Introduction 1
Cat. No. 01023095
Introduction
Read this Manual First
Before you operate the Culligan® Series M2 reverse osmosis systems, read this manual to become familiar with the
device and its capabilities.
Culligan®Series M2 reverse osmosis systems are designed to meet the needs of applications for high quality water. This
manual contains important information about the unit, including information needed for installation, operating, and mainte-
nance procedures. A troubleshooting section provides a guide for quick and accurate problem solving.
In order for the water treatment system to continue to provide high quality water, you must develop a thorough under-
standing of the system and its operation. Review this manual before making any attempt to install, operate, or service
the system. Installation or maintenance done on this system by an untrained service person can cause major damage to
equipment or property damage.
About this Manual
This manual:
• Familiarizes the operator with the equipment
• Explains installation and setup procedures
• Provides basic programming information
• Explains the various modes of operation
• Gives specifications and troubleshooting information
This publication is based on information available when approved for printing. Continuing design refinements could cause
changes that may not be included in this publication.
Safe Practices
Throughout this manual there are paragraphs set off by special headings.
Notice
Notice is used to emphasize installation, operation or maintenance information which is important, but does not present
any hazard. For example,
NOTICE The nipple must extend no more than 1 inch above the cover plate.
Caution
Caution is used when failure to follow directions could result in damage to equipment or property. For example,
CAUTION! Disassembly while under water pressure can result in flooding.
Warning
Warning is used to indicate a hazard which could cause injury or death if ignored. For example,
WARNING! Electrical shock hazard! Unplug the unit before removing the timer mechanism or
cover plates!
The CAUTION and WARNING paragraphs are not meant to cover all possible conditions and situations that may occur. It
must be understood that common sense, caution, and careful attention are conditions which cannot be built into the equip-
ment. These MUST be supplied by the personnel installing, operating, or maintaining the system.
Be sure to check and follow the applicable plumbing codes and ordinances when installing this equipment. Local codes
may prohibit the discharge of acid or caustic solutions to drain. An extra solution tank should be used to neutralize the
solution before discharging to drain.
Use protective clothing and proper face or eye protection equipment when handling chemicals or power tools.

2 Culligan® Series M2 Reverse Osmosis 2 Cat. No. 01023095
Features
The M2 Series Reverse Osmosis systems are the direct result of Culligan’s long time experience in membrane applica-
tions around the world. From process water for any size business to treating water for an entire city, Culligan has the
knowledge and the range of products you need to get the job done.
The M2 reverse osmosis system is sized to serve many small-to-medium-sized applications that require high-quality
reverse osmosis water. It is designed with the flexibility to closely match your treatment requirements from 2.8 to 6.9 gal-
lons per minute (4,000 to 10,000 gallons per day). A rich standard feature set with multiple options can satisfy virtually any
application. Select the right size and choose any options needed to complete your system.
Key Product Features
• Simple System Integration
• Global Product Platform
• Flexible Configurations
• Quick Delivery/Easy Installation
• Exclusive Culligan Advanced Electronics
• Historical Operating Data
• Alarm Recognitions
• US Standard and Metric Readings
• Remote Monitoring Options
• Telemetry Options
• Real Time Clock: Tracks date and time has five-year battery back up.
• TDS Probe: TDS probe measures product water quality.
• Remote Alarm Output Connection (Optional): Provides either a N.O. or N.C. Dry Contacts. This feature can be
used to activate an alarm or programmed into a customers (DCS) building alarm system.
GBE RO Controller (GROC) Features
System Computes Normalized Flow
The system computes normalized flow and can be set to trigger an alarm if the normalized flow drops below a specified
limit.
Power Up Mode
The system can be configured to either go to standby mode or to automatically return to making RO water in the event of
power loss and restoration.
Storage Tank and Pressure Logic
The system has the ability to monitor high and low level switches in an atmospheric storage tank and a pressure switch in
a pressurized storage tank to automatically put the system into standby mode when the tank is full.
Pretreatment Lockout
Allows for single softener or filter pretreatment that can be set to go into regeneration or backwash cycle at low water use
periods and have the RO in standby until cycle is completed. RO product water tank would need to be sized correctly
based on flow demand if continuous RO product water is required.
GBE Historical Data
The GBE RO Controller stores basic performance data over the lifetime of the membranes as an aid to optimizing RO
performance and determining when the membranes need to be cleaned or replaced.
Flush Options
The system offers five different membrane flush modes to improve performance and extend membrane life.

Features 3
Cat. No. 01023095
Target TDS
The RO system keeps track of the average product water TDS whenever the RO system is operating, mixing lower quality
water with product water to meet the average product water TDS.
Communications via Modem
An optional modem and monitoring service can be used to remotely monitor the RO performance over time. This service
can also be used to alert the customer and the Culligan dealer in the event that an alarm or error condition occurs.
Wireless Remote Communication
An optional wireless remote can display the current operational status and performance statistics up to 200 feet from the
G1 RO system.
PLC Outputs Available
The GBE Controller collects data once per minute and then streams the data to a customer-owned PLC for data collection
or monitoring. Customer would have to write code to take text information and convert the data for their data collection
system. For more information, see Culligan P/N 01021512 Advanced Communication Manual.
This data, once converted from a text stream, can easily be imported to an excel spreadsheet and the data logged can
then be graphed and trended.
Multi-Unit RO
The GBE RO controller supports two multi-unit modes: Two Pass and Duplex-Alternating.
When in two-pass or duplex-alternating mode, the system is configured to support two GBE RO controllers that are con-
nected together using the communication cable (P/N 01016327). One of these boards is set as the master, controlling the
operations of the other unit, also known as the slave. The slave unit performs as a sensing device.
• When in Two-Pass RO mode, the primary unit, identified as the master, issues commands to control the secondary
unit, identified as the slave.
• The GBE RO controller controller is capable of coordinating the alternating operation of two RO units plumbed in
parallel. This operation mode is designed for situations where RO redundancy is desired.

4 Culligan® Series M2 Reverse Osmosis 4 Cat. No. 01023095
Error Flags (E-Mail Notice Service Level 2)
• Low inlet pressure
• Low RO Recovery/Low Normalized flow
• High RO Recovery
• High Product TDS
• Maximum RO pump hours per day
• External Alarm Input
Wireless Remote Communication on Main Screen
• Most recent RO % recovery
• Total feed water gallons since new
• Total product water since new
• Reject flow
• Most recent RO membrane normalization data
• TDS Out
• Any current text error messages
RS 232, RS 485, and MODBUS Outputs Available
The GBE Controller collects data every one minute and can stream the texted data to a customer’s own PLC for data
collection or monitoring. The Errors and historical data are listed below. Customer would have to write code to take text
information and convert the data for their data collection system.
Data Stream Available
• RO Status: Running, Standby or Offline
• All current Error Flags listed above
• Most recent feed flow in GPM
• Most recent product flow in GPM
• Total product gallons produced in gallons since new
• Total feed water gallons since new
• Most recent Normalized flow in GPM
• Total pump hours
• RO Product tank level switch status (Hi/Low or Opened/Closed)
• Most recent %RO Recovery
• Most recent product TDS
• Daily average gallons of product water produced
This data, once converted from a text stream, can easily be imported to an excel spreadsheet and the data logged can
then be graphed and trended.

Series M2 Specifications 5
Cat. No. 01023095
Series M2 Specifications
NOTE The International Specifications for M2 are in Appendix A on page 87.
M2-2 M2-3 M2-4 M2-5 M2-6
Nominal Capacity, GPD* 4000 5800 7500 9000 10000
Dimensions, Series M2 Units
Width - in [mm] 25.8 [655.3]
Depth - in [mm] 29.3 [744.2]
Height - in [mm] 52.6 [1336]
Operating Weight lb [kg] 198 [89.1] 228 [102.6] 258 [116.1] 288 [129.6] 318 [143.1]
Unit Connections
Inlet (NPT) 0.75"
Product (Tube) 0.5"
Concentrate (Tube) 0.5"
Electrical
Motor Horsepower (hp) 1.0
Power Requirement (VAC/Hz/phase) 208–230/60/1
Full Load Current (amp) 3.4-3.7
Hydraulic - Prefilter
Housing Quantity 2 3 4 5 6
Cartridge Quantity 1
Cartridge Size - in [mm] 10 [254]
Cartridge Rating (micron) 5
Hydraulic - RO
RO Housing Quantity 2 3 4 5 6
RO Element Quantity 2 3 4 5 6
RO Element Length - in [mm] 40 [1016] 40 [1016] 40 [1016] 40 [1016] 40 [1016]
Product Flow - gpm [L/min]* 2.78 [10.52] 4.03 [15.25] 5.21 [19.72] 6.25 [23.66] 6.94 [26.29]
Concentrate Flow - gpm [L/min]* 2.78 [10.52] 2.69 [10.16] 3.47 [13.14] 2.08 [7.89] 2.31 [8.76]
Recovery (%)*
Design 50 60 60 75 75
Minimum 40 50 50 60 60
Maximum Module Feed Pressure psig [kPa] 160 [1103]
Nominal Module Feed Pressure psig [kPa] 140 [965]
Maximum Product Pressure psig [kPa] 40 [276]
Operating Temperature °F [°C] 40–100 [4–38]
Inlet Pressure
Minimum, dynamic psig [kPa] 15 [103]
Maximum, dynamic psig [kPa] 40 [276]
Maximum, static psig [kPa] 100 [689]
Required Inlet Feed Flow gpm [L/min] 5.56 [21.0] 6.71 [25.4] 8.68 [32.9] 8.33 [31.5] 9.26 [35.1]
Pump Flow @ 125 psi gpm [Lmin] 11.0 [41.6] 11.0 [41.6] 11.0 [41.6] 11.0 [41.6] 11.0 [41.6]
Salt Rejection, Nominal (%) 97 97 97 96 95
†Calculated using a 0.85 fouling factor
*Nominal capacity based on new RO membranes operating on a properly pretreated feed water of 500 ppm TDS as NaCl,
77 °F (25 °C), Silt Density Index (SDI) below 3, and supplying water to atmosphere. Productivity will vary depending on
the actual feed water quality and temperature.

6 Culligan® Series M2 Reverse Osmosis 6 Cat. No. 01023095
Unit Configurations
An M2-6 unit is pictured in Figure 1. See “M2 RO Parts Diagrams and Lists” on page 73 for a list of component part
numbers.
Membranes
Product Flow Meter
RO Controller (GROC)
Pump
Pump Feed Pressure
Prefilter
Recirculation Control
Waste Control
Figure 1. M2 RO front view.

RO Installation 7
Cat. No. 01023095
RO Installation
Unpacking the RO
This manual, the warranty, and registration card are packed in the control assembly box. Please complete the registration
card and mail it promptly.
NOTICE Examine each unit component carefully to check for loose or damaged parts. Report any apparent
or concealed shipping damage to the freight carrier immediately.
Materials Required
To install the system, the following items are required:
1. Level
2. Drill
3. Screwdrivers, including a small, flat-bladed (1/8” wide) screwdriver for wiring
4. Adjustable wrench
5. Tubing;
All—Nat 1/2” P.E. Tube, P/N 00901801 or 1/2" PVC piping Sched. 80 for Product
All—Nat 1/2” P.E. Tube, P/N 00901801 for Concentrate Waste.
All—3/4" PVC Sched. 80 for Feed
6. Bucket calibrated and stopwatch for taking flow rates
7. Clean rags
8. Thermometer
9. Portable Total Dissolved Solids meter
10. Safety glasses
Installation Location
The specification data lists the dimensions. Note that these figures do not account for working space around the unit and
the space for plumbing connections.
NOTICE The installer is responsible for the power supply to the unit.
The steel frame is designed to distribute the operating weight on an even floor space. If the floor is uneven, grout beneath
the steel frame feet so that the unit is evenly supported. Secure the base of the frame with four (4) 5/16” diameter bolts.
NOTICE Do NOT use any bolt size smaller than 5/16" diameter.
The unit must be located near a drain able to handle 3.5 gallons per minute (13 liters/min). This is in addition to the flow
from any other water treatment equipment.
CAUTION! The system must not be located near any corrosive chemicals which may cause failure
of the plastic or metal parts of the unit. In addition, do not locate the unit where the tem-
perature may exceed the feed water temperature limits.
A 230 VAC/60 Hz/single-phase grounded power supply with 15 Amp fuse protection and a local disconnect switch is
required.
WARNING! The system must be grounded. An improperly grounded unit could cause injury from
electrical shock!

8 Culligan® Series M2 Reverse Osmosis 8 Cat. No. 01023095
RO Module Tubing
For 3-D tube fitting diagrams, see the parts section starting on page 79.
CENTER PORT
OF END CAPS
CENTER PORT
OF END CAPS
CENTER PORT
OF END CAPS
OFF-CENTER PORT
OF END CAPS
OFF-CENTER POR
T
OF END CAPS
OFF-CENTER POR
T
OF END CAPS
Figure 2. Module Tubing, two to four membranes.

RO Installation 9
Cat. No. 01023095
CENTER PORT
OF END CAPS
CENTER POR
T
OF END CAPS
CENTER POR
T
OF END CAPS
OFF-CENTER POR
T
OF END CAPS
OFF-CENTER PORT
OF END CAPS
OFF-CENTER PORT
OF END CAPS
Figure 3. Module Tubing, five or six membranes.

10 Culligan® Series M2 Reverse Osmosis 10 Cat. No. 01023095
WARNING! The system must be grounded. An improperly grounded unit could cause injury
from electrical shock!
Plumbing Installation
Refer to the appropriate hydraulic schematic/flow diagram on page 71 for further information.
Feed Water Connections
Connect pipe or tubing to the Feed water inlet. Observe the following:
1. To minimize pressure loss, the pipe or tubing size should be at least 3/4”.
2. Install optional pressure gauges (quantity 2 of P/N D1006272) before and after the pre-filter to measure the
pressure differential across the filter cartridge.
3. Install a tee, with an upstream shutoff valve on the branch, before the feed flow meter to provide a connection
for introducing cleaning solutions.
4. If necessary, install a pressure regulator (100 psi downstream max. setting) in the inlet plumbing, to assure
constant pressure and to prevent harmonic vibration.
5. Install a shutoff valve in the inlet plumbing to simplify maintenance and service.
6. If the feed water can be used for a short period, install bypass plumbing around the unit.
Concentrate Water Connections
1. Direct 1/2" tubing to drain from the outlet of the unit.
2. To prevent siphoning of the water in the unit to drain, raise the concentrate plumbing above the level of the
modules and provide an anti-siphon loop.
WARNING! An air gap must be provided between the end of the concentrate tubing and the
drain to prevent back-siphoning of drain contents.
Product Water Connections
The product water exits on the pump side of the unit in either 1/2” piping or tubing. Connect the product plumbing to the
fitting on the flow meter.
CAUTION! This unit produces high quality product water. This water can be contaminated by
plumbing following the unit or it can corrode the plumbing. Use only plumbing com-
ponents of inert material that are compatible with the application.
The connection of the main product plumbing to service plumbing will depend on how the product water will be stored.
CAUTION! Reverse osmosis elements will fail immediately if product water is allowed to flow
backward into the unit.
Pressurized Storage Tank
The product water can be stored in a pressurized storage tank with the reverse osmosis unit controlled by a pressure
switch. Use the same components used for direct feed (see Figure 4) with the addition of a pressure switch which needs
to be wired to the control panel (see page 72 for RO standard wiring). A pressurized water storage kit is available under
part number D1018976.

RO Installation 11
Cat. No. 01023095
Non-Pressurized Product Water Storage Tank
Connect the product tubing to a bulkhead fitting at the top of the storage tank.
CAUTION! The highest point of the tubing should not be higher than four feet above the top of
the reverse osmosis modules, or the elements may be damaged.
Depending on the type of application, a level control may be required to turn the unit off when the storage tank is full.
Install the level control according to the instructions provided with the control. Refer to the wiring section in this manual for
electrical connections.
NOTICE If a repressurization pump is used, an additional level control is recommended to prevent the
pump from running dry if the storage tank is empty.
To maintain high water quality, a hydrophilic air vent filter, vacuum breaker, pop-off valve, ultraviolet lamp, and pressure
relief valve may be required.
Direct Feed
If the product water is to be used directly, without storage, a few precautions are necessary to prevent damage to the
elements. Install a pressure gauge, pressure relief valve, and a normally-open (“dump”) solenoid in the product water line
as shown in Figure 4. The pressure gauge will allow the operator to monitor the product water pressure. The relief valve,
which should be set to open at 40 psig, will prevent the product water pressure from exceeding 40 psi. The dump solenoid
will relieve all pressure when the unit is off.
*Use of Pressurized Storage Tank requires use of Pressurized Storage Kit D1018976.
When using D1018976 you must set the float switches to be NORMALLY CLOSED
(D1018976)
Figure 4. Direcfeed connection.
Wire the direct feed/pressurized storage solenoid valve in parallel with the motor.
NOTICE Install a check valve after these valves in case the service line remains under pressure. Product
back pressure will decrease the net pressure pushing water through the reverse osmosis ele-
ments. Therefore, the flow of product water will decrease.

12 Culligan® Series M2 Reverse Osmosis 12 Cat. No. 01023095
Electrical Installation
CAUTION! Observe the precautions listed below before the electrical installation of your GROC
controller. Failure to do so might cause permanent damage to the RO controller.
Electrical Installation of M2 RO Controller
Pre-Installation Recommendations
• Follow the local electrical code requirements.
• Be sure electrical power is off and disconnected at the source before completing any wiring/cabling connections.
• DO NOT include the GROC wiring cables in any conduit or raceway containing other 120-volt or higher circuits.
• Maintain a distance of at least 10 feet between the GBE controller and any electrical distribution panels, raceways
carrying 300 volts or more.
• Use the cabling provided. Failure to do so may affect performance of the GBE controller adversely.
Series M2 Electrical Installation
To open the control panel, loosen the two screws and carefully open the cover by rotating it to the left.
Motor Cord
Incoming Power
Product TDS
Feed Flow Meter
Solenoid Valve 1
Optional for Fast
Flush Kit 01025703
Product Flow Meter
Plugged
Pressure Switch
Figure 5.M2 controller connections.

GROC Board Layout 13
Cat. No. 01023095
GROC Board Layout
Series Global RO Controller Circuit Board Layout—Front
NOTE For a detailed explanation on wiring the circuit boards, refer to “GBE RO Controller Wiring” on page 72
Keypad connector
Battery
CR2032 (Postitive Side Up)
OLED display
Figure 6. GROC circuit board layout—front
P/N: XXXXXXXX rev. X
VENDOR: XXXXXX
DATE CODE: WK/YY
HEX FILE: XXXXXXXX rev. X
Power
Hi and Lo Float
Switches (J12)
Inlet Flow Meter (J13)
MT Board (J20)
Remote Display
RF Board Connector
Modem
Connectors
Aux Board
Product Flow Meter (J1)
Pressure Switch and
Pretreat Lockout (J2)
24VAC
Figure 7.GROC circuit board layout—back

14 Culligan® Series M2 Reverse Osmosis 14 Cat. No. 01023095
NOTE For Series M2 RO Systems, make sure the voltage selector switch is set at 230 VAC.
115
230
Voltage Selector Switch Transformer
Fuse 315mA
Power
115V-230VAC
50-60Hz
Fuse 5A
Relays
Figure 8.GBE 115V/230V relay board.

GROC Programming 15
Cat. No. 01023095
GROC Programming
Program Data Input
There are a few items to note that can make programming the Culligan®Global Reverse Osmosis Controller (GROC)
easier:
Slew Rates This term refers to the speed at which the display moves through the input of material. For ex-
ample, holding down the up arrow key for (5) seconds when inputting minutes for Time of Day
will cause the minutes to pass in (10) minute blocks of time. Press the up arrow or down arrow
keys for shorter periods (less than 5 seconds) will slow the rate. To move through the program-
ming slowly, do not hold down the up arrow or the down arrow keys.
Beeper A beeper is available to assist the user by providing an audible tone (about 70 decibels) to signi-
fy valid (one beep) and invalid (three beeps) key presses. The beeper can be deactivated in the
programming mode. (If error occurs, beep will still sound even if set to “No” programming.)
Programming
Mode Timeout
If there is no keypad activity for a one (1) minute period while in the programming mode, the
controller will exit the programming mode and return to the main display. Any setting that was
changed prior to the control timing out will revert to the original value. Pressing the CHECK
MARK button saves the setting.
Program Input
Acceptance
For programming information to be accepted, the check mark key must be depressed prior to
programming mode timeout.
NOTE The following programming section is used for the G1, M2, G2 & G3 RO systems. The controller used
on the G1 & M2 RO units have the same programming but the controller has fewer features. Unless
otherwise specified, the programming is applicable to all units. Features not available on the G1 and
M2 are noted with a double-cross symbol (‡).

16 Culligan® Series M2 Reverse Osmosis 16 Cat. No. 01023095
Menu and Key Navigation
Key Pad Familiarization
UP ARROW Button
CHECK MARK Button
DOWN
ARROW Button
CANCEL
or EXIT Button
UP ARROW button: scrolls up the menu
Controller
Remote
DOWN ARROW button: scrolls down the
menu
CHECK MARK button: selects the highlight-
ed option, opens a new screen, or accepts a
changed setting
CANCEL or EXIT button: returns to the pre-
vious screen or cancels a changed setting
NOTE Hold down the or button to quickly scroll through the setting without repeatedly pressing the
button.
CAUTION! Use the and only to scroll through the menu settings. Do not use to perform
scrolling. Improper use of might cause the controller to reset certain functions.
