CrimeStopper CS-2016DPII-FM Informer II User manual

CS-2016DPII-FMInformerII™
DPSERIES II (DATAPORT)
2-Way FMPaging Alarm&RemoteEngineStarting System
OPERATIONINSTRUCTIONS
INTRODUCTION
CONGRATULATIONSon yourchoiceofthe InformerII™withDPtechnologybyCrimestopperSecurityProductsInc.
Thisbookletcontainsthe information necessaryforoperating yoursystem.If anyquestionsarise,contactyour
installation dealerorCrimestopperSecurityProductsInc.
*IMPORTANTINFORMATION:Primaryand OptionalFeatures
-PRIMARY:Thesearefeaturesthatmustbe connected inorderforthe systemtooperateproperlyi.e.Power,
Ground,LED,etc.
-OPTIONAL:Optionalfeaturesareconnected onlyifdesired oragreed upon bythe installing dealeri.e.HornHonk,
Domelightillumination,DoorLocks,TrunkPop,etc.Thesefeaturesmayrequireadditionalpartsand laborcharges.
ConsultwithyourinstalleraboutthesefeaturesBEFOREinstallation!
CONTACTINFORMATION:
TECHNICALSUPPORT(800)-998-6880
Monday -Friday 8:00am-4:30pmPacific
Website:www.crimestopper.com
E-mail:[e-mail]
CRIMESTOPPER
SECURITYPRODUCTS,INC.
1770 S.TAPOSTREET
SIMIVALLEY,CA.93063 REV.2.27.2007
ThisdevicecomplieswithFCC Rulespart15.Operation issubject
tothe following twoconditions:1)Thisdevicemaynotcause
interference,and (2)thisdevicemustacceptanyinterferencethat
maybe received,including interferencethatmaycauseundesired
operation.The manufacturerisnotresponsibleforanyradioorTV
interferencecaused byunauthorized modification tothis
equipment. Suchmodification couldvoidthe user'sauthorityto
operatethe equipment.

2
TABLEOFCONTENTS
Operation Cautions&Warnings……..…………..……………………………………………………………………2
Transceiver/Pager-Remote……….....…………..……………………………………………………………………3
CS-516TWSidekick RemoteControl…………………….…………………………………………………..…...…..4
Operating Instructions-Alarm……………………………………………………….………..……………..……..5-8
RemoteEngineControl………………………...……………………………………………….…….………...….9-12
OptionalTurbo TimerMode….……...…………...……………………………………………….…….………...….13
Anti-Carjack Protection...……………………………………….………….……..………………..………..………..14
LEDDiagnostics………………..……………………………………………………………………….………..….…15
Transceiver/RemoteControlProgramming……………………………………………………..……………15-16
2VehicleOperation……...………………………….……………………………….………….…………….….……17
Troubleshooting /FAQSection……………….…………………………………………………………..……..18-19
LowBatteryWarning –LCD Remote……………………………………………………………………………….19
Setting Clock –LCD Remote…………………………………………………………………..……………….….…20
RemoteStartDiagnostics……………………………….…………………………………………….…………...…20
OPERATIONCAUTIONS&WARNINGS
CRIMESTOPPERSECURITYPRODUCTS,INC.and itsVENDORSshall notbe liableforanyaccident
resulting fromthe useofthisequipment. Thissystemisdesigned tobe professionallyinstalled intoacaror
vehicleingood running order.Items,suchasparking brake,doorswitches,and all engine safetyfeatures,
mustbe inperfectworking condition.
DAMAGEresulting frommisuse ornegligence isNOTcoveredunderwarrantyand will be subjectto
repairand /orreplacementcharges.
ITISABSOLUTELYTHEOWNER’SSOLERESPONSIBILITYTO:A)Understand the operation ofthis
systemand itssafetyfeatures.B)Check forproperoperation ofthesesafetyfeaturespriortoaccepting
deliveryofthe vehiclefromthe installation facility.C)Check and maintainthe condition ofthe vehicleand all
itemsrelativetothe properoperation ofthissystemand itssafetyfeatures.

3
TRANSCEIVER/PAGER-REMOTE
PAGER/REMOTETRANSCEIVER:
The hand-heldremotetransceiverisused tosend and
receiveinformation fromthe vehicle.The ControlModule
transmitsHigh Frequency FMsignalsfromthe vehicletoyour
overlong distances.Yourrange will varydepending on
location,terrain,and localRFnoise/interference.This
systemisnotguaranteed topage you ifyou arebehind
concretewalls,underground,inalarge structure,orinan
area withhigh levelsofelectronicinterference.Handlethe
pager/remotewithcareifthe LCD displayand/orthe
electronics maybe damaged ifsubjected toabuse.The AAA
Cell 1.5Valkaline batterycan easilybe replaced bysliding
open the batteryaccess dooron the back ofthe remote.
Batterylifewill varydepending on usage.The LCD screen
will displayalowbatteryicon when the batteryislow.For
moreon range,see “Range Questions”on page 18.
QUICK CHART
Button Button FunctionsButton OptionsButtonsButton Functions
Button Options
Lock Doors&Arm SystemPress and Holdfor3
seconds
Activate“Panic”feature
Aux#3 Press Button #1 and #4 at
the sametime
Unlock Doors&Disarm
SystemPress twiceforsecond door unlock
Aux#4 Press Button #3 and #4 at
the sametime
TrunkRelease(Aux#1)Press and ReleaseforAux
#1
CarJack
(See page 14)Press Button #1 and #3 at the sametime
Aux#2 Press and Holdbutton #2&
#3for3sec.
SilentArm/DisarmPress Button #2 and #4 at
the sametime
StartorStop engine
Press and Holdfor2 seconds
Press and Holdfor3seconds
Press 5timestoDisable/Enableaudiblebeep tonesfromthe remote
2-caroperation (Side Button)
(Change fromCar1toCar
2)orCar2toCar1
Press and ReleasetoRecall the lastmessage fromthe LCD screen
#1 ARM/
LOCK#4 ENGINE
START/STOP
#5
RECALL /
CARIORII
#3 TRUNK
POP
#2 DISARM/
UNLOCK
ANTENNA
FIXED
LCD
SCREEN
PM

4
CS-516TWSIDEKICK REMOTE
516TW1-Waysidekick remoteaddsflexibilitytoyour
CS-2016DPII-FM.You can havethe convenienceof
operating yoursystemwithoutneeding tocarrythe
largerpagerremote.The Sidekick remotehasless
range and offersall ofthe sameoperation features
exceptforpage-back confirmation.See diagrambelow
forSidekick 1-Wayremoteoperation.
QUICKCHART
Button Button
FunctionsButton OptionsButtonsButton FunctionsButton options
Lock Doors&Arm
SystemPress and Holdfor3seconds Activate“Panic”feature
ActivatesAux#3 Press Button #5 then
Button #2
Unlock Doors&Disarm
SystemPress twiceforsecond door unlock
ActivatesAux#4 Press Button #5 then
Button #4
TrunkRelease(Aux#
1)Press and ReleaseforAux#1
ActivatesCarJack
(See page 14)Press Button #1 and #3 at the sametime.
ActivatesAux#2 Press *.Then press &hold#1
for3Sec.
StartorStop engine Press and Holdfor3seconds
SilentArm/Disarm Press Button #2 and #4 at
the sametime.
2-caroperation (Center
Button)
(Change fromCar1to
Car2)orCar2toCar1.
2nd Function Button
Press and Holdfor2seconds
WhileinCar2mode you have
5secondstopress afunction
orremotewill returntoCar1.

5
PM
ARM/LOCK
PM
DISARM/UNLOCK
PM
DOORTRIGGER
PM
SHOCK TRIGGER
PM
HOOD/TRUNK TRIGGER
PM
IGN
(<<<< MOVING<<<<<)
IGNITIONTRIGGER
OPERATINGINSTRUCTIONS-ALARM
Active Arming /Locking:
Press button #1 (Lock symbol)on the transceiver.The Systemwill arm emitone siren
chirp,one lightflash,and the LEDwill begintoflash.Powerlocks will lock (if
equipped).Starterdisablecircuitwill turnon.LCD Pagerwill beep oncewhile
displaying aDownArrowand aLock symbolfollowed bythe CSP logo.Afterashort
delaytoallowthe vehicleand electronics tosettle,the systemwill be completelyarmed.
Disarming:/Unlocking
Press button #2 (Unlock symbol)on the transceiver.Systemwill disarm and confirm
withtwosiren chirps,twolightflashes,and the LEDwill turnoff. Powerlocks will Unlock
and InteriorDomelightwill turnon (ifinstalled withtheseoptionalfeatures).LCD Pager
will beep twicewhiledisplaying an UpArrowand an Unlock symbolfollowed bythe CSP
logo.
Alarm Triggers:
If thereisan intrusion intothe vehicle,ahardimpacttothe body,orthe ignition isturned on the alarm will
sound and flashthe lightsfor1minute.After1minute,the triggercyclewill automaticallystop and alarm will
remainarmed tocontinue protecting the vehicle.If adoorisleft open afteran intrusion then the unitwill cycle
amaximumof2minutesand continue toprotectthe otherun-tampered orunopened zones.
LCD RemotePaging /ZoneViolations:
When the systemistriggered,the alarm sendsapaging signaltothe remote.If you arewithinrange,you will
receiveaviolation paging signalwhichconsistsofavibration followed by6audiblebeepstonotifyyou the
vehiclehasbeen tampered with.

6
PM
SILENTARM
PM
SILENTDISARM
PM
P
PANICMODE
OPERATINGINSTRUCTIONS-ALARM
Disarming WhileTripped(Triggered):
Disarming the Systemwhileitistriggering requiresTWOpressesofthe #2 Unlock Button.The firstpress of
Button #2 Resetsthe alarm cycleonly(systemstill armed)whileasecond press will disarm/unlock the system.
Selective SilentArming/Disarming:
ToArm orDisarm the systemwithoutsiren
chirps,press and releasebothButtons#2
(Unlock)and #4 (Start)atthe sametime.
Systemwill Arm orDisarm withoutsiren chirps.
Flashing lightsand LEDwill be the only
indicatorsofArm/Disarm status.The LCD will
Displayamusicalnotewithan “X”when the
systemisarmed ordisarmed withoutachirp.
Priorintrusion Alert
Thissystemwill notifyyou ifthe alarm wastripped whileyou whereaway.Upon disarming,the twonormal
disarm chirpswill be heardthen the systemwill emit4additionalsiren chirps.Check yourvehicleforany
signsofabreakinortampering.Alsosee LEDDiagnostics Section todetermine the causeofthe trigger.
RemotePanicProtection
Tosound the alarm inan emergency situation ortodrawattention toyourvehicle,press
and holdButton #1 (Lock)foratleast3secondsuntil the siren sounds.Press Button #2
(Unlock)toresetpanicmode.The LCD pager/remotewill displaya“P”and emit8
beepswhen the panicmode istriggered.
Selective Shock SensorDisable
Toarm the alarm and bypass shock sensorprotection,press Button #1 asnormalthen
press and releaseButton #1 and #2 togetherwithin2seconds.You will hear3extra
siren chirpsindicating shock sensorbypass forthisarming cycleonly.Thisfeaturecan be used when parking
nearrailroad tracks,airports,orarea withexcessiveloud machineryornoisetopreventthe nuisanceof
unnecessaryfalsealarms.
OpenDoorAlert/Bypass
Upon arming,thissystemwill warnyou ifadoorisleft open.The LCD pagerwill vibrateand beep oncealong
withdisplaying the Lock Icon on yourLCD screen.Thiszone will automaticallybe bypassed until closed,
otherwisethe alarm will continue toprotectall otherzones.

7
PM
PRE-WARN
PM
PASSIVE LOCK/ARM
PM
TRUNK POP
OPERATINGINSTRUCTIONS-ALARM
Pre-Warning Shock Protection
The Pre-warning (warn-away)featurewill activatewhen alow-levelshock orvibration
detected bythe system’sshock sensor.The alarm will chirpthe siren 5timesand
flashthe lightsoncetohelpdeteranyfurthertampering withthe vehicle.The
pager/remotewill vibrateonceand beep (6X’s).
Passive Arming Mode:(Programmable)
Passive(automatic)arming occurs30 secondsafterthe ignition isturned off and the
lastdoorisclosed.Upon closing the lastdoor,the unitwill flashthe lightstwiceand LEDwill be flashing
rapidlytoconfirm passivecountdown.If adoorisreopened withinthe 30 second period,the countdownstop
and beginagainwhen the doorisclosed.Passivearming providesfailsafeprotection incaseyou forgetto
arm the system.
Passive Locking:(Programmable)
The CS-2016DPII-FMsystemcan be programmed topassivelylock the doorswhen
the systempassivelyarms.The defaultsetting isOFF becausepassivelocking
increasesthe risk oflocking the keys inthe vehicle.When the systemarms/locks
passively,withoutyou pressing the remote,the LCD pagerwill still provide a
confirmation signal.The LCD screen will havean arrowonlywithoutalock symbol.
Trunk/HatchPop (Optional, RemoteAUX.Output1)
Thisfeatureisdesigned tointerfacewithexisting Factorypowertrunkorpower
hatchreleasesystemsand mayrequireadditionalpartsand/orlaborcharges.
Press and releaseButton #3 (Trunk)on the transmittertopop/open the trunk/hatch.
If the systemisarmed,itwill alsodisarm when the button #3 ispressed.The LCD
pager/remotewill confirm with3beepsand the trunkicon on the screen.
RemoteAUX.Output2(Optional, Requires specialprogramming)
Thissystemcontainsasecond auxiliaryoutputtoactivateotheraccessoriesordevices.Toactivatethe
systems’Second AuxiliaryOutput, press and HOLDButton #3 +#2 on the transmitterformorethan 2
seconds.Thisisamomentaryoutputthatwill stayactiveaslong asthe remotebutton ishelddown.Thereis
no LCD/pagerconfirmation forAux.2output. DomeLightIllumination (Optional)
Thisfeaturewill turnon the vehicle’sdomelightupon disarming for30 secondsoruntil the keyisinserted and
turned on.Thiswill provide illuminated entrytoyourvehicleindimlylitareasforsafetyand security.

8
PM
VALETMODE
PM
VALETLOCK
PM
VALETUNLOCK
OPERATINGINSTRUCTIONS-ALARM
Emergency Override(Disarm)
If you havelostthe transmitteroritstopsworking foranyreason and the Alarm isarmed,you will haveto
disarm the systemmanually.Open the doorwiththe key[alarm will sound], turnthe ignition on,and press the
override/programbutton forabout5seconds.The Alarm will disarm and allowyou tousethe vehicleuntil you
can repair/replacethe remote.Valetmode alsopreventsPassiveArming.
ValetMode(Entermanuallyorusing theremote)
TodisableAlarm and RemoteEngine Starting forvehicleservicing orotherwise,turnthe ignition on and press
the override/programbutton [about5-7seconds]until you hear(3)siren chirpsand the LEDturnson solid.
Repeatthe process toexitVALETmode.Toenter/exitvaletviathe remote:disarm system,then press and
holdbothbuttons#1 (Lock)and Button #2 (unlock)togetherforabout3secondsuntil 3chirpsareheard.
Repeatthisstep toexitviathe remotetransmitter.Lock/Unlock and AUXfeatureswill still operateinwhen in
VALETmode howeverremotestartand alarm functionsareinhibited.
ValetParkMode(Using theremotetransmitteronly)
Note:ValetParkmode isonlyaccessiblewhen using the remotetransmitter.Valetparkmode allowsyou to
turnoverthe vehicletoavaletallowing access todrive/lock/unlock yourvehicle,butalarm will triggerifthe
trunkisopened.ToactivateValetPark:disarm system,then press and holdbothbuttons#1 (Lock)and
Button #2 (unlock)togetherforabout3seconds.3chirpswill be heardfirstwhen unitgoesintoregularValet
Then press and holdbothbuttonsagain,you will hear2morechirps.LEDwill always flashslowlywhen in
ValetParkeven when the Ignition isturned on (ordriving vehicle).Repeatstep abovetoexitValetPark
mode.

9
PM
IGN
CONFIRMREMOTE
STARTREQUEST
PM
IGN
(<<<< MOVING<<<<<)
SUCCESFULSTART
REMOTEENGINECONTROL
REMOTEENGINESTARTING-SUCCESSFULSTART
1)Press remotestartbutton on the remotetransmitter.Systemwill chirp3timesforaudibleconfirmation.
(Chirpscan be programmed on oroff-See installation manual.)
2)Parking lightsflashonce,then turnon solid,Ignition/Accessorycircuitsturnon.
3)Afterafewseconds,StarterMotorengages,Parking lightsand Accessorycircuitsturnoff whilecranking.
4)Engine Startsand Runs.Parking Lightsand Accessoryturnback on,DoorsLock.
5)Engine will remainrunning forprogrammed run timeuntil resetwithBrakepedal.If needed,the engine can
be turned off withremotetransmitter.
REMOTEENGINESTARTING-SUCCESSFULSTARTDIAGRAM:
DOUBLEBUTTONPRESS FORREMOTESTARTand TRUNK RELEASE
Thisoption will allowyou tochange whetherthe Remotestarterand Trunkreleaseactivatebyasinglepress
oradoublebutton press.Check withyourinstallerorfollowprogramming option instructionsinthe installation
manual.
REMOTEENGINESTARTING–LCD PAGER-REMOTE:
When requesting aremotestartthe LCD pagerremotewill
confirm withan Ignition Icon along with4beeps.Oncethe
vehiclehassuccessfullystarted the remotewill confirm
back with2vibrations,amoving vehicleIcon,and 4
beeps.
AFTER
IGN
3
STARTER
THEN
FLASH1X
SOLID
SOLID
SEC.
START

1
0
REMOTEENGINECONTROL
UNSUCCESSFULREMOTESTART
Inthe eventthatthe engine doesnotstarton the firstattempt, the systemshutsdownforafewseconds,then
attemptstorestartthe engine a2nd and 3rdtime.Forhardstarting engines,the unitwill allowastartercrank
timeofup to13 secondsmaximum.Thisshouldprovide amplecranking timefordifficultstarts,butislimited to
13 secondstohelppreventdamage tothe starterfromovercranking.
1)If engine startson 2nd or3rdattempt, see steps4&5(on lastpage)under"SuccessfulStart".
2)If Thirdattemptfailstostartengine,the systemwill turnoff and doorswill remainlocked.NOFURTHER
ATTEMPTSWILL BE MADEAUTOMATICALLYUNLESS YOUPRESS THEREMOTESTARTBUTTON
AGAIN.
TURNINGOFF YOUR REMOTESTARTEDENGINE(VIAREMOTECONTROL):
1)Engine isrunning inRemoteStart(Parking lightsON).
2)Press RemoteStartbutton on remotetransmitter.
3)Engine &parking lightsturnOFF,Doorsremainlocked orwill re-lock ifapplicable.
ENGINE&LIGHTSOFF
START
ENTERINGYOUR REMOTESTARTEDVEHICLE:
1)Withengine running,RemoteUnlock/Disarm system(If armed)oropen doorwithkey.
2)Entervehicleand be carefulnottostep on brakepedal!(RemoteStartReset)
3)TurnIgnition toON/RUN position,then press brakepedaltoresetthe RemoteStarter&Shift outofpark.
4)Remotestarterwill resetinstantlywhen the brakeispressed.Parking lightswill turnoff and the ignition key
isnowcontrolling yourvehicle.

1
1
REMOTEENGINECONTROL
IDLEDOWNMODE(TAKE-OVEROPERATION)
Thismode allowsthe unittotakeoveroperation ofyouridling,parked vehiclewhilethe ignition keyis
removed and you exitthe vehicle.The vehicleisputintoaremoterunning condition beforeyou exitand itwill
remainrunning forthe programmed run time,until you return,oruntil the remotestartbutton ispressed.
Example:
You pull up toaconveniencestoreforaquick stop,"IdleDown"mode keepsengine running when you
exitthe vehicle,(withkeys inhand)remotelock/arm alarm.When you return,unlock/disarm alarm,turn
ignition ONand driveaway.Thismode can alsobe used on Turbo vehiclesthatneed idleforcool-down.
IDLEDOWNMODE-EXITINGTHEVEHICLE:
1)Withengine running,press RemoteStartbutton on remotetransmitter.Siren will chirp3timesfor
confirmation.
2)Parking Lightswill turnON.
3)Doorswill unlock,orifbrakepedalisbeing depressed then doorswill unlock when itisreleased.
4)TurnOFF Ignition and removekey.Engine shouldremainrunning.
5)Exitvehiclethen remotelock doorsifdesired.
6)Engine will remainrunning forprogrammed run time,until you return,orpress the remotestartbutton.
INFINITYRUN MODE
Thismode allowsthe vehicle’sengine toremainrunning INDEFINITELY.Thismode can be beneficialtolaw
enforcementvehiclesorcommercialvehiclesthatneed toremainrunning unattended forlong periodsoftime.
INFINITYRUN MODE–EXITINGTHEVEHICLE:
1)Followstepsfor“IDLEDOWNMODE-EXITINGTHEVEHICLE”(above),exceptpress the remotestart
button asecond timewithin10 secondsatSTEP #1.
2)Parking Lightswill startflashing instead ofcoming on solid,and doorswill unlock.
3)TurnIgnition switchOFF,removekeyand exitthe vehicle.Engine shouldremainrunning.
4)The vehicle’sparking lightswill flashforthe programmed run timeof12,24,or36,or48 minutesand then
switchtosolidwhilemotorrunsindefinitelyoruntil fuelsupplyrunsout.

1
2
REMOTEENGINECONTROL
TIMEDSELF STARTMODE
Thismode allowsthe vehicletobe programmed toself-startevery4hoursand run forthe programmed run
time.Thiscan be helpfulduring extremelycoldconditionswhereengine orfluidfreeze-up isaconcern.!!THE
VEHICLEMUSTBE OUTDOORSORINAWELL VENILATEDAREA!!
TIMEDSELF-STARTMODE–EXITINGTHEVEHICLE:
1)Haveengine running withthe Key,then press the Startbutton on the transmitter.
2)Within10 secondspress the valet/programbutton once.
3)Parking Lightswill turnOFF forabout5seconds,and doorswill unlock.
4)TurnIgnition switchOFF,removekeyand exitthe vehicle.Engine shouldremainrunning.
5)Press the remotestartbutton againtoturnoff the engine.The parking lightswill flash4TIMES asa
confirmation thatthe unitisinTimed Self-StartMode.
6)The Vehiclewill Startbyitselfevery4hours,oruntil driven withkeyorstarted viaremotecontrol.
IGN
SOLID
OFF
UNLOCK
PRESS 1X
WITHIN10 SEC.
LIGHTSOFF 5SEC.
FLASH4X
LOCK
START
START
RESETTINGTIMEDSELF STARTMODE
Toresetthe timed self-startmode,startthe vehicleusing the keyorthe manuallywiththe remotecontrol

1
3
OPTIONALTURBOTIMERMODE
OPTIONALTURBOTIMERMODE:
IMPORTANTNOTE:Thismoderequires theuse ofanextrapartcalledamomentaryswitchorbutton
thatisnotincludedwiththekit.Check withyourinstalleraboutadding thisfeature.Theoptional
Turbo Timermodeallowstheyoursystemtokeepyourvehiclerunning for1to5minutes [selectively]
afteryou remove thekey,exitthevehicle,and lock thedoorsremotely[ifyou ownaTurbo orTurbo
Diesel].Thisishandyforturbo cooldownwithouttheneedforexpensive Turbo Timers.
1)Engine shouldbe running withthe key.Press and holdthe brakepedal.
2)Press your“Turbo Timer” button 1to5timesforeachminuteofrun timeyou desire.(1press =1min.)
3)Releasethe brakepedaland yoursystemwill confirm byflashing the lightsthe samenumberoftimesthe
button waspressed.
4)TurnIgnition switchOFF,removekeyand exitthe vehicle.Remotelock yourdoorsforsafety.The engine
shouldremainrunning forthe selected numberofminutes.
REMOVE KEY
PRESS TURBO
FLASH1-5X
EXITVEH.
PRESS
AND HOLD
BRAKE
TIMERBUTTON
1-5TIMES
RUNNINGRELEASE
BRAKE
LIGHTS
RUNNING
REMAIN
1-5MIN.

1
4
ANTICARJACK PROTECTION
REMOTEOPERATEDCARJACK PROTECTION
ThisfeatureprovidesActiveCarjack protection through the remotecontrol.When the Ignition ison (vehicleis
running),press and holdthe #1 LOCKButton and #3 TRUNKButton for2seconds.The parking lightswill
flash2timesand the LEDwill begintoflashrapidlytoconfirm the beginning ofaCarjack countdown.30
Secondslater,the unitwill beginaCarjack Cycleconsisting of20 secondsofpre-warning chirpsturning intoa
full systemactivation withsiren /flashing lightpulsesforup to5min.If the Ignition isturned off during a
Carjack triggerthe siren and lightsstop butCarjack protection isstill active.The Siren and Lightswill resume
ifthe Carjackertriestoturnthe Ignition back ON.TORESET:Press Button #2 (UNLOCK)on the remoteand
the siren will chirponce,orturnthe keyon and press and holdthe override button foratleast5seconds.
SWITCH-CONTROLLED&FULL TIMECARJACK (PINK WIRECONFIGURATION)
Thisfeaturecan provide PassiveorManualcontrolCarjack protection depending on the configuration ofthe
PinkCarjack wireofthe alarm system.The systemmustbe programmed forthe Pinkwiretobe used asa
Carjack triggerwithprogramming option #20.Onceprogrammed forthe PinkwireforuseasaCarjack trigger,
itcan be configured indifferentways toprovide differentlevelsofprotection.It can be connected toahidden
+12Vtoggle/momentaryswitchorto+12VIgnition Power.Read following sectionsforfurtherdescriptions.
HIDDENSWITCH-CONTROLLEDCARJACK:
Thisconfiguration will enablethe vehicleownertoactivateaCarjack countdownbypressing ahidden push-
button (notincluded withkit)during aCarjack situation.ACarjack countdownwill beginunderthe following
conditions:Ignition isON(vehicleisrunning),the push-button ispressed,and the dooropens/closes.Upon
these3events,inthatorder,the alarm will startaCarjack countdown.Afteradelayofone minute,the system
will beginchirping for20 secondsthen triggerintoafull cycleforup to5minutes.ToresetthisCarjack mode,
Ignition mustbe ONthen press and holdthe override/valetbutton for5seconds(until LEDgoesout.)
FULL-TIME[Permanent] CARJACK:
Werecommend thatthisconfiguration onlybe used ifaseriousthreatofCarjack existsduring everyday
situations.When the Ignition ison (vehicleisrunning),anytimeadoorisopened the Carjack countdown
sequencewill be initiated.Therewill be 2lightflashesand the LEDwill change fromsolidtoquick pulsing as
confirmation ofacountdownsequence.ToresetFULL TIMECarjack,the Ignition hastobe ON,then press
and holdthe override/programbutton 5secondsuntil LEDstopspulsing.The LEDwill be on SOLIDwhen in
thismode anytimethe Ignition isON(orwhiledriving)asareminderthatCarjack iswaiting foradoortoopen.

1
5
LEDDIAGNOSTICS
The CS-2016DPII-FMsystemincludesdisarm diagnostics,through the REDLEDlight, thatwill helpin
determining whatcaused the lasttriggerofthe alarm system.Thisisavaluabletoolindetermining howthe
vehiclewastampered withorifthereisafalsealarm probleminwhichcaseyou can makethe necessary
adjustmentstocorrectthe problem.When the systemisdisarmed withthe remoteyou will hearthe normal2
chirps,then 4quick chirpsthatindicatethe alarm wastriggered whileyou wereaway.Check the LEDlightfor
asequenceofflashes:
Shock Sensor=1FlashDoor=2Flashes Hood/Trunk=3Flashes Ignition =4Flashes
Diagnostics will resetwhen the Ignition isturned on orwhen the systemisre-armed.
TRANSCEIVER/REMOTECONTROLPROGRAMMING
Note:All transmittercodes mustbelearnedattimeofprogramming!! Upto4differenttransmitter
codes canbestoredinthememoryofthesystem.
1.Turnkeytothe ONposition.
2.Press Programming button 4times,then afterafewsecondsthe unitwill flashthe parking lights4times.
3.Press buttons#1 (Lock)&#2 (Unlock)togetheratthe sametimeofeachtransceivertobe learned.You
shouldget2lightflashesindication the unitiswaiting fora2nd code,then press button #1 &#2 ofasecond
transmitterortransceiver,the unitwill flash3timesindicating itswaiting forthe 3rdcode and lightswill flash
4timesfor4thcode.If all 4codesarelearned,the unitwill automaticallyexitcode learning mode,
otherwiseturnkeyoff and closehood.
NOTE:Whenlearning 2-Way FMremotes waitfortheLCD toconfirm withabeepand theantenna
ICONon theLCD screenBEFORElearning thenextremote.
SEE DIAGRAMONNEXTPAGE

1
6
TRANSCEIVER/REMOTECONTROLPROGRAMMING
IGN
OFF
WAITFOR
4FLASHES
PRESS 4X's
FLASH2,3,or4X's
2-WAYSYSTEMS&
IGN
OFF
PRESS TOGETHER
LOCK &
UNLOCK
"SideKick"REMOTES
COMPLETE
LCD Code-LearnScreen

1
7
2VEHICLEOPERATION
2VEHICLECONTROL
YourCS-2016DPII-FMremoteshavethe abilitytocontrolasecond vehiclewithaCrimestopperCS-2016DPII-
FMorolderCS-2015FMsysteminstalled.See diagrambelowon howtoswitchyourremote(s)tovehicle#2
operation.
Tosetup the 2-Vehicleoperation you must
firstprogramyourremotestoVehicle#2.
Followthe “TransmitterProgramming”
steps(Pg.15)atthe second vehicleand
learnYOUR remote,along withvehicle#2’s
existing remotes.
2-VEHCLEOPERATIONNOTES:
(1)You do nothavetoswitchbetween
VehicleIand II togetpagesfromeach
vehicle.Yourremotepagerwill receive
pagesfrombothcarsregardless ofwhich
vehiclethe pagerissetto.The “I”or“II”
icon will always displaywitheachpage
indicatewhichvehiclethe page originated
from.
(2)When programming CS-2016DPII-FM
systems,all remote/pagersand sidekick
remotesforthatvehiclemustbe learned at
the timeofprogramming.When you
programyourremoteatthe second vehicle,
thatvehicle’soriginalremotemustalsobe
programmed.Yourremoteshouldbe setin
VehicleII and the vehicle’soriginalremote
shouldbe setinVehicleI.
Press MiddleButton
for2secondsfirst,
Thenyou have 3
secondstoControl
vehicle#2
START
PM
CS-2016DP-FM
Press &holdsidebutton
for5seconds.Remote
will beepand "II"icon will
appearinlowerrightLCD.
"Sidekick"
VEHICLE#2 CONTROL:
Remote

1
8
TROUBLESHOOTINGFAQ’s:“BEFOREYOUCALL SECTION”
Beforecalling yourdealerorCrimestopper,readthefollowing section fortipsthatmay remedyor
explainyourproblem.
RANGEQUESTIONS(2-Way Pager/Remote):
YourCS-2016DPII-FMsystemusesFMHigh-Frequency signalstosend/receivedatabetween the pagerand
the vehicleand fromthe vehicletothe remoteforstate-of-the-artoperation.
1)Undernormaloperation,the distancefromthe vehicle-paging-the-remotewill be greaterthan thatfromthe
remote-to-the-vehicle.Thisisdue topowersupplies.The maincontrolmodule(brain)inthe vehicleis
connected tothe electricalwiring receiving powerfromthe vehiclebattery,whereasthe remote/pageris
operating fromthe AAA 1.5Valkaline battery.Thisisanormalfeatureforan FM2-Waypaging system.
2)Yoursystemisdesigned toalways operatewithmaximumefficiency,howeverrange maybe affected by
the following circumstances:PhysicalDistance,Obstructions,and RF/ElectronicInterference.(On
US/Domesticsystems,poweroutputislimited byFCC Regulations/Specifications.)
3)ThisCS-2016DPII-FMsystemdoesNOTuse“Paging”or“Cellular” antenna service.Thereareno monthly
feesassociated withitsoperation.The CS-2016DPII-FMunitinthe vehiclesendsapaging signaldirectlyto
yourpager/remotefromitsownantenna mounted inside the vehicle.
MYIN-DASHLEDFLICKERSWHENPRESSINGREMOTECONTROLBUTTONS:
Thisisnormaloperation.Theremaybe aslightflickervisiblefromthe LEDwhen pressing the remoteasthe
systemisauthorizing/processing the code sentfromthe remotecontrol.Thereisnothing wrong withyour
system.
MYSYSTEMFLASHES THELIGHTSONCEAND WILL NOTATTEMPTAREMOTESTART(2parts):
1)The systemispossiblyinvaletmode.Check the statusofthe REDLEDlight. If itison solid,then the unit
isinVALETMODEand will NOTremotestartwhen inValetmode.Thisistoprotectthe systemfrom
unauthorized engine starting when yourvehicleserviced orvaletparked.TOEXITVALETMODE:Turn
Ignition ON,and press the valetbutton forabout5secondsuntil LEDgoesout. See the Valetpartofthe
operating instructionsformoreinformation.
2)The unitsensesapossiblewiring faultatthe Brakeorthe Hood isOPEN(Blue wiregrounded).Thisisa
safetyfeatureofthe unit. Check installation forfaultsand makesurehood isclosed and verifybrakeinput
connection.The LCD will alsonotconfirm back asignalofaremotestartrequestwhen thisoccurs.

1
9
PM
LOWBATTERYWARN
TROUBLESHOOTINGcontinued
WHENARMINGAND DISARMINGMYALARMHASIRREGULAR “LONG”SIRENCHIRPS:
Thisisan audiblewarning thatthe batteryinthe LCD pagerremoteislow.Replacethe AAA batteryinthe
pagerand yourchirpswill returntonormal.
SYSTEMISNOTSUCCESSFULATREMOTESTARTINGDURINGEXTREMECOLDCONDITIONS:
Pleasebe awarethatduring sub-freezing conditionsyourremotestartermaytakemorethatone attemptto
start, oritmaynotsuccessfullystartthe vehicleafter3attempts.During theseconditionsthe vehiclemaynot
properlystarteven using the key,thereforetrying tostartthe vehiclebyremotewouldalsobe unsuccessful.
MYSYSTEMDOES NOTRESPOND TOTHEREMOTECONTROL(4Parts):
1)You maybe outofrange ofyourvehicle.Movecloserand attemptagain.
2)Check forproperpower/ground wiring connectionsofthe alarm.
3)Check Antenna Moduleconnection.The antenna included withthissystemmustbe plugged into
send/receivesignals.Antenna Modulegetsvoltage fromthe controlmodule.
4)The Remote/Pagermayneed anewbatteryorneed tobe reprogrammed tooperatethe system.See “2-
WayFMTransceiverprogramming”formoreinformation.
LOWBATTERYWARNING-LCD REMOTE
Your2-Waypagerremotewill warnyou when the batterygetslow.You will
see abattery“L”icon on the LCD screen when itistimetoreplacethe AAA
battery.You mayalsoirregular“long”siren chirpswhen arming and disarming
you system.Toreplacethe battery,simpleunlatchand slide open the battery
dooron the back ofthe 2-WayLCD remote.Carefullyinsertanewbattery,
using the outline on the bottomofthe batterycompartmentasaguide.Your
remotewill beep onceifthe batterywasinserted correctly.

SETTINGTHECLOCK (2-WAY-LCD REMOTE)
1.Press and holdall 4buttonsofremotecontrolforapproximately3secondsuntil remotebeeps.
2.The minutedisplaywill beginflashing.Usethe lock and unlock button tochange the minuteup ordown
tothe correcttimeand then press button #3 (Trunk)tosetthe minutevalue.
3.The hourdisplayshouldbeginflashing.Usethe lock and unlock button tochange the hourup ordown
tothe correctamorpmhour.
4.Oncethe correcttimeisdisplayed,wait6seconds,the remotewill beep twiceand the timeofdayisset.
REMOTESTARTDIAGNOSTICS
If the systemflashesthe parking lightsone tothree timesand doesn’tattemptremote,itmeansthe following:
1Parking LightFlash=ProblemwithBrake Switch.Therecouldbe aproblemwithabad brakelight. Many
dualfilamentlightbulbsconnectthe brakeand parklightstogetherwhen bulbgoesbad.Check all brakelights
workproperly.
2Parking LightFlashes =ProblemwithHood Switch.Makesurehood isclosed orthatthe Blue hood pin
wireisnotshorted toGround.
3Parking LightFlashes =ValetService Mode.Check the Alarm StatusLEDlightand ifitison SolidBlue
(withdoorsclosed)then the systemisinValetMode.ToexitValetMode,turnthe Ignition on,press and hold
ValetButton forabout5secondsuntil LEDgoesout. UnitisnowoutofValetMode and shouldperform a
remotestart.
CrimestopperSecurityProductsInc.
1770 So.Tapo Street
SimiValley,CA93063
[phone]
www.crimestopper.com
[e-mail]
©2007 CrimestopperSecurityProducts
ONLINETECHNICALSUPPORT
www.crimestopper.com
