AIR PURIFIER
USER MANUAL
CAC-I0510FW

2
Dear customers,
Please keep this User Manual for your reference.
This manual will guide you if you have any questions or troubleshooting
problems.
This product filters out fine dust, allergens, and more that is airborne using a True HEPA 3-Stage Filter mounted
in the base of the product.
3 Color LED Air Quality Display
The product automatically detects the cleanliness of the indoor air through the dust sensor and displays the cleanliness.
The air quality display screen represents the pollution degree of solid contaminants in the air with 3 colors.
Please read the instructions carefully before using the product and keep them properly.
Filter Replacement Indicator
Built-in replacement indicator reminds user when the filter is needed to be replaced.
Compact Size
Light and portable design, perfect size for small room and office.
True HEPA 3-Stage Filter
Collect pet dander, ultrafine dust, harmful gases and much more with this 3 in 1 True HEPA Filter.
Timer Setting
You can set the timer from 2 to 8 hours depending on preference.
Automatic Operation function through Dust Sensor
The product detects the pollution status of the air indoors in real time through the dust sensor.
When automatic operation setting is selected, the product automatically adjust the fan speed according
to the surrounding pollution degree to make the indoor environment pleasant.
Top Features of CUCKOO Air Purifier

●
Description of Parts
●
How to Replace Filter
Names and Functions of Control / Display Panel
About the Filter
Caution
Attention
●
Troubleshooting
●
Before Use
During Use
Before Asking for
Support
Service Information
2
4
5~6
7~ 8
9~10
11~12
13~14
15~16
17
CONTENTS
Top Features of CUCKOO Air Purifier

Unboxing
To unbox the air purifier, open the box, take out the foam lining, and take out the internal
accessories and user manual. Pull the air purifier out of the box and pull down the plastic
covering surrounding it. Keep the product box in a safe location for future use.
After clearing the inner packaging of the air purifier, open the base of the air purifier,
take out the True HEPA filter and remove plastic packaging.
Description of Parts
Description of Parts
4
Accessories
User Manual
※The picture may differ from the actual product.
DC Adapter
Control Panel
Air Vent
Filter
Intake
Base
DC
Adapter
Outlet

5
How to Replace Filter
* Note :
• Please remove the packaging from the filter before using it.
• Ensure the product is unplugged before removing or installing the filter.
• Please wipe the dust on the filter regularly, do not wash or use it repeatedly.
• Please do not use other filters that are not designed for this air purifier.
When the red rings of light around the
control panel blink repeatedly, it means
the filter needs to be changed.
1
To change the filter, invert the air purifier
and twist the base cover to the direction
marked "OPEN".
2
Take out the old filter from the air purifier.
3
Remove the packaging around the new filter.
4
1
3
2
Open
3
4
High

In order to keep the best purification effect, it is recommended to keep the air purifier standing
on the floor and keep it at least 1 ft (30cm) away from the wall.
Resetting the filter replacement alert
Place the new filter into the base of the
air purifier.
Put the base cover back on the bottom and twist
to the direction marked "CLOSE".
*Please make sure cover is securely fastened.
5
6
Please press the power button for 7 seconds to
reset the filter replacement alert after installing
a new filter.
If it is the first time using the product, do not
reset the product.
Maximum Purification Efficiency
How to Replace Filter
6
1 ft (30cm)
1 ft (30cm)
6
Close
5
* Note
The air purifier works without tightening the base.
However, this may cause damage to the filter,
so make sure that the base is closed properly.

1. Touch the power button to turn on the product, the buzzer will sound
one time and high fan speed will start.
2. Touch the button again, the buzzer will ring for one time and the
product will turn off with all lights turn off.
Button Description
1. While the air purifier is on, keep pressing the timer button to select
desired time setting. 2 hours, 4 hours, and 8 hours are the only
available options.
2. To turn off the timer, press the timer button until the timer indicator light
below the times does not appear.
3. In the status of timing, the product begins to count down.
When the timer is up the fan will stop working and all lights will be off.
7
Names and Functions of Control / Display Panel
Power Button
Timer Button
Timer button
Light control button
Fan speed button
Power button
High
* Note
When the product connects to the power outlet, the buzzer will ring for 1 second.
The product enters the pre-processing mode (the light ring will change in blue, cyan, green,
yellow, red, purple, and after 30 seconds of pre-processing, the color corresponding to the
current air quality will be displayed.

Please confirm that the input voltage is 100-240V, 50Hz/60Hz, and ensure that the power
plug and your hands are dry before you insert the power cord plug into the outlet.
Note: Contact Customer Service when the power cord or plug is damaged or the power
outlet is loose.
We strongly recommend that the damaged parts be repaired or replaced.
To replace the damaged power cord or plug, please visit Cuckoo's website and contact
Customer Service.
Connect the power
1. To change the fan speed, press the fan speed button.
The fan speed will cycle between SLEEP, HIGH, and AUTO and will
be indicated by a white light below the name.
2. SLEEP will have the fan on the lowest speed.
HIGH will have the fan on the highest speed.
AUTO will adjust the speed according to the current air quality.
Note : When the sleep mode is activated, LED turns off.
3. When the air quality is poor, the fan speed is automatically adjusted
to HIGH, and the light ring will display red. When the air quality is
moderate, the fan speed is automatically adjusted to MEDIUM, and
the light ring will display yellow. When the air quality is excellent, the
fan speed is automatically adjusted to LOW, and the light ring will
display blue.
1. To adjust the lighting, touch the light control button repeatedly to dim
the light to desired preference.
2. To turn off the light, touch the light control button repeatedly until
LED turns off.
Note : The light control button couldn’t operate in the status of shutdown.
If the light ring keeps blinking red, the filter needs to be replaced.
Names and Functions of Control / Display Panel
8
Fan Speed Button
Light Control Button
Air Pollution Level Poor Moderate Excellent
Color Red Yellow Blue
High

9
About the Filter
About the Filter
Pre-Filter It removes large dust, hair, fur which maximizes the filter's life.
True HEPA It removes at least 99.97% of particles as small as 0.3 microns
such as smoke, dust pollen, dander and mites.
Active Carbon Filter It absorbs unpleasant odors, harmful gases, food smell, cigarette
smoke, fur, and VOCs.
※ The picture may differ from the actual product.
True HEPA 3-Stage Filter
Stage 1 Pre Filter
Stage 2 True HEPA
Stage 3 Active Carbon Filter
Air Purification
True HEPA
3-Stage Filter

Maintenance
• Ensure the product is unplugged before maintenance.
• Do not immerse the air purifier into water or any liquid.
• Do not use abrasive, corrosive or flammable cleansers (such as bleach or alcohol) to
clean any part of the unit.
• Do not wash the filter.
• Do not use a vacuum cleaner to clean the filter.
• Ensure the product is powered-off and unplugged.
• Use a soft cloth with neutral cleanser to clean away any dust or debris from the surface
of the product and air intake/vent.
• If you do not use it for a long time, please turn on the product for a few minutes from time
to time to ensure a good performance.
• Please do not drop any water into the product when cleaning the air outlet.
Cleaning and Storage
About the Filter
10
Filter Replacement Cycle
Filter Room size When to Replace
Up to 228 sqft
On average, every 6 months
* The expected filter replacement cycle is estimated by a close review of the filters to display its proper
performance. This is determined based on the product usage time (12 hours) per day and indoor pollution
index of 150㎍/㎥. Thus the cycle may shorten as the usage time or indoor pollution index goes up.
(Based on GB/T 18801-2015 standard)
True HEPA
3-Stage Filter

11
Caution
Safety Instructions
Introduction
Thank you for choosing a device from Cuckoo.
Intended use
•
The device is used exclusively for cleaning the ambient air indoors.
• Please read these operating instructions before using the
machine and please follow the safety instructions.
The operating instructions must be kept available at all times.
Safety instructions
• Keep packing material, such as plastic wrapping, away from children!
(Risk of suffocation)
•
Please follow the safety instructions to prevent fire or electric shock.
Only use the device indoors.
• Only use a socket that supplies the correct voltage
(see rating plate).
• Do not modify or repair the device.
• Do not use the device if the power cable or mains plug is
damaged or if the connection at the socket is not stable.
• Make sure that the power cable does not get crushed while you
are using the device and that it cannot be damaged in any other
way. Place the cable so that no one will trip over it.
Do not pull the power cable tight.
• Disconnect the plug from the socket for cleaning purposes and
whenever the device is not in use for a significant period of time.
• Do not touch the plug or the device if you have wet hands.
• Do not spray any insect repellent.
• Do not use in rooms where the device may come into contact
with fuel vapour, oil vapour or metal dust.
• Do not use any volatile liquids, petroleum, kerosene, paint
thinner or polishing paste to clean the device. Such liquids may
damage the surface of the device.
• Do not expose the device to rain, water, moisture or high
humidity, and do not set it up in a bathroom or kitchen next to a sink.
• Make sure that no foreign objects get into the outlet grilles.
• Do not use near a naked flame or sparks.
• The device is not suitable for removing harmful gases (carbon
monoxide, e.g. from heating appliances).
• Unless they are supervised, the device must not be used by
those(including children) with reduced, physical, sensory and
mental abilities or who do not have the required experience
and knowledge.

Caution
12
Safety Instructions
Safety instructions
• Do not block the air intake or outlet.
•
Do not expose the air purifier to direct sunlight, a naked flame or heat.
• Only use the air purifier in living quarters and within the specified
technical parameters. Improper usage may pose a threat to life
and health.
•
Do not use the device near a smoke detector. Air blowing towards
a smoke detector could delay the alarm or not trigger at all.
Caution
Risk of injury due to electric shock.
Always disconnect the mains plug prior to :
• Maintenance and cleaning
• Moving the device
• Changing the filter
Caution
• Do not use any spray cans with flammable contents near to the
air purifier!
Caution
• Do not use any flammable cleaning agents

13
13
Attention
Consignes de sécurité
Préface
Nous vous remercions d’avoir opté pour un appareil de la maison Cuckoo.
Utilisation conforme
• L’appareil est exclusivement destiné à la purification de l’air
ambiant en intérieur.
• Veuillez lire impérativement ce mode d’emploi et observer
les consignes de sécurité avant la mise en service de la machine.
Ce mode d’emploi doit être disponible à tout moment.
Consignes de sécurité
• Conservez les emballages, telles que les films d’emballage,
hors de portée des enfants!(Risque d’asphyxie)
•
Respectez les consignes de sécurité pour éviter le risque d’incendie
ou d’électrocution. N’utilisez l’appareil qu’à l’intérieur.
•
Utilisez uniquement une prise de courant avec la tension indiquée
(voir plaque signalétique).
• Ne procédez à aucune modification ou réparation sur l’appareil.
• N’utilisez l’appareil en aucun cas si le cordon d’alimentation ou
la fiche secteur est endommagée ou si le branchement dans la
prise murale est instable.
• Veillez à ce que le cordon d’alimentation ne soit pas pincé et ne
puisse pas être endommagé d’une autre manière pendant le
fonctionnement.
Posez le cordon de manière à éviter que quelqu’un puisse trébucher
sur le cordon. Le cordon d’alimentation ne doit pas être tendu.
• Débranchez la fiche en cas de non-utilisation prolongée ou à
des fins de nettoyage.
• Ne touchez pas la fiche ou l’appareil avec des mains mouillées.
• Ne pulvérisez pas de produit insecticide.
• N’utilisez pas l’appareil dans des locaux dans lesquels l’air est
susceptible de contenir des vapeurs de combustibles, des vapeurs
d’huile ou des poussières métalliques.
• N’utilisez pas de liquide volatile, de white-spirit, de kérosène, de
diluant ou de la pâte de polissage pour le nettoyage.
Ces produits risquent d’endommager la surface de l’appareil.
•
N’exposez en aucun cas l’appareil à la pluie, à l’eau ou à une forte
humidité de l’air, ne le placez pas dans la salle de bains ou dans
la cuisine à proximité d’un lavabo ou d’un évier.
• Veillez à ce qu’aucun corps étranger ne pénètre dans les grilles
d’évacuation.
• Les flammes nues et les étincelles sont à proscrire.
•
L’appareil n’est pas destiné à l’élimination de gaz nocifs (monoxyde de
carbone provenant par ex. d’installations de chauffage à combustion).
• L’appareil ne doit pas être utilisé par des personnes (y compris
des enfants) dont les capacités physiques, sensorielles ou mentales
sont réduites ou qui manquent d’expérience et de connaissances,
à moins que celles-ci soient surveillées ou supervisées.

14
Attention
14
Consignes de sécurité
Consignes de sécurité
• N’obstruez jamais les orifices d’entrée et d’évacuation de l’air.
• N’exposez pas le purificateur d’air à la lumière directe du soleil, aux
flammes nues ou à la chaleur.
• N’utilisez le purificateur d’air que dans des pièces d’habitation et dans les
limites spécifiées dans les caractéristiques techniques. Toute utilisation
non conforme peut gravement menacer la santé et même la vie des
personnes.
• N’utilisez pas l’appareil à proximité d’un détecteur de fumée. Si l’air
souffle en direction d’un détecteur de fumée, l’alarme risque d’être
retardée ou de ne pas se déclencher du tout.
Attention
Risque de blessure en raison d’un choc électrique.
Toujours débrancher la fiche secteur avant :
• l’entretien et le nettoyage
• le déplacement de l’appareil
• le remplacement du filtre
Attention
• Ne pas utiliser d’aérosols contenant des
substances inflammables à proximité du purificateur d’air !
Attention
• Ne pas utiliser de détergents inflammables.

▼Not following this user manual may result in your device not working. Please read the following
measures accordingly if you are having problems with your device. If you are still having problems,
please contact our Customer Service Centers.
The product won’t work
even if I press the Power button.
Are you in a black out? Check the power supply.
Is the power cord plugged into
the power outlet?
Put the power plug in a
power outlet.
No air is blowing out.
Loud Noises
Is there material blocking the
intake or air vent?
Remove material from vent/intake.
Check if plastic packaging has been
removed from filter.
Is the air purifier placed where
the intake or blocked preventing
air from moving freely?
Remove objects blocking the air
purifier or place it elsewhere.
Please remove any objects you see
from the fan intake/vent.
Air purifier is on by fan does
not work.
Is there anything stuck in the
fan or air intake/ vent?
Unplug from the wall and contact
Cuckoo customer service.
USA : www.cuckooamerica.com
India : www.cuckooindia.in
Vietnam : www.cuckoovina.com
Indonesia : www.cuckoo.co.id
Malaysia : www.cuckoo.com.my
Problem RecommendationChecklist
15
Troubleshooting
Is the air purifier tilted on its side? Make sure the base is level on a flat
surface.
Is the fan really loud? Set your air purifier to a lower fan
speed to reduce the noise.

Note : If these suggestions do not work accordingly, please contact CUCKOO customer service and
await instructions. Do not disassemble, repair or fix anything by yourself.
16
The air purifier is not purifying
the area well.
The air purifier may be placed in
an area with no ventilation, or
there is an obstacle near it.
Ventilate the room and then use
the product. Use the product in
an area not exceeding its
coverage limit.
(Avoid placing the device where it is
well ventilated like a door or window.)
Is the filter dusty? Maybe it is time
to replace the filter.
Change the filter if it looks like it needs
to be replaced.
Problem RecommendationChecklist
Troubleshooting
The plastic bag of the filter may not have
been removed, so please open the cover
and check if the plastic bag is removed.
Have you removed the filter from
it's packaging?
Do you smell plastic?
It is common that in the first uses the
smell of plastic will be emitted.
It will eventually go away. If not, please
call our customer service centers.
Is there a burning smell? Turn off your air purifier, unplug it from
the wall and call our customer service
center.
Is there any dust in the pre-filter? Wipe the Pre-Filter
Are there any objects blocking the
air intake/ vent?
Please remove any objects from the
intake/vent.
The filter replacement alert is
still blinking after I changed the
filter.
Have you reset the filter change
button?
Press and hold the filter button for 7
seconds to reset the filter replacement
alert.
Coming out nasty smell
Is the air purifier in a place with
a lot of smoke and odor?
Should I clean or replace my
filter?
The performance of the air purifier
may decrease over time if there is
excessive smoke and odor in the area.
To remedy this, please air out the room
before using the air purifier.
Check the filter replacement indicator
and clean or replace the filter if
necessary.
Is intake/vent dusty? Clean the air vent/intake.

CAC-I0510FW
Input : 100-240V , 50Hz/60Hz
Output : 24V / 1.2A
23W
103.2 m³/h
under 55dB (A)
Replaces the air 2x per hour in 228 sqft (21.1m²)
Replaces the air 4x per hour in 114 sqft (10.6m²)
Mechanical dust collecting method
7.7 x 7.7 x 15.3 (inch)
4.4 lbs
For indoors
17
Product Specifications
1. The information (exterior, design, and specifications) provided in this User Manual is subject to change without prior
notice to improve the quality of the device.
2. CADR (Clean Air Delivery Rate)* is tested based on GB/T 18801-2015 Standard.
3. Room Coverage** is based on the Air Change Per Hour or ACPH which is how many times per hour the air in your
room will be fully purified.
The air purifier will clean the air 2 times per hour in a 228 sq. ft. Room and 4 times per hour in 114 sq. ft. room.
Product parts may wear out due to heat, moisture, dust and other causes over time, which in tum may cause malfunction of the product.
In the case that
1 Something other than the symptoms coming under "Troubleshooting" in page 15~16 occurs;
2 You can feel electricity when you touch the product with your hands;
3 The power is supplied, but the motor does not work
4 Other malfunctions occur
Please stop using the product.
Please unplug the product and contact our Customer Service Center.
Warranty
For questions about our warranty or to look at our other products, please visit our website.
USA : www.cuckooamerica.com India : www.cuckooindia.in
Vietnam : www.cuckoovina.com Indonesia : www.cuckoo.co.id
Malaysia : www.cuckoo.com.my
Category Air Purifier
Inquiry about Malfunction
Model
Power Supply
Rated Power Input
CADR(Clean Air Delivery Rate)*
Noise
Coverage Area**
Dust Collecting Method
Product Size
Product Weight
Place for Use

MEMO

MEMO

Z0383-0097A0.Rev0
We provide satisfying consultation and services concerning your complaints,suggestions, and recommendations
upon receiving your troubledproduct model name, status, and contact information.
♣ After reading this manual, keep it in a place easily accessible to the user for future reference.
♣ Caution : Please read this manual carefully to ensure safety and a longer product lifespan.
USA : www.cuckooamerica.com India : www.cuckooindia.in
Vietnam : www.cuckoovina.com Indonesia : www.cuckoo.co.id
Malaysia : www.cuckoo.com.my
