Crestron TSW-70-RMB Series User manual

The Crestron® TSW-70-RMB series retrofit mounting brackets and
TSW-70-RMKseries rack mount kits provide versatile mounting solutions
for TSW-70 series touch screens.
lTSW-770/1070-RMB-1,TSW-770/1070-RMB-2, and
TSW-1070-RMB-3 brackets mount over an existing back box,
mounting kit, or cutout for a wall-mounted Crestron touch screen.
lTSW-570/770-RMK-1 and TSW-1070-RMK-2 rack mount kits permit
mounting the touch screen into an equipment rack.
This document describes installation procedures for each of the solutions
above.
In the Box
1 TSW-770/1070-RMB-1,TSW-770/1070-RMB-2,
TSW-1070-RMB-3,TSW-570/770-RMK-1, or
TSW-1070-RMK-2, Mounting Bracket or Rack Mount Kit
TSW-770/1070-RMB-1 Only
1 Bracket, Adapter, APAD(2055401)
2 Bracket, Mounting, LC/CT-1000(4001193)
1 Cover Plate, Adapter, APAD (2055405)
8 Screw, 4-40 x 3/4 in., Phillips (2029110)
4 Screw, 4-40 x 1-1/2 in., Phillips (2037906)
TSW-770/1070-RMB-2 Only
1 Bracket, Adapter, TPS-4L(2055402)
2 Bracket, Mounting, TPS-4L(4519515)
1 Cover Plate, Adapter, TPS-4L (2055406)
8 Screw, 4-40 x 3/4 in., Phillips (2029110)
4 Screw, 4-40 x 1-1/2 in., Phillips (2037906)
TSW-1070-RMB-3 Only
1 Bracket, Adapter, TPS-6L(2055403)
2 Bracket, Mounting, TPS-6L(4519516)
1 Cover Plate, Adapter, TPS-6L (2055407)
8 Screw, 4-40 x 3/4 in., Phillips (2029110)
4 Screw, 4-40 x 1-1/2 in., Phillips (2037906)
TSW-570/770-RMK-1 Only
1 Plate, Rack Mount (2048550)
1 Bracket, Mounting (2055409)
4 Screw, 4-40 x 3/8 in., Phillips (2007173)
2 Screw, 6-32 x 5/16 in., SEMS, Phillips (2007224)
4 Screw, 6-32 x 3/8 in., Phillips (2007235)
TSW-1070-RMK-2 Only
1 Plate, Rack Mount (2048551)
4 Screw, 4-40 x 3/8 in., Phillips (2007173)
1
TSW-70-RMB and TSW-70-RMKSeries QuickStart
Retrofit Mounting Brackets and RackMount Kits for TSW-70 Series

Install the TSW-70-RMB
For simplicity within this section, the term "TSW-70-RMB"is used to
refer to all model variants unless noted.
Determine Compatibility
Refer to the following table to determine the touch screens and legacy
installations that are compatible with each TSW-70-RMBmodel.
TSW-70-RMB Model Compatibility
TSW-70-RMBModel Compatible Touch
Screens
Compatible Legacy
Installations
TSW-770/1070-RMB-1 TSW-770,
TSW-1070
APAD, CT-1000,
LC-1000,
TPS-2000L
TSW-770/1070-RMB-2 TSW-770,
TSW-1070
TPS-4L
TSW-1070-RMB-3 TSW-1070 TPS-6L
Install with a Back Box
To install the TSW-70-RMB in applications with an existing back box:
1. Attach the TSW-70-RMB adapter bracket to the existing back box
using the included 4-40 x 1-1/2 in. screws.
2. Attach the TSW-770/1070 mounting bracket (included with the touch
screen) and the TSW-70-RMB cover plate to the adapter bracket using
four of the included 4-40 x 3/4 in. screws. Refer to the following
illustration.
3. Attach the touch screen to the TSW-770/1070 mounting bracket to
complete the installation.
2
TSW-70-RMB and TSW-70-RMKSeries QuickStart
Retrofit Mounting Brackets and RackMount Kits for TSW-70 Series

Install without a Back Box
To install the TSW-70-RMB in applications without an existing back box:
1. Attach the TSW-70-RMB adapter bracket loosely to the included
mounting brackets using four of the 4-40 x 3/4 in. screws. Insert the
screws far enough that they engage the threads in the bracket, but do
not tighten them yet.
2. Push the assembly into the wall until the mounting brackets are seated
fully and clip to the wall.
3. Tighten the four screws to secure the mounting bracket.
4. Attach the TSW-770/1070 mounting bracket (included with the touch
screen) and the TSW-RMB-70 cover plate to the adapter bracket using
the remaining four 4-40 x 3/4 in. screws. Refer to the following
illustration.
5. Attach the touch screen to the TSW-770/1070 mounting bracket to
complete the installation.
3
TSW-70-RMB and TSW-70-RMKSeries QuickStart
Retrofit Mounting Brackets and RackMount Kits for TSW-70 Series

Install the TSW-70-RMK
For simplicity within this section, the term "TSW-70-RMK"is used to
refer to all model variants unless noted.
Determine Compatibility
Refer to the following table to determine the touch screens that are
compatible with each TSW-70-RMKmodel and the units of rack space
required for installation.
TSW-70-RMK Model Compatibility
TSW-70-RMKModel Compatible Touch
Screens
Required Units of
Rack Space
TSW-570/770-RMK-1 TSW-570, TSW-770 3U
TSW-1070-RMK-2 TSW-770, TSW-1070 4U
NOTE:The TSW-1070-RMK-2 uses the same hardware as the
TSW-1060-RMK-2. Either product can be used to install a TSW-1070
into a rack.
Install a TSW-570 into a Rack
To install a TSW-570 into a rack with the TSW-570/770-RMK-1:
1. Attach the TSW-70-RMKmounting bracket to the included rack
mounting plate using the included 6-32 x 3/8 in. screws.
2. Attach the rack mounting plate to the rack using the appropriate
mounting hardware.
3. Separate the two halves of the TSW-570 universal mounting bracket
(included with the touch screen) by removing the two 1 in. screws that
hold the halves together.
4. Attach the front portion of the TSW-570 universal mounting bracket
to the rack mounting plate using the included 6-32 x 5/16 in. SEMS
screws.
5. Attach the touch screen to the TSW-570 universal mounting bracket
to complete the installation.
4
TSW-70-RMB and TSW-70-RMKSeries QuickStart
Retrofit Mounting Brackets and RackMount Kits for TSW-70 Series

Install a TSW-770 or TSW-1070 into a Rack
To install a TSW-770 or TSW-1070 into a rack with the
TSW-570/770-RMK-1 or TSW-1070-RMK-2:
1. Attach the rack mounting plate to the rack using the appropriate
mounting hardware.
2. Attach the TSW-770/TSW-1070 mounting bracket (included with the
touch screen) to the rack mounting plate using the included
4-40x3/8in. screws.
3. Attach the touch screen to the TSW-770/TSW-1070 mounting
bracket to complete the installation.
Visit the Product Pages
Scan the QR codes to visit the product pages.
TSW-770/1070-RMB-1
www.crestron.com/model/6511130
TSW-770/1070-RMB-2
www.crestron.com/model/6511131
TSW-1070-RMB-3
www.crestron.com/model/6511132
TSW-570/770-RMK-1
www.crestron.com/model/6511134
5
TSW-70-RMB and TSW-70-RMKSeries QuickStart
Retrofit Mounting Brackets and RackMount Kits for TSW-70 Series

TSW-1070-RMK-2
www.crestron.com/model/6511135
