Crosswater GLIDE II GL3516F User manual

BATHROOM FURNITURE RANGE GLIDE II
Two Door Tower Unit
GL3516F
x2 x4
Tools & equipment needed: Drill, 8mm Suitable drill bit, Phillips screwdriver, Spirit level, Ruler/tape measure, Pencil,
Silicone sealant (clear).
IMPORTANT - Advice and safety - Please read before installation
Please read these instructions carefully before starting
installation and keep in a safe place for future reference.
Check the contents of the pack carefully before installation.
Crosswater will not be held responsible for any de-t/ re-t
costs where faulty product has been tted.
If any fault is found with materials or workmanship, it must be
reported immediately to the manufacturer. Remedial action
will be taken, based on information received, on condition
that: 1. Full details are supplied to the manufacturer; 2. The
product has not been modied or tampered with; 3. The ma-
nufacturer is informe damage/shortages prior to installation.
We do not accept responsibility for any problems that may
occur through incorrect installation.
Advice & Safety
This product should be only be installed by a suitably quali-
ed Plumber/installer. Should the installation be completed
by a non-qualied person any product guarantee maybe con-
sidered invalid. For a claim made under our warranty written
certication of your installers qualications can be required.
It is advised that all doors and drawers are removed prior to
tting to avoid unnecessary damage occurring.
Ensure the room is well heated and ventilated.
It is recommended that walls are fully tiled before furniture
and accessory installation. This ensures that the product is
installed at to the tile face and allows product to be easily
removed if required in the future.
INSTALLATION INSTRUCTIONS
These instructions have been prepared for your guidance,
you must exercise due care at all times.
Please note that some units are heavy. Always take care
when lifting, and follow health and safety guidelines. It is re-
commended that 2 people carry out the installation of larger
basin/vanity units.
Handle glass with care. Although the glass supplied is tou-
ghened safety glass (to BS6206), impacts can damage both
the glass and the furniture.
Warning! Please check for any hidden pipes or electrical ca-
bles before drilling holes in the oor or walls.
When using power tools always follow the manufacturer’s
user instructions.
Care & Cleaning
NEVER use products containing bleach, cleaners of a gritty
or abrasive nature or so called “glass and mirror” cleaning
products. Use a well wrung chamois leather or micro bre
cloth for furniture carcasses.
Resin wash basins should only be cleaned with a mild deter-
gent or warm soapy water; in hard water areas a good quality
lime-scale remover can be applied.
Clean mirrors only with a micro bre cloth.
If any maintenance is required then it must be carried out by
a qualied Plumber.
1

Tower Unit Installation
Step 1
Plan unit position
We suggest positioning the
tower unit so it is level with
any other unit that has been
installed.
Step 2
Remove the TOP door before installation. a: Lift the tab
(shown) on both hinges, to release. b: Pull door back.
Step 3
a: Use the measurements opposite, to
position the ‘wall brackets.
b: Mark the xing hole positions onto the
wall.
Drill Ø 8mm holes, insert the wall plugs
and the ‘wall brackets’.
c: The ‘wall brackets’ should protrude
from the wall by 5-7mm.
Position the unit on the wall brackets.
Step 4
a: Check the unit is level. If leve-
ling is required: inside the unit,
use a screwdriver to adjust the
hanging position.
d: To lift or lower the unit adjust the
screw shown.
c: To move the unit closer or fur-
ther from the wall adjust the screw
shown.
Step 5
Once the unit is correctly
levelled, carefully apply a
bead silicone sealant to
the join between the unit
and wall, on all four sides.
Leave silicone, 24 hours
to dry.
Step 6
Note: Only re-t the door now if
not changing the opening side.
Re-t door:
a: Reposition both hinges onto the
hinge plates.
b: Push the front until the hinge
‘clicks’ into position.
If changing the door opening
side or the door alignment
needs adjusting, follow the ins-
tructions on the next page.
2

a: Lift tab (shown) on both hinges, to release.
b: Pull door back. c: Lift the hinge plate tabs. d: Remove
the hinge plates. e: Re-t hinge plates on the opposite
side. f: Fold hinge plate tabs back.
g: Rotate the top door ‘1’ as shown.
h: Reposition both hinges onto the hinge plates.
i: Push the front until the hinge ‘clicks’ into position.
Door 1: changing door opening side
3

a: Lift tab (shown) on both hinges, to release.
b: Pull door back.
c: Lift the hinge plate tabs.
d: Remove the hinge plates.
e: Re-t hinge plates on the opposite side.
f: Fold hinge plate tabs back.
g: Lift tab hinges, to release.
h: Remove the plugs.
i: Re-t hinges on the opposite side.
j: Re-t plugs on the opposite side.
k: Reposition both hinges onto the hinge plates.
l: Push the front until the hinge ‘clicks’ into position.
Door 2: changing door opening side
g
g: h:
i: j:
k: l:
For any further information please contact
Crosswater on: 0345 873 8840
Or visit our web-site at:
www.crosswater.co.uk
The manufacturer reserves the right to make technical
modications without prior notice.
Important information
Before installing wooden bathroom products into a new
property, extension or recently plastered room we strongly
advise the building/room is completely dry, well ventilated
and adequately heated.
Door 1, 2: Hinge adjustment
To move door up or down: Turn screw
shown to move door up or down to suit
To move door in or out: Turn screw
shown to move door in or out to suit
To move door left or right: Turn screws
shown to move door left or right to suit.
