QM896741
ELBOW OPERATED
SOAP DISPENSER
ALL PRODUCT DIMENSIONS DETAILED IN
THIS INSTALLATION AND MAINTENANCE
MANUAL ARE APPROXIMATE
ALL ILLUSTRATIONS OF THE PRODUCT ARE
FOR REFERENCE ONLY. COMPONENTS
SUPPLIED WITH INDIVIDUAL PRODUCTS
MAY DIFFER
CONTACT DETAILS
Croydex
Central Way
Andover
Hampshire
SP10 5AW
UK
Tel: +44 (0)1264 365881
Email: info@croydex.co.uk
www.croydex.com
SECTION 1 - INTRODUCTION
INTRODUCTION
Please follow all assembly and product
care instructions to ensure that your
product is assembled safely and retains it's
high quality finish.
PLEASE RETAIN THIS MANUAL FOR
FUTURE REFERENCE
PRODUCT FITTING
IMPORTANT!
Before attempting to fit or use this
product. Ensure that it can be properly
installed in the location you wish it to be
in.
x1
S&H 083 R01
2
SECTION 1 - INTRODUCTION
WALL FIXING PACK
SECTION 2 - INSTALLATION
x2 wall
screws
x2 wall
plugs
SAFETY & PRODUCT CARE
1. ALWAYS take care when using power tools, particularly if
there is any water in the working area.
2. ALWAYS wear eye protection when using power tools.
3. ALWAYS check for pipes and cables before drilling into
walls.
4. NEVER use a hammer drill when drilling into tiled surfaces.
5. ALWAYS use a drill bit that is suitable for the surface that is
being drilled.
6. The wall plugs supplied are for use on solid walls only. For
cavity walls or plasterboard ALWAYS use specialist fixings
that are suitable for the type of wall construction.
7. DO NOT use abrasive or chemical cleaners as these may
damage the product.
6
mm
TOOLS REQUIRED
1. Place the dispenser cage in the desired location and mark the
positions of the mounting holes. Drill 6mm holes in the marked
positions and insert two wall plugs. Then, fix the dispenser cage
to the wall using the supplied screws.
(See Fig. 1)
fig. 1
2. Fill the dispenser with a MAXIMUM of 1 Litre of your desired
liquid. The bottle MUST be inserted into the dispenser cage in
the correct orientation as shown below. Before use ensure the
lock is turned fully clockwise towards 'open'.
(See Fig. 2)
fig. 2
