Crown CE-1000A Manual

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
E.C.N REV DATE DWN PE CM
05N0216 B R605,R609, AND R610 WERE OPEN 04/25/05 TLM BC DSV
UNLESS OTHERWISE SPECIFIED, THIS PRINTED WIRING ASSEMBLY SHALL MEET
THE SPECIFICATION DESCRIBED IN IPC-A-610C CLASS 2 STANDARDS.
NOTES:
1. PRINTED WIRING BOARD PART NUMBER 137555-3.
2. SEE 137556-3_B.TIF FOR SCHEMATIC AND BOARD MAP
3. ALL LEADS SHALL BE TRIMMED TO 0.093" OR LESS.
4. POSITION COMPONENTS AS SHOWN ON COMPONENT MAP.
5. THE PRINTED WIRING ASSEMBLY PART NUMBER FOR THIS ASSEMBLY SHALL
BE MARKED ON THE PRINTED WIRING BOARD AND SHALL BE PERMANENT.
6. MAP LOCATIONS DENOTED BY AN ASTERISK (*), INDICATE COMPONENTS
MOUNTED ON THE BOTTOM SIDE OF THE PRINTED WIRING BOARD.
7. REMOVE SOLDER OR PREVENT SOLDER FROM ACCUMULATING IN HOLE.
8. CONNECT THE WIRES THAT COME FROM HS2 AND HS4 TO WP4 AND WP5 RESPECTIVELY.
9. INSTALLATION OF U106 AND U206 IS AS FOLLOWS:
A. BEND TRANSISTOR AT 90 DEG. FLAT SIDE DOWN
B. PLACE TRANSISTOR INTO THE PWB AS SHOWN ON THE COMPONENT MAP DETAIL B
C. MIX OUTPUT EPOXY (125482-1) AND ACCELERATOR (125483-1) TOGETHER. APPLY THE MIXTURE
TO THE TRANSISTOR AND HEATSINK. THE MIXTURE MUST FILL THE HEATSINK HOLE AND THE
LEADS OF THE DEVICE, ESPECIALLY THE CENTER LEAD. (NOTE: NO VISIBLE AIR GAPS
AROUND THE TRANSISTOR AND THE TRANSISTOR LEADS CANNOT TOUCH THE HEATSINK)
D. HOLD THE TRANSISTOR AGAINST THE HEATSINK UNTIL EPOXY SETS-UP.
10. TORQUE 6-32 HEX NUTS (CPN 132491-1) AS FOLLOWS:
A. PRE-WAVE TORQUE OF 13-15 INCH LBS.
11. INSTALL J3 CONNECTOR AS SHOWN ON COMPONENT MAP.
12. INSTALL SHUNT (C 6419-3) OVER ONE PIN ONLY OF P1 AND P2 AS SHOWN ON COMPONENT MAP
13. APPLY CLEAR SILICONE (126825-1) OVER Q104 AND HS2, AND Q204 AND HS4 TO FORM A
SILICONE CAP OVER THE COMPONENTS.
14. ON FASTON TABS, CPN 101031-1, THE COMPONENT SIDE MUST HAVE A MINIMUM OF 50% OF
THE ORIGINAL LAND COVERED WITH WETTED SOLDER. THIS IS IN ADDITION TO THE IPC-A-610
REQUIREMENTS.
DWN KLW 01/28/05 PE BC 01/28/05 CM DSV 02/02/05 DIST. K
REVISION HISTOR
Y
DESCRIPTION
INITIAL RELEASE DERIVED FROM 137556-2 REV 1 WITH THE
FOLLOWING CHANGES. DELETED C27, HW37, HW38, R278,
AND W4. ADDED D132, D133, D232, D233, S2, U1X, AND U2X.
C1 WAS A11427-102K2. C221 WAS C10196-1. D114, D115,
D214, AND D215 WERE 137615-1. J7 WAS 101572-1. P3 AND
P4 WERE 130940-1. PWB1 WAS 137555-2. R1 WAS A11368-
10011. R138 AND R238 WERE A11371-1213. R19 WAS A11371-
3313. R274 WAS A11368-60432. R605, R609, AND R610 WERE
A11371-1501. TP15, TP38, AND TP39 WERE 138063-1.
A 01/28/05 KLW BC DSV
UNCONTROLLED
UNLESS OTHERWISE MARKED IN RED INK BY CM AS A CONTROLLED COPY, COPIES OF THESE DOCUMENTS
INCLUDING ASSOCIATED ELECTRONIC REPRODUCTIONS ARE FOR REFERENCE ONLY
THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF CROWN INTERNATIONAL, INC. AND SHALL NOT BE
REPRODUCED, COPIED, OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES
WITHOUT PERMISSION.
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 1 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
REF. DES. CPN DESCRIPTION MAP LOC.
C1 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R F 9*
C2 A10434-473JD .047UF 250VDC 5% MET POLY T/A G 10
C3 C 7377-2 .68UF 250V RFI CAP D 7
C4 C 4477-3 470 UF 35V VERT H 10
C5 C 4477-3 470 UF 35V VERT H 10
C6 OPEN H 10*
C7 OPEN H 10*
C8 OPEN C 7
C10 136803-1 CAPACITOR, 8200MF 110V 4TERM B 10
C11 136803-1 CAPACITOR, 8200MF 110V 4TERM C 9
C12 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R I 9*
C20 OPEN B 10
C21 OPEN C 9
C22 C10515-2 .47 UF 16V 20% X7R MLC 1206 O 9*
C24 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R O 10*
C25 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R O 9*
C28 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R I 9*
C29 C10196-1 2.2UF 50V 20% LOW LEAK CAP I 9
C30 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R I 9
C31 C 4477-3 470 UF 35V VERT J 10
C100 C10515-2 .47 UF 16V 20% X7R MLC 1206 N 9*
C101 C10515-2 .47 UF 16V 20% X7R MLC 1206 M 9
C102 C10515-2 .47 UF 16V 20% X7R MLC 1206 N 9
C103 102467-1 22UF 25V 20% RADIAL T/R M 9
C104 102438-101K2 100PF 200V NPO 0805 T/R M 9*
C105 126551-1 100UF 25V ELCAP SMD L 9
C106 102438-560K2 56PF 200V 10% NPO 0805 T/R M 9*
C107 A11369-270K2 27PF 50V 10% NPO 0805 T/R M 9*
C108 102438-820K2 82PF 200V 10% NPO 0805 T/R L 10*
C109 A11427-103K2 .01 UF 50V 10% X7R MLC 0805 I 6*
C110 A11369-471K2 470PF 50V 10% NPO 0805 T/R N 7*
C111 A11427-103K2 .01 UF 50V 10% X7R MLC 0805 N 8*
C112 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R O 7*
C113 127299-1 47UF 6.3V 20% NP LYTIC SMT T/R N 8
C114 127299-1 47UF 6.3V 20% NP LYTIC SMT T/R N 8
C115 A11427-103K2 .01 UF 50V 10% X7R MLC 0805 N 8*
C116 A11427-472K2 4700PF 50V 10% X7R 0805 T/R N 7*
C117 A11427-272K2 2700PF 50V 10% X7R 0805 T/R I 8*
C118 A10434-104JD .1UF 250V 5% MTL POLY FILM T/A J 8
C119 A11427-472K2 4700PF 50V 10% X7R 0805 T/R I 8*
C120 OPEN I 7*
C121 C10196-1 2.2UF 50V 20% LOW LEAK CAP G 8
C122 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R G 8*
C123 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R N 8*
C124 C10196-1 2.2UF 50V 20% LOW LEAK CAP L 9
C125 102438-101K2 100PF 200V NPO 0805 T/R I 7*
C126 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R N 10*
C127 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R N 9*
C128 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R M 10*
C129 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R M 9*
C130 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R H 8*
C131 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R H 7*
C132 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R G 7*
C133 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R G 8*
C135 102438-101K2 100PF 200V NPO 0805 T/R N 7*
C136 103210-1 2.2UF 160V RADIAL T/R J 7
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 2 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
C137 103210-1 2.2UF 160V RADIAL T/R I 7
C139 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R G 7*
C140 C 7091-9 CAP, .33UF 50V 20% 1206 Z5U M 9
C141 102438-101K2 100PF 200V NPO 0805 T/R N 10
C142 A11369-330J2 33 PF 50V 5% NPO MLC 0805 N 10
C143 A11427-103K5 0.01UF 50V 10% X7R SMD 1206 N 9*
C144 C10515-2 .47 UF 16V 20% X7R MLC 1206 G 8*
C145 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R O 8*
C146 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R L 8*
C147 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R M 8*
C148 103210-1 2.2UF 160V RADIAL T/R M 8
C200 C10515-2 .47 UF 16V 20% X7R MLC 1206 K 9*
C201 C10515-2 .47 UF 16V 20% X7R MLC 1206 K 9
C202 C10515-2 .47 UF 16V 20% X7R MLC 1206 K 9
C203 102467-1 22UF 25V 20% RADIAL T/R K 9
C204 102438-101K2 100PF 200V NPO 0805 T/R K 9*
C205 126551-1 100UF 25V ELCAP SMD J 9
C206 102438-560K2 56PF 200V 10% NPO 0805 T/R J 9*
C207 A11369-270K2 27PF 50V 10% NPO 0805 T/R J 9*
C208 102438-820K2 82PF 200V 10% NPO 0805 T/R J 10*
C209 A11427-103K2 .01 UF 50V 10% X7R MLC 0805 I 4*
C210 A11369-471K2 470PF 50V 10% NPO 0805 T/R K 7*
C211 A11427-103K2 .01 UF 50V 10% X7R MLC 0805 K 8*
C212 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R L 8*
C213 127299-1 47UF 6.3V 20% NP LYTIC SMT T/R K 8
C214 127299-1 47UF 6.3V 20% NP LYTIC SMT T/R K 8
C215 A11427-103K2 .01 UF 50V 10% X7R MLC 0805 K 8*
C216 A11427-472K2 4700PF 50V 10% X7R 0805 T/R K 2*
C217 A11427-272K2 2700PF 50V 10% X7R 0805 T/R E 1*
C218 A10434-104JD .1UF 250V 5% MTL POLY FILM T/A G 9
C219 A11427-472K2 4700PF 50V 10% X7R 0805 T/R E 1*
C220 OPEN E 2*
C221 OPEN E 8
C222 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R E 8*
C223 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R K 8*
C224 C10196-1 2.2UF 50V 20% LOW LEAK CAP J 9
C225 102438-101K2 100PF 200V NPO 0805 T/R E 2*
C226 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R L 10*
C227 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R K 9*
C228 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R J 10*
C229 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R J 9*
C230 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R F 8*
C231 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R F 7*
C232 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R E 7*
C233 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R E 8*
C235 102438-101K2 100PF 200V NPO 0805 T/R J 2*
C236 103210-1 2.2UF 160V RADIAL T/R J 2
C237 103210-1 2.2UF 160V RADIAL T/R I 2
C239 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R E 7*
C240 C 7091-9 CAP, .33UF 50V 20% 1206 Z5U J 9
C241 102438-101K2 100PF 200V NPO 0805 T/R L 10
C242 A11369-330J2 33 PF 50V 5% NPO MLC 0805 K 10
C243 A11427-103K5 0.01UF 50V 10% X7R SMD 1206 K 10*
C244 C10515-2 .47 UF 16V 20% X7R MLC 1206 E 8*
C245 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R L 8*
C248 103210-1 2.2UF 160V RADIAL T/R K 2
C500 A11369-120K2 12PF 50V 10% NPO 0805 T/R B 2
C501 A11369-120K2 12PF 50V 10% NPO 0805 T/R B 3
C502 A11369-120K2 12PF 50V 10% NPO 0805 T/R B 2
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 3 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
C503 102467-1 22UF 25V 20% RADIAL T/R C 2
C504 102438-221K2 220PF 200V 10% NPO 0805 T/R B 2
C505 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R B 2
C506 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R B 2
C509 OPEN D 2
C510 A11427-103K2 .01 UF 50V 10% X7R MLC 0805 C 1*
C600 A11369-120K2 12PF 50V 10% NPO 0805 T/R B 2
C601 A11369-120K2 12PF 50V 10% NPO 0805 T/R B 2
C602 A11369-120K2 12PF 50V 10% NPO 0805 T/R B 2
C603 102467-1 22UF 25V 20% RADIAL T/R C 2
C604 102438-221K2 220PF 200V 10% NPO 0805 T/R B 2
C605 A11427-104K2 .1UF 50V CHIP CAP 10% 0805 X7R B 1
C609 OPEN C 2
C610 A11427-103K2 .01 UF 50V 10% X7R MLC 0805 C 3*
D1 125594-1 DIODE, RECTIFIER 400V 1A SMB G 10
D2 125594-1 DIODE, RECTIFIER 400V 1A SMB G 10
D3 125594-1 DIODE, RECTIFIER 400V 1A SMB G 10
D4 125594-1 DIODE, RECTIFIER 400V 1A SMB G 10
D5 125594-1 DIODE, RECTIFIER 400V 1A SMB F 9
D6 125594-1 DIODE, RECTIFIER 400V 1A SMB F 9
D7 C10370-2 DIODE, ZENER 10V MMBZ5240BL I 9
D9 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT I 9*
D101 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT N 9*
D102 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT N 9*
D103 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT M 9*
D104 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT M 9*
D105 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT L 10*
D106 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT N 8*
D107 131648-1 DIODE, ZENER 500MW 16V SOD 123 M 7
D108 126549-1 DIODE,30V 200MA SCHOTTKY SOT23 N 8*
D109 131648-1 DIODE, ZENER 500MW 16V SOD 123 M 7
D110 126549-1 DIODE,30V 200MA SCHOTTKY SOT23 N 8*
D111 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT N 8*
D112 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT O 8*
D113 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT O 8*
D114 C10422-1 DIODE, 3A 400V 1N5404 AXIAL J 6
D115 C10422-1 DIODE, 3A 400V 1N5404 AXIAL J 5
D117 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT N 10*
D118 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT N 10*
D119 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT I 9*
D120 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT I 9*
D121 OPEN L 9*
D122 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT M 10*
D123 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT G 9*
D124 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT G 7*
D125 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT H 7*
D126 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT N 8
D127 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT N 8
D128 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT H 8*
D129 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT G 7*
D130 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT M 9*
D131 OPEN N 8
D132 133264-1 DIODE, 250V SWITCH MINIMELF N 7
D133 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT N 7
D201 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT L 9*
D202 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT K 9*
D203 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT J 9*
D204 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT K 9*
D205 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT J 10*
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 4 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
D206 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT K 8*
D207 131648-1 DIODE, ZENER 500MW 16V SOD 123 K 1
D208 126549-1 DIODE,30V 200MA SCHOTTKY SOT23 K 8*
D209 131648-1 DIODE, ZENER 500MW 16V SOD 123 K 1
D210 126549-1 DIODE,30V 200MA SCHOTTKY SOT23 K 8*
D211 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT K 8*
D212 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT L 8*
D213 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT L 8*
D214 C10422-1 DIODE, 3A 400V 1N5404 AXIAL J 3
D215 C10422-1 DIODE, 3A 400V 1N5404 AXIAL J 3
D217 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT K 10*
D218 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT L 10*
D221 OPEN J 9*
D222 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT K 10*
D223 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT E 9*
D224 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT E 7*
D225 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT F 7*
D226 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT K 8
D227 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT K 8
D229 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT E 7*
D230 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT K 9
D232 133264-1 DIODE, 250V SWITCH MINIMELF K 8
D233 C 9283-0 DIODE, MMBD4148/914 SOT-23 SMT K 8
E1 102476-1 LED, SMT R/A GREEN I 1
E100 102477-1 LED, SMT R/A RED K 1
E101 102476-1 LED, SMT R/A GREEN J 1
E102 102477-1 LED, SMT R/A RED K 1
E200 102477-1 LED, SMT R/A RED M 1
E201 102476-1 LED, SMT R/A GREEN M 1
E202 102477-1 LED, SMT R/A RED N 1
F1 134732-1 FUSE, 4A FAST 125V SMT G 10
F2 134732-1 FUSE, 4A FAST 125V SMT G 10
HS1 102606-6 HEATSINK, CE1000 J 5
HS2 102606-6 HEATSINK, CE1000 D 5
HS3 102606-7 HEATSINK, CE1000 PC J 2
HS4 102606-7 HEATSINK, CE1000 PC D 2
HW1 102608-1 SPACER, 6 X .187 LONG AL D 6
HW2 102608-1 SPACER, 6 X .187 LONG AL I 7
HW3 102608-1 SPACER, 6 X .187 LONG AL J 6
HW4 102608-1 SPACER, 6 X .187 LONG AL O 7
HW5 102608-1 SPACER, 6 X .187 LONG AL D 3
HW6 102608-1 SPACER, 6 X .187 LONG AL I 4
HW7 102608-1 SPACER, 6 X .187 LONG AL J 3
HW8 102608-1 SPACER, 6 X .187 LONG AL O 4
HW9 A10020-7 6-32 X .625 PCB CAPTIVE STUD D 6
HW10 A10020-7 6-32 X .625 PCB CAPTIVE STUD I 7
HW11 A10020-7 6-32 X .625 PCB CAPTIVE STUD D 3
HW12 A10020-7 6-32 X .625 PCB CAPTIVE STUD I 4
HW13 A10020-7 6-32 X .625 PCB CAPTIVE STUD J 6
HW14 A10020-7 6-32 X .625 PCB CAPTIVE STUD O 7
HW15 A10020-7 6-32 X .625 PCB CAPTIVE STUD J 3
HW16 A10020-7 6-32 X .625 PCB CAPTIVE STUD O 4
HW17 132491-1 NUT, 6-32 HEX NYLON LOCK D 6
HW18 132491-1 NUT, 6-32 HEX NYLON LOCK I 7
HW19 132491-1 NUT, 6-32 HEX NYLON LOCK J 6
HW20 132491-1 NUT, 6-32 HEX NYLON LOCK O 7
HW21 132491-1 NUT, 6-32 HEX NYLON LOCK D 3
HW22 132491-1 NUT, 6-32 HEX NYLON LOCK I 4
HW23 132491-1 NUT, 6-32 HEX NYLON LOCK J 3
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 5 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
HW24 132491-1 NUT, 6-32 HEX NYLON LOCK O 4
HW25 102579-1 STAND, 1/4 RD SWAGE AL B 1
HW26 102579-1 STAND, 1/4 RD SWAGE AL B 3
HW27 101016-1 LBL, BARCODE C 4
HW30 101016-1 LBL, BARCODE J 8
HW31 101016-1 LBL, BARCODE B 3
HW32 103180-1 BUMPER, 0.4" TALL BLK W/ADH B 9*
HW33 103180-1 BUMPER, 0.4" TALL BLK W/ADH F 5*
HW34 103180-1 BUMPER, 0.4" TALL BLK W/ADH L 5*
HW35 C 6419-3 SHUNT, .025" SQ POST 2 POS K 10
HW36 C 6419-3 SHUNT, .025" SQ POST 2 POS M 10
HW37 OPEN L 10
HW38 OPEN L 10
HW39 136319-1 WIRE,18AWG BLK2.7 W/6RX.25FAST D 6
HW40 136319-1 WIRE,18AWG BLK2.7 W/6RX.25FAST D 3
HW41 102577-1 ISOLATOR, TO-3 0.16 GOLD C/W E 4
HW42 102577-1 ISOLATOR, TO-3 0.16 GOLD C/W E 6
HW43 126017-2 SHLDR WSHR, #4 GLASS/NYLON RED D 3
HW44 126017-2 SHLDR WSHR, #4 GLASS/NYLON RED E 4
HW45 126017-2 SHLDR WSHR, #4 GLASS/NYLON RED D 6
HW46 126017-2 SHLDR WSHR, #4 GLASS/NYLON RED E 7
HW47 103233-1 SEMS,M3X10 TFS TORX-15 PNHD BZ N 7
HW48 103233-1 SEMS,M3X10 TFS TORX-15 PNHD BZ I 7
HW49 103233-1 SEMS,M3X10 TFS TORX-15 PNHD BZ J 2
HW50 103233-1 SEMS,M3X10 TFS TORX-15 PNHD BZ E 2
HW51 126785-1 4-40X3/8 #6PNHD T10 SEM STL Z J 6
HW52 126785-1 4-40X3/8 #6PNHD T10 SEM STL Z K 7
HW53 126785-1 4-40X3/8 #6PNHD T10 SEM STL Z D 6
HW54 126785-1 4-40X3/8 #6PNHD T10 SEM STL Z E 7
HW55 126785-1 4-40X3/8 #6PNHD T10 SEM STL Z J 3
HW56 126785-1 4-40X3/8 #6PNHD T10 SEM STL Z K 4
HW57 126785-1 4-40X3/8 #6PNHD T10 SEM STL Z D 3
HW58 126785-1 4-40X3/8 #6PNHD T10 SEM STL Z E 4
HW59 102719-1 6-32X.312 TORX PAN HD TFS K 5
HW60 102719-1 6-32X.312 TORX PAN HD TFS L 6
HW61 102719-1 6-32X.312 TORX PAN HD TFS M 6
HW62 102719-1 6-32X.312 TORX PAN HD TFS N 7
HW63 102719-1 6-32X.312 TORX PAN HD TFS M 5
HW64 102719-1 6-32X.312 TORX PAN HD TFS O 6
HW65 102719-1 6-32X.312 TORX PAN HD TFS E 5
HW66 102719-1 6-32X.312 TORX PAN HD TFS F 6
HW67 102719-1 6-32X.312 TORX PAN HD TFS G 6
HW68 102719-1 6-32X.312 TORX PAN HD TFS H 7
HW69 102719-1 6-32X.312 TORX PAN HD TFS H 5
HW70 102719-1 6-32X.312 TORX PAN HD TFS I 6
HW71 102719-1 6-32X.312 TORX PAN HD TFS K 3
HW72 102719-1 6-32X.312 TORX PAN HD TFS L 3
HW73 102719-1 6-32X.312 TORX PAN HD TFS M 3
HW74 102719-1 6-32X.312 TORX PAN HD TFS N 4
HW75 102719-1 6-32X.312 TORX PAN HD TFS M 3
HW76 102719-1 6-32X.312 TORX PAN HD TFS O 3
HW77 102719-1 6-32X.312 TORX PAN HD TFS E 3
HW78 102719-1 6-32X.312 TORX PAN HD TFS F 3
HW79 102719-1 6-32X.312 TORX PAN HD TFS G 3
HW80 102719-1 6-32X.312 TORX PAN HD TFS H 4
HW81 102719-1 6-32X.312 TORX PAN HD TFS H 3
HW82 102719-1 6-32X.312 TORX PAN HD TFS I 3
HW83 OPEN K 6
HW84 OPEN L 7
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 6 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
HW85 OPEN L 5
HW86 OPEN M 6
HW87 OPEN K 3
HW88 OPEN L 4
HW89 OPEN L 3
HW90 OPEN M 3
HW91 OPEN F 6
HW92 OPEN G 7
HW93 OPEN F 5
HW94 OPEN H 6
HW95 OPEN F 3
HW96 OPEN G 4
HW97 OPEN F 3
HW98 OPEN H 3
J1 OPEN O 10
J2 101573-1 HDR, 4 POS .1 CTR MTA SHRD G 10
J3 102472-3 CABLE, 12POS 7INCH FLEX W/CONN M 8
J4 101573-1 HDR, 4 POS .1 CTR MTA SHRD J 10
J5 101993-1 JACK, 6P4 COND MODULAR R/A N 10
J6 101571-1 HDR, 2 POS .1 CTR MTA SHRD F 9
J7 OPEN L 8
J100 102473-1 SPEAKON, 4 POLE PCB HORZ D 10
J200 102473-1 SPEAKON, 4 POLE PCB HORZ F 10
J500 126929-1 TRS/XLR, 1/4" COMBO PCB VERT C 3
J500X OPEN C 3
J502 102471-2 HDR, 12POS .1CTR SGL ROW C 2
J600 126929-1 TRS/XLR, 1/4" COMBO PCB VERT C 1
J600X OPEN C 1
K1 103198-1 RELAY 30A 110VDC T9A SEALED CE D 5
K100 126317-1 REL, 30A 24V SPST PCB W/FASTON G 9
K200 126317-1 REL, 30A 24V SPST PCB W/FASTON E 9
L100 137717-1 IDCTR, 470UH PM75 10% SMD T/R O 8
L101 137717-1 IDCTR, 470UH PM75 10% SMD T/R H 8
L102 102470-1 INDUCTOR, 2.75UH 11A RADIAL H 8
L200 137717-1 IDCTR, 470UH PM75 10% SMD T/R J 1
L201 137717-1 IDCTR, 470UH PM75 10% SMD T/R E 1
L202 102470-1 INDUCTOR, 2.75UH 11A RADIAL F 8
P1 C 9202-0 2 PIN SGL ROW VERT GOLD HDR M 10
P2 C 9202-0 2 PIN SGL ROW VERT GOLD HDR K 10
P3 OPEN L 10
P4 OPEN L 10
P5 OPEN M 8
P6 OPEN L 1
PWB1 137555-3 PWB, CE PLATFORM MAIN A 1
Q1 102479-1 PWR NPN DARLINGTON 100V 2A I 10
Q2 102479-1 PWR NPN DARLINGTON 100V 2A I 10
Q3 102479-1 PWR NPN DARLINGTON 100V 2A I 10
Q4 137218-1 SCR, 12A MCR12DSN DPAK 369A F 9
Q5 103193-1 SOT-223 PNP 300V 500MA 50MHZ O 9
Q100 C 7448-1 MMBT3904 CHIP NPN M 9*
Q101 C 7448-1 MMBT3904 CHIP NPN N 9*
Q102 C 9931-4 MMBT5087LT1 PNP XSISTOR SOT-23 N 9*
Q103 102483-1 PNP 300V 500MA SOT-23 L 10*
Q104 C 9252-5 2N3904 40V NPN TRANSISTOR T/A I 6
Q107 103192-1 SOT-223 NPN 300V 500MA 50MHZ N 8*
Q108 102481-1 NPN 25V LOW NOISE SOT-23 N 8*
Q109 C 9931-4 MMBT5087LT1 PNP XSISTOR SOT-23 N 8*
Q110 103192-1 SOT-223 NPN 300V 500MA 50MHZ N 7*
Q111 C 9931-4 MMBT5087LT1 PNP XSISTOR SOT-23 N 7*
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 7 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
Q112 103200-1 2SC5242 NPN 230V 15A 30MHZ N 7
Q114 102659-1 NPN, TO-3 MJ21194 PWR J 6
Q115 102659-1 NPN, TO-3 MJ21194 PWR K 6
Q116 OPEN L 6
Q117 OPEN M 6
Q118 102659-1 NPN, TO-3 MJ21194 PWR M 6
Q119 102659-1 NPN, TO-3 MJ21194 PWR N 6
Q120 103193-1 SOT-223 PNP 300V 500MA 50MHZ I 7*
Q121 103200-1 2SC5242 NPN 230V 15A 30MHZ I 7
Q123 102659-1 NPN, TO-3 MJ21194 PWR E 6
Q124 102659-1 NPN, TO-3 MJ21194 PWR F 6
Q125 OPEN F 6
Q126 OPEN G 6
Q127 102659-1 NPN, TO-3 MJ21194 PWR H 6
Q128 102659-1 NPN, TO-3 MJ21194 PWR I 6
Q129 C 7448-1 MMBT3904 CHIP NPN G 9*
Q133 102480-1 FET, N-CH 25V 50MA SOT-23 M 9*
Q200 C 7448-1 MMBT3904 CHIP NPN K 9*
Q201 C 7448-1 MMBT3904 CHIP NPN K 9*
Q202 C 9931-4 MMBT5087LT1 PNP XSISTOR SOT-23 L 9*
Q203 102483-1 PNP 300V 500MA SOT-23 J 10*
Q204 C 9252-5 2N3904 40V NPN TRANSISTOR T/A I 3
Q207 103192-1 SOT-223 NPN 300V 500MA 50MHZ K 8*
Q208 102481-1 NPN 25V LOW NOISE SOT-23 K 8*
Q209 C 9931-4 MMBT5087LT1 PNP XSISTOR SOT-23 K 8*
Q210 103192-1 SOT-223 NPN 300V 500MA 50MHZ J 2*
Q211 C 9931-4 MMBT5087LT1 PNP XSISTOR SOT-23 K 2*
Q212 103200-1 2SC5242 NPN 230V 15A 30MHZ J 2
Q214 102659-1 NPN, TO-3 MJ21194 PWR J 4
Q215 102659-1 NPN, TO-3 MJ21194 PWR K 3
Q216 OPEN L 4
Q217 OPEN M 3
Q218 102659-1 NPN, TO-3 MJ21194 PWR M 4
Q219 102659-1 NPN, TO-3 MJ21194 PWR N 3
Q220 103193-1 SOT-223 PNP 300V 500MA 50MHZ D 2*
Q221 103200-1 2SC5242 NPN 230V 15A 30MHZ E 2
Q223 102659-1 NPN, TO-3 MJ21194 PWR E 4
Q224 102659-1 NPN, TO-3 MJ21194 PWR F 3
Q225 OPEN F 4
Q226 OPEN G 3
Q227 102659-1 NPN, TO-3 MJ21194 PWR H 4
Q228 102659-1 NPN, TO-3 MJ21194 PWR I 3
Q229 C 7448-1 MMBT3904 CHIP NPN E 9*
Q233 102480-1 FET, N-CH 25V 50MA SOT-23 J 9*
R1 A11368-10021 10K 1/10W 1% SMD 0805 T/R F 9*
R2 A11368-10011 1.KOHM .1W 1% CHIP 0805 F 9*
R5 A11368-69811 6.98KOHM .1W 1% 0805 T/R D 8*
R6 A11368-93111 9.31K .1W 1% SMD 0805 T/R D 8*
R7 A11368-49902 499 OHM .125W 1% 1206 T/R N 10
R8 A11371-1022 1. KOHM .125W 5% CHIP RES T/R N 10*
R9 A11368-10021 10K 1/10W 1% SMD 0805 T/R I 9*
R10 A11368-20021 20.KOHM .1W 1% CHIP 0805 I 9*
R11 A11368-49921 49.9KOHM .1W 1% CHIP 0805 I 9
R14 A11371-R221 .22OHM .1W 5% O8O5 SMT I 10*
R15 A11371-R221 .22OHM .1W 5% O8O5 SMT I 10*
R16 A11368-49902 499 OHM .125W 1% 1206 T/R O 10*
R17 A11368-82511 8.25KOHM .1W 1% CHIP 0805 G 10*
R18 A11368-71511 7.15K 1/10W 1% SMD 0805 T/R D 8*
R19 A11371-6814 680 OHM .5W 5% 2010 T/R I 1*
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 8 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
R20 A11368-57621 57.6KOHM 0.1W 1% 0805 T/R J 9*
R21 A11368-10021 10K 1/10W 1% SMD 0805 T/R J 9*
R22 A11368-60432 604 KOHM .125W 1% MF CHIP I 9*
R23 A11368-10021 10K 1/10W 1% SMD 0805 T/R O 9
R24 A11368-82511 8.25KOHM .1W 1% CHIP 0805 O 9*
R25 A11368-10031 100.KOHM .1W 1% CHIP 0805 N 9*
R27 A11368-20021 20.KOHM .1W 1% CHIP 0805 L 9*
R28 A11371-7511 750 OHM .1W 5% 0805 T/R L 9*
R29 A11368-10021 10K 1/10W 1% SMD 0805 T/R N 9*
R30 A11368-10011 1.KOHM .1W 1% CHIP 0805 O 9*
R31 A11368-10021 10K 1/10W 1% SMD 0805 T/R O 9*
R33 A11371-R221 .22OHM .1W 5% O8O5 SMT I 10*
R100 102595-3 POT, 5K LIN 21 DNT 12MM HORIZ L 2
R101 A11368-10011 1.KOHM .1W 1% CHIP 0805 M 10*
R102 A11368-39231 392 KOHM .1W 1% 0805 T/R N 9*
R103 A11368-49901 499 OHM .1W 1% 0805 T/R N 9*
R104 A11368-10021 10K 1/10W 1% SMD 0805 T/R N 9*
R105 A11371-6814 680 OHM .5W 5% 2010 T/R J 1*
R106 A11368-10011 1.KOHM .1W 1% CHIP 0805 M 9*
R107 A11368-10021 10K 1/10W 1% SMD 0805 T/R M 10*
R108 A11368-10021 10K 1/10W 1% SMD 0805 T/R M 10*
R109 A11368-19122 19.1 KOHM .125W 1% CHIP RES M 9*
R110 A11368-10011 1.KOHM .1W 1% CHIP 0805 L 9*
R111 A11368-24911 2.49K 1/10W 1% SMD 0805 T/R M 9*
R112 A11368-10023 10.0KOHM .25W 1% 1210 T/R L 9*
R113 A11368-42211 4.22KOHM .1W 1% 0805 T/R L 10*
R114 A11368-12421 12.4K OHM 0.1W 1% 0805 T/R L 10*
R115 A11368-68121 68.1KOHM 0.1W 1% CHIP 0805 L 10*
R116 A11368-22601 226 OHM 0.1W 1% 0805 T/R M 9*
R117 A11371-3341 330 KOHM .1W 5% 0805 T/R M 9*
R118 A11368-68111 6.81K 0.10W 1% CHIP 0805 N 10
R119 A11371-3333 33 KOHM .25W 5% 1210 T/R M 9*
R120 A11368-90921 90.9K, 0.10W 1% MF 0805 M 9*
R121 A11368-10021 10K 1/10W 1% SMD 0805 T/R M 10
R122 A11368-15831 158KOHM .1W 1% 0805 T/R N 9*
R123 A11368-10031 100.KOHM .1W 1% CHIP 0805 N 9*
R124 A11368-15831 158KOHM .1W 1% 0805 T/R N 9*
R125 A11368-10031 100.KOHM .1W 1% CHIP 0805 N 9*
R126 A11368-49921 49.9KOHM .1W 1% CHIP 0805 M 9*
R127 A11371-6821 6.8KOHM .1W 5% CHIP 0805 N 9*
R128 A11371-6814 680 OHM .5W 5% 2010 T/R K 1*
R129 A11371-8211 820 OHM .1W 5% 0805 T/R N 7*
R130 A11368-10023 10.0KOHM .25W 1% 1210 T/R M 9*
R131 A11368-10031 100.KOHM .1W 1% CHIP 0805 M 9
R132 A11371-2223 2.2K 0.25W 5% 1210 T/R I 6*
R133 A11371-7511 750 OHM .1W 5% 0805 T/R I 7*
R134 C10613-5 1 KOHM TOP ADJUST TRIMMER T/R M 8
R135 A11368-10023 10.0KOHM .25W 1% 1210 T/R M 7*
R136 A11371-8201 82 OHM .1W 5% 0805 T/R N 7*
R137 A11368-49902 499 OHM .125W 1% 1206 T/R N 8*
R138 A11368-12103 RES, 121 OHM 0.25W 1% 1210 T/R N 8*
R139 A11368-16203 162 OHM 0.25W 1% 1210 T/R N 8*
R140 OPEN O 8*
R141 A11371-8211 820 OHM .1W 5% 0805 T/R O 8*
R142 125478-1 3.83KOHM 0.5W 1% 2010 T/R O 8*
R143 OPEN O 8*
R144 A11368-13003 130 OHM 0.25W 1% 1210 T/R N 8*
R145 A11368-16203 162 OHM 0.25W 1% 1210 T/R N 8*
R146 A11368-49R91 RES, 49.9 OHM 1% 0.1W SMT 0805 I 6*
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 9 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
R147 A11371-1011 100 OHM .1W 5% 0805 T/R N 7*
R148 A11371-1811 180 OHM .1W 5% 0805 T/R N 7*
R149 A11368-60432 604 KOHM .125W 1% MF CHIP N 9*
R150 A11371-5R63 5.6 OHM .25W 5% 1210 T/R N 7*
R151 A11368-20021 20.KOHM .1W 1% CHIP 0805 N 9*
R152 A11371-1R83 1.8 OHM 5% .25W 1210 K 6*
R153 A11371-1R83 1.8 OHM 5% .25W 1210 K 6*
R154 OPEN L 6*
R155 OPEN M 6*
R156 A11371-1R83 1.8 OHM 5% .25W 1210 M 6*
R157 A11371-1R83 1.8 OHM 5% .25W 1210 N 6*
R158 A11371-5R65 5.6 OHM 1W 5% 2512 T/R I 8
R159 A11371-1R83 1.8 OHM 5% .25W 1210 D 6*
R160 A11371-1501 15 OHM .1W 5% 0805 T/R I 8*
R161 A11368-10023 10.0KOHM .25W 1% 1210 T/R M 7*
R162 A11371-4701 RES, 47 OHM .1W 5% CHIP 0805 H 7*
R163 A11371-1811 180 OHM .1W 5% 0805 T/R I 7*
R164 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX M 9
R165 A11371-5R63 5.6 OHM .25W 5% 1210 T/R I 5*
R166 A11371-0R01 RES, 0 OHM 0805 50 MILOHM MAX L 8*
R167 A11371-1R83 1.8 OHM 5% .25W 1210 F 6*
R168 A11371-1R83 1.8 OHM 5% .25W 1210 F 6*
R169 OPEN G 6*
R170 OPEN G 6*
R171 A11371-1R83 1.8 OHM 5% .25W 1210 H 6*
R172 A11371-1R83 1.8 OHM 5% .25W 1210 H 6*
R173 A11368-10023 10.0KOHM .25W 1% 1210 T/R M 7*
R174 A11368-60432 604 KOHM .125W 1% MF CHIP H 8*
R175 A11368-51111 5.11KOHM .1W 1% 0805 T/R G 8*
R176 A11368-10021 10K 1/10W 1% SMD 0805 T/R H 8*
R177 A11368-10023 10.0KOHM .25W 1% 1210 T/R H 8*
R178 A11368-82521 82.5K 0.10W 1%CHIP 0805 N 9*
R179 A11368-10031 100.KOHM .1W 1% CHIP 0805 G 7*
R180 A11368-39231 392 KOHM .1W 1% 0805 T/R G 8*
R181 A11371-6814 680 OHM .5W 5% 2010 T/R K 1*
R182 A11368-10021 10K 1/10W 1% SMD 0805 T/R G 8*
R183 A11368-10031 100.KOHM .1W 1% CHIP 0805 G 8*
R184 A11371-5R65 5.6 OHM 1W 5% 2512 T/R I 8
R185 OPEN G 7*
R186 A11368-10031 100.KOHM .1W 1% CHIP 0805 N 10*
R187 A11368-15831 158KOHM .1W 1% 0805 T/R N 10*
R188 A11368-15831 158KOHM .1W 1% 0805 T/R N 10*
R189 A11368-10031 100.KOHM .1W 1% CHIP 0805 N 10*
R190 A11368-57621 57.6KOHM 0.1W 1% 0805 T/R O 6*
R191 A11368-22601 226 OHM 0.1W 1% 0805 T/R N 6*
R192 A11368-60432 604 KOHM .125W 1% MF CHIP L 9*
R193 A11368-10021 10K 1/10W 1% SMD 0805 T/R N 9*
R194 A11368-10023 10.0KOHM .25W 1% 1210 T/R M 7*
R195 A11368-10031 100.KOHM .1W 1% CHIP 0805 G 7*
R196 A11368-10021 10K 1/10W 1% SMD 0805 T/R M 9*
R197 A11368-51111 5.11KOHM .1W 1% 0805 T/R M 10
R198 A11368-31623 31.6K OHM .25W 1% 1210 N 8
R199 A11368-49901 499 OHM .1W 1% 0805 T/R N 8*
R200 102595-3 POT, 5K LIN 21 DNT 12MM HORIZ N 2
R201 A11368-10011 1.KOHM .1W 1% CHIP 0805 K 10*
R202 A11368-39231 392 KOHM .1W 1% 0805 T/R L 9*
R203 A11368-49901 499 OHM .1W 1% 0805 T/R L 9*
R204 A11368-10021 10K 1/10W 1% SMD 0805 T/R L 9*
R205 A11371-6814 680 OHM .5W 5% 2010 T/R M 1*
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 10 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
R206 A11368-10011 1.KOHM .1W 1% CHIP 0805 K 9*
R208 A11368-10023 10.0KOHM .25W 1% 1210 T/R M 7*
R209 A11368-19122 19.1 KOHM .125W 1% CHIP RES K 9*
R210 A11368-10011 1.KOHM .1W 1% CHIP 0805 J 9*
R211 A11368-24911 2.49K 1/10W 1% SMD 0805 T/R J 9*
R212 A11368-10023 10.0KOHM .25W 1% 1210 T/R J 9*
R213 A11368-42211 4.22KOHM .1W 1% 0805 T/R J 10*
R214 A11368-12421 12.4K OHM 0.1W 1% 0805 T/R J 10*
R215 A11368-68121 68.1KOHM 0.1W 1% CHIP 0805 J 10*
R216 A11368-22601 226 OHM 0.1W 1% 0805 T/R K 9*
R217 A11371-3341 330 KOHM .1W 5% 0805 T/R K 9*
R218 A11368-68111 6.81K 0.10W 1% CHIP 0805 K 10
R219 A11371-3333 33 KOHM .25W 5% 1210 T/R K 9*
R220 A11368-90921 90.9K, 0.10W 1% MF 0805 K 9*
R221 A11368-10021 10K 1/10W 1% SMD 0805 T/R K 10
R222 A11368-15831 158KOHM .1W 1% 0805 T/R L 9*
R223 A11368-10031 100.KOHM .1W 1% CHIP 0805 K 9*
R224 A11368-15831 158KOHM .1W 1% 0805 T/R K 9*
R225 A11368-10031 100.KOHM .1W 1% CHIP 0805 L 9*
R226 A11368-49921 49.9KOHM .1W 1% CHIP 0805 K 9*
R227 A11371-6821 6.8KOHM .1W 5% CHIP 0805 L 9*
R228 A11371-6814 680 OHM .5W 5% 2010 T/R M 1*
R229 A11371-8211 820 OHM .1W 5% 0805 T/R K 7*
R230 A11368-10023 10.0KOHM .25W 1% 1210 T/R J 9*
R231 A11368-10031 100.KOHM .1W 1% CHIP 0805 J 9
R232 A11371-2223 2.2K 0.25W 5% 1210 T/R I 4*
R233 A11371-7511 750 OHM .1W 5% 0805 T/R I 4*
R234 C10613-5 1 KOHM TOP ADJUST TRIMMER T/R J 8
R235 A11368-10023 10.0KOHM .25W 1% 1210 T/R K 2*
R236 A11371-8201 82 OHM .1W 5% 0805 T/R K 7*
R237 A11368-49902 499 OHM .125W 1% 1206 T/R K 8*
R238 A11368-12103 RES, 121 OHM 0.25W 1% 1210 T/R L 8*
R239 A11368-16203 162 OHM 0.25W 1% 1210 T/R L 8*
R240 OPEN L 8*
R241 A11371-8211 820 OHM .1W 5% 0805 T/R L 8*
R242 125478-1 3.83KOHM 0.5W 1% 2010 T/R L 8*
R243 OPEN L 8*
R244 A11368-13003 130 OHM 0.25W 1% 1210 T/R L 8*
R245 A11368-16203 162 OHM 0.25W 1% 1210 T/R L 8*
R246 A11368-49R91 RES, 49.9 OHM 1% 0.1W SMT 0805 I 3*
R247 A11371-1011 100 OHM .1W 5% 0805 T/R K 2*
R248 A11371-1811 180 OHM .1W 5% 0805 T/R K 2*
R249 A11368-60432 604 KOHM .125W 1% MF CHIP L 9*
R250 A11371-5R63 5.6 OHM .25W 5% 1210 T/R J 3*
R251 A11368-20021 20.KOHM .1W 1% CHIP 0805 K 9*
R252 A11371-1R83 1.8 OHM 5% .25W 1210 K 4*
R253 A11371-1R83 1.8 OHM 5% .25W 1210 K 3*
R254 OPEN L 4*
R255 OPEN M 3*
R256 A11371-1R83 1.8 OHM 5% .25W 1210 N 4*
R257 A11371-1R83 1.8 OHM 5% .25W 1210 N 3*
R258 A11368-10023 10.0KOHM .25W 1% 1210 T/R K 2*
R259 A11371-1R83 1.8 OHM 5% .25W 1210 E 3*
R260 A11371-1501 15 OHM .1W 5% 0805 T/R E 1*
R261 A11368-10023 10.0KOHM .25W 1% 1210 T/R K 2*
R262 A11371-4701 RES, 47 OHM .1W 5% CHIP 0805 E 2*
R263 A11371-1811 180 OHM .1W 5% 0805 T/R E 2*
R265 A11371-5R63 5.6 OHM .25W 5% 1210 T/R E 2*
R267 A11371-1R83 1.8 OHM 5% .25W 1210 F 4*
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 11 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
R268 A11371-1R83 1.8 OHM 5% .25W 1210 F 3*
R269 OPEN G 4*
R270 OPEN G 3*
R271 A11371-1R83 1.8 OHM 5% .25W 1210 G 4*
R272 A11371-1R83 1.8 OHM 5% .25W 1210 H 3*
R273 A11368-10023 10.0KOHM .25W 1% 1210 T/R K 2*
R274 OPEN E 8*
R275 A11368-51111 5.11KOHM .1W 1% 0805 T/R E 8*
R276 A11368-10021 10K 1/10W 1% SMD 0805 T/R E 8*
R277 A11368-10023 10.0KOHM .25W 1% 1210 T/R F 8*
R279 A11368-10031 100.KOHM .1W 1% CHIP 0805 E 7*
R280 A11368-39231 392 KOHM .1W 1% 0805 T/R E 8*
R281 A11371-6814 680 OHM .5W 5% 2010 T/R M 1*
R282 A11368-10021 10K 1/10W 1% SMD 0805 T/R E 8*
R283 A11368-10031 100.KOHM .1W 1% CHIP 0805 E 8*
R286 A11368-10031 100.KOHM .1W 1% CHIP 0805 L 10*
R287 A11368-15831 158KOHM .1W 1% 0805 T/R K 10*
R288 A11368-15831 158KOHM .1W 1% 0805 T/R L 10*
R289 A11368-10031 100.KOHM .1W 1% CHIP 0805 L 10*
R290 A11368-57621 57.6KOHM 0.1W 1% 0805 T/R O 3*
R291 A11368-22601 226 OHM 0.1W 1% 0805 T/R N 3*
R292 A11368-60432 604 KOHM .125W 1% MF CHIP J 9*
R293 A11368-10021 10K 1/10W 1% SMD 0805 T/R L 9*
R294 A11368-10023 10.0KOHM .25W 1% 1210 T/R K 2*
R296 A11368-10021 10K 1/10W 1% SMD 0805 T/R K 9*
R297 A11368-51111 5.11KOHM .1W 1% 0805 T/R K 10
R298 A11368-31623 31.6K OHM .25W 1% 1210 K 8
R299 A11368-49901 499 OHM .1W 1% 0805 T/R K 8*
R300 A11371-1R83 1.8 OHM 5% .25W 1210 E 6*
R301 A11371-1R83 1.8 OHM 5% .25W 1210 K 6*
R302 A11371-1R83 1.8 OHM 5% .25W 1210 L 6*
R303 OPEN L 6*
R304 OPEN M 6*
R305 A11371-1R83 1.8 OHM 5% .25W 1210 M 6*
R306 A11371-1R83 1.8 OHM 5% .25W 1210 N 6*
R307 A11371-1R83 1.8 OHM 5% .25W 1210 F 6*
R308 A11371-1R83 1.8 OHM 5% .25W 1210 F 6*
R309 OPEN G 6*
R310 OPEN G 6*
R311 A11371-1R83 1.8 OHM 5% .25W 1210 H 6*
R312 A11371-1R83 1.8 OHM 5% .25W 1210 H 6*
R313 A11368-10021 10K 1/10W 1% SMD 0805 T/R H 7*
R314 A11371-3341 330 KOHM .1W 5% 0805 T/R H 7*
R315 A11368-51111 5.11KOHM .1W 1% 0805 T/R H 7*
R316 A11368-10011 1.KOHM .1W 1% CHIP 0805 M 10*
R317 A11368-31623 31.6K OHM .25W 1% 1210 N 8
R318 A11368-31623 31.6K OHM .25W 1% 1210 O 8
R319 OPEN M 10*
R320 A11371-1R83 1.8 OHM 5% .25W 1210 J 7*
R321 OPEN O 9
R322 A11371-1013 100 OHM .25W 5% 1210 SMT T/R L 9
R323 A11368-31623 31.6K OHM .25W 1% 1210 O 8
R324 A11371-1R83 1.8 OHM 5% .25W 1210 J 7*
R325 A11371-1R83 1.8 OHM 5% .25W 1210 J 6*
R326 A11371-1R83 1.8 OHM 5% .25W 1210 J 6*
R327 A11371-1R83 1.8 OHM 5% .25W 1210 K 7*
R328 A11371-1R83 1.8 OHM 5% .25W 1210 K 7*
R329 A11371-1R83 1.8 OHM 5% .25W 1210 K 6*
R330 A11371-1R83 1.8 OHM 5% .25W 1210 L 6*
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 12 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
R331 A11371-1R83 1.8 OHM 5% .25W 1210 K 6*
R332 A11371-1R83 1.8 OHM 5% .25W 1210 K 6*
R333 A11371-1R83 1.8 OHM 5% .25W 1210 K 6*
R334 A11371-1R83 1.8 OHM 5% .25W 1210 K 6*
R335 OPEN L 7*
R336 OPEN L 7*
R337 OPEN L 6*
R338 OPEN K 6*
R339 OPEN L 7*
R340 OPEN K 7*
R341 OPEN M 6*
R342 OPEN M 6*
R343 OPEN L 6*
R344 OPEN L 6*
R345 OPEN L 6*
R346 OPEN L 6*
R347 A11371-1R83 1.8 OHM 5% .25W 1210 M 7*
R348 A11371-1R83 1.8 OHM 5% .25W 1210 M 7*
R349 A11371-1R83 1.8 OHM 5% .25W 1210 M 7*
R350 A11371-1R83 1.8 OHM 5% .25W 1210 M 7*
R351 A11371-1R83 1.8 OHM 5% .25W 1210 M 6*
R352 A11371-1R83 1.8 OHM 5% .25W 1210 M 6*
R353 A11371-1R83 1.8 OHM 5% .25W 1210 N 6*
R354 A11371-1R83 1.8 OHM 5% .25W 1210 N 6*
R355 A11371-1R83 1.8 OHM 5% .25W 1210 N 6*
R356 A11371-1R83 1.8 OHM 5% .25W 1210 M 6*
R357 A11371-1R83 1.8 OHM 5% .25W 1210 N 6*
R358 A11371-1R83 1.8 OHM 5% .25W 1210 M 6*
R359 A11371-1R83 1.8 OHM 5% .25W 1210 D 6*
R360 A11371-1R83 1.8 OHM 5% .25W 1210 E 6*
R361 A11371-1R83 1.8 OHM 5% .25W 1210 E 7*
R362 A11371-1R83 1.8 OHM 5% .25W 1210 D 7*
R363 A11371-1R83 1.8 OHM 5% .25W 1210 E 7*
R364 A11371-1R83 1.8 OHM 5% .25W 1210 D 7*
R365 A11371-1R83 1.8 OHM 5% .25W 1210 E 6*
R366 A11371-1R83 1.8 OHM 5% .25W 1210 E 6*
R367 A11371-1R83 1.8 OHM 5% .25W 1210 E 7*
R368 A11371-1R83 1.8 OHM 5% .25W 1210 E 7*
R369 A11371-1R83 1.8 OHM 5% .25W 1210 F 7*
R370 A11371-1R83 1.8 OHM 5% .25W 1210 F 7*
R371 A11371-1R83 1.8 OHM 5% .25W 1210 F 6*
R372 A11371-1R83 1.8 OHM 5% .25W 1210 F 6*
R373 A11371-1R83 1.8 OHM 5% .25W 1210 E 6*
R374 A11371-1R83 1.8 OHM 5% .25W 1210 E 6*
R375 A11371-1R83 1.8 OHM 5% .25W 1210 E 6*
R376 A11371-1R83 1.8 OHM 5% .25W 1210 E 6*
R377 OPEN G 7*
R378 OPEN G 7*
R379 OPEN F 7*
R380 OPEN F 7*
R381 OPEN F 6*
R382 OPEN F 6*
R383 OPEN G 6*
R384 OPEN G 6*
R385 OPEN G 6*
R386 OPEN G 6*
R387 OPEN G 6*
R388 OPEN G 6*
R389 A11371-1R83 1.8 OHM 5% .25W 1210 H 7*
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 13 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
R390 A11371-1R83 1.8 OHM 5% .25W 1210 H 7*
R391 A11371-1R83 1.8 OHM 5% .25W 1210 H 7*
R392 A11371-1R83 1.8 OHM 5% .25W 1210 G 7*
R393 A11371-1R83 1.8 OHM 5% .25W 1210 G 6*
R394 A11371-1R83 1.8 OHM 5% .25W 1210 H 6*
R395 A11371-1R83 1.8 OHM 5% .25W 1210 H 6*
R396 A11371-1R83 1.8 OHM 5% .25W 1210 H 6*
R397 A11371-1R83 1.8 OHM 5% .25W 1210 H 6*
R398 A11371-1R83 1.8 OHM 5% .25W 1210 H 6*
R399 A11371-1R83 1.8 OHM 5% .25W 1210 H 6*
R400 A11371-1R83 1.8 OHM 5% .25W 1210 D 3*
R401 A11371-1R83 1.8 OHM 5% .25W 1210 K 4*
R402 A11371-1R83 1.8 OHM 5% .25W 1210 L 3*
R403 OPEN L 4*
R404 OPEN M 3*
R405 A11371-1R83 1.8 OHM 5% .25W 1210 N 4*
R406 A11371-1R83 1.8 OHM 5% .25W 1210 N 3*
R407 A11371-1R83 1.8 OHM 5% .25W 1210 E 4*
R408 A11371-1R83 1.8 OHM 5% .25W 1210 F 3*
R409 OPEN G 4*
R410 OPEN G 3*
R411 A11371-1R83 1.8 OHM 5% .25W 1210 H 4*
R412 A11371-1R83 1.8 OHM 5% .25W 1210 H 3*
R413 A11368-10021 10K 1/10W 1% SMD 0805 T/R E 7*
R414 A11371-3341 330 KOHM .1W 5% 0805 T/R E 7*
R415 A11368-51111 5.11KOHM .1W 1% 0805 T/R F 7*
R416 A11368-10011 1.KOHM .1W 1% CHIP 0805 K 10*
R417 A11368-31623 31.6K OHM .25W 1% 1210 K 7
R418 A11368-31623 31.6K OHM .25W 1% 1210 L 8
R419 OPEN K 10*
R420 A11371-5R65 5.6 OHM 1W 5% 2512 T/R F 8*
R421 A11371-5R65 5.6 OHM 1W 5% 2512 T/R F 8*
R422 A11371-1013 100 OHM .25W 5% 1210 SMT T/R J 9
R423 A11368-31623 31.6K OHM .25W 1% 1210 L 8
R424 A11371-1R83 1.8 OHM 5% .25W 1210 H 6*
R425 A11371-1R83 1.8 OHM 5% .25W 1210 K 4*
R426 A11371-1R83 1.8 OHM 5% .25W 1210 K 4*
R427 A11371-1R83 1.8 OHM 5% .25W 1210 K 4*
R428 A11371-1R83 1.8 OHM 5% .25W 1210 K 4*
R429 A11371-1R83 1.8 OHM 5% .25W 1210 K 4*
R430 A11371-1R83 1.8 OHM 5% .25W 1210 K 4*
R431 A11371-1R83 1.8 OHM 5% .25W 1210 D 3*
R432 A11371-1R83 1.8 OHM 5% .25W 1210 E 3*
R433 A11371-1R83 1.8 OHM 5% .25W 1210 D 4*
R434 A11371-1R83 1.8 OHM 5% .25W 1210 E 4*
R435 A11371-1R83 1.8 OHM 5% .25W 1210 D 4*
R436 A11371-1R83 1.8 OHM 5% .25W 1210 E 4*
R437 A11371-1R83 1.8 OHM 5% .25W 1210 K 3*
R438 A11371-1R83 1.8 OHM 5% .25W 1210 L 3*
R439 A11371-1R83 1.8 OHM 5% .25W 1210 K 3*
R440 A11371-1R83 1.8 OHM 5% .25W 1210 K 3*
R441 A11371-1R83 1.8 OHM 5% .25W 1210 K 3*
R442 A11371-1R83 1.8 OHM 5% .25W 1210 K 3*
R443 OPEN L 4*
R444 OPEN L 4*
R445 OPEN L 4*
R446 OPEN L 4*
R447 OPEN L 4*
R448 OPEN L 4*
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 14 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
R449 OPEN M 3*
R450 OPEN M 3*
R451 OPEN L 3*
R452 OPEN L 3*
R453 OPEN L 3*
R454 OPEN L 3*
R455 A11371-1R83 1.8 OHM 5% .25W 1210 N 4*
R456 A11371-1R83 1.8 OHM 5% .25W 1210 N 4*
R457 A11371-1R83 1.8 OHM 5% .25W 1210 M 4*
R458 A11371-1R83 1.8 OHM 5% .25W 1210 M 4*
R459 A11371-1R83 1.8 OHM 5% .25W 1210 M 4*
R460 A11371-1R83 1.8 OHM 5% .25W 1210 M 4*
R461 A11371-1R83 1.8 OHM 5% .25W 1210 N 3*
R462 A11371-1R83 1.8 OHM 5% .25W 1210 N 3*
R463 A11371-1R83 1.8 OHM 5% .25W 1210 N 3*
R464 A11371-1R83 1.8 OHM 5% .25W 1210 M 3*
R465 A11371-1R83 1.8 OHM 5% .25W 1210 M 3*
R466 A11371-1R83 1.8 OHM 5% .25W 1210 N 3*
R467 A11371-1R83 1.8 OHM 5% .25W 1210 F 4*
R468 A11371-1R83 1.8 OHM 5% .25W 1210 E 4*
R469 A11371-1R83 1.8 OHM 5% .25W 1210 E 4*
R470 A11371-1R83 1.8 OHM 5% .25W 1210 E 4*
R471 A11371-1R83 1.8 OHM 5% .25W 1210 E 4*
R472 A11371-1R83 1.8 OHM 5% .25W 1210 E 4*
R473 A11371-1R83 1.8 OHM 5% .25W 1210 F 3*
R474 A11371-1R83 1.8 OHM 5% .25W 1210 F 3*
R475 A11371-1R83 1.8 OHM 5% .25W 1210 E 3*
R476 A11371-1R83 1.8 OHM 5% .25W 1210 E 3*
R477 A11371-1R83 1.8 OHM 5% .25W 1210 E 3*
R478 A11371-1R83 1.8 OHM 5% .25W 1210 E 3*
R479 OPEN G 4*
R480 OPEN G 4*
R481 OPEN F 4*
R482 OPEN F 4*
R483 OPEN F 4*
R484 OPEN F 4*
R485 OPEN G 3*
R486 OPEN G 3*
R487 OPEN G 3*
R488 OPEN G 3*
R489 OPEN G 3*
R490 OPEN G 3*
R491 A11371-1R83 1.8 OHM 5% .25W 1210 H 4*
R492 A11371-1R83 1.8 OHM 5% .25W 1210 G 4*
R493 A11371-1R83 1.8 OHM 5% .25W 1210 H 4*
R494 A11371-1R83 1.8 OHM 5% .25W 1210 H 4*
R495 A11371-1R83 1.8 OHM 5% .25W 1210 H 4*
R496 A11371-1R83 1.8 OHM 5% .25W 1210 H 4*
R497 A11371-1R83 1.8 OHM 5% .25W 1210 H 3*
R498 A11371-1R83 1.8 OHM 5% .25W 1210 H 3*
R499 A11371-1R83 1.8 OHM 5% .25W 1210 H 3*
R500 A11368-10021 10K 1/10W 1% SMD 0805 T/R B 3
R501 A11368-10021 10K 1/10W 1% SMD 0805 T/R B 3
R502 A11368-10021 10K 1/10W 1% SMD 0805 T/R B 2
R503 A11368-10021 10K 1/10W 1% SMD 0805 T/R B 2
R504 A11368-20011 2.0K, 0.10W 1% MF 0805 B 3
R505 A11371-1R83 1.8 OHM 5% .25W 1210 H 3*
R506 A11368-20011 2.0K, 0.10W 1% MF 0805 B 2
R507 A11371-1R83 1.8 OHM 5% .25W 1210 H 3*
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 15 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
R508 OPEN C 2
R509 A11371-1R83 1.8 OHM 5% .25W 1210 H 3*
R600 A11368-10021 10K 1/10W 1% SMD 0805 T/R B 1
R601 A11368-10021 10K 1/10W 1% SMD 0805 T/R B 2
R602 A11368-10021 10K 1/10W 1% SMD 0805 T/R B 2
R603 A11368-10021 10K 1/10W 1% SMD 0805 T/R B 2
R604 A11368-20011 2.0K, 0.10W 1% MF 0805 B 2
R605 A11368-49R91 RES, 49.9 OHM 1% 0.1W SMT 0805 D 3
R606 A11368-20011 2.0K, 0.10W 1% MF 0805 B 2
R607 A11371-8205 82 OHM 1W 5% SMD 2512 B 1
R608 OPEN C 1
R609 A11368-49R91 RES, 49.9 OHM 1% 0.1W SMT 0805 D 3
R610 A11368-49R91 RES, 49.9 OHM 1% 0.1W SMT 0805 C 1
R999 A11368-10031 100.KOHM .1W 1% CHIP 0805 L 1
RT1 101103-1 PTC, 6.0 OHM 265V E 9
RT2 101103-1 PTC, 6.0 OHM 265V C 6
S1 C 7325-1 2POLE 2POS PC SLIDE SWITCH M 10
S2 C 7325-1 2POLE 2POS PC SLIDE SWITCH L 10
TB1 102475-1 BLOCK, 5 POS TERMINAL B 2
TP15 138063-2 TEST POINT, SMD TP-107 SERIES D 9
TP38 138063-2 TEST POINT, SMD TP-107 SERIES K 1
TP39 138063-2 TEST POINT, SMD TP-107 SERIES N 7
U1 C 5095-2 MC7815CT +15V. REG H 10
U1X C 9918-1 TO220 VERT CLIP-ON HEATSINK H 10
U2 C 5096-0 MC7915CT -15V. REG H 9
U2X C 9918-1 TO220 VERT CLIP-ON HEATSINK H 9
U3 102486-1 OPTO BJT NPN SOIC-8 CTR=100% O 10
U4 133552-1 OP AMP, LM358 LOW PWR DUAL S08 I 9
U5 133552-1 OP AMP, LM358 LOW PWR DUAL S08 O 9
U100 102723-2 OPTOCELL ON<.5KOHM OFF>10M5SEC M 10
U101 C 9012-3 OP AMP, QUAD LO NOISE MC33079D M 10
U102 C 9038-8 COMPARATOR, QUAD LM339D SO-14 N 9
U104 C 9038-8 COMPARATOR, QUAD LM339D SO-14 H 8
U105 133552-1 OP AMP, LM358 LOW PWR DUAL S08 G 8
U106 127683-1 SENSOR, CE THERMAL N 6
U200 102723-2 OPTOCELL ON<.5KOHM OFF>10M5SEC K 10
U201 C 9012-3 OP AMP, QUAD LO NOISE MC33079D J 10
U202 C 9038-8 COMPARATOR, QUAD LM339D SO-14 L 9
U204 C 9038-8 COMPARATOR, QUAD LM339D SO-14 E 8
U205 133552-1 OP AMP, LM358 LOW PWR DUAL S08 E 8
U206 127683-1 SENSOR, CE THERMAL N 3
U500 C 9012-3 OP AMP, QUAD LO NOISE MC33079D B 2
W1 101031-1 .250 FASTON, AUTO INSERTABLE D 7
W2 101031-1 .250 FASTON, AUTO INSERTABLE C 7
W3 138030-1 WIRE HARNESS, SOFT START D 4
W5 101031-1 .250 FASTON, AUTO INSERTABLE D 8
W6 101031-1 .250 FASTON, AUTO INSERTABLE C 8
WP1 A11378-A050U WIRE, 16 RED FAST X 5 X TERM A 10
WP2 103331-N050R WIRE, 16 BLK/WHT TAB X 5 XTERM A 10
WP3 A11379-C050U WIRE, 16 BLUE FAST X 5 X TERM A 9
WP4 101031-1 .250 FASTON, AUTO INSERTABLE D 7
WP5 101031-1 .250 FASTON, AUTO INSERTABLE D 5
WP7 101031-1 .250 FASTON, AUTO INSERTABLE D 8
Z1 OPEN E 10
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 16 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
Count of CPN
CPN Total
(blank) 0
101016-1 3
101031-1 7
101103-1 2
101571-1 1
101573-1 2
101993-1 1
102438-101K2 8
102438-221K2 2
102438-560K2 2
102438-820K2 2
102467-1 4
102470-1 2
102471-2 1
102472-3 1
102473-1 2
102475-1 1
102476-1 3
102477-1 4
102479-1 3
102480-1 2
102481-1 2
102483-1 2
102486-1 1
102577-1 2
102579-1 2
102595-3 2
102606-6 2
102606-7 2
102608-1 8
102659-1 16
102719-1 24
102723-2 2
103180-1 3
103192-1 4
103193-1 3
103198-1 1
103200-1 4
103210-1 6
103233-1 4
103331-N050R 1
125478-1 2
125594-1 6
126017-2 4
126317-1 2
126549-1 4
126551-1 2
126785-1 8
126929-1 2
127299-1 4
127683-1 2
131648-1 4
132491-1 8
133264-1 2
133552-1 4
134732-1 2
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 17 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
136319-1 2
136803-1 2
137218-1 1
137555-3 1
137717-1 4
138030-1 1
138063-2 3
A10020-7 8
A10434-104JD 2
A10434-473JD 1
A11368-10011 10
A11368-10021 30
A11368-10023 16
A11368-10031 17
A11368-12103 2
A11368-12421 2
A11368-13003 2
A11368-15831 8
A11368-16203 4
A11368-19122 2
A11368-20011 4
A11368-20021 4
A11368-22601 4
A11368-24911 2
A11368-31623 8
A11368-39231 4
A11368-42211 2
A11368-49901 4
A11368-49902 4
A11368-49921 3
A11368-49R91 5
A11368-51111 6
A11368-57621 3
A11368-60432 6
A11368-68111 2
A11368-68121 2
A11368-69811 1
A11368-71511 1
A11368-82511 2
A11368-82521 1
A11368-90921 2
A11368-93111 1
A11369-120K2 6
A11369-270K2 2
A11369-330J2 2
A11369-471K2 2
A11371-0R01 2
A11371-1011 2
A11371-1013 2
A11371-1022 1
A11371-1501 2
A11371-1811 4
A11371-1R83 144
A11371-2223 2
A11371-3333 2
A11371-3341 4
A11371-4701 2
A11371-5R63 4
A11371-5R65 4
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 18 OF 19

137556-3 REV. B PWA, MAIN/INPUT CE1000A MDCE100
A11371-6814 7
A11371-6821 2
A11371-7511 3
A11371-8201 2
A11371-8205 1
A11371-8211 4
A11371-R221 3
A11378-A050U 1
A11379-C050U 1
A11427-103K2 8
A11427-103K5 2
A11427-104K2 37
A11427-272K2 2
A11427-472K2 4
C 4477-3 3
C 5095-2 1
C 5096-0 1
C 6419-3 2
C 7091-9 2
C 7325-1 2
C 7377-2 1
C 7448-1 6
C 9012-3 3
C 9038-8 4
C 9202-0 2
C 9252-5 2
C 9283-0 44
C 9918-1 2
C 9931-4 6
C10196-1 4
C10370-2 1
C10422-1 4
C10515-2 9
C10613-5 2
Grand Total 754
137556-3_B.xls
R04.1CDE-004_(Fm) JAW 10/6/01 CROWN AUDIO, INC. ELKHART, IN. 19 OF 19
