Curtis 47587421001 Operating instructions

1 of 3
INSTALLATION & OWNER’S MANUAL
CLUB CAR CARRYALL
DOME LIGHT
p/n: 47587421001
(*=Not including accessories)
Requires:
Carryall 4x2 models 300, 500 550 and 700:
Overheard Console Kit (47587420001)
Carryall 4x4 models 1500, XRT 1550, 1700 and XRT 1550 SE:
Overhead Console Kit (47617522001)
Approximate Installation Time *
Experienced Dealer Technician – 15 Minutes
Average Dealer Technician – 30 Minutes
Do-It-Yourself – 45 Minutes
Approximate Product Specifications
Rev. C, 11/25/2020
p/n: IM-47587421001
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.

2 of 3
For accurate installation, proper operation, and years of satisfaction, please read and
understand the installation and owner’s manual fully prior to installing the dome light.
From all of us at Curtis, we thank you for choosing our product.
driver and passenger.
Curtis accessory weights are listed in product
add additional weight to the base vehicle. All
Curtis Cabs, blades and general accessories
ADDED
WEIGHT
brochures. Deduct the accessory's total weight
from the vehicle's rated capacity and never
exceed the vehicle's rated capacity including
Exposure to Carbon Monoxide
can Cause illness, serious injury or
death. Never operate vehicle if suspicious of Carbon Monox-
ide. Inspect exhaust system for leaks monthly. Leaks can
result from loose connections, corrosion, cracks or other
damage to the exhaust manifold. If leaks are found, repair or
replace exhaust system. Do not use vehicle until repair or
replacement is complete.
• #1 (small) Phillips screwdriver
• 5/16” open-end wrench or socket
• 3/16” Allen wrench or driver
WARNINGS, TIPS, & REQUIRED TOOLS
TOOLS REQUIRED:

CAB INSTALLATION
3 of 3
CARRYALL 4x2:
1. Vehicle Preparation:
1.1 Remove the plastic roof from the metal roof pan
by removing the 6 button head bolts, metal fender
washers and rubber fender washers keep this
hardware for reuse. See figure 1.1.
2. Dome Light Installation:
2.1 Locate the holes at the center-front of the metal
roof pan for the dome light. Poke through the roof
headliner from underneath with a small
screwdriver or awl. See figure 2.1.
2.2 Feed dome light wires through the slotted hole in
the roof pan, then secure the light to the pan with
the #6-32 x 3/4” pan head screw and #6-32 Nylon
locknut supplied. Shown in figure 2.2. Torque to
10 inch-lbs.
2.3 Connect orange/black wires to dome light.
2.4 If accessory installation is complete, reattach roof
at this time. To the roof bolts, apply Loctite
Threadlocker Blue 240 and tighten until the rubber
washer begins to compress.
Fig. 1.1
Fig. 2.1
Hole For Strobe
Light wires
Hole For Dome
Light wires
Pre-drilled holes
for Dome Light
Main Harness
Fig. 2.2
CARRYALL 4x4:
NOTE: If overhead console is already installed, lower console
before proceeding.
3. Dome Light Installation:
3.1 Push the plastic plug out of the hole in the underside of
the overhead console, near the switches.
3.2 Feed dome light wires through the larger hole in
the console, then secure the light to the pan with
the #6-32 x 3/4” pan head screw and #6-32 Nylon
locknut supplied. Shown in figure 3.2. Torque to
10 inch-lbs.
3.3 Connect orange/black wires to dome light.
3.4 Proceed with installation of any additional
accessories including the overhead console.
Fig. 3.2
Hole For wires
Remove and
discard
