Quick Reference 931681A © 2019, CyberData Corporation, ALL RIGHTS RESERVED© 2019, CyberData Corporation, ALL RIGHTS RESERVED 931681A Quick Reference
Dimensions are in Inches [Millimeter]
Ceiling Hole
Wall Cutout Diameter: Ø6.7 in. [Ø170 mm]
The wall thickness must not exceed 1.0 in. [25 mm]
Mounting Template
Dimensions are in Inches [Millimeter]
Typical System Installation
Getting Started
• Download the Operations Guide PDF file, from the Downloads tab at the following webpage:
http://www.cyberdata.net/products/011504/
• Create a plan for the locations of your speakers.
• WARNING: This product should be installed by a licensed electrician according to all local electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
• WARNING: The PoE connector is intended for intra-building connections only and does not route to the outside plant.
• WARNING: This enclosure is not rated for any AC voltages!
Parts
Parameter Factory Default Setting
IP Addressing DHCP
IP Addressa
a. Default if there is not a DHCP server present.
10.10.10.10
Web Access Username admin
Web Access Password admin
Subnet Maska255.0.0.0
Default Gatewaya10.0.0.1
802.3af/at Compliant Ethernet Switch
Speaker IP Phone InformaCast ServerSpeaker Speaker
*More installation options are
illustrated in the Operations Guide.
(1) Template for Speaker*(1) Speaker Assembly
* See the last page of this document
The IP Endpoint Company
Installation Quick Reference
InformaCast Enabled Ceiling Speaker
011504

© 2019, CyberData Corporation, ALL RIGHTS RESERVED 931681A Quick Reference Quick Reference 931681A © 2019, CyberData Corporation, ALL RIGHTS RESERVED
Mounting
Contacting CyberData
Joist
Eyebolt
Ceiling Tile
Template
Speaker
Seismic
Tether Bracket
Assembly
Steel Wire
(Pre-Installed)
Tools Required for Installation:
• (1) Sheetrock Saw or Drywall Cutter
• (1) #2 Phillips Screw Driver or Powered
Screw Driver with #2 Phillips Hex Bit
To mount the speaker:
1. Loosen the Four (4) flag nuts with a #2
Phillip Screw Driver or Powered Screw
Driver.
2. Use the TEMPLATE on the back of this
document to cut a hole in the wall* or
ceiling.
*Skip the seismic tether mounting when
mounting it to the wall.
3. Tighten the Four (4) flag nuts with a #2
Phillip Screw Driver or Powered Screw
Driver.
4. Replace the speaker grill to the speaker
housing.
Flag Nut
1
Channel
3
2
Remove the Speaker Grill out of the Speaker
Housing:
1. Turn and line up at least two of the flag nuts
with their channel.
2. Grasp the speaker grill with your index,
middle, and ring fingers.
3. Place your thumb over the flag nut. At the
same time, slowly push out the speaker
grill.
Sales: [phone] ext. 334
Support: 831-373-2601 ext. 333
Support Website: http://support.cyberdata.net/
RMA Department: [phone] ext. 136
RMA Email: [email protected]
RMA Status: http://support.cyberdata.net/
Warranty Information: http://support.cyberdata.net/
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA
Phone: [phone]
Fax: [phone]
http://www.cyberdata.net/
Dimensions
Features
Connecting Power
Ø6.70 [Ø170]
Ceiling Cutout
3.52 [89.4]
Dimensions are in Inches [Millimeter]
4 x Flagnut
Ethernet
RTFM
0.35 [8.9]
ø7.93 [ø201.5]
RTFM Switch
To broadcast a device’s current IP address, use a paper
clip or a similar instrument to press and release the
RTFM switch within a five second window.
To restore a device’s factory default settings, press and
hold the RTFM switch for more than five seconds.
Network 100 Mb (Yellow)
The yellow 100 Mb LED is illuminated when the network
100 Mb link to the speaker is established.
Speaker Link/Activity (Green)
The green Link/Activity LED comes on immediately to
show that there is a good network connection, and then
blinks to show network activity.
Ethernet Port
PoE Injector
Non PoE Switch
802.3af Compliant PoE Switch
(Part #010867)
