CyberData 011236 Manual

Quick Reference 930586C © 2014, CyberData Corporation, ALL RIGHTS RESERVED
The IP Endpoint Company
Installation Quick Reference 
3-Port Gigabit Ethernet Switch
011236
Parts List
●(1) 3-Port Gigabit Ethernet Switch
●6-foot USB-B to USB-A cable
Front and Back Views
Dimensions
ø0.189 [ø4.8]
3.150 [80.0]
3.792 [96.3]
1.087 [27.6]
2.746 [69.8]
(2 Places)
Dimensions are in Inches [Millimeter]

© 2014, CyberData Corporation, ALL RIGHTS RESERVED 930586C Quick Reference
LEDs
1 Gigabit StatusLink/ACT
Mounting Screws
3-Port Gigabit Ethernet Switch
Double-sided tape
Adhere to a flat surface
(optional)
Typical Installation
Ethernet Access
USB(B)
USB(A)
Ethernet
Ethernet Switch
Computer
VoIP Phone
Contacting CyberData
Sales: [phone] ext. 334
Support: 831-373-2601 ext. 333
Web: http://www.cyberdata.net/support/contactsupportvoip.php
RMA Dept: [phone] ext. 136
Email: [email protected]
RMA Status: http://www.cyberdata.net/support/rmastatus.html
Warranty and RMA information is available at the following website:
http://www.cyberdata.net/support/warranty/index.html
