Custom Equipment PS-1030 Use and care manual

OPERATION & SAFETY
MANUAL
SUPO-741 | REV A
PS-1030
PS-1430
MOBILE ELEVATING WORK PLATFORM
BY CUSTOM EQUIPMENT LLC

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
2
NOTES
Custom Equipment, LLC
Original instructions are written in English.
The purpose of this Operations and Safety manual is to provide users with the instructions and operating procedures
essential to properly and safely operate the Custom Equipment Hy-Brid Lift for its intended purpose, and to position
personnel and their necessary tools and materials.
THE OPERATION AND SAFETY MANUAL MUST BE
READ AND UNDERSTOOD PRIOR TO OPERATING THE MACHINE.
• The user/operator should not accept operating responsibility until the manual has been read and understood as well
as having operated the lift under supervision of an experienced and qualified operator.
• Because the manufacturer has no direct control over machine application and operation, proper safety practices are
the responsibility of the user and all operating personnel.
ANY MODIFICATION ON THIS MACHINE WITHOUT THE EXPRESS WRITTEN CONSENT OF THE
MANUFACTURER IS PROHIBITED.
Fall protection notice:
The guardrail system around the perimeter of the platform is the fall protection system for self-propelled elevating
work platforms per the ANSI A92.6 Standard. It is prohibited to use an Mobile Elevated Work Platform manufactured
by Custom Equipment, LLC, with any portion—or all—of the guardrails removed. Lanyard anchorage points on
this type of equipment are not required to conform to the applicable standard. However, if anchorage points for
lanyard attachments are required by site authorities or other regulations, the anchorage points on all equipment
manufactured by Custom Equipment, LLC are recommended to be used for work positioning restraints of personnel
only. Lanyard lengths are to be determined by operator/owner to restrict the operator to the confines within the
guardrail system.
USE OF FALL ARREST SYSTEMS ATTACHED TO ANCHORAGE POINTS
ON EQUIPMENT MAY CAUSE MACHINE TO TIP, RESULTING IN SERIOUS INJURY OR DEATH.
Lanyard
Attachment
Point
DANGER
WARNING
WARNING
General Information
2647 Hwy 175
Richfield, WI 53076
U.S.A.
P: [phone]
F: [phone]
www.hybridlifts.com
Service Information
P: [phone]
E: [email protected]
Parts Information
P: [phone]

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
3
FOREWORD
Original instructions are written in English.
The purpose of this Operations and Safety manual is to provide users with the instructions and operating procedures
essential to properly and safely operate the Custom Equipment Hy-Brid Lift for its intended purpose, and to position
personnel and their necessary tools and materials.
THE OPERATION AND SAFETY MANUAL MUST BE
READ AND UNDERSTOOD PRIOR TO OPERATING THE MACHINE.
• The user/operator should not accept operating responsibility until the manual has been read and understood as well
as having operated the lift under supervision of an experienced and qualified operator.
• Because the manufacturer has no direct control over machine application and operation, proper safety practices are
the responsibility of the user and all operating personnel.
ANY MODIFICATION ON THIS MACHINE WITHOUT THE EXPRESS WRITTEN CONSENT OF THE
MANUFACTURER IS PROHIBITED.
Fall protection notice:
The guardrail system around the perimeter of the platform is the fall protection system for self-propelled elevating
work platforms per the ANSI A92.6 Standard. It is prohibited to use an Mobile Elevated Work Platform manufactured
by Custom Equipment, LLC, with any portion—or all—of the guardrails removed. Lanyard anchorage points on
this type of equipment are not required to conform to the applicable standard. However, if anchorage points for
lanyard attachments are required by site authorities or other regulations, the anchorage points on all equipment
manufactured by Custom Equipment, LLC are recommended to be used for work positioning restraints of personnel
only. Lanyard lengths are to be determined by operator/owner to restrict the operator to the confines within the
guardrail system.
USE OF FALL ARREST SYSTEMS ATTACHED TO ANCHORAGE POINTS
ON EQUIPMENT MAY CAUSE MACHINE TO TIP, RESULTING IN SERIOUS INJURY OR DEATH.
Lanyard
Attachment
Point
DANGER
WARNING
WARNING

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
4
TABLE OF CONTENTS
NOTES.......................................................................................................................................................................................... 2
FOREWORD ................................................................................................................................................................................ 3
TABLE OF CONTENTS............................................................................................................................................................... 4
INDEX OF FIGURES.................................................................................................................................................................... 5
SECTION 1 | SAFETY .................................................................................................................................................................. 6
1.1 | SAFETY SYMBOLS.......................................................................................................................................................................... 6
1.2 | GENERAL RULES AND PRECAUTIONS .................................................................................................................................. 6
1.3 | SAFETY FEATURES ........................................................................................................................................................................ 7
1.4 | SAFETY INDICATORS & INTERLOCKS ..................................................................................................................................... 7
1.5 | SAFETY CONTROLS ..................................................................................................................................................................... 8
1.6 | MAINTENANCE LOCK ................................................................................................................................................................. 9
1.7 | SAFETY GUIDELINES.................................................................................................................................................................. 10
SECTION 2 | PRODUCT DESCRIPTION................................................................................................................................ 12
2.1 | GENERAL....................................................................................................................................................................................... 12
SECTION 3 | DECALS............................................................................................................................................................... 14
3.1 | DECAL LOCATION...................................................................................................................................................................... 14
3.2 | DECAL DESCRIPTIONS............................................................................................................................................................. 14
3.3 | DECAL SYMBOLS........................................................................................................................................................................ 16
SECTION 4 | TRANSPORT, HANDLING & STORAGE..........................................................................................................20
4.1 | PRELIMINARY UNPACKING INSTRUCTIONS AND DEALER INSPECTION ..................................................................20
4.2 | STORAGE......................................................................................................................................................................................20
4.3 | PREPARATION FOR TRANSPORT ..........................................................................................................................................20
4.4 | LIFTING AND TIEDOWN POINTS.........................................................................................................................................20
4.5 | FORK LIFT POCKETS ................................................................................................................................................................. 21
SECTION 5 | OPERATION ....................................................................................................................................................... 22
5.1 | BEFORE YOU OPERATE ............................................................................................................................................................22
5.2 | STARTUP/SHUT DOWN............................................................................................................................................................23
5.3 | AUDIO ALARMS...........................................................................................................................................................................24
5.4 | DRIVING AND STEERING .........................................................................................................................................................25
5.5 | ELEVATING AND LOWERING ..................................................................................................................................................25
5.6 | EXTENDING THE PLATFORM..................................................................................................................................................26
5.7 | DAILY MAINTENANCE ............................................................................................................................................................... 27
5.8 | CHARGING THE BATTERY....................................................................................................................................................... 27
5.9 | BATTERY DISPLAYS ....................................................................................................................................................................28
SECTION 6 | PRESTART INSPECTION ................................................................................................................................ 32
6.1 | PRESTART INSPECTION CHECKLIST...................................................................................................................................32
NOTES........................................................................................................................................................................................34

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
5
INDEX OF FIGURES
Revisions:
REV A .............................................................................................................................................................................................May 2019
FIGURE 1: Pothole Guard........................................................................................................................................................................ 7
FIGURE 2: Emergency Lowering Valve................................................................................................................................................8
FIGURE 3: Down Instruction ..................................................................................................................................................................8
FIGURE 4: Maintenance Lock Pin use ................................................................................................................................................. 9
FIGURE 5: Maintenance Lock Pin storage.......................................................................................................................................... 9
FIGURE 6: Decal Locations .................................................................................................................................................................. 14
FIGURE 7: Fork Pockets......................................................................................................................................................................... 21
FIGURE 8: Tie-Down Points ................................................................................................................................................................. 21
FIGURE 9: Center of Gravity................................................................................................................................................................. 21
FIGURE 10: Base Controls.....................................................................................................................................................................22
FIGURE 11: Platform Controls..............................................................................................................................................................22
FIGURE 12: Main power switch ...........................................................................................................................................................23
FIGURE 13: Main power switch o.....................................................................................................................................................23
FIGURE 14: Main power switch knob removed ..............................................................................................................................23
FIGURE 15: Secure Location ................................................................................................................................................................23
FIGURE 16: Slide Lock............................................................................................................................................................................26
FIGURE 17: Standard Battery Charge Indicator Location..............................................................................................................28
FIGURE 18: Lester SLM Battery Charge Indicator Location .........................................................................................................29
FIGURE 19: Signet Battery Charge Indicator Location ..................................................................................................................30
FIGURE 20: PCS/Dual Pro Battery Charge Indicator Location....................................................................................................30

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
6
1.1 | SAFETY SYMBOLS
FAILURE TO FOLLOW THIS WARNING WILL CAUSE
DEATH OR PERSONAL INJURY.
“DANGER” indicates an imminently hazardous situation,
which, if not avoided, will result in death or serious
injury.
FAILURE TO FOLLOW THIS WARNING MAY CAUSE
DEATH OR PERSONAL INJURY.
“WARNING” indicates a potentially hazardous situation,
which, if not avoided, could result in death or serious
injury.
FAILURE TO FOLLOW THIS WARNING MAY CAUSE
INJURY OR DAMAGE TO EQUIPMENT.
“CAUTION” indicates a potentially hazardous situation
which, if not avoided, could result in minor or
moderate injury or damage to equipment.
1.2 | GENERAL RULES AND PRECAUTIONS
An operator of any type of work platform is subject to certain hazards that cannot be protected by mechanical
means. It is therefore essential that operators be competent, careful, physically and mentally fit and thoroughly
trained in safe operation of this machine.
Although Custom Equipment, LLC conforms to specified ANSI & OSHA requirements, it is the responsibility of the
owner to instruct operators with the safety requirements made not only by Custom Equipment, LLC, but by the
various safety boards in your area, as well as additional requirements set forth by ANSI and OSHA. If you come
across a situation that you think might be unsafe, stop the platform and request further information from qualified
sources before proceeding.
NEVER REACH BETWEEN SCISSORS LINKS OR PROP UP PLATFORM.
STEERING BRACKETS EXTENDING BEYOND THE SIDES OF
THE BASE MAY OCCUR IN TIGHT TURNING SITUATIONS.
Potential damage to walls, etc., may occur in tight turning situations due to the steering brackets extending beyond
the sides of the base.
SECTION 1 | SAFETY
DANGER
CAUTION
WARNING
CAUTION
WARNING

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
7
SECTION 1 | SAFETY
1.3 | SAFETY FEATURES
• Puncture-Proof Wheels.
• Guardrails—43.5 in (1.1 m) height with 6 in (15 cm) kick plates.
• Non-Slip Deck.
• Entrance Gate.
• Automatic Parking Brake.
• Free Descent Protection. A velocity fuse is installed in the hydraulic circuit to prevent the platform from
descending in case of a ruptured hydraulic hose. The platform is hydraulically locked until hose has been
replaced.
• Decals: Danger, Caution, and Warning decals are displayed at various locations on this unit.
• Key Switch Security. A key switch is required to prevent unauthorized use.
1.4 | SAFETY INDICATORS & INTERLOCKS
Tilt Alarm
An audible alarm sounds when the machine is tilted more than 2°. Elevating and driving functions are inhibited.
Lower the platform and move to a level surface.
Descent/Motion Alarm
An audible alarm sounds when the machine is lowering. Some models also sound an alarm when the machine is
elevating or driving.
Pothole Protection
Pothole guards are required to be in place when the lift is in the elevated position. If the guards are blocked or not
functioning properly, elevating functions will be inhibited. Lower the machine and do not operate until the problem
is repaired or the obstruction is removed.
FIGURE 1: Pothole Guard

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
8
IF PLATFORM SHOULD FAIL TO LOWER, DO NOT ATTEMPT TO CLIMB
DOWN THE BEAM ASSEMBLY. SERIOUS INJURY MAY RESULT. HAVE
AN EXPERIENCED OPERATOR USE THE EMERGENCY LOWERING
PROCEDURE TO SAFELY LOWER THE PLATFORM.
SECTION 1 | SAFETY
1.5 | SAFETY CONTROLS
Descent - Manual Override
For manually lowering the scissors, a manual valve on the pump is provided. Lift the panel on the side cover and
locate valve on the hydraulic pump. Push and turn the knob located on down valve counterclockwise to open.
Knob will pop up. To reset, push and turn counterclockwise direction.
FIGURE 2: Emergency Lowering Valve
FIGURE 3: Down Instruction
WARNING
WARNING
WARNING
BEFORE LOWERING PLATFORM, RETRACT THE DECK EXTENSION.
Emergency Stop
This lift is equipped with two emergency stop switches, one at the platform control and one at the base control,
that when activated, will render the unit inoperable until reset. To reset, pull the button out.
PUSHING THE EMERGENCY STOP BUTTON WILL APPLY BRAKES
IMMEDIATELY. THIS MAY CAUSE UNEXPECTED PLATFORM MOVEMENT
AS THE MACHINE COMES TO A SUDDEN STOP. BRACE YOURSELF AND
SECURE OBJECTS ON THE PLATFORM DURING OPERATION OF THE
MACHINE.

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
9
SECTION 1 | SAFETY
FIGURE 4: Maintenance Lock Pin use FIGURE 5: Maintenance Lock Pin storage
1.6 | MAINTENANCE LOCK
The maintenance lock pins must be placed into position whenever the machine is being serviced in the raised or
partially raised position. Serious injury and/or death could result if maintenance lock is not used properly.

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
10
SECTION 1 | SAFETY
1.7 | SAFETY GUIDELINES
Only qualified operators may operate this unit.
• All operators must read and understand the Operation and Safety Manual. They must understand all decals and
warning labels on unit.
• Do not work on platform if your physical condition is such that you feel dizzy or unsteady in any way.
• Do not neglect/misuse machine. Report any misuse of equipment to proper personnel.
• Prevent unauthorized use; when unit is not in use, remove key.
• It is recommended all personnel on unit wear approved personal protective equipment (PPE), i.e. head gear.
Use machine only for purposes for which it was intended.
• Lift should never be used as a crane.
• Do not exceed the load capabilities of the platform.
• Distribute load evenly over platform floor area.
• Never use unit as electrical grounds for arc welding.
• Do not override any hydraulic, mechanical, or electrical safety devices.
Check job site for unsafe working conditions.
• Watch out for others. Keep others clear of operating platform. Never allow others to pass under a raised
platform or position the platform over someone.
• Avoid contact with fixed objects (walls, buildings, or other machinery, etc) or moving vehicles (automobiles,
cranes, etc).
• Follow any applicable national trac regulations.
• Use indoors only. Lift is not designed for windy conditions or electrical storms.
• Unit must be on hard level surface before elevating. Do not operate on incline or uneven surface.
• You must maintain a clearance between any part of the machine, or its load, and any electrical line or apparatus.
Follow local power line clearance regulations.
DO NOT OPERATE MACHINE NEAR POWER LINES.
THE PLATFORM AND ENCLOSURES ARE NOT INSULATED.
Equipment is only as safe as the operator.
• Do not use ladders or scaolding on the platform to obtain greater height.
• Do not enter or exit platform while machine is in motion.
• Never mount or dismount a raised platform.
• Make sure entry gate is secured before operating machine from the platform.
• Never belt or tie o to an adjacent structure.
• Secure tools and materials.
• Personnel must maintain a firm footing on the platform floor and work only within the platform area.
• It is recommended to avoid sudden braking or steering. Go slowly and leave more maneuvering room during
cold weather operation
Before operation, ensure that the machine is properly serviced.
• Do not use machine if it is not working properly.
• Make sure platform rails and pins are secured.
• Operator shall use the maintenance lock when performing all types of maintenance procedures.
• Do not smoke while charging the battery.
DANGER

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
11
THIS PAGE WAS INTENTIONALLY LEFT BLANK

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
12
Custom Equipment’s Hy-Brid Scissors Lift is a mobile elevating work platform designed to be safe and reliable. The
purpose of the machine is to elevate personnel, along with their necessary tools and materials to overhead work
locations.
Manufacturer approval is required for any use other than the intended use.
Before operation, the operator must read and understand the manufacturer’s operating instructions and user’s safety
rules, or have them explained, understand all labels, warnings, and instructions displayed on the aerial platform or
have them explained, ensure that all occupant of the work platform wear appropriate protective equipment for the
conditions, including the environment in which the work platform will be operated.
The operator must inspect the workplace for environmental hazards such as, but not limited to drop-os, holes,
slopes, debris, floor or overhead obstructions, surface, wind and weather conditions, or presence of unauthorized
persons. Vibration does not create significant hazards on this machine.
PS-1030 PS-1430
Working Height (maximum) 16 ft 4.87 m 20 ft 6.1 m
Platform Height (maximum) 10 ft 3 m 14 ft 4.26 m
Stowed Height 67.42 in 1.71 m 71 in 1.79 m
Ground Clearance (Pothole Guard
Stowed) 3 in 7.7 cm 3 in 7.6 cm
Ground Clearance (Pothole Guard
Engaged) 0.375 in 0.95 cm 0.375 in 0.95 cm
Overall Width 30 in 0.76 m 30 in 0.76 m
Overall Length 69.5 in with step 1.77 m with step 69.5 in 1.77 m with step
Platform (Retracted, Inside) 24 in x 60 in 0.64 m x 1.52 m 24 in x 60 in 0.64 m x 1.52 m
Slide-Out Deck Length 30 in 0.76 m 30 in 0.76 m
Guard Rail Height 43.5 in 1.1 m 43.5 in 1.1 m
Platform Entrance 23.5 in 0.59 m 26.8 in 0.69 m
Step Height 12.5 in 0.32 m 15.33 in 0.39 m
Wheel Base 51 in 1.3 m 51 in 1.3 m
Wheel Track 23.63 in 0.6 m 23.63 in 0.6 m
Turning Radius (Inside) 21 in 0.53 m 21 in 0.53 m
Tire Size (Solid, Non-Marking) - Front /
Rear 10 in 25.4 cm 10 in 25.4 cm
RATED LOAD
Lift Capacity (Evenly Distributed): 750 lb / 2
Persons
340.2 kg / 2
Persons
670 lb / 2
Persons
304 kg / 2
Persons
Slide-Out Deck Capacity 250 lb / 1
Person
113.4 kg / 1
Person
250 lb / 1
Person
113.4 kg / 1
Person
Horizontal/Manual Force 112.5 lb 500 N 100.5 lb 447 N
SECTION 2 | PRODUCT DESCRIPTION
2.1 | GENERAL

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
13
SECTION 2 | PRODUCT DESCRIPTION
FLOOR LOADING PS-1030 PS-1430
Machine Weight (Unloaded) (Approx.) 1415 lb 641.8 kg 1720 lb 780.2 kg
Minimum Wheel Load-Contact
Pressure 75.8 psi 522.9 kPa 87.4 psi 602.3 kPa
Maximum Wheel Load-Contact
Pressure 116.0 psi 800.0 kPa 121.4 psi 836.9 kPa
Minimum Machine Loading-Floor
Pressure 107.0 psf 5.12 kPa 130.0 psf 6.23 kPa
Maximum Machine Loading-Floor
Pressure 163.7 psf 7.84 kPa 180.7 psf 8.65 kPa
ENVIRONMENTAL LIMITATIONS
Wind No Windy Conditions/Indoor Use
Only
No Windy Conditions/Indoor Use
Only
Rated Slope Level Surface Level Surface
Tilt Sensor Activated 2° 2°
Gradeability (Stowed Position) 30% (16.7°) 30% (16.7°)
Temperature -4°F to 104°F -20°C to 40°C -4°F to 104°F -20°C to 40°C
Vibration 8.2 ft/s2max 2.5 m/s2max 8.2 ft/s2max 2.5 m/s2max
Sound - Normal Use, Alarms 86 dB, 100 dB 86 dB, 100 dB 86 dB, 100 dB 86 dB, 100 dB
POWER SYSTEMS - Drive System (Proportional Electric):
Drive Speed (Platform Elevated) 0-0.7 mph 0-0.31 m/s 0-0.7 mph 0-0.31 m/s
Drive Speed (Platform Lowered) 0-2.5 mph 0-1.18 m/s 0-2.5 mph 0-.1.18 m/s
Lift/Lower Speed 21/20 sec 21/20 sec 27/21 sec 27/21 sec
Hydraulic Pressure (max) 1300 psi 8963 kPa 1300 psi 8963 kPa
Hydraulic Fluid Capacity 1.325 gal 5.38 L 1.325 gal 5.38 L
Power System-Voltage 24V DC 24V DC 24V DC 24V DC
Batteries-Deep Cycle Marine (2) 12V, Group
27
(2) 12V, Group
27
(2) 12V, Group
27
(2) 12V, Group
27

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
14
SECTION 3 | DECALS
3.1 | DECAL LOCATION
FIGURE 6: Decal Locations

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
15
SECTION 3 | DECALS
3.2 | DECAL DESCRIPTIONS
ITEM # PART # DECAL MEANING OR DESIGNATION QTY
1112-21-418-50-K
112-21-418-55-K
DECALS,PS-1030 S4
DECALS,PS-1430 S4 1
2 DE1103 DECAL,KEEP 2
3 DE1104 DECAL,CLEAR 2
4 DE717-62 DECAL,SAFETY STRIPE (12.00) 4
5 DE1002 DECAL,WEBSITE 2
6 DE1203 DECAL,MANUAL BOX 1
7 DE1011 DECAL,LWR 2
8 DE1007 DECAL,MAINT LOCK 3
9 DE717-61 DECAL,SAFETY STRIPE (24.00) 2
10 DE1217 DECAL,UPR HB 1
11 DE1209
DE1210
DECAL,CAPACITY,750#,2P,I,W/SO
DECAL,CAPACITY,670#,2P,I,W/SO 2
12 DE1218 DECAL,LANYARD ATTACHMENT,1P 2
13 DE1207 DECAL,HY-BRID LIFTS 1
14 DE1208 DECAL,BRAKE RELEASE/NO TOW 1
15 DE1021 DECAL,CHARGER CORD 1
16 DE1008 DECAL,HYDR FLUID 1
17 DE1219 DECAL,BATT CHARGE DAILY 1
18 DE1013
DE1014
DECAL,WHEEL LOAD PS-1030 S4
DECAL,WHEEL LOAD PS-1430 S4 4
19 DE837 DECAL,CTL LWR HBLGS4 1
20 DE793 DECAL,CTL UPR HBS4,ACT 1
21 DE1204 DECAL,CAPACITY,TOOL TRAY 1
22 DE1022 DECAL,BATT/CHR COMPATABILITY 1
23 DE794 DECAL,CTL UPR ID HBS4,ACT 1
24 DE1023 DECAL,PTP 1
25 DE1230 DECAL,PROP 65 1
26 DE1221 DECAL,MADE IN USA 2
27 DE1236 DECAL,SERIES PS 2
28 DE1237
DE1238
DECAL,PS-1030 INFO
DECAL,PS-1430 INFO 1
29 DE1028 DECAL,E- DOWN LOCATION 1
30 DE1031 DECAL,MADE IN USA MIRROR 1
31 DE1239 DECAL,E-DOWN INSTRUCTION 1
32 DE838 DECAL,CHARGER 1
33 DE1213
DE1214
DECAL,MODEL PS-1030
DECAL,MODEL PS-1430 2
34 DE841 DECAL,BATT DISCONNECT 1
98 N/A SERIAL NUMBER LABEL 0
99 N/A SERIAL NUMBER REFERENCE 0

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
16
SECTION 3 | DECALS
3.3 | DECAL SYMBOLS
• No unauthorized use
• Do not operate this machine unless you have been trained in safe
operation.
• Training includes complete knowledge of the safety and operating
instructions contained in the manufacturer’s manual, your employer’s
work rules, and applicable government regulations.
• An untrained operator subjects himself and others to death or serious
injury.
• Read and understand all dangers and warnings in the operator’s manual
before operating this machine.
• Improper use of this machine could cause death or serious injury.
• Inspect machine and make sure that it is operating properly, that all
name plate and hazard signs are in place and legible, and that the
machine is in accordance with the manufacturer’s maintenance
requirements contained in the operating and maintenance
requirements contained in the operation and maintenance manual and
the daily safety checklist.
• Crushing hazard
• Do not enter the space beneath the work platform or scissor structure
unless the maintenance lock is in place.
• Refer to Maintenance Manual
• Only qualified service personnel may service the machine. Failure to
comply with listed safety precautions may result in machine damage,
personnel injury, or death.
• Replace designated items with manufacturer’s specified equipment
only. Failure to use these items may cause instability of platform.
• Batteries produce explosive gas. Only charge batteries in a well-
ventilated area.
• Do not expose to sparks or flames.
• Do not smoke while charging battery.
• Battery charger cord

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
17
SECTION 3 | DECALS
• Tip hazard
• Tip hazard
• Do not elevate platform on an incline or step.
• Tip hazard
• Do not elevate platform on a slope.
• Tip hazard
• Do not elevate platform on uneven or soft surfaces.
• Indoor use only: No Wind Load
• Electrocution hazard
• This machine is not insulated.
• Maintain safe clearance from electrical lines and apparatus. You must
allow for machine sway, rock or sag and electrical lines swaying.
• This machine does not provide protection from contact with or
proximity to an electrically charged conductor.
• You must maintain a clearance between any part of this machine or its
load and any electrical apparatus. Follow local power line regulations.
• Death or serious injury will result from contact or inadequate clearance.
• Brake release

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
18
SECTION 3 | DECALS
• Manual lowering override
• Battery disconnect
• Fork pocket
• Hydraulic oil level
• Engaging mechanical action: Enable Switch
• Lanyard anchorage point location: Capacity 1 Person
• Lanyard anchorage points are for work positioning restraints only, not
for fall protection.
• Use of fall arrest systems attached to anchorage points on mobile
equipment may cause machine to tip, resulting in serious injury or
death.
x1

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
19
THIS PAGE WAS INTENTIONALLY LEFT BLANK

OPERATION & SAFETY
PS-1030 | PS-1430
SUPO-741
REV A
20
SECTION 4 | TRANSPORT, HANDLING & STORAGE
4.1 | PRELIMINARY UNPACKING INSTRUCTIONS AND DEALER INSPECTION
Maintenance locks must be engaged prior to inspecting or servicing the unit when the platform is elevated.
Inspect machine for any possible damage during shipment; perform pre-delivery inspection. See checklist in the
Maintenance Manual. Reset emergency stop switches, if necessary.
4.2 | STORAGE
After periods of storage or exposure to extremes of ambient conditions (heat, cold, moisture, dust etc.) inspect the
machine. Refer to the Pre-Delivery/Frequent Inspection Checklist of the Maintenance Manual.
4.3 | PREPARATION FOR TRANSPORT
Lower the work platform to the down position. Bring the platform slide-out extension into the retracted position
and lock in place. Turn the key switch to o position. Check the entire machine for loose or unsecured items.
Remove any loose items from machine.
The machine can be pushed by releasing the parking brake at the rear of the machine. Push both levers toward the
floor. To resume normal operation, make sure both levers are up.
Do not attempt to push or tow unit with the brakes applied. Severe gear damage will occur. Towing is not
recommended.
To release brake for winching or pushing
1. Ensure the unit is powered up and in the stowed position.
2. Select ground mode with the key switch on the lower control panel.
3. Press and hold the down function on the lower control panel until a solid tone from the alarm is heard (this
should take approximately 5 seconds).
4. The brakes are released while the solid alarm is present.
5. To reengage the brakes, cycle the power o and on from any of the e-stops or the key switch.
Do not push at speeds more than 2 mph (0.9 m/s).
NOTE: The drive system will not function if the parking brake is released.
4.4 | LIFTING AND TIEDOWN POINTS
Tie-down points are provided for securing the machine on a trailer or truck bed for transport between places of use.
They may also be used as lift points.
DO NOT OVERLOAD BINDERS WHEN SECURING
LOAD FOR TRANSPORT
WARNING
