Cross Technologies 2016-1522 User manual

Instruction Manual Model 2016-1522#
Downconverter
June 2017, Rev A
MENU
EXECUTE
MODEL 2016
CROSS TECHNOLOGIES INC.
F=1544 G=25
ATTEN=10 REF=AUTO-I
REMOTEALARM POWER
DOWNCONVERTER
Data, drawings, and other material contained herein are proprietary to Cross Technologies, Inc.,
but may be reproduced or duplicated without the prior permission of Cross Technologies, Inc.
for purposes of operating the equipment.
When ordering parts from Cross Technologies, Inc., be sure to include the equipment model number,
equipment serial number, and a description of the part.
CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]

INSTRUCTION MANUAL
Model 2016-1522# Downconverter
TABLE OF CONTENTS PAGE
Warranty 2
1.0 General 3
1.1 Equipment Description 3
1.2 Technical Characteristics 4
1.3 Monitor & Control Interface 5
1.4 Environmental Use Information 8
2.0 Installation 9
2.1 Mechanical 9
2.2 Rear Panel Inputs & Outputs 10
2.3 Front Panel Controls & Indicators 11
2.4 Operation 12
2.5 Menu Settings 13
WARRANTY - The following warranty applies to all Cross Technologies, Inc. products.
All Cross Technologies, Inc. products are warranted against defective materials and
workmanship for a period of one year after shipment to customer. Cross Technologies,
Inc.’s obligation under this warranty is limited to repairing or, at Cross Technologies, Inc.’s
option, replacing parts, subassemblies, or entire assemblies. Cross Technologies, Inc. shall
not be liable for any special, indirect, or consequential damages. This warranty does not
cover parts or equipment which have been subject to misuse, negligence, or accident by the
customer during use. All shipping costs for warranty repairs will be prepaid by the
customer. There are not other warranties, express or implied, except as stated herein.
CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
WEB www.crosstechnologies.com
E-MAIL [email protected]
2016-1522# Manual, Rev. 0 Page 2 06/19/17

Model 2016-1522# Downconverter, 1.544 or 2.226 GHz to 70 ± 5 MHz
1.0 General
1.1 Equipment Description
The 2016-1522# Downconverter converts 1.544 or 2.226 GHz to 70 MHz. The gain is 0 to +50 dB, adjustable
in 1±1 dB steps. Push button switches select the input frequency, gain, and other parameters. Front panel LEDs
provide indication of DC power (green), PLL alarm (red), and Remote operation (yellow). Gain is adjustable
manually (MGC) over a 0 to 50 dB range. Remote operation allows selection of frequency and gain. Parameter
selection and frequency and gain settings appear on the LCD display. Connectors are Type N female for the IF
out and RF in and BNC female for the external 10 MHz reference input (Option E) which includes a 10 MHz
output connector which contains either the internal or external 10 MHz reference signal. The unit is powered by
a 100-240 ± 10% VAC power supply, and housed in a 1 3/4” X 19” X 16” rack mount chassis.
MENU
EXECUTE
MODEL 2016
CROSS TECHNOLOGIES INC.
F=1544 G=25
ATTEN=10 REF=AUTO-I
REMOTEALARM POWER
DOWNCONVERTER
FRONT PANEL
AC
GND
J3
J10
J18J2
RF IN 10 MHZ REF 10 MHZ AND
MONITOR EXT REF
CONTROL
OUTPUT INPUT
J20
1
5
234 6
789
J1
IF OUT
REAR PANEL (Optional Ethernet Shown)
FIGURE 1.1 Model 2016-1522# Front and Rear Panels
70 ±5
MHz
OUT
RF IN
1.544
and
2.226
GHz
1750 MHz
BP
2870
MHz
3.294
or
3.976
GHz
1.5 to 2 .3
GHz HP/LP 70 ±5 MHz
BP
CONTROLLER
2016-1522# Downconverter Block Diagram
VAR
ATT EXT
10 M
INT/EXT*
10 M
M&C
* OPTIONAL
FIGURE 1.2 Model 2016-1522# Downconverter Block Diagram
2016-1522# Manual, Rev. 0 Page 3 06/19/17

1.2 Technical Characteristics
TABLE 1.0 2016-1522# Downconverter Specifications*
Input Characteristics
Impedance/Return Loss 50 Ω/12 dB
Frequency 1.544 and 2.226 GHz
Noise Figure, Max. 15 dB at maximum gain
Input Level Range -50 to -20 dBm
Output Characteristics
Impedance/Return Loss 50 Ω/18 dB
Frequency 70 ± 5 MHz
Output Level/max. linear -20 to 0 dBm
Output 1 dB compression +10 dBm maximum gain
Channel Characteristics
Gain at Fc +50 ±3dB maxium, (+50 to 0 dB variable in 1 ±1 dB steps)
Image Rejection > 50 dB, minimum
Frequency Response 1544 or 2226, 10 MHz BW, ± 0.75 dB
Spurious Response <-50 dBc, in band, 70 ± 5 MHz
Group Delay, maximum 0.015 ns/MHz2 parabolic; 0.05 ns/MHz linear; 1 ns ripple
Frequency Sense Non-inverting
Lo Characteristics
LO Step Size NONE, Fixed tuned to 1544 or 2226 MHz In
Frequency Accuracy ±0.01 ppm maximum over temperature internal reference
-110-100-90-80-75
1MHz100kHz10kHz1kHz100Hz
Standard dBC/
(
Hz
)
Phase Noise @ F
(
Hz
)
>
Controls, Indicators
Frequency/Gain Selection Direct readout LCD; manual or remote selection
Power; Alarm; Remote Green LED, Red LED, Yellow LED
Remote RS232C, 9600 baud (RS485, Ethernet Optional)
Other RF, IF Connectors N (female), N (female)
10 MHz Connectors BNC (female), 75Ω, works with 50 or 75 ohms (option E)
Alarm, Remote Connector DB9 (female), - NO or NC contact closure on Alarm
Size 19 inch standard chassis 1.75” high X 16.0” deep
Power 100-240 ±10% VAC, 47-63 Hz, 25 watts maximum
*Custom Specifications and/or Standard Options (shown below) included with Model 2016-1522#
Option H - ±0.01 10MHz Internal Reference
Option NN - Connector N-Type (RF), N-Type (IF)
Available Options
E - External 10 MHz Reference
Comm. Interface/Standard RS232
Q - RS485 Remote Interface
W8 - Ethernet; with Web Browser
W18 - Ethernet; with Web Browser & SNMP
W28 - Ethernet; with TCP/IP, Telnet®
Connectors / Impedance
STD - 50ΩType N (RF), 50ΩType N (IF)
SS - 50ΩSMA (RF), 50ΩSMA (IF)
+10˚C to +40˚C; Specifications subject to change without notice.
2016-1522# Manual, Rev. 0 Page 4 06/19/17

1.3 Monitor and Control Interface
A) Remote serial interface
Protocol: RS-232C, 9600 baud rate, no parity, 8 data bits, 1 start bit, and 1 stop bit.
(RS-232C, RS-422, or RS-485 - Option-Q)
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
Female DB-9
PC Com Port Male DB-9
2015/16/17 M&C Port
M&C Cable Diagram - Cross Technologies Frequency Converters
RX RX
TX TX
DTR
SG
DSR
RTS
CTS
SG
Connector: Rear panel, DB-9 male
J10 Pinouts
(RS-232C/422/485)
Pinouts (RS-232C/422/485)
Pin Function
1 Rx-
2 Rx+ (RS-232C)
3 Tx+ (RS-232C)
4Tx-
5GND
6 Alarm Relay: Common
7 Alarm Relay: Normally Open
8 Not Used
9 Alarm Relay: Normally Closed
2016-1522# Manual, Rev. 0 Page 5 06/19/17

B) Status Requests
Table 1.1 lists the status requests for the 2016-1522# and briefly describes them.
*PLEASE NOTE: The two character {aa}(00-31) prefix, in the table below,
should be used ONLY when RS-485, (OPTION-Q), is selected.
TABLE 1.1 2016-1522# Status
2016-1522# Status Reqquests
TABLE 1.1 2016-1522# Status Requests
Command Syntax* Description
Get Frequency {aaSF} returns {aaSFxxxx}
where: xxxx = frequency in MHz (either 1544 or 2226)
Get Gain {aaSGxx} returns {aaSGxx}
where: xx = gain in dB (00 to 50)
Get reference status {aaSE} returns {aaSExy}
(option E only) where: x = setting:1 for internal 10 MHz; 2 for external 10MHz; 3 for auto detect
y = currently selected in hardware: 1 for internal 10 MHz; 2 for external 10 MHz
Get Reference Insertion Status {aaSL} returns {aaSLx}
(option E only) where: x = 0 for non-insertion; 1 for insertion
Get Output Attenuation {aaSN} returns {aaSNxx}
(option Z20 only) where: xx = output attenuation in dB (00 to 20)
xxx = LNB current in amps to 2 decimal places (e.g., 065 = 0.65 amps)
Get IP address {aaSi} returns {aaSixxx.xxx.xxx.xxx}
(ethernet options only) where xxx.xxx.xxx.xxx = IP address
Get subnet mask {aaSs} returns {aaSsxxx.xxx.xxx.xxx}
(ethernnet options only) where xxx.xxx.xxx.xxx = subnet mask
Get alarm status {aaSA} returns {aaSAa}
where a = alarm state (0 for alarm off; 1 for alarm on)
Get product/model info {aaSV} returns {aaSV2016-1522#xxxxver5.00}
where 2016-1522# = product model
xxx = list of options, if any
"ver" = separates model & options from firmware version
5.00 = firmware version
2016-1522# Manual, Rev. 0 Page 6 06/19/17

C) Commands
Table 1.2 lists the commands for the 2016-1522# and briefly describes them. After a command is sent the
2016-1522# sends a return “>” indicating the command has been received and executed.
General Command Format - The general command format is {aaCND...}, where:
{ = start byte
aa = address (RS-485 only - option -Q)
C = 1 character, either C (command) or S (status)
N = 1 character command or status request
D = 1 character or more of data (depends on command)
} = stop byte
*PLEASE NOTE: The two character {aa}(00-31) prefix, in the table below,
should be used ONLY when RS-485, (OPTION-Q), is selected.
Table 1.2 2016-1522# Commaands
Commands
Table 1.2 2016-1522# Commands
Command Syntax* Description
Set Frequency {aaCFx} where: x = 0 for 1544 MHz: x = 1 for 2226 MHz
Set Gain {aaCGxx} where: xx = gain (Range: 00 to 50) in 1 dB steps
10 MHz reference mode {aaCEx} where: x = 0 for internal 10 MHz;1 for external 10 MHz;
(option E only) 2 for auto detect
Reference insertion on output {aaCLx} where: x = 0 for non-insertion; 1 for insertion
(option E only)
Set Output Attenuation {aaCNxx} where: xx = attenuation (Range 00 to 20) in 1 dB steps
(option Z20 only)
2016-1522# Manual, Rev. 0 Page 7 06/19/17

1.4 Use Information
A.Rack-Mounting - To mount this equipment in a rack, please refer to the installation instructions
located in the user manual furnished by the manufacturer of your equipment rack.
B. Mechanical loading - Mounting of equipment in a rack should be such that a hazardous condition
does not exist due to uneven weight distribution.
C.Elevated operating ambient temperature - If installed in a closed or multi-unit rack assembly,
the operating ambient temperature of the rack may be greater than room ambient temperature.
Therefore, consideration should be given to Tmra (Maximum Recommended Ambient Temperature).
D. Reduced air flow - Installation of the equipment in a rack should be such that the amount of air flow
required for safe operation of the equipment is not compromised. Additional space between unit
may be required.
E. Circuit Overloading - Consideration should be given to the connection of the equipment to the supply
circuit and the effect that overloading of circuits could have on over current protection and supply wiring.
Appropriate consideration of equipment name plate rating should be used, when addressing this concern.
F. Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained. Particular
attention should be given to supply connections other than direct connection to the Branch
(use of power strips).
G. Top Cover - There are no serviceable parts inside the product so, the Top Cover should not be removed.
If the Top Cover is removed the ground strap and associated screw MUST BE REINSTALLED
prior to Top Cover screw replacement. FAILURE TO DO this may cause INGRESS and/or EGRESS
emission problems.
2016-1522# Manual, Rev. 0 Page 8 06/19/17

2.0 Installation
2.1 Mechanical
The 2016-1522# consists of one RF/Controller PCB housed in a 1 RU (1 3/4 inch high) by 16 inch deep chassis.
A switching, ±12, +24, +5 VDC power supply provides power for the assemblies. The 2016-1522# can be
secured to a rack using the 4 holes on the front panel. Figure 2.1 shows how the 2016-1522# is assembled.
POWER
SUPPLY
FIGURE 2.1 2016-1522# Mechanical Assembly
2016-1522# Manual, Rev. 0 Page 9 06/19/17

2.2 Rear Panel Input/Output Signals
Figure 2.2 shows the input and output connectors on the rear panel.
AC
GND
J3
J10
J18J1
IF OUT 10 MHZ REF 10 MHZ AND
MONITOR EXT REF
CONTROL
OUTPUT INPUT
J20
1
5
234 6
789
AC1 - POWER IN
AC input for switching power
supply. 100-240 ±10% VAC,
47-60 Hz.
J2 - RF IN
-50 to -20 dBm input
1.544 & 2.226 GHz
see Table 2.2.
J10 - MONITOR AND CONTROL
DB9 female connector
see Table 2.1
J20 - Ethernet Connection
RJ45 Ethernet Connector
J18 - 10 MHz REF OUTPUT (option -E)
10 MHz external reference output
3 ± 3 dBm, 75Ω, BNC female connector.
J3 - 10 MHz EXT REF INPUT (Option -E)
10 MHz external reference input
3 ± 3 dBm, 75Ω, BNC female connector.
J1 - IF OUT
-20 to 0 MHz output
70 ±5 MHz dBm
see Table 2.2.
J2
RF IN
FIGURE 2.2 2016-1522# Rear Panel I/Os
TABLE 2.1 J110
2.1 J10 Pinouts (RS-232C*)
Pin Function
1 Not Used
2 Rx+ (RS-232C)
3 Tx+ (RS-232C)
4 Not Used
5GND
6 Alarm Relay: Common
7 Alarm Relay: Normally Closed
8 Not Used
9 Alarm Relay: Normally Open
*Remote Serial Interface
Interface: DB-9 Male
Protocol: RS-232C, 9600 baud rate, no parity, 8 data bits, 1 start bit, 1 stop bit
TABLE 2.2 IFF/RF
2.2 IF/RF Connector Options
Options
Option IF RF
STD BNC, 75ΩType F, 75Ω
B BNC, 75ΩBNC, 75Ω
C BNC, 75ΩBNC, 50Ω
D BNC, 50ΩBNC, 50Ω
F Type F, 75 ΩType F, 75 Ω
FN Type F, 75 ΩType N, 50 Ω
J BNC, 50ΩType F, 75 Ω
K BNC, 50ΩBNC, 75 Ω
M BNC, 50ΩType N, 50Ω
N BNC, 75ΩType N, 50Ω
S BNC, 50ΩSMA, 50Ω
2016-1522# Manual, Rev. 0 Page 10 06/19/17

2.3 Front Panel Controls and Indicators - The following are the front panel controls and indicators.
MENU
EXECUTE
REMOTEALARM POWER
LCD DISPLAY
Display shows Downconverter
frequency in MHz and Gain in dB
S1 - MENU/EXECUTE BUTTON
Press this to get into Program mode
and to execute any changes.
DS3 - DOWN ALARM LED
Red LED indicates
downconverter alarm.
DS6 - POWER LED
Green LED indicates
presence of DC power.
DS1 - REMOTE LED
Yellow LED indicates
remote operation.
S2 - VERT. TOGGLE
Vertical toggle switch that controls
values in the Menu items when in
program mode. Does not function in the
normal display mode
S3 - HORIZ. TOGGLE
Horizontal toggle switch that
controls which values are being
adjusted. Does not function in the
normal display mode
F=1544 G=25
ATTEN=10 REF=AUTO-I
FIGURE 2.3 2016-1522# Front Panel Controls and Indicators
2016-1522# Manual, Rev. 0 Page 11 06/19/17

2.4 Operation
2.4.1 Installing and Operating the 2016-1522# Downconverter
1. Connect a -50 dBm to -20 dBm signal to RF IN, J2 (Figure 2.2).
2. Connect the IF OUT, J1, to the external equipment.
3. Connect 100-240 ±10% VAC, 47 - 63 Hz to AC on the back panel.
4. Set the input frequency (See Section 2.5 Menu Settings).
5. Set the gain for +50 to +0 dB (See Section 2.5 Menu Settings).
6. Be sure DS6 (green, DC Power) is on and DS3 (red, Alarm) is off (Figure 2.3).
7. Option -L only - To insert LNB +24 VDC on the RF center pin install 0.5A fast blo fuse in F1 and
check that DS8 lights yellow (Figure 2.1).
8. AC Fuse - The fuse is a 5 mm X 20 mm, 2 amp slow blow (Type T) and is inserted in the far slot
in the drawer below the AC input as shown in Figure 2.4. There is a spare fuse in the near slot.
If a fuse continues to open, the power supply is most likely defective.
AC Fuse - 2 amp slow blow (Type T),
5 mm X 20 mm
FUSE DRAWER
SPARE FUSE
~
INPUT
100-240± 10%VAC
47-63 Hz
2A MAX
FUSE
TYPE T 2A GDC
250 VOLT
FOR 100 - 240 V~
~
FIGURE 2.4 Fuse Location and Spare Fuse
2016-1522# Manual, Rev. 0 Page 12 06/19/17

2.5 Menu Settings
2.5.1 Functions
This section describes operation of the front panel controls. There are three operator switches, the
LCD display and alarm indicator LEDs. All functions for the equipment are controlled by these components.
The functions are (see Figure 2.5):
Power Up
Normal Display
Menu 1 Frequency in MHz
Menu 2 Gain (+50 to 0)
Menu 2a. Output Attenuator (option Z20)
Menu 3 Set Unit to Remote Operation
Menu 4 Select External 10 MHz Ref (option -E)
Menu 5 Select Reference Out (option -E)
Menu 6 Set Remote mode (option -Q)
Menu 7 Set RS-485 address (option -Q)
Menu 8 View LNB Current (option -L)
Save Menu When go to end
Alarm indications appear on the LEDs (see figure 2.3).
All program changes must start with the operation of the Menu/Execute switch and must also end with the
operation of the Menu/Execute switch verified by the “Save Settings?” Menu. If this sequence is not followed,
none of the changes will take effect. If programming is initiated and no operator action takes place for
approximately 30 seconds (before the final press of the Menu/Execute switch) the display will revert to its
previous status and you will need to start over.
2016-1522# Manual, Rev. 0 Page 13 06/19/17

2.5.2 Power On Settings
NOTE: THE LAST STATUS OF A UNIT IS RETAINED EVEN WHEN POWER IS REMOVED.
WHEN POWER IS RESTORED, THE UNIT WILL RETURN TO IT'S PREVIOUS SETTINGS.
When power is first applied, the LCD display goes through three steps.
1. The LCD goes black to show all segments are functioning.
2. The software version will be displayed.
REV 1.00
3. The present frequency and gain of the downconverter is shown.
F = 1544 G=+25.0
ATTN=10 REF=AUTO-I
The unit is now operational and ready for any changes the operator may desire.
2.5.3 Control Switches
1. Menu/Execute - Any change to the programming of the unit must be initiated by pressing the
Menu/Execute switch and completed by pressing the Menu/Execute switch.
2. Horizontal Switch - This switch is mounted so its movement is horizontal and moves the cursor
left or right.
3. Vertical Switch - This switch is mounted so its movement is vertical and has two functions:
a. During frequency , gain changes, the vertical movement will raise or lower the number in
the direction of the arrows.
b. For other functions such Mute on/off, the vertical switch will alternately turn the function on
or off regardless of the direction operated.
2016-1522# Manual, Rev. 0 Page 14 06/19/17

2.5.4 Frequency Changes
At any time during the modification process, if you have made a mistake and do not wish to save the changes
you have made, do not press the Menu/Execute switch; simply do nothing for approximately 30 seconds, and
the system will return to the normal operating mode or scroll to “R” and push the menu/Execute switch and
select “NO” in the “SAVE SETTINGS?” window.
To change the FREQUENCY:
Operate the Menu/Execute switch until you get to the menu item you want to change see Figure 2.5
for the sequence of menu options. The following display is for changing the downconverter frequency:
F=1554
R
Pressing the Up/Down switch down will toggle the display to:
F=2226
R
NOTE: CHANGES DO NOT TAKE PLACE ON FREQUENCY UNTIL YOU GO TO THE SAVE
MENU AND INDICATE YOU WANT TO SAVE THE CHANGES.
When the display indicates the value desired you can push the Menu/Execute switch
to get to the next item:
G=+10
R
OR you can scroll to “R”, push the Menu/Execute switch to get to:
SAVESETTINGS? YN
Selecting Ywill save the new settings. Selecting Nwill revert to the previous settings.
Pushing the Menu/Execute switch then takes you to this:
F=1544 G=+10
R
Figure 2.5 gives the menu items and how to make changes.
2016-1522# Manual, Rev. 0 Page 15 06/19/17

2.5.5 Gain Changes
When you get to this menu note that the gain changes will be made as you make them but if you do not wish to
save the changes you have made, scroll to “R” and push the Menu/Execute switch and select “NO” in the
“SAVE SETTINGS?” window or do not press the Menu/Execute switch; simply do nothing for
approximately 30 seconds, and the system will return to the normal operating mode.
To change the DOWNCONVERTER GAIN:
Push the Menu/Execute switch to get to the gain setting.
(See Figure 2.5 for the sequence of menu options):
G=+10
R
Pressing the Up/Down switch will change the gain in 1 or 10 dB steps depending on the cursor location:
G=+20
R
By using the horizontal rocker switch the cursor can be moved left or right. Pressing the Up/Down
switch will toggle the display digit selected until you have the desired gain.
G=+20
R
NOTE: THE GAIN WILL BE CHANGED AS YOU ADJUST THE NUMBERS. HOWEVER, THE
VALUE WILL NOT BE STORED UNTIL YOU INDICATE YES IN THE SAVE SETTINGS
WINDOW.
When the display indicates the value desired you can push the Menu/Execute switch to get to the next
item:
OTHER? YN
R
OR you can scroll to “R” and push the Menu/Execute switch to get to:
SAVESETTINGS? YN
Selecting Ywill save the new settings. Selecting Nwill revert to the previous settings. Pushing the
Menu/Execute switch then takes you to this:
F=1544 G=+20
R
Figure 2.5 gives the menu items and how to make changes.
2016-1522# Manual, Rev. 0 Page 16 06/19/17

2.5.5 Alarm Indications
An alarm condition for will occur if any local oscillator phase lock loop (PLL) comes out of lock. The Mute
LED will light if you select Mute and the Remote LED will light when you select the Remote mode.
2.5.6 10 MHz Reference Mode Operation
Internal Mode: The unit uses its own built-in 10 MHz OCXO. The Internal Reference is present on the
Reference Output Connector, J18. REF = INT appears on the front panel display.
External Mode: The unit uses a 10 MHz Reference that is connected to the External Reference Input, J3.
REF = EXT appears on the front panel display. The External 10 MHz Reference level
must be +3dBm, ±3dB. If the External 10 MHz signal does not meet the unit’s
specified parameters then the unit will not function properly. The External Reference
is present on the Reference Output connector, J18.
Auto Mode: The unit defaults to the External 10 MHz Reference as long as the level meets the +3dBm,
±3dB specification. REF = AUTO - E appears on the front panel display where the -E
indicates that the unit is using the External 10 MHz Reference. The External Reference is
present on the Reference Output connector, J18.
If the external 10 MHz Reference signal level is less than -1dBm, the unit switches to
Internal 10 MHz Reference. REF = AUTO -I appears on the front panel display
where -I indicates that the unit is using the Internal 10 MHz Reference. The Internal
10 MHz Reference is present on the reference output connector, J18.
2016-1522# Manual, Rev. 0 Page 17 06/19/17

FIGURE 2.5 Menu Display and Sequence
ON POWER UP
NORMAL DISPLAY
PUSHING MENU/EXECUTE SEQUENCE
REV 1.00
F = 1544 G = +25.0
F = 1500
SCROLL <>
SCROLL
PUSH BUTTON
REMOTE OFF
EXT REF OFF
SCROLL <>
SCROLL
PUSH BUTTON
PUSH BUTTON
Power Up
Normal Display
Menu 1 Frequency
Menu 2 Gain (+50 to 0)
Menu 2a Output Attenuation
Option Z20
Menu 3 Set Unit to Remote
Operation
Menu 4 Select External 10 MHz
Reference (option -E)
Menu 5 Select 10MHz Reference
Out (option -E)
Menu 6 Set Remote Mode
(option -Q)
Menu 7 Set RS-485 Address
(option -Q)
Menu 8 View LNB current
(option -L)
Save? When “R” is selected or at
the end of the menu options
OUTPUT ATTENUATION=R
15
SCROLL <>
SCROLL
PUSH BUTTON
SCROLL <>
SCROLL
PUSH BUTTON
LNB DC = 0.250A
SAVE SETTINGS? Y N
R
R
R
R
R
REF OUT OFF
SCROLL <>
SCROLL
PUSH BUTTON
R
RS 485 OFF
SCROLL <>
SCROLL
PUSH BUTTON
R
ADDRESS = 00
SCROLL <>
SCROLL
PUSH BUTTON
R
SCROLL <>
SCROLL
PUSH BUTTON
SCROLL <>
PUSH BUTTON
G = +50
SCROLL <>
SCROLL
PUSH BUTTON
R
2016-1522# Manual, Rev. 0 Page 18 06/19/17

CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]
Printed in USA
2016-1522# Manual, Rev. 0 Page 19 06/19/17
