Crown ScreenArray PIP-3632 User manual

PIP-4632
Frequency Response: See Figure 4 on back.
Signal-to-Noise Ratio: 90 dB, A weighted.
Input Impedance: 20 k ohms balanced, 10 k
ohms unblanced.
Input Connector: Electronically balanced,
3-position removable terminal block.
Input/Output Connector: HD15 connector.
Crown®ScreenArray®PIP™ modules are
custom two-channel crossover networks
with equalization and delay specifically
designed for use with JBL ScreenArray cinema
speaker systems installed in cinemas, studio
production and post-production environments.
The PIP-4622 is designed for use with model
4622 ScreenArray system, the PIP-3632 is
designed for use with model 3632 ScreenArray
system, and the PIP-4632 is designed for use
with model 4632 ScreenArray system.
The ScreenArray PIP modules install into the
back of Crown PIP2™-compatible amplifiers,
saving rack space and simplifying system
wiring.
The HD15 connector on ScreenArray PIPs is
designed for quick and easy interface with
popular cinema monitor products such as the
USL CM680.
You must have a PIP2-compatible amplifier to
use the ScreenArray PIP modules. To deter-
mine if your amplifier is PIP2-compatible, look
for the logo on the back of the
amplifier. The ScreenArray PIP modules are
NOT compatible with older Crown PIP ampli-
fiers.
Typical system wiring is shown in Figure 1.
For more details about the ScreenArray
PIP series, contact the Crown Technical
Support Group at 800-342-6939 or
574-294-8200. Also, visit the Crown Audio
website at www.crownaudio.com.
Specifications
PIP-4622
Frequency Response: See Figure 2 on back.
Signal-to-Noise Ratio: 90 dB, A weighted.
Input Impedance: 20 k ohms balanced, 10 k
ohms unblanced.
Input Connector: Electronically balanced,
3-position removable terminal block.
Input/Output Connector: HD15 connector.
PIP-3632
Frequency Response: See Figure 3 on back.
Signal-to-Noise Ratio: 90 dB, A weighted.
Input Impedance: 20 k ohms balanced, 10 k
ohms unblanced.
Input Connector: Electronically balanced,
3-position removable terminal block.
Input/Output Connector: HD15 connector.
SCREENARRAY®SERIES
• Custom 2-channel crossover networks
designed for use with JBL ScreenArray cinema
speaker systems
• Installs into the back of Crown PIP2-compat-
ible amplifiers, saving rack space and simplify-
ing system wiring
• HD15 connector provides integrated signal
input and amplifier output monitoring; works
with USL CM680 monitor panel (or other)
• User setable 6.6 dB full-band attenuator
• Standard VGA cables can be wired for intercon-
nect
• Applications include cinemas, studio produc-
tion and post-production environments
• Low noise, wide frequency response
• Three-Year, No-Fault, Fully Transferable War-
ranty completely protects your investment
and guarantees its specifications
Features
PIP-4622
PIP-3632
PIP-4632
Figure 1. Typical System Wiring
From Cinema Processor
From USL CM680
OPTIONAL INPUT PATHS

Crown International
1718 W. Mishawaka Rd.
Elkhart, IN 46517-9439
TEL: [phone]
FAX: [phone]FAX
www.crownaudio.com
7/05 135801-1B
Crown’s Three-Year, No-Fault, Fully Transferable Warranty
Crown offers a Three-Year, No-Fault, Fully Transferable Warranty for every new Crown amplifier
product—an unsurpassed industry standard. With this unprecedented No-Fault protection, your
new Crown amplifier product is warranted to meet or exceed original specifications for the first
three years of ownership. During this time, if your unit fails, or does not perform to original
specifications, it will be repaired or replaced at our expense. About the only things not covered
by this warranty are those losses normally covered by insurance and those caused by intentional
abuse. And the coverage is transferable, should you sell your unit.
See your authorized Crown dealer for full warranty disclosure and details. For customers outside
of the USA, please contact your authorized Crown distributor for warranty information or call
574-294-8200.
Specifications subject to change without prior notice. Latest
information available at www.crownaudio.com.
Crown and Crown Audio are registered trademarks of Crown
International. PIP and PIP2 are trademarks of Crown Interna-
tional. Other trademarks are the property of their respective
owners. Printed in U.S.A.
© 2005 Crown Audio®, Inc.
PIP-4622
PIP-3632
PIP-4632
Figure 2. PIP-4622 Frequency Response
Figure 3. PIP-3632 Frequency Response
Figure 4. PIP-4632 Frequency Response
HD15 PINOUT
1 Inverting input (–)
2 NC
3 Ch. 1 output voltage monitor
4 NC
5 NC
6 Chassis ground
7 Non-inverting input (+)
8 NC
9 NC
10 Signal ground
11 NC
12 NC
13 Ch. 2 output voltage monitor
14 NC
15 NC
1
6
11
5
10
15
