Cyber Power CPS5000ECH48 User manual

User’s Manual
All-In-One Off-Grid Inverter

Contents
1 Brief Introduction ...........................................................................................................1
1.1 Preface .................................................................................................................................................1
1.2 Target Group ........................................................................................................................................1
1.3 Product Description .............................................................................................................................1
1.4 Basic System Architecture....................................................................................................................2
1.5 Product Overview.................................................................................................................................2
2 Safety Instructions ..........................................................................................................4
3 Installation......................................................................................................................5
3.1 Unpacking and Inspection....................................................................................................................5
3.2 Basic Installation Requirements...........................................................................................................5
3.3 Inverter Connection .............................................................................................................................7
3.3.1 Lead acid battery connection....................................................................................................7
3.3.2 AC Input & Output Connection.................................................................................................9
3.3.3 PV Connection.........................................................................................................................11
3.3.4 Finally assemble......................................................................................................................12
4 Communication Connection..........................................................................................13
5 Dry Contact................................................................................................................... 14
6 Operation .....................................................................................................................15
6.1 Power ON/OFF ...................................................................................................................................15
6.2 Operation and Display Panel..............................................................................................................15
6.3 LCD Display description......................................................................................................................17
7 Specifications................................................................................................................24
8 Trouble Shooting ..........................................................................................................27
9 Manufacturer Warranty................................................................................................28
10 Appendix ....................................................................................................................29

1
1 Brief Introduction
1.1 Preface
This manual describes the assembly, installation, operation and troubleshooting. Please read this
manual carefully and put this manual on some place where is convenient to installation, operation,
obtain. Any modifications of user’s manual, we will not notify the user.
1.2 Target Group
Only qualified and trained electrical technicians are allowed to install and operate the unit.
The unit is compatible with lead acid battery. For lead acid battery, you are easy to find it on the market.
However, we strongly recommend you to contact your installer or CyberPower system to confirm before
the procedure.
1.3 Product Description
The unit is sort of off-grid inverter. It uses surplus PV generation to charge the battery in the day time.
After the sun goes down, the PV generation is unavailable, it discharge the battery or utilize grid
electricity to power the load at night. It enjoys following features:
Pure sine wave inverter
Built-in MPPT solar charge controller
Configurable input voltage range for home appliances and personal computers via LCD setting
Configurable battery charging current based on applications via LCD setting
Configurable AC/Solar Charger priority via LCD setting
Auto restart while AC is recovering
Overload/Over temperature/Short circuit protection
Smart battery charger design for optimized battery performance
Cold start function

2
1.4 Basic System Architecture
Solar power
Generator
OR
Utility External
Battery Packs
Home Appliances
Figure 1-1
As shown in above system diagram, the unit is used to power common house appliances including some
inductive load such as light, refrigerator. Also, diesel generator and power grid can be compensation in
which solar energy is insufficient as well as to charge the battery.
1.5 Product Overview
DEFGHNI
J K M L
A
B
C
O P Q
Figure 1-2

3
NOTE:
For parallel model installation and operation, please check separate” parallel & three phase
installation guide”for the details. Only CPS5000ECH48 have the function.
Tab le 1 -1
Position Description
A LCD Display
B Status Indicator
C Function Buttons
D Power ON/OFF Switch
E Dry Contact
F RS485 Communication Port (Reserve)
G RS232 Baffle
H Battery Input
I Circuit Breaker
J AC Input
K AC Output
L PVB Input
M PVA Input
N Parallel Baffle
O Parallel Communication Cable
P Parallel Current Sharing Cable
Q RS232 Communication Port

4
2 Safety Instructions
1. Before using the unit, read all instructions and cautionary marking on the unit, the batteries and all
appropriate sections of this manual. The company has the right not to quality assurance, if not
according to the instructions of this manual for installation and cause equipment damage.
2. All the operation and connection please professional electrical or mechanical engineer.
3. All the electrical installation must comply with the local electrical safety standards.
4. When install PV modules in the daytime, installer should cover the PV modules by opaque materials,
otherwise it will be dangerous as high terminal voltage of modules in the sunshine.
5. CAUTION：To reduce risk of injury, charge only deep-cycle lead-acid type rechargeable batteries. Other
types of batteries may burst, causing personal injury and damage.
6. Do not disassemble the unit. Take it to a qualified service center when service or repair is required.
Incorrect re-assembly may result in a risk of electric shock or fire.
7. To reduce risk of electric shock, disconnect all wirings before attempting any maintenance or cleaning.
Turning off the unit will not reduce this risk.
8. NEVER charge a frozen battery.
9. For optimum operation of this inverter, please follow required spec to select appropriate cable size. It’s
very important to correctly operate this inverter.
10. Be very cautious when working with metal tools on or around batteries. A potential risk exists to drop a
tool to spark or short circuit batteries or other electrical parts and could cause an explosion.
11. Please strictly follow installation procedure when you want to disconnect AC or DC terminals. Please
refer to INSTALLATION section of this manual for the details.
12. GROUNDING INSTRUCTIONS -This inverter should be connected to a permanent grounded wiring
system. Be sure to comply with local requirements and regulation to install this inverter.
13. NEVER cause AC output and DC input short circuited. Do NOT connect to the mains when DC input
short circuits.
14. Make sure the inverter is completely assembled, before the operation.
This chapter contains important safety and operating instructions. Read
and keep this manual for future reference.
!
WARNING

5
3 Installation
3.1 Unpacking and Inspection
Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. You
should have received the following items inside of package:
The unit×1
User manual×1
Setting screws×3
3.2 Basic Installation Requirements
1. The installation location must be suitable for inverter’s weight for a long period time.
2. The installation location must conform to dimension of the inverter.
3. Do not install the unit on structures constructed of flammable or thermo labile materials.
4. The Ingress Protection rate is IP20 and the pollution degree is PD2, The install area shall be generally
conditioned in term of temperature, humidity and air filtration.
5. Battery installation option is not far below the position of inverter.
6. The humidity of the installation location should be 5 ~ 85%.
7. The ambient temperature should be 0℃~ 55℃.
8. The inverter can be installed in vertical or lean back on plane, Please refer to the below. Installation
position shall not prevent access to the disconnecting means.
Monitor
Connector
Connector Monitor Monitor
Connector
Monitor
Connector
Connector
Monitor
Figure 3-1

6
9. In order to ensure machine can run normally and easy to operate, please pay attention to provide
adequate space for the inverter. Please refer to below:
Figure 3-2
10. Do not install the machine near television antenna or any other antennas and antenna cables.
11. Do not install the machine in the living area.
12. Be sure that the machine is out of the children’s reach.
13. Install the unit by screwing three crews as below. It’s recommended to use M6 screws.
248mm(9.76")
380mm(14.96")
69mm(2.71")
Figure 3-3

7
3.3 Inverter Connection
3.3.1 Lead acid battery connection
User can choose proper capacity lead acid battery with a nominal voltage at 48V. Also, you need to
choose battery type as “lead acid battery”.
CAUTION:
Figure 3-6
Recommended battery cable and terminal size:
Tab le 3 -1
Note:
For lead acid battery, the recommended charge current is 0.2C (C  battery capacity).
Model
Max.
Charging
Current
Battery
Capacity Wire Size
Ring Terminal
Torque
Value
Recommended
Charge Current
Cable
( 
)
Dimensions
D
(mm)
L
(mm)
CPS5000ECH48 130A 200AH 2*8AWG 14 6.4 29.2 2-3Nm 40A
CPS3000ECH48 100A 100AH 1*6AWG 14 6.4 29.2 2-3Nm 20A
For safety operation and regulation compliance, it’s requested to install a separate DC
over-current protector or disconnect device between battery and
inverter. It may not be
requested to have a disconnect device in some applications,
however, it’s still requested to
have over-current protection installed.
All wiring must be performed by a qualified personnel.
It's very important for system safety and efficient
operation to use appropriate cable for battery
connection. To reduce risk of injury, please use the proper
recommended cable and terminal size as below.
!
WARNING

8
Please follow below steps to implement lead-acid battery connection:
1. Assemble battery ring terminal based on recommended battery cable and terminal size
(same as Lead acid,see section 3.3.2 for details).
2. Insert the ring terminal of battery cable flatly into battery connector of inverter and make sure
the bolts are tightened with torque of 2-3Nm.Make sure polarity at both the battery and the
inverter/charge is correctly connected and ring terminals are tightly screwed to the battery
terminals.
Figure 3-7
CAUTION:
!
WARNING
Shock Hazard
Installation must be performed with care due to high battery voltage in series.
Do NOT place anything between the flat part of the inverter terminal and the
ring terminal. Otherwise, overheating may occur.
Do NOT apply anti-
oxidant substance on the terminals before terminals are
connected tightly.
Before making the final DC connection or closing DC breaker, be sure positive
(+) must be connected to positive (+) and negative (-) must be connected to
negative (-).

9
3.3.2 AC Input & Output Connection
CAUTION:
Suggested cable requirement for AC wires:
Tab le 3 -2
Please follow below steps to implement AC input/output connection:
1. Before making AC input/output connection, be sure to open DC protector or disconnector first.
2. Remove insulation sleeve 10mm for six conductors. And shorten phase L and neutral conductor
N 3mm.
3. Insert AC input wires according to polarities indicated on terminal block and tighten the terminal
screws. Be sure to connect PE protective conductor ( ) first.
→Ground (yellow-green)
L →LINE (brown)
N →Neutral (blue)
Model Wire size Torque value
CPS5000ECH48 1*8AWG 1.4-1.6Nm
CPS3000ECH48 1*10AWG 1.4-1.6Nm
Before connecting to AC input power source, please install a separate
AC breaker
between inverter and AC input power source. This will ensure the inverter can be
securely disconnected during maintenance and fully protected from over current of
AC input. The recommended spec of AC breaker is 50A for 5KVA.
There are two terminal blocks with “IN” and “OUT” markings. Please do NOT
mis-connect input and output connectors.
!
WARNING
All wiring must be performed by qualified personnel.
It's very important for system safety and efficient operation to use appropriate cable
for AC input connection. To reduce risk of injury, please use the proper recommended
cable size as below.

10
Figure 3-8
4. Then, insert AC output wires according to polarities indicated on terminal block and tighten
terminal screws. Be sure to connect PE protective conductor ( ) first.
→Ground (yellow-green)
L →Line (brown)
N →Neutral (blue)
Figure 3-9
5. Make sure the wires are securely connected.
CAUTION:
!
WARNING
Be sure that AC power source is disconnected before attempting to hardwire
it to the unit.
Be sure to connect AC wires with correct polarity. If L and N wires are
connected reversely, it may cause utility short-circuited when these inverters
are worked in parallel operation.

11
3.3.3 PV Connection
CAUTION:
Tab le 3 -3
Model Max charging current per string Diameter Torque
CPS5000ECH48 35A 1*10AWG 1.2-1.6Nm
CPS3000ECH48 35A 1*10AWG 1.2-1.6Nm
PV Module Selection:
When selecting proper PV modules, please be sure to consider below parameters:
1. Open circuit Voltage (Voc) of PV modules not exceeds max. PV array open circuit voltage
of inverter.
2. Open circuit Voltage (Voc) of PV modules should be higher than min. battery voltage.
Tab le 3 -4
Model CPS5000ECH48 CPS3000ECH48
Max. PV array open circuit voltage 145Vdc
PV array MPPT voltage range 60~115Vdc
Min. battery voltage for PV charge 36Vdc
There’re two pairs of string for PV Input. Also, it’s allowed to make two PV input parallel (see section
6.2 for details).
Please follow below steps to implement PV input connection:
1. Remove insulation sleeve 10 mm for positive and negative conductors.
Figure 3-10
Before connecting to PV modules, please install separately a DC circuit
breaker between inverter and PV modules.
!
WARNING
All wiring must be performed by qualified personnel.
It's very important for system safety and efficient operation to use
appropriate cable for PV module connection. To reduce risk of injury, please
use the proper recommended cable size as below.

12
2. Check correct polarity of connection cable from PV modules and PV input connectors.
Then, connect positive pole (+) of connection cable to positive pole (+) of PV input connector.
Connect negative pole (-) of connection cable to negative pole (-) of PV input connector.
Figure 3-11
Figure 3-12
3. Make sure the wires are securely connected.
3.3.4 Finally assemble
After connecting all wirings, please put bottom cover back by screwing two screws as shown below:
Figure 3-13

13
4 Communication Connection
The unit is compatible with RS232 and RS485 communication.
It can be monitored by RS232 port on local PC or RS485 port on data logger, and configured by RS232
port on local PC.
RS232
RS485
Figure 4-1

14
5 Dry Contact
There’s one dry contact (2A/30VDC) available on the rear panel. It could be used to deliver signal to
external device when battery voltage reached warning level.
Tab le 5 -1
Unit Status Condition
Dry contact port:
NC & N NO & N
Power Off No output is powered Close Open
Power On
Output is powered from Utility Close Open
Output is
powered
from
Battery or
Solar
AC output
source is
"UTI first"
Battery voltage < Low DC
warning voltage Open Close
Battery voltage > Battery
charging reaches floating
stage
Close Open
AC output
source is
"PV first" or
"BAT first"
Battery voltage < Setting
value in "Battery Low Volt"
Open Close
Battery voltage > Battery
charging reaches floating
stage
Close Open

15
6 Operation
6.1 Power ON/OFF
Once the unit has been properly installed and the batteries are connected well, simply press On/Off
switch (located on the button of the case) to turn on the unit.
Figure 6-1
6.2 Operation and Display Panel
The operation and display panel, shown in below chart, are on the front panel of the inverter. It includes
LCD display, indicators, and function keys to show the operating status and input/output power
information.
LCD Display
LED Display
Function Keys
Figure 6-2
LED indicator
：
Tab le 6 -1
LED
indicators
LED
status Description
Green Solid on Normal: Inverter working well
Red Flashing Warning : Warning, but still working
Red Solid on Error: Inverter stop work

16
Buzzer
：
Tab le 6 -2
Buttons
：
Tab le 6 -3
Function
Key Description
ESC To exit setting mode
UP To go to previous selection
DOWN To go to next selection
ENTER To confirm the selection in setting mode or enter setting mode
LCD Display
：
Character Display
Icon Display
Figure 6-3
Status Description
Beeps every 3 seconds Inverter is in warning state
Beeps constantly Inverter is in error state

17
6.3 LCD Display description
In the first line of the LCD, it displays the warning error code & current status & setting item.
The current status includes Normal, Warn, and Error. More info about error & warning code
and setting item please refer to following pages. In the second line of the LCD, it displays input
& output parameters and time of inverter
Tab le 6 -4
Items Description
Vb/Cb: xx.xV/ xxx% Battery Voltage/Battery Capacity
Vpv: xxxV/ xxxV PV Voltage：PVA Voltage/PVB Voltage
Ic_pv: xx.x / xx.x A PV Charge Current: PVA Charge Current/ PVB Charge Current
Ppv: xxxx/ xxxxW PV Charge Power: PVA Charge Power/ PVB Charge Power
AC_In: xxxV/ xxHz Voltage/Frequency of input AC
AC_Out: xxxV/ xxHz Voltage/Frequency of output AC
Ichr_ac: xx.xA AC Charge Current
Ichr_all: xxx.xA Max. Charge Current
PL: xxxxW/ xxxxVA Power of Load
Per_Load: xxx% Load Percentage
Epv_d: xxxx.x KWh Daily PV Generation
Epv_a: xxxx.x KWh Total PV Generation
Ec_d: xxxx.x KWh Daily Charged Capacity of Battery
Ec_a: xxxx.x KWh Total Charged Capacity of Battery
Ed_d: xxxx.x KWh Daily Discharged Capacity of Battery
Ed_a: xxxx.x KWh Total Discharged Capacity of Battery
20xx/xx/xx xx:xx Time
SerNo: xxxxxxxxxx Series Number
FW Version: xxxx Firmware Version
