit LED
Viewing Angle ± 80° horizontal, +80°/-50° vertical
Touchscreen Resistive membrane
(Continued on following page)
2 •3.6-Inch Wall Mount Touchpanel: TPS-4L Operations & Installation Guide – DOC. 6449A

Crestron Isys®TPS-4L 3.6-Inch Wall Mount Touchpanel
TPS-4L Specifications (Continued)
SPECIFICATION DETAILS
Processor
CPU 32-bit Freescale ColdFire® Microprocessor
Memory
DRAM 16 MB
Flash 8 MB
Maximum Project Size 7 MB
Graphic engine Isys engine; 16-bit non-palette graphics; 65,536
colors; synapse image rendering algorithm,
multi-mode objects, dynamic graphics, PNG
translucency, full-motion (60 fps) animation
Ethernet 10BaseT/100BaseTX, auto-switching,
auto-negotiating, full/half duplex, TCP/IP, UDP/IP,
CIP, DHCP, IEEE 802.3U compliant
Audio
Hardware Feature Built-in amplified speaker (rear), internal volume
control
Audio Feedback
(WAV)
8-bit PCM, mono, 8 kHz sampling rate
Amplification 1 Watt for built-in speaker
Power
Cresnet Power Usage 5 Watts (0.21 Amp @ 24 Volts DC)
Default Net ID 03
Firmware tps-4l_c2n-ft-tps-4_qm-ftcc-tps_tps-4_2.007.0163
or later
Minimum 2-Series Control
System Update File1, 2, 3
Version 3.137.CUZ or later
Environmental
Temperature 32º to 104ºF (0º to 40ºC)
Humidity 10% to 90% RH (non-condensing)
Enclosure
Construction Injection-molded plastic, flush-mountable using
clips provided (additional mounting kits available)
Faceplate Injection-molded plastic
Dimensions
Height 4.54 in (11.52 cm)
Width 6.19 in (15.72 cm)
Depth 2.13 in (5.40 cm)
Weight 15 oz (0.43 kg)
1. The latest software versions can be obtained from the Crestron website. Refer to the NOTE following
these footnotes.
2. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product
Catalog for a complete list of 2-Series control systems.
3. When loading VisionTools Pro-e files or firmware through the RS-232 port of the control system, be
sure that the baud rate is at 38400 (Cresnet speed) or lower. Otherwise, Toolbox may post the
“Transfer Failed” message.
Operations & Installation Guide – DOC. 6449A 3.6-Inch Wall Mount Touchpanel: TPS-4L •3

3.6-Inch Wall Mount Touchpanel Crestron Isys®TPS-4L
NOTE: Crestron software and any files on the website are for authorized Crestron
dealers and Crestron Authorized Independent Programmers (CAIP) only. New users
may be required to register to obtain access to certain areas of the site (including the
FTP site).
Physical Description
This section provides information on the connections, controls and indicators
available on your TPS-4L.
TPS-4L Physical View
TPS-4L Overall Dimensions
2.13 in
(5.40 cm)
1.71 in
(4.34 cm)
4.54 in
(11.52 cm)
6.19 in
(15.72 cm)
1
1
4 •3.6-Inch Wall Mount Touchpanel: TPS-4L Operations & Installation Guide – DOC. 6449A

Crestron Isys®TPS-4L 3.6-Inch Wall Mount Touchpanel
TPS-4L Overall Dimensions (continued)
3.45 in
(8.76 cm)
5.42 in
(13.77 cm)
3
2
4
Connectors, Controls & Indicators
# CONNECTORS1,
CONTROLS &
INDICATORS
DESCRIPTION
1 FUNCTION BUTTONS
(10) Translucent white backlit pushbuttons,
programmable.
2 LAN2
GREEN
LED
YELLOW
LED
PIN 8
PIN 1
(1) 8-wire RJ-45 with 2 LED indicators;
10/100BaseT Ethernet port;
Green LED indicates link status
Yellow LED indicates Ethernet activity.
PIN SIGNAL PIN SIGNAL
1 TX + 5 N/C
2 TX - 6 RC -
3 RC+ 7 N/C
4 N/C 8 N/C
(Continued on following page)
Operations & Installation Guide – DOC. 6449A 3.6-Inch Wall Mount Touchpanel: TPS-4L •5

3.6-Inch Wall Mount Touchpanel Crestron Isys®TPS-4L
Connectors, Controls & Indicators (Continued)
# CONNECTORS1,
CONTROLS &
INDICATORS
DESCRIPTION
3 NET
Four-position terminal block connector for
data and power. Connects to Cresnet control
network.
Pin 1 (24) Power (24 Volts DC)
Pin 2 (Y) Data
Pin 3 (Z) Data
Pin 4 (G) Ground
4 RESET (1) Miniature pushbutton behind faceplate,
used for resetting touchpanel.
1. Interface connectors for NET ports are provided with the unit.
2. To determine which is pin 1 on the cable, hold the cable so that the end of the eight pin modular jack
is facing away from you, with the clip down and copper side up. Pin 1 is on the far left.
Industry Compliance
As of the date of manufacture, the TPS-4L has been tested and found to comply with
specifications for CE marking and standards per EMC and Radiocommunications
Compliance Labelling.
NOTE: This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
 Consult the dealer or an experienced radio/TV technician for help.
6 •3.6-Inch Wall Mount Touchpanel: TPS-4L Operations & Installation Guide – DOC. 6449A

Crestron Isys®TPS-4L 3.6-Inch Wall Mount Touchpanel
Setup
Network Wiring
When wiring the network, consider the following:
• Use Crestron Certified Wire.
• Use Crestron power supplies for Crestron equipment.
• Provide sufficient power to the system.
CAUTION: Insufficient power can lead to unpredictable results or damage
to the equipment. Please use the Crestron Power Calculator to help calculate
how much power is needed for the system (www.crestron.com/calculators).
• For larger networks, use a Cresnet Hub/Repeater (CNXHUB) to maintain
signal quality.
For more details, refer to “Check Network Wiring” on page 27.
Identity Code
The Net ID of the TPS-4L has been factory set to 03. The Net IDs of multiple
TPS-4L devices in the same system must be unique. The Net ID is set using the
internal setup menu (refer to “Interface Menu” on page 9). Net ID may also be set
from a personal computer (PC) via the Crestron Toolbox (refer to “Establishing
Communication” on page 24).
When setting the Net ID, consider the following:
• The Net ID of each unit must match an ID code specified in the SIMPL™
Windows®program.
• Each network device must have a unique Net ID.
For more details, refer to the Crestron Toolbox help file.
Operations & Installation Guide – DOC. 6449A 3.6-Inch Wall Mount Touchpanel: TPS-4L •7

3.6-Inch Wall Mount Touchpanel Crestron Isys®TPS-4L
Configuring the Touchpanel
MAIN MENU
This menu can also be obtained
via digital reserved join number,
17242.
NOTE: The only connection required to configure the touchpanel is power. Refer
to “Hardware Hookup” on page 15 for details.
NOTE: The touch screen responds to both finger and stylus commands. Since the
screen is small, Crestron recommends that a stylus (not supplied) be used to ensure
the accuracy of commands. Use a stylus that will not damage the surface of the
screen.
Prior to normal operation, it is advisable to configure the unit using a series of setup
screens. The MAIN MENU for configuring the touchpanel appears when a finger
(or stylus) is held (approximately five seconds) to the touchscreen when power is
applied or when the reset button is pressed.
Upon entering SETUP MODE, the MAIN MENU, shown to the left, displays four
buttons: Touch Screen Calibration, Exit and Run Program, Setup, and
Diagnostics.
Selecting Exit and Run Program verifies that all of the setup information has been
saved to EEPROM and displays the main page that has been programmed into the
touchpanel. The remaining buttons on the MAIN MENU open other menus, which
are discussed in subsequent paragraphs.
Calibration Menu
CALIBRATION MENU
Calibration of the touchscreen is required if the active touch area of a button does
not coincide with the button's image. Select the Touch Screen Calibration button
to display the CALIBRATION MENU, as shown to the left. The CALIBRATION
MENU offers the choice to initiate calibration with the Perform Calibration
button or return to the previous screen with the Return button. Choose an option by
touching the appropriate button.
If you need to calibrate the touchpanel, the screen displays the message "Touch
Upper Left" centered on the panel with a cross hair in the upper left corner. Touch
the cross hair to initiate calibration. Another message, "Touch Upper Right",
appears with a cross hair in the correct corner. Touch the cross hair. A final
message, “Touch Lower Right”, appears with a cross hair in the correct corner.
Touch the crosshair to finish the calibration and return to the MAIN MENU.
NOTE: When touching each crosshair during calibration, be as accurate as possible.
Use a stylus or the tip of a capped pen or the eraser end of a pencil. To cancel
calibration and return to the CALIBRATION MENU without saving calibration data,
create a calibration error by touching the screen in an area that is opposite from the
instructed area.
8 •3.6-Inch Wall Mount Touchpanel: TPS-4L Operations & Installation Guide – DOC. 6449A

Crestron Isys®TPS-4L 3.6-Inch Wall Mount Touchpanel
Setup Menu
SETUP MENU
To obtain the SETUP MENU, shown to the left, press the Setup button from the
MAIN MENU. The SETUP MENU offers a series of buttons, which open additional
menus and screens that are detailed in subsequent paragraphs. After setup parameters
have been set, select the Return button to return to the MAIN MENU.
NOTE: For convenience, the current CRESNET ID setting is displayed in the lower
left corner.
NOTE: All touchpanel settings are automatically saved in non-volatile memory.
Interface
INTERFACE MENU
The touchpanel communicates with a control system to activate commands or to
display feedback from components within the system. The communication interface
must be correctly specified or communication will not occur. To set communication
parameters, first select the Interface button on the SETUP MENU to display the
INTERFACE MENU screen, shown to the left. Then, use the CRESNET ID UP and
DOWN buttons to set the Cresnet network identity (CRESNET ID).
Use the other buttons on the screen to enable/disable the preferred communications
protocol: Cresnet II, Ethernet, or CIP (Crestron Internet Protocol).
Cresnet II buttons determine the touchpanel’s communication mode. Select Enable
for normal Cresnet communications (default); select Disable to disable the Cresnet
communications interface.
The Ethernet Enable and Disable buttons determine the touchpanel’s ability to
communicate with other devices via Ethernet.
The CIP Enable and Disable buttons determine the touchpanel’s ability to
communicate with other Crestron devices using CIP. CIP must be enabled for the
touchpanel to communicate with other Crestron Ethernet devices.
After the Cresnet ID setting has been verified and the communications protocol has
been selected, press Return to save the settings and return to the SETUP MENU.
AUDIO MENU
Audio
From the SETUP MENU, press the Audio button to open the AUDIO MENU
screen, shown at left.
Press the WAV button to open the AUDIO SETUP – WAV screen. Use the buttons
on this screen to set the WAV file volume level, to enable/disable the WAV file
function and to play the WAV file to verify your settings. The area to the right of the
volume UP/DOWN buttons shows the relative volume from 0% to 100%, both as a
numeric value and, for a quick visual reference, as an analog bar.
Similarly, press the KEY CLICK Enabled/Disabled button to open the AUDIO
SETUP – KEY CLICK screen. Use the buttons on this screen to adjust the key click
volume level (0 – 100%), and to enable/disable an audible tone (beep) when the
touchpanel buttons are pressed. The area to the right of the volume UP/DOWN
buttons shows the relative volume from 0% to 100%, both as a numeric value and,
for a quick visual reference, as an analog bar.
Press the Restore Default Audio Settings button to cancel any changes and restore
all default audio settings: WAV volume = 100%, and WAV function enabled; key
click volume = 100%, and key click function enabled.
Press Return to save the settings and return to the SETUP MENU.
Operations & Installation Guide – DOC. 6449A 3.6-Inch Wall Mount Touchpanel: TPS-4L •9

3.6-Inch Wall Mount Touchpanel Crestron Isys®TPS-4L
Screen Settings
SCREEN SETTINGS
From the SETUP MENU, press the Screen Settings button to open the SCREEN
SETTINGS screen, shown at left.
Press the Brightness button to open the SCREEN SETTINGS – BRIGHTNESS
screen. Use the UP/DOWN buttons to set the display brightness (0 – 100%). The
area to the right of the buttons shows the relative brightness from 0% to 100%, both
as a numeric value and, for quick visual reference, as an analog bar.
Press the Key Backlight button to open the SCREEN SETTINGS – KEY
BACKLIGHT screen. Use the UP/DOWN buttons to set the key backlight brightness
(0 – 100%). The area to the right of the buttons shows the relative brightness from
0% to 100%, both as a numeric value and, for quick visual reference, as an analog
bar.
Press the LCD Bias button to open the SCREEN SETTINGS – LCD BIAS screen.
Use the UP/DOWN buttons to set the LCD bias (0 – 255). Use the graphic on the
right side of the screen to see the effects of the adjustment. The bias setting is best
when the lines are crisp and dark and the white area around them is bright.
Press Return to save the settings and return to the SETUP MENU.
Timeout Settings
TIMEOUT SETTINGS
From the SETUP MENU, press the Timeout button to open the SCREEN
SETTINGS – TIMEOUT screen. Use the UP/DOWN buttons to set the timeout
from 0 through 120 minutes, where 0 disables the timeout. Adjustment is in one-
minute increments from 1 to 10; in ten-minute increments from 20-120.
STANDBY timeout turns the display and backlight off when the touchpanel is
inactive for the specified time. When the touchpanel is reactivated, the last screen to
be displayed reappears. The specified time is displayed in minutes. The default
STANDBY timeout is 10 minutes.
Press Return to save the settings and return to the SETUP MENU.
Diagnostics Menu
DIAGNOSTICS MENU
The Diagnostics button from the MAIN MENU should only be used under
supervision from a Crestron customer service representative during telephone
support. Many options available from the DIAGNOSTICS MENU, shown to the left,
are numeric in nature and their interpretation is beyond the scope of this manual.
10 •3.6-Inch Wall Mount Touchpanel: TPS-4L Operations & Installation Guide – DOC. 6449A

Crestron Isys®TPS-4L 3.6-Inch Wall Mount Touchpanel
Mounting Options
The TPS-4L touchpanel installs simply and cleanly into existing or newly
constructed walls, with an assortment of pre- and post-construction mounting
options. The TPS-4L is supplied with four screws and clips for post-construction
installation. All available mounting options are listed in the following table. (The
Wall Mount Kit – Bracket, Model WMKB-4L, consists of multiple sets of clips like
the ones supplied.)
NOTE: Refer to the latest version of the supplied Touchpanel Mounting QuickStart
Guide, Doc. 6140, which is available from the Crestron website
(www.crestron.com/manuals), for details about the available mounting options
before starting any actual installation procedures.
Mounting Options for the TPS-4L
PRE-
CONSTRUCTION
OPTION
POST-
CONSTRUCTION
OPTION
MODEL
NUMBER
DOCUMENT
NUMBER
Back Box Kit - BB-4L 6387
Pre-Construction
Mount Kit
- PMK-4L 6388
Mud Ring Mount Kit
(Accessory)
- MMK-4L 6389
Trim Ring Mount Kit
(Accessory)
- TMK-4L 6390
- Wall Mount Kit – Mud
Ring
WMKM-4L 6389
- Wall Mount Kit – Trim
Ring
WMKT-4L 6390
Wall Mount Kit –
Bracket
WMKB-4L Not Applicable
NOTE: Pre-construction refers to framed walls prior to hanging drywall.
Post-construction refers to framed walls with drywall hung.
If the BB-4L or PMK-4L are to be used and a touchpanel is not available, the
installer can either leave the hole in the mounting surface open (if permitted by local
building codes) or attach the cover plate supplied with the mounting kit.
Touchpanel Mounting
Physical installation of the TPS-4L includes mounting the unit to the wall and
installing an engraved touchpanel bezel. The only tools required for the procedures
presented here are masking tape (or equivalent), a gypsum board saw (or equivalent),
and a #2 Phillips tip screwdriver. The following procedures are based on the use of
the supplied screws and clips for post-construction installation.
Mounting to the Wall
The TPS-4L is designed to be mounted in a wall or lectern. Two overlay cutout
templates (0V40078) are supplied. One is in the shape of the required opening; the
other is similar to a frame, with the inner area of the frame the shape of the required
opening. (Refer to the following diagrams.) Use the template that is most convenient.
Operations & Installation Guide – DOC. 6449A 3.6-Inch Wall Mount Touchpanel: TPS-4L •11

3.6-Inch Wall Mount Touchpanel Crestron Isys®TPS-4L
Supplied Hardware for the TPS-4L
DESCRIPTION PART NUMBER QUANTITY
Mounting Clip 2014237 4
Overlay Template Cutout 4007314 1
Conn, Plug, 4 Pin, SKT, Single Row 2003576 1
Screw, #06-AB, 2-1/2”, Pan Head 2014276 2
NOTE: The following drawings are not to scale. Do not attempt to use them to
prepare the hole in the mounting surface.
TPS-4L Cutout Dimensions (4007314, 1 of 2)
4 1/4 in
(105 mm)
5 1/2 in
(140 mm)
12 •3.6-Inch Wall Mount Touchpanel: TPS-4L Operations & Installation Guide – DOC. 6449A

Crestron Isys®TPS-4L 3.6-Inch Wall Mount Touchpanel
TPS-4L Cutout Dimensions (4007314, 1 of 2)
6 1/2 in
(165 mm)
5 1/4 in
(130 mm)
5 1/2 in
(140 mm)
1/2 in
(13 mm)
4 1/4 in
(105 mm)
1/2 in
(13 mm)
1. Locate an area on the wall that is free of miscellaneous wiring and studs.
2. Make a small hole near the middle of the designated site, and verify that the
location is suitable.
3. Using masking tape (or equivalent), fasten the template to the wall; verify
that the template is level, and trace the opening shape on the wall.
4. Remove the template, and then cut out and remove the traced shape to
produce the required opening.
NOTE: Before inserting the TPS-4L in the mounting hole, ensure that all required
cables have been installed in the wall.
5. Install the four supplied #6x 2-½” screws and mounting clips as shown in
the diagram on the next page (two on the top and two on the bottom).
• Insert the screws through the touchpanel flange and then through the
larger hole in the mounting clip.
• Thread the screws through the smaller hole in the mounting clips and
tighten the screws only enough that the mounting clips are brought
flush with the rear of the touchpanel flange. Do not compress the
mounting clips at this time.
Operations & Installation Guide – DOC. 6449A 3.6-Inch Wall Mount Touchpanel: TPS-4L •13

3.6-Inch Wall Mount Touchpanel Crestron Isys®TPS-4L
Attaching the Screws and Mounting Clips
6. Connect the Cresnet cable, using the supplied mating connector, to the
Cresnet port; attach the Ethernet cable, if required, and position the TPS-4L
in the mounting hole.
Insert the TPS-4L Into the Mounting Surface
14 •3.6-Inch Wall Mount Touchpanel: TPS-4L Operations & Installation Guide – DOC. 6449A

Crestron Isys®TPS-4L 3.6-Inch Wall Mount Touchpanel
7. Tighten the mounting screws evenly and only enough to compress the
mounting clips and secure the TPS-4L squarely in the mounting surface. Do
not over tighten the screws.
NOTE: If it becomes necessary to remove the touchpanel from the mounting
surface, the original mounting clips cannot be reused to remount the touchpanel.
Additional mounting clips are available in the Mounting Kit WMKB-4L identified in
“Mounting Options” on page 11.
Installing the Bezel
Use the Crestron Engraver software package to obtain a custom-engraved bezel for
the TPS-4L. Install the bezel as follows.
1. Carefully position the bezel over the face of the touchpanel.
2. Ensure that the bezel is oriented properly and press against the TPS-4L until
the bezel snaps into place.
Touchpanel Removal
If it is necessary to remove the touchpanel after it has been installed into a mounting
surface, complete the following steps in the order provided to remove the
touchpanel. The only tool required is a #2 Phillips tip screwdriver.
1. Lift one edge of the bezel to free it from the touchpanel, and lift it off. Do
not apply excessive pressure to the touchscreen.
2. Loosen and remove the screws that secure touchpanel to the mounting
option in use.
3. Using equal pressure, carefully remove the touchpanel from the opening.
If necessary, secure and label the attached cables before disconnecting them from the
back of the touchpanel.
Hardware Hookup
NOTE: To prevent overheating, do not operate this product in an area that exceeds
the environmental temperature range listed in the specifications table. Consideration
must be given if installed in a closed or multi-unit rack assembly, inside a closed
desk, or in a closed podium since the operating ambient temperature of these
environments may be greater than the room ambient. Contact with thermal insulating
materials should be avoided on all sides of the unit.
Connect the Device Make the necessary connections as called out in the illustration on the next page.
Refer to “Network Wiring” on page 7 before attaching the 4-position terminal block
connector. Apply power after all connections have been made.
When making connections to theTPS-4L use Crestron power supplies for Crestron
equipment.
Operations & Installation Guide – DOC. 6449A 3.6-Inch Wall Mount Touchpanel: TPS-4L •15

3.6-Inch Wall Mount Touchpanel Crestron Isys®TPS-4L
Hardware Connections for the TPS-4L
CAUTION: Do not apply excessive pressure to the touchscreen display during
handling. Doing so can crack the screen and damage the touchpanel.
Label the Buttons Use Crestron Engraver software to print custom labels for the TPS-4L’s front panel
buttons and LEDS. Crestron recommends printing on 100-pound paper. Paper
weighing less than 100 pounds will tend to crumple while sliding in, while paper
weighing more than 100 pounds may not fit.
Recommended Cleaning
Keep the surface of the touchscreen free of dirt, dust or other materials that could
degrade optical properties. Long-term contact with abrasive materials can scratch the
surface, which may detrimentally affect image quality.
For best cleaning results use a clean, damp, non-abrasive cloth with any
commercially available non-ammonia glass cleaner. Bezels may not provide a
complete watertight seal. Therefore, apply cleaning solution to the cloth rather than
the surface of the touchscreen. Wipe touchscreen clean and avoid getting moisture
beneath the bezels.
16 •3.6-Inch Wall Mount Touchpanel: TPS-4L Operations & Installation Guide – DOC. 6449A
