AIR PURIFIER
USER MANUAL
CAC-AB0610FI

2
Dear customers,
Please keep this User Manual for your reference.
This manual will guide you if you have any questions or troubleshooting
problems.
This product filters out fine dust, allergens, and other airborne particles using a True HEPA 3-Stage Filter mounted
in the base of the product.
4-Color LED Air Quality Display
The detected air quality is shown on the display screen with 4 different colors of LED lights.
Each color represents the pollution degree of solid contaminants found in the surrounding air.
Please read the instructions carefully before using the product and keep them properly.
Filter Replacement Indicator
Features a built-in replacement indicator that reminds the user when the filter is in need of replacement.
Compact Size
With a light and portable design, this product is the perfect size for use in small rooms, offices, and apartments.
H13 True HEPA 3-Stage Filter
Collects pet dander, ultra-fine dust, harmful gases, and other airborne particles with the 3-in-1 H13 True HEPA Filter.
Automatic Operation through Dust Sensor
This product detects the pollution status of the surrounding indoor air in real time through the dust sensor.
When the automatic operation setting is selected, the product automatically adjust the fan speed according
to the surrounding pollution degree to make the indoor environment pleasant.
Features of CUCKOO Air Purifier

●
Parts & Accessories
●
Replacing the Filter
Controls/Display Panel
About the Filter
Safeguards
●
Troubleshooting
●
Before Use
During Use
Before Asking for
Support
Service Information
2
4
5 - 6
7
8 - 9
10 -11
12-13
CONTENTS
Features of CUCKOO Air Purifier

Unboxing
To unbox the air purifier, remove the foam lining, the accessories, and user manual.
Pull the air purifier out of the box and remove the plastic covering.
We recommend keeping the product box in a safe, dry location for future use.
After clearing the inner packaging, open the base of the air purifier,
take out the True HEPA filter and remove plastic packaging.
Parts
Parts & Accessories
4
Accessories
User Manual
※The picture may differ from the actual product.
DC Adapter
Control Panel
Air Vent
Filter
Intake
Base
Dust Sensor Cover

5
Replacing the Filter
* Note :
• Remove the plastic packaging from the purifier and all accessories before attempting to use.
• Ensure the purifier is unplugged before removing or installing the filter.
• Regularly wipe any dust found on the filter—do not wash or reuse a used filter.
• Do not use filters or any other accessories not designed for compatibility with this purifier.
Remove the base plate by turning it
counterclockwise.
1
Remove the True HEPA filter by pulling it
out toward you.
2
Remove any protective film or plastic packaging
from the replacement filter.
3
Install the filter by securely and carefully inserting
it into the cavity of the purifier.
4
1
3
2
3
4

To ensure the purifier's longevity and the efficiency of its purification,
Resetting the Filter Replacement Indicator
Replace the base plate by turning it clockwise
until securely tightened.
Plug the power cord into an available wall outlet.
5
7
Plug in the adapter cable.
6
Press the Filter Replacement button for 3 seconds
after installing a new filter.
If it is the first time using the product, do not
reset the the filter replacement indicator.
Proper Placement
Replacing the Filter
6
1 ft (30cm)
1 ft (30cm)
6
7
5
* Note
Always ensure the base plate is securely tightened
before using the purifier. The purifier will operate
if the base is not tightened, however this may cause
irreversible damage to the filter or purifier.

Filter Replacement Indicator
When illuminated, the True HEPA filter needs to be replaced.
For instructions on replacing the filter, see pages 5-6.
Button Descriptions
Turbo Mode
The purifier's fan will run at maximum speed for quick and efficient
purification.
Sleep Mode
The purifier's fan will run softly and at a slower speed to quietly purify the
air without disturbing your sleep.
Automatic Mode
The fan and wind speed will automatically adjust according to the surrounding
air quality.
7
Controls/Display Panel
Reset Filter Replacement
Button.
Press the button for
3 seconds to reset.
Mode Button
Cycles through Automatic
Mode, Sleep Mode, and
Turbo Mode with each press
Power Button
The digital air quality display screen shows the concentration of PM2.5 numerically.
It also represents the pollution level of solid contaminants in the air by displaying colors.
Air Pollution Level
Color
Bad
Red
Moderate
Orange
Good
Green
Excellent
Blue
Display and & Quality Indicator

About the Filter
8
About the Filter
Pre-Filter
Optimally removes large dust, hair, and fur and maximizes the filter's life.
H13 True HEPA Filter
Removes at least 99.97% of air particles such as smoke, dust
pollen, dander, and mites.
Active Carbon Filter Absorbs unpleasant odors, harmful gases, food odors, cigarette
smoke, fur, and volatile organic compounds.
※ The picture may differ from the actual product.
True HEPA 3-Stage Filter
Stage 1 Pre-Filter
Stage 2 H13 True HEPA
Stage 3 Activated Carbon Filter
Air Purification
True HEPA
3-Stage Filter

Maintenance
• Ensure the product is unplugged before maintenance.
• Do not immerse the air purifier into water or any liquid.
• Do not use abrasive, corrosive or flammable cleansers (such as bleach or alcohol) to
clean any part of the unit.
• Do not wash the filter.
• Do not use a vacuum cleaner to clean the filter.
• Ensure the product is powered off and unplugged.
• Use a soft cloth with neutral cleanser to clean away any dust or debris from the surface
of the product and air intake/vent.
• If the purifier sits idle and remains unused for an extended period of time, turn the purifier
on occasionally to ensure the purifier's longevity.
• Take care to not drop any water or liquid into the purifier while cleaning.
Cleaning & Storage
1. Filter model :
CACF-AB
2. When the filter replacement light is on,
it reminds that the HEPA filter should be
replaced.
If it is not replaced in time, the Prompt will
appear every startup.
Replacement of the filter components
9
About the Filter
Filter Replacement Cycle
Filter Room size When to Replace
AHAM Verified Room Size
231 sqft On average, every 6 months*
* The expected filter replacement cycle is estimated by a close review of the filters to display its proper
performance. This is determined based on the product usage time (12 hours) per day and indoor pollution
index of 150㎍/㎥. Thus the cycle may shorten as the usage time or indoor pollution index goes up.
(Based on GB/T 18801-2015 standard)
H13 True HEPA
3-Stage Filter

Safeguards
10
Safety Instructions
Intended Use
•
The device is used exclusively for monitoring and cleaning air quality
indoors.
• Read all important instructions and safeguards before using
the purifier.
Safety instructions
• Keep packaging material such as plastic wrapping, away from children
as they can pose a risk of suffocation.
• Please follow the safety instructions to prevent fire or electrical shock.
• Only use the device indoors.
• Use only with appropriate wall outlets with the correct voltage output.
(see rating plate).
• Do not attempt to modify or repair the device.
• Do not use the device if the power cable or mains plug is
damaged or if the connection at the outlet is not stable.
• Make sure that the power cable does not get crushed while you
are using the device and that it cannot be damaged in any other
way. Place the cable so that no one will trip over it.
Do not pull the power cable tight.
• Disconnect the plug from the outlet for cleaning purposes and
whenever the device is not in use for a significant period of time.
• Do not touch the plug or the device if you have wet hands.
• Do not spray any insect repellent on or around the purifier.
• Do not use in rooms where the device may come into contact
with fuel vapor, oil vapor or metal dust.
• Do not use any volatile liquids, petroleum, kerosene, paint
thinner or polishing paste to clean the device. Such liquids may
damage the surface of the device.
• Do not expose the device to rain, water, moisture or high
humidity, and do not set it up in a bathroom or kitchen next to a sink.
• Make sure that no foreign objects get into the outlet grilles.
• Do not use near a naked flame or sparks.
• The device is not suitable for removing harmful gases (carbon
monoxide, e.g. from heating appliances).
• Unless they are supervised, the device must not be used by
those(including children) with reduced, physical, sensory and
mental abilities or who do not have the required experience
and knowledge.

11
Safeguards
Safety Instructions
• Do not block the air intake or outlet.
•
Do not expose the air purifier to direct sunlight, a naked flame or heat.
• Only use the air purifier in living quarters and within the specified
technical parameters. Improper usage may pose a threat to life
and health.
•
Do not use the device near a smoke detector. Air blowing towards
a smoke detector could delay the alarm or not trigger at all.
Caution
Risk of injury due to electrical shock.
Always disconnect the mains plug prior to :
• Maintenance and cleaning
• Moving the device
• Changing the filter
Caution
• Do not spray any flammable content on or near the purifier.
Caution
• Do not use any flammable cleaning agents

12
Troubleshooting
▼Your purifier may cease to work if the instructions in this manual are not followed carefully.
Refer to the chart below to identify the problem and explain the next course of action.
If the problem persists, please contact our Customer Service Center.
The product won’t work
even when the Power button
is pressed.
Is the rest of your power grid up
and operational?
Check the power supply.
Is the power cord securely
plugged into a power outlet.
Put the power plug in a power outlet
with the correct voltage output.
No air is blowing out.
The purifier is emitting loud
noises while in use
Is there material obstructing the
intake or air vent?
Remove material from vent/intake.
Check if plastic packaging has been
removed from the filter.
Is the air purifier placed where
the vent/intake is preventing air
from moving freely?
Remove any objects obstructing the
vents and ensure the purifier is placed
at least 1 ft. away from walls.
Remove any objects obstructing the
intake/vent.
The fan has ceased to operate.
Is there anything stuck in the
fan or intake/vent?
Unplug from the outlet and contact
CUCKOO customer service.
USA : www.cuckooamerica.com
India : www.cuckooindia.in
Vietnam : www.cuckoovina.com
Indonesia : www.cuckoo.co.id
Malaysia : www.cuckoo.com.my
Problem RecommendationChecklist
Is the air purifier tilted on its side? Ensure the base of the purifier is placed
on a flat, level surface.
Is the fan really loud? Set your air purifier to a lower fan
speed to reduce the noise.

13
Troubleshooting
Note: If these suggestions do not work accordingly, please contact CUCKOO Customer Service Center
and await instructions. Do not disassemble, repair or fix anything by yourself.
The air purifier is not purifying
the area well.
The air purifier may be placed in
an area with no ventilation, or
there is an object obstructing the
intake/vent
Ventilate the room and then use
the product. Use the product in
an area not exceeding its
coverage limit.
(Avoid placing the device where it is
well ventilated like a door or window.)
Is the filter dusty? If the filter replacement indicator is
illuminated, the filter needs to be replaced.
Following the instructions on pages 5-6,
replace the filter.
Problem RecommendationChecklist
Ensure the replacement filter does not
have any of the plastic packaging on it.
If so, remove it before continuing to use
the purifier.
Have you removed the filter from
its packaging?
Do you smell plastic?
It is normal for the purifier to emit a
plastic smell during its first use.
If the smell persists after the first couple
of uses, contact the CUCKOO Customer
Service Center.
Is there a burning smell? Turn off your air purifier, unplug it from
the outlet and call our CUCKOO
Customer Service Center.
Is there any dust in the pre-filter? Wipe the pre-filter
Are there any objects blocking the
air intake/vent?
Please remove any objects from the
intake/vent.
The filter replacement indicator is
still blinking after I changed the
filter.
Reset Filter Replacement
Press and hold the reset filter replacement
button for 3 seconds to reset.
The purifier is emitting
unpleasant odors while in use.
Is the air purifier in a place with
a lot of smoke and odor?
Should replace my
filter?
The performance of the air purifier
may decrease over time if there is
excessive smoke and odor in the area.
To remedy this, air out the room
before using the air purifier.
If the filter replacement indicator is
illuminated, the filter needs to be
replaced. Following the instructions on
pages 5-6, replace the filter.
Is the intake/vent dusty? Clean the invent/vent
13

CAC-AB0610FI
Input: 100-240V~, 50/60Hz
Output: 24V / 1.5A
36W
Smoke: 149 / Dust: 152 / Pollen: 152
under 55dB (A)
231 sq. ft. (21m²)
Mechanical dust collecting method
9.4 x 9.4 x 15.3 (inches)
5.5 lbs.
Indoor Use Only
1614
Product Specifications
1. The information (exterior, design, and specifications) provided in this User Manual is subject to change without prior
notice to improve the quality of the device.
2. The CADR indicates how much filtered air is delivered (airflow) by the air purifier operating at the highest setting, and
how well the system removes tobacco smoke, dust and pollen pollutants from the air (efficiency). Tests are performed
in accordance with ANSI/AHAM AC-1-2020.
Product parts may wear out due to heat, moisture, dust and other causes over time, which in tum may cause malfunction of the product.
In the case that :
1 Something other than the symptoms coming under "Troubleshooting" in page 12-13 occurs;
2 You can feel electricity when you touch the product with your hands;
3 The power is supplied, but the motor does not work,
Do not continue use of the purifier.
Unplug the purifier and contact our Customer Service Center.
Warranty
For inquiries regarding the product's warranty or to view replacement parts, please visit our website according to
your region.
USA : www.cuckooamerica.com India : www.cuckooindia.in
Vietnam : www.cuckoovina.com Indonesia : www.cuckoo.co.id
Malaysia : www.cuckoo.com.my
Category Air Purifier
Inquiry about Malfunction
Model
Power Supply
Rated Power Input
AHAM Verified CADR
Noise
AHAM Verified Room Size
Dust Collecting Method
Product Size
Product Weight
Place for Use
14

MEMO

Z0383-0097A0.Rev0
CUCKOO strives to always provide satisfying consultation and services regarding your complaints, suggestions, and inquiries.
When contacting us, you will need to provide your product's model number, its operation status, and your contact information.
♣ After reviewing, keep this manual in an easily accessible place for future reference.
♣ Caution: Read this manual carefully to ensure user safety and to lengthen your purifier's lifespan.
USA : www.cuckooamerica.com India : www.cuckooindia.in
Vietnam : www.cuckoovina.com Indonesia : www.cuckoo.co.id
Malaysia : www.cuckoo.com.my
